FEATURES:
Line 1 / Line 2 priority input switching
Line 2 auxiliary output
Speaker A/B switching
Front panel balance and volume controls
Front panel diagnostic LEDs
Signal sensing "Power On"
12VDC "Trigger On"
Rack-mount ready
AMP110 also features:
Triple-Darlington Power Amplifier Stages
Dual-differential error amplifiers
AudioSource®
13790 SW 72nd Ave.
Portland, OR 97223
503.914.4688
www.audiosource.net
AMP102 / AMP110
Home Audio Multi-Zone Power Amplifier
Congratulations on your purchase of the AudioSource® AMP102/110.
Please take a few moments to read this entire manual, and be sure to
retain this document for future reference. Please read and observe all
safety instructions detailed on page 2.
NOTE: if any part of this product is damaged or missing, please call your
dealer or AudioSource® directly at 1.877.715.5439 or 503.914.4688.
Please read your warranty and retain your receipt and original carton for
possible future use.
For more information about AudioSource® electronics, speakers and
accessories please visit www.audiosource.net
AMP102 / AMP110 Owner's Manual 8100.0360A
AMP102 / AMP110
OWNER'S MANUAL
Advertisement
Table of Contents
Related Manuals for AudioSource AMP 102
Summary of Contents for AudioSource AMP 102
- Page 1 Line 2 auxiliary output Speaker A/B switching Front panel balance and volume controls Congratulations on your purchase of the AudioSource® AMP102/110. Front panel diagnostic LEDs Please take a few moments to read this entire manual, and be sure to Signal sensing “Power On”...
-
Page 2: Explanation Of Safety Symbols
If an equipment rack is used, we recommend locating the amplifier(s) in the bottom of the rack and the preamplifier or other sensitive equipment at the top. 13970 SW 72nd Ave. Portland, OR 97223 • 503.914.4688 • www.audiosource.net... -
Page 3: Technical Support
AudioSource®, or damage that is attributable to Acts of God. It does not cover costs of transportation to AudioSource® or damage in transit. The customer should return his defective product, freight prepaid and insured, to AudioSource®... -
Page 4: Rear Panel Controls
Turns light bar display on front panel on or off. Does not control Signal/Clip LEDs or power button light ring. Right Channel Speaker Output Right channel terminals for speaker outputs A and B. 13970 SW 72nd Ave. Portland, OR 97223 • 503.914.4688 • www.audiosource.net... -
Page 5: Front Panel Controls
Note: The front panel power switch must be in the “ON” position for the 12V source while the changer moves from one disc to another. triggers or “Auto ON” features to operate. 13970 SW 72nd Ave. Portland, OR 97223 • 503.914.4688 • www.audiosource.net... - Page 6 230V ~50Hz AC mains. Installed mains fuse must be of type and rating marked on amplifier corresponding to configured AC mains voltage. Should you wish to configure the AMP102/110 for use at 230V ~50Hz please contact your dealer or distributor. 13970 SW 72nd Ave. Portland, OR 97223 • 503.914.4688 • www.audiosource.net...
- Page 7 Line 2 inputs of your AMP102/110. Connect your mono speaker to the terminals of your AMP102/110 (see “Speaker will occur. Terminals” on Page 6). Leave the balance set to the center detent position. 13970 SW 72nd Ave. Portland, OR 97223 • 503.914.4688 • www.audiosource.net...
-
Page 8: Caractéristiques
POUR TOUTE INFORMATION SUR LE SERVICE AUX ÉTATS-UNIS VEUILLEZ APPELER : Service à la clientèle AudioSource : (503) 914-4688 ou (877) 715-5439 7:00 à 17:30 Heure du Pacifique. - Page 9 Le fusible doit être du même type et disposer des mêmes spécifications que celles qui sont indiquées Sur l’amplificateur pour une utilisation selon la tension des réseaux locaux. 13970 SW 72nd Ave. Portland, OR 97223 • 503.914.4688 • www.audiosource.net...
- Page 10 (rouge) du haut-parleur à la borne positive (rouge) de l’amplificateur, et la borne négative (noire) du haut-parleur à la borne négative (noire) de l’amplificateur (tout de suite à côté de la borne positive). 13970 SW 72nd Ave. Portland, OR 97223 • 503.914.4688 • www.audiosource.net...
- Page 11 (voir «Bornes de haut-parleur» à la Page 10). Utilisez le contrôle du «Niveau principal» de gauche placé sur la panneau arrière afin de régler le volume. Laissez l’équilibrage réglé en position de cran centrale. 13970 SW 72nd Ave. Portland, OR 97223 • 503.914.4688 • www.audiosource.net...
- Page 12 GARANTÍA LIMITADA PARA ELECTRÓNICOS (ESTADOS UNIDOS) AudioSource garantiza sus productos contra defectos en materiales y mano de obra por un período limitado de tiempo. Para un período de 1 año a partir de la fecha original de compra, repararemos o repondremos el producto, a nuestro criterio, sin cargo por partes y mano de obra. El cliente debe pagar todos las partes y cargos por mano de obra después de la expiración del período de garantía.
-
Page 13: Controles Del Panel Frontal
áreas donde se requiere 230V, contacte a su representante. El fusible debe ser del tipo y evaluación marcados en el amplificador para uso con el voltaje primario local. 13970 SW 72nd Ave. Portland, OR 97223 • 503.914.4688 • www.audiosource.net... - Page 14 (roja) del parlante a la terminal positiva (roja) del amplificador, y la terminal negativa (negra) del parlante al la terminal negativa (negra) del amplificador (inmediatamente al lado de la terminal positiva). 13970 SW 72nd Ave. Portland, OR 97223 • 503.914.4688 • www.audiosource.net...
- Page 15 AMP102/110. Conecte su parlante mono a las terminales de su AMP102/110 (vea “Terminales de Parlantes” en la Página 14). Lleve la configuración del balance a la posición central. 13970 SW 72nd Ave. Portland, OR 97223 • 503.914.4688 • www.audiosource.net...
- Page 16 Sensitivity: Variable, 350mV to 2.8V for rated power at 8 ohms AC Power Consumption: 600W maximum 13.75” Net Weight: 23.1lbs / 10.5kgs (349mm) Gross Weight: 30.8lbs / 14.0kgs AudioSource® 13970 SW 72nd Ave. Portland, OR 97223 503.914.4688 AMP102 / AMP110 Owner’s Manual 8100.0360A www.audiosource.net...
