AudioSource AMP 310 Owner's Manual
Home audio multi-zone power ampli?er
Hide thumbs
Also See for AMP 310:
- Application manual (12 pages) ,
- Owner's manual (17 pages) ,
- Owner's manual (8 pages)
Advertisement
FEATURES:
Line 1 / Line 2 priority input switching
Line 2 auxiliary output
High level input
Speaker A/B switching
Front panel balance and volume trim controls
Independent rear left / right master level controls
Front panel diagnostic LEDs
Signal sensing "Power On"
12VDC "Trigger On"
Triple-Darlington Power Amplifier Stages
Dual-differential error amplifiers
SN Ratio: 100dBA
Rack-mount ready
AudioSource®
13790 SW 72nd Ave.
Portland, OR 97223
503.914.4688
www.audiosource.net
AMP210 / AMP310
Home Audio Multi-Zone Power Amplifier
Congratulations on your purchase of the AudioSource® AMP210/310.
Please take a few moments to read this entire manual, and be sure to
retain this document for future reference. Please read and observe all
safety instructions detailed on page 2.
NOTE: if any part of this product is damaged or missing, please call your
dealer or AudioSource® directly at 1.877.915.5439 or 503.914.4688.
Please read your warranty and retain your receipt and original carton for
possible future use.
For more information about AudioSource® electronics, speakers and
accessories please visit www.audiosource.net
AMP210 / AMP310 Owner's Manual 8100.0359A
AMP210 / AMP310
OWNER'S MANUAL
Advertisement
Table of Contents
Related Manuals for AudioSource AMP 310
Summary of Contents for AudioSource AMP 310
- Page 1 Speaker A/B switching Front panel balance and volume trim controls Congratulations on your purchase of the AudioSource® AMP210/310. Independent rear left / right master level controls Please take a few moments to read this entire manual, and be sure to Front panel diagnostic LEDs retain this document for future reference.
-
Page 2: Important Safety Instructions
If an equipment rack is used, we recommend locating the amplifier(s) in the bottom of the rack and the preamplifier or other sensitive equipment at the top. 13970 SW 72nd Ave. Portland, OR 97223 • 503.914.4688 • www.audiosource.net... -
Page 3: Technical Support
AudioSource®, or damage that is attributable to Acts of God. It does not cover costs of transportation to AudioSource® or damage in transit. The customer should return his defective product, freight prepaid and insured, to AudioSource®... - Page 4 Switches the amplifier from Stereo mode to Bridged mode Turns light bar display on front panel on or off. Does not control Signal/Clip LEDs or power button light ring. 13970 SW 72nd Ave. Portland, OR 97223 • 503.914.4688 • www.audiosource.net...
-
Page 5: Front Panel Controls
These adjustments set the master level and if not configured at initial setup available. The switch routes the speaker level signal to either the Line 1 of the AMP210/310 may adversely affect the performance of the amplifier. or Line 2 input. 13970 SW 72nd Ave. Portland, OR 97223 • 503.914.4688 • www.audiosource.net... - Page 6 230V ~50Hz AC mains. Installed mains fuse must be of type and rating marked on amplifier corresponding to configured AC mains voltage. Should you wish to configure the AMP210/310 for use at 230V ~50Hz please contact your dealer or distributor. 13970 SW 72nd Ave. Portland, OR 97223 • 503.914.4688 • www.audiosource.net...
-
Page 7: Applications
210/310 will no longer be able to pass the Whole House Distributed Audio to another zone via the Line 2 Output. If you have any questions regarding how to set this up, please call AudioSource® Tech support at 1.877.715.5439 or 503.914.4688. -
Page 8: Caractéristiques
POUR TOUTE INFORMATION SUR LE SERVICE AUX ÉTATS-UNIS VEUILLEZ APPELER : Service à la clientèle AudioSource : (503) 914-4688 ou (877) 715-5439 7:00 à 17:30 Heure du Pacifique. -
Page 9: Contrôles Du Panneau Avant/Arrière
19. Contrôle de l’affichage des barres de signalisation Allume ou éteint l’affichage de barres de signalisation sur le panneau avant. Ne contrôle ni les DEL Signal/Clip, ni l’anneau lumineux du bouton d’alimentation. 13970 SW 72nd Ave. Portland, OR 97223 • 503.914.4688 • www.audiosource.net... - Page 10 à celle que l’amplificateur est conçu pour absorber et peut endommager votre amplifcateur. L’impédance minimale pour la charge totale connectée à un couple de chaînes en mode raccordé est de 8 ohms. 13970 SW 72nd Ave. Portland, OR 97223 • 503.914.4688 • www.audiosource.net...
- Page 11 Distributed Audio) à une autre zone via la Sortie de la Ligne 2. Si vous avez des questions au sujetde cette configuration, veuillez appeler le service d’assistance technique de AudioSource® au 1.877.715.5439 ou 503.914.4688. 13970 SW 72nd Ave. Portland, OR 97223 • 503.914.4688 • www.audiosource.net...
- Page 12 GARANTÍA LIMITADA PARA ELECTRÓNICOS (ESTADOS UNIDOS) AudioSource garantiza sus productos contra defectos en materiales y mano de obra por un período limitado de tiempo. Para un período de 1 año a partir de la fecha original de compra, repararemos o repondremos el producto, a nuestro criterio, sin cargo por partes y mano de obra. El cliente debe pagar todos las partes y cargos por mano de obra después de la expiración del período de garantía.
- Page 13 19. Control de Exhibición de Barra de Luz Enciende o apaga la barra de luz en el panel frontal. No controla las lámparas LED de Señal/Clip o anillo de luz del botón de encendido. 13970 SW 72nd Ave. Portland, OR 97223 • 503.914.4688 • www.audiosource.net...
- Page 14 La impedancia mínima para la carga total conectada a un par de canales en modo puente es de 8 ohms. 13970 SW 72nd Ave. Portland, OR 97223 • 503.914.4688 • www.audiosource.net...
- Page 15 Audio Distribuido en Cámara a otra zona a través de la Salida de Línea 2. Si usted tiene cualquier pregunta relativa a esta configuración, llame al soporte técnico de AudioSource® al 1.877.715.5439 o 503.914-4688. 13970 SW 72nd Ave. Portland, OR 97223 • 503.914.4688 • www.audiosource.net...
-
Page 16: Specifications
Sensitivity: Variable, 350mV to 2.8V for rated power at 8 ohms AC Power Consumption: 1200W maximum 13.75” Net Weight: 33.1lbs / 15.0kgs (349mm) Gross Weight: 41.9lbs / 19.0kgs AudioSource® 13970 SW 72nd Ave Portland, OR 97223 503.914.4688 AMP210 / AMP310 Owner’s Manual 8100.0359A www.audiosource.net...
