AT-610 User Manual
C、Number 7 stands for PPPoE, when the IP phone get IP address in PPPoE mode .
the indicator is on , or else it blinks
2、4、6 Answering mode indicator ,
A、Number 2 stands for answering call with handset
B、Number 4 stands for answering call in hand-free mode
C、Number 6 stands for answering call with headset
8 Mute indicator , when the phone is muted , this indicator is on , when the muted
mode is canceled the indicator will be off
9、11 Protocol indicator
A、Number 9 stands for SIP
�
When you enable register and successfully register to SIP server , this
indicator is on
�
when you enable register but do not successfully register to server , this
indicator blinks
�
when you disable register , this indicator is off
B、Number 11 stands for IAX protocol
�
When you enable register and successfully register to IAX server , this
indicator is on
�
when you enable register but do not successfully register to server , this
indicator blinks
�
when you disable register , this indicator is off
10 Missed call indicator , when there is the missed call , this indicator will be on .
After you checked all the missed calls , this indicator will turn off
12 Voicemail indicator , when there is new voice mail , this indicator will be on , after
you checked all the voicemail , this indicator will turn off
13 incoming call indicator
A、 when the phone is in standby without incoming call , the indicator is off
B、when the Ethernet connection is off , the indicator is on
C、when there is the incoming call , indicator blinks
D、 when there is a new voicemail , the indicator blinks
14 Monday to Sunday indicator , the correct day will be on while others will be off
15 This is the multi function key
A、 In standby mode , press Menu/Enter to enter the Menu
B、In functional menu , press Menu/Enter to confirm selection.
16 Press info to check network status
17 press Pbook to enter the phone book and edit or delete.
18 Press History button to check call history including incoming calls , outgoing calls
and missed calls.
19 Exit button
A、 when you're dialing , press exit to delete the dialed number and return to and
you can dial a new number
B、in functional menu , press EXIT to exit current menu and return to the upper
