AudioSource AMP210 Owner's Manual

AMP210 / AMP310
OWNER'S MANUAL
AMP210 SPECIFICATIONS
Stereo (8 ohm): 90W RMS per channel at 8 ohms,
20Hz - 20kHz, <0.1% THD+N
Stereo (4 ohm): 125W per channel at 4 ohms,
20Hz-20kHz, <0.1% THD+N
Bridged Mono (8 ohm): 250W RMS at 8 ohms,
20Hz - 20kHz, <0.2% THD+N
Frequency Response: 10Hz - 50kHz, +0dB, -3dB
Signal to Noise Ratio: 100dB A-weighted, referred to rated
power at 4 ohms
Channel Separation: 69dB @ 1kHz, referred to rated power
at 8 ohms
Sensitivity: Variable, 350mV to 2.8V for rated
power at 8 ohms
AC Power Consumption: 700W maximum
Net Weight: 24lbs / 10.9kgs
Gross Weight: 31.7lbs / 14.4kgs
AMP310 SPECIFICATIONS
Stereo (8 ohm): 150W RMS per channel at 8 ohms,
20Hz - 20kHz, <0.1% THD+N
Stereo (4 ohm): 225W per channel at 4 ohms,
20Hz-20kHz, <0.1% THD+N
Bridged Mono (8 ohm): 450W RMS at 8 ohms,
20Hz - 20kHz, <0.1% THD+N
Frequency Response: 10Hz - 50kHz, +0dB, -3dB
Signal to Noise Ratio: 100dB A-weighted, referred to rated
power at 4 ohms
Channel Separation: 68dB @ 1kHz, referred to rated power
at 8 ohms
Sensitivity: Variable, 350mV to 2.8V for rated
power at 8 ohms
AC Power Consumption: 1200W maximum
Net Weight: 33.1lbs / 15.0kgs
Gross Weight: 41.9lbs / 19.0kgs
AudioSource®
9200 North Decatur St.
Portland, OR 97203
503.286.9300
www.audiosource.net
3.8"
(96.5mm)
Speakers
A B
13.75"
(349mm)
5.5"
(140mm)
Speakers
A B
13.75"
(349mm)
16.5" (419mm)
AMP210
Stereo Power Amplifier
Power
Signal / Clip Signal / Clip
Left Right
16.5" (419mm)
AMP310
Stereo Power Amplifier
Balance Trim
Power
Signal / Clip Signal / Clip
Left Right
AMP210 / AMP310 Owner's Manual 8100.0359A
Balance Trim Volume Trim
Left Right -12dB +6dB
Volume Trim
Left Right -12dB +6dB
