CE100
MINI USB KVM Extender
The CE100 USB KVM Extender with superior video quality and built-in ESD protection allows access to a computer
system from a remote USB console (USB keyboard, USB mouse, and monitor).
The CE100 improves on previous designs by: 1) incorporating a compensation adjustment function at the Remote
unit for greater video quality; and 2) using inexpensive Cat 5e cable, instead of bulky, expensive, standard cables, to
provide a neater, more convenient, more reliable data transfer connection.
Resolution
Wide
Screen
1920 x 1200
Win, Mac, Linux
Support
Features
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
• Extends local PC VGA/keyboard/Mouse to Remote side
• Uses Cat 5e cable to connect the local and remote units
• Easily add or remove computers connected to the installation
• Supports real time DDC communication
• Superior video quality – up to 1920 x 1200
• Allow access to a computer from the remote console up to 100 m
distance
• Support manual compensation adjustment for better video
quality
• No external power supply needed for local unit
• Built-in 8KV/15KV ESD protection (Contact voltage 8KV; Air voltage
15KV)
• Wall mountable
Headquarters
ATEN International Co., Ltd.
3F., No.125, Sec. 2, Datong Rd., Sijhih District., New Taipei City 221, Taiwan
Tel: 886-2-8692-6789
© Copyright 2011 ATEN® International Co., Ltd. All brand names and trademarks are the registered property of their respective owners.
Supports
Supports
Supports
Fax: 886-2-8692-6767
E-mail: marketing@aten.com
Setup
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
CE100L
Cat 5e Cable
(up to 100 m)
CE100R

Specifications

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Function
Keyboard
Console
Video
Ports
Mouse
Connectors
Keyboard
KVM
/ Mouse
Ports
Video
Power
Unit to Unit
Switch
Link
LEDs
Power
Video
Power Consumption
Operating Temp.
Environment
Storage Temp
Humidity
Housing
Physical
Weight
Properties
Dimensions
(L x W x H)
* Product specifications and appearance are subject to change without notice.
CE100L
CE100R
1 x USB Type A
N/A
Female (White)
1 x HDB-15
N/A
Female (Blue)
1 x USB Type A
N/A
Female (White)
1 x USB Type B
N/A
Female (White)
1 x HDB-15
N/A
Male (Blue)
1 x DC Jack
1 x RJ-45 Female (Black)
N/A
1 x Knob
1 (Blue)
1 (Green)
1920 x 1200 @ 60 Hz (30m);
1280 x 1024 @ 60 Hz (100m)
DC5V, 0.5W
DC5V, 1.25W
0–50ºC
-20–60ºC
0–80% RH, Non-condensing
Metal
0.16 kg
9.00 x 5.50 x 2.40 cm
2011. Version 2.0
