ATN OTS-30
ATN OTS-60
THERMAL IMAGING SYSTEM
o p e r a t o r ' s m a n u a l
Important Export Restrictions! Commodities, products,
technologies and services contained in this manual are
subject to one or more of the export control laws and
regulations of the U.S. Government and they fall under the
control jurisdiction of either the US Department of State
or the US BIS-Department of Commerce. It is unlawful
and strictly prohibited to export, or attempt to export or
otherwise transfer or sell any hardware or technical data
or furnish any service to any foreign person, whether
abroad or in the United States, for which a license or written
approval of the U.S. Government is required, without
first obtaining the required license or written approval
from the Depar tment of the U.S. Government having
jurisdiction. Diversion contrary to U.S. law is prohibited.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OTS-30 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ATN OTS-30

Summary of Contents for ATN OTS-30

  • Page 1 ATN OTS-30 ATN OTS-60 THERMAL IMAGING SYSTEM o p e r a t o r ’ s m a n u a l Important Export Restrictions! Commodities, products, technologies and services contained in this manual are subject to one or more of the export control laws and regulations of the U.S.
  • Page 2 Manual (OTS-30, OTS-60 ver. 2011) Revision 1 - 2011 The information in this manual furnished for information use only, is subject to change without notice, is not to be construed as a commitment by ATN Corp. ATN Corp. assumes no responsibility or liability for any errors or inaccura- cies that may appear in this book.

  • Page 3: Safety Summary

    STUDY CAREFULLY THIS MANUAL BEFORE TURNING ON AND OPERATING THIS PRODUCT. CAUTIONS The ATN OTS-30 and ATN OTS-60 thermal imaging systems are precision optical-electronic instruments and requires care- ful handling. To provide safe use of the systems the following instructions should be observed: •...
  • Page 4 WARNING Do not permanently attach the camera to dynamic-mount applica- tions that continuously transmit vibration (such as on vehicles or heavy machinery). WARNING Do not point the camera directly at any high-intensity objects that you must not view with your eyes (such as the sun or a welding arc).
  • Page 5 WARNING Do not replace batteries in a possibly explosive environment, such as a gas station (or any place where you must turn off your vehicle engine). If you do, sparks can cause an explosion. WARNING Remove the batteries before you store the camera for extended periods (2 weeks or more).

  • Page 6: Table Of Contents

    TABLE OF CONTENTS SECTION I. INTRODUCTION 1.1 General Information 1.1.1. Scope 1.1.2. Reports 1.1.3. Storage 1.1.4. Warranty Information 1.2. Description and Data 1.2.1. Description 1.2.2. OTS Standard Components 1.2.3. OTS Optional Components 1.2.4. Specifications 1.2.5. Mechanical Functions 1.2.6. Optical Functions 1-10 1.2.7.
  • Page 7 3.2.6. Recalibrate Switch 3.2.7. Shut Down Operations SECTION IV. MAINTENANCE INSTRUCTIONS 4.1. Preventive Maintenance Checks and Services (PMCS) 4.1.1. Purpose of PMCS 4.1.2. Frequency of Performing PMCS 4.2. Troubleshooting 4.2.1. General 4.2.2. Troubleshooting Procedures 4.3. Maintenance Procedures 4.3.1. Scope Maintenance 4.3.2.

  • Page 9: Section I. Introduction

    SECTION I INTRODUCTION...

  • Page 10: General Information

    1.1.1. SCOPE This manual contains instructions for use in operating and main- taining the ATN OTS-30 and ATN OTS-60 thermal imaging sys- tems. Throughout this manual, the ATN OTS-30 and ATN OTS-60 will be referred to as the scope or OTS.

  • Page 11: Warranty Information

    ATN, at its option, will either repair or replace the product, and such action on the part of ATN shall be the full extent of ATN’s liability, and the Customer’s sole and exclusive remedy.

