AudioSource AMP102 Owner's Manual

AMP102 / AMP110
OWNER'S MANUAL
AMP102 SPECIFICATIONS
Stereo (8 ohm): 50W RMS per channel at 8 ohms,
20Hz - 20kHz, <0.1% THD+N
Stereo (4 ohm): 75W per channel at 4 ohms,
20Hz-20kHz, <1% THD+N
Bridged Mono (8 ohm): 150W RMS at 8 ohms,
20Hz - 20kHz, <0.2% THD+N
Frequency Response: 10Hz - 50kHz, +0dB, -3dB
Signal to Noise Ratio: 100dB A-weighted, referred to rated
power at 4 ohms
Channel Separation: 65dB @ 1kHz, referred to rated power
at 8 ohms
Sensitivity: Variable, 350mV to 2.8V for rated
power at 8 ohms
AC Power Consumption: 500W maximum
Net Weight: 14.7lbs / 6.7kgs
Gross Weight: 15.9lbs / 7.2kgs
AMP110 SPECIFICATIONS
Stereo (8 ohm): 75W RMS per channel at 8 ohms,
20Hz - 20kHz, <0.1% THD+N
Stereo (4 ohm): 110W per channel at 4 ohms,
20Hz-20kHz, <0.1% THD+N
Bridged Mono (8 ohm): 225W RMS at 8 ohms,
20Hz - 20kHz, <0.1% THD+N
Frequency Response: 10Hz - 50kHz, +0dB, -3dB
Signal to Noise Ratio: 100dB A-weighted, referred to rated
power at 4 ohms
Channel Separation: 70dB @ 1kHz, referred to rated power
at 8 ohms
Sensitivity: Variable, 350mV to 2.8V for rated
power at 8 ohms
AC Power Consumption: 600W maximum
Net Weight: 23.1lbs / 10.5kgs
Gross Weight: 30.8lbs / 14.0kgs
AudioSource®
9200 North Decatur St.
Portland, OR 97203
503.286.9300
www.audiosource.net
3.8"
(96.5mm)
Speakers
A B
8.25"
(210mm)
3.8"
(96.5mm)
Speakers
A B
13.75"
(349mm)
16.5" (419mm)
AMP102
Stereo Power Amplifier
Power
Signal / Clip Signal / Clip
Left Right
16.5" (419mm)
AMP110
Stereo Power Amplifier
Power
Signal / Clip Signal / Clip
Left Right
AMP102 / AMP110 Owner's Manual 8100.0360A
Balance Volume
Max
Left Right Min
Balance Volume
Left Right Min Max
