AT-620 User Manual
3rd、 Keypad of IP Phone
Describe of the buttons and Screen:
Soft buttons Press to select an feature shown in the soft button features
Soft button Shows available choices based on current phone function
features displayed on the last line of LCD screen
Status Shows the phone status, if the phone is standby, the LED is
with light. If there is income calling, the LED will flicker.
LCD Screen Display screen for the phone: It shows the date, time, phone
number, incoming caller's ID(if available),line/call status,
extension numbers and the soft button features.
ATCOM TECHNOLOGY CO., LIMITED
If the phone is starting ,the LED is flicker
If the phone is standby, the LED is off
If there is income calling, the LED will flicker. The
frequency is 500ms off, 500ms on.
When have voicemail, LED shows red and flicker, and the
frequency is 1000ms off, 1000ms on.
If the phone not obtain the IP address, the LED is ON