  • Page 12: Product Warranty Registration

    ATN by the customer or customer’s dealer. ATN shall not, in any event, be liable for special, indirect, incidental, or consequential damages, including, but not limited to, lost income, lost revenue, or lost profit, whether such dam-...

  • Page 13: Description And Data

    The ATN OTS-30 and OTS-60 are ideal for home security, public safety, first responder and security operations. Figure 1-1. ATN OTS Thermal Imaging System B.

  • Page 14: Ots Standard Components

    Standard professional thermal systems come in 30hz (Fast Imag- ing or FI) while many commercial viewers run at 9hz (Standard Im- aging or SI). In 2012, ATN is proud to offer 60hz (Enhanced Imaging or EI) options for most of its thermal systems. With Enhanced Im- aging you will never have to worry about hitting behind the moving target because your skill outpaces the technology in your scope.
  • Page 15 Figure 1-2. OTS Standard Components Table 1-1. OTS Standard Components ITEM DESCRIPTION Scope Soft Carrying Case Lens Tissue Lithium Battery CR123A Operator’s Manual Wrist Strap Scope The monocular thermal imaging device. Soft Carrying Case A protective bag used for storing of OTS and accessories. Lens Tissue Uses for cleaning of lenses surface.

  • Page 16: Ots Optional Components

    1.2.4. SPECIFICATIONS The following tables provide information pertaining to the opera- tional, electrical, mechanical, optical and environmental character- istics for the sights. Table 1-3. Specifications ITEM OTS-30 OTS-60 Resolution 320 x 240 640 x 480 Frame Rate 9 Hz (TIMPOTIS30HZ9 )
  • Page 17 Operating Time w/one 4 hrs battery pack Operating from -30°C to +60°C Temperature Range Weatherproof Dimensions 118 x 81 x 52 mm Weight (w/batteries) 0.34 kg * ATN reserves the right to change the above specifications at any time without notice...

  • Page 18: Mechanical Functions

    1.2.5. MECHANICAL FUNCTION The mechanical adjustments of the OTS sights allow for physi- cal differences between individual operators using the system. The scope functions include the switchboard, recalibrate switch, universal connector, eyepiece diopter adjustment ring, battery compartment cover, mounting rail. The mechanical controls are identified in Figure 1-4.

  • Page 19: Section Ii. Assembly And Preparation

    SECTION II ASSEMBLY AND PREPARATION...

  • Page 20: Preparation

    2.1. PREPARATION 2.1.1. PREPARATION FOR USE This chapter contains the information necessary to prepare the scope for operation. This includes unpacking, examination for da- mage, and battery installation. A. UNPACkING The following steps must be accomplished prior to each mission where the sight is used.

  • Page 21: Examination For Operation

    Install CR123A Lithium batteries as follows. 1. Remove the battery cap by turning it counterclockwise. 2. Check to ensure the o-ring is present. If not, replace it. 3. Observe polarity, as indicated on the outside of the battery compartment, and insert two 3.0 Volt CR123A Lithium bat- tery into the battery compartment, plus (+) end first (Figure 2-1).

  • Page 22: Assembly

    2.2. ASSEMBLY 2.2.1. VIDEO OUTPUT The OTS incorporates a sealed Connector used for video transmis- sion. Video Cable attaches the scope to the video facilities for video recording or video transmission. Connect the monocular to an external video display/recorder as follows: 1.

  • Page 23: Section Iii. Operation

    SECTION III OPERATION...

  • Page 24: General Information

    3.1. GENERAL INFORMATION 3.1.1. GENERAL This section contains instructions for operation of OTS. The func- tion of controls and indicators is explained. 3.1.2. CONTROLS The OTS scope is designed to adjust for different users and cor- rects for most differences. The controls for the scope are shown or described in Figure 3-1 and Tables 3-1.

  • Page 25: Operating Procedure

    3.2. OPERATING PROCEDURE 3.2.1. TURNING ON Open the objective lens cover. The objective lens cover protects the scope from inadvertent exposure to extremely high levels of radiant flux. Never leave the scope with the objective lens cover off. To turn the unit on press the button labeled ON/OFF. After warm up time of approximately 5 seconds, video of the thermal scene appears.

  • Page 26: Polarity And Color Modes

    3.2.3. POLARITY AND COLOR MODES Push quickly POLARITY button to switch to between white hot and black hot. Hold down to turn on and cycle through color modes. 3.2.4. BRIGHTNESS Press «BRIGHTNESS +» and «BRIGHTNESS –» buttons for bright- ness adjustment. Each short push of the buttons «BRIGHTNESS +» or «BRIGHTNESS –»...

  • Page 27: Section Iv. Maintenance Instructions

    SECTION IV MAINTENANCE INSTRUCTIONS...

  • Page 28: Preventive Maintenance Checks And Services (Pmcs)

    4.1. PREVENTIVE MAINTENANCE CHECkS AND SERVICES (PMCS) 4.1.1. PURPOSE OF PMCS PMCS is performed daily when in use to be sure that the sight is ready at all times. Procedures listed in Table 4-1 are a systematic inspection of OTS that will enable you to discover defects that might cause the sight to fail on a mission.
  • Page 29 SEq. ITEM TO NOT FULLY MISSION CHECkING PROCEDURE CHECk CAPABLE IF: Chipped, cracked or Inspect for cleanliness, if scratches hinder Lenses scratches, chips or cracks. vision through the Clean as required. sight. Objective Check to ensure the objec- Objective lens loose. Lens tive lens is not loose.

  • Page 30: Troubleshooting

    4.2. TROUBLESHOOTING 4.2.1. GENERAL This section contains information for locating and removal most of the OTS operating troubles which may occur. Each malfunction for an individual component or assembly is followed by a list of tests or inspections that will help determine probable causes and corrective action to take.
  • Page 31 PROBLEM PROBABLE CAUSE CORRECTIVE ACTION The brightness The batteries has a Replace the batteries. of the image low voltage. on the screen Factory alignment Send the scope to the ser- is low. broken. vice center.

  • Page 32: Maintenance Procedures

    4.3. MAINTENANCE PROCEDURES 4.3.1. SCOPE MAINTENANCE The OTS maintenance consists of external inspection of its com- ponents for serviceability, cleaning and installation of the stan- dard and optional accessories. Maintenance instructions covered elsewhere in this manual (PMCS, troubleshooting, etc.) are not repeated in this section.

  • Page 33: Preparing For Extended Storage

    4.3.3. PREPARING FOR EXTENDED STORAGE To prepare the OTS for extended storage, perform the following: 1. Check the scope for serviceability as outlined in item 4.1 of this manual. 2. Remove the batteries. 3. Clean the scope and accessories. 4. Replace all items in the case.

  • Page 34: Appendix A. Spare Parts List

    APPENDIX A SPARE PARTS LIST The Spare Parts List is an illustrated catalog of main parts and assemblies completing the OTS system. Therefore, in case of failure of any part or assembly User could replace it by ordering the corresponding part/assembly from the Spare Parts List.
  • Page 35 PART NO. DESCRIPTION FIG. ITEM qTY AT 88831.006 Eye Piece AT 88831.007 Rubber Eye-cup AT 88831.008 Battery Cap AT 88831.009 Connector Cap AT 88831.010 CR123A type battery Figure A-2. OTS Accessories Table A-2. OTS Accessories parts list PART NO. DESCRIPTION FIG.
  • Page 36 800-910-2862, 650-989-5100; fax: 650-875-0129 European Office The following countries can use our toll free number: 00 800 9102-8620 Austria, France, Germany, Holland, Italy, Spain, Sweden, Switzerland For other countries, please use 38 048-7770214 or 38 048-7770345 www.atncorp.com ©2011 ATN Corporation...
