- Page 1 KVM-08H / KVM-16H Switch with Remote Console Stackable TWO-CONSOLE (One Local , One CAT5 Remote) 8 port / 16 port 19” RACK MOUNTABLE PS/2 KVM SWITCH USER’S MANUAL...
- Page 2 Product that are not covered or permitted in the manual for the Product; damages that occur dur- ing shipment, or damages due to power failures or acts of God; cosmetic damage to the Product; the Product if the Product, in freedom9’s sole judgment, has been subjected to abuse, accident, modification, tampering, negligence, faulty installation, lack of reasonable care, repair or service, or misuse or use otherwise than as contemplated in the manual for the Product;...
-
Page 3: Table Of Contents
Table of Contents Chapter 1 Chapter 2 Chapter 3 Chapter 4 Chapter 5 Introduction ......1 Features ........2 Package contents . -
Page 4: Chapter 1: Introduction
The CAT5 console port extends COMPUTER/SERVER up to 500 feet away from your control- ling keyboard, mouse and VGA monitor. A transmitter is built into the KVM switch. It synthe- sizes the PS/2 keyboard signal, PS/2 mouse signal and VGA monitor signal, and allows trans- mission over long distances using standard Ethernet CAT5 cable. -
Page 5: Features
Chapter 1: Introduction Features • 8/16 port Two-Console PS/2 KVM switch is standard 1U 19” rack mount size design. • Support one local console and one CAT5 remote console up to 500 feet away from KVM switch. • Support Microsoft ®... -
Page 6: Technical Specifications
Scan Intervals Keyboard Emulation Mouse Emulation VGA Resolution Bandwidth Daisy Chain MAX Level MAX Computer Connection Housing (KVM Switch) KVM Switch Power Adapter Cat5 Remote Console Receiver Power Adapter Operation Temperature Storage Temperature Humidity Size Weight (g) (KVM Switch) Weight (g) (CAT5 Receiver) -
Page 7: System Requirement
1 to 3 Hi Density KVM cable (KCB-1236F or KCB-1231) (HDDB 15 pin male to one HDDB 15 pin video and Mini Din 6 pin keyboard and mouse connectors) Note: One per computer, max. 8 per switch Two-Console 16 port PS/2 KVM Switch One VGA Monitor... -
Page 8: Cable Diagrams
Chapter 1: Introduction Cable Diagrams Computer Port Special Cable: 1 to 3 Hi Density KVM cable (KCB-1236F or KCB-1231) HDDB 15 pin male to one HDDB 15 pin video and Mini Din 6 pin keyboard and mouse connectors AT to PS/2 keyboard adapter: (Optional) Din 5 pin Male to Mini Din 6 pin Female Daisy Chain Cable: PS/2 Cable:... -
Page 9: Chapter 2: Hardware Installation
16 port Rack Mount KVM Switch. Step 1 Find a convenient place to put your KVM Switch. Its 19” rack mount form factor makes it ideal to be mounted on a 19” rack. When mounting to a rack, attach the included brackets to the sides of the KVM Switch. -
Page 10: Step 4-1 (Remote Console)
Chapter 2: Hardware Installation Step 3 Connect the keyboard to the KVM Switch. If you have an AT type keyboard, you will need an AT to PS/2 adapter. Step 4 Connect the mouse to the KVM Switch. Step 4-1 (Remote Console) Extending your computer console up to 500 feet away: (1) Make sure the CAT5 cable used is a straight through type. - Page 11 1280X1024 and CAT5 cable length could be up to 500 feet. 3. There is a Dip Switch on the rear of the KVM switch. The factory default value is “OFF/ OFF” state. When you use CAT5 cable length over 300 feet, please set DIP Switch to “ON/ON”...
- Page 12 Step 8 Attach the power supply to the KVM unit and plug the other end into an electrical receptacle. Now you will see the LED for Port 1 light up, and you will hear a beep. Switch on your monitor. NOTE: Though the computers connected to KVM Switch are able to support enough power to the stand alone switch, it is suggested that the power adapter be plugged in.
-
Page 13: Daisy Chain Connection Diagram
VGA signal. NOTE: If you would like to daisy chain 8 port, or 16 port PS/2 or KVM Switch together, the master bank must be 16 port PS/2 or KVM Switch... -
Page 14: Chapter 3: Console Operation
Press Port Select and Bank Select of bank 1 (master) simultaneously to reset KVM switch. This reset action will not only return KVM switch back to initial state but it will also re-check any slave banks which are connected to the master KVM switch. -
Page 15: Selecting Computer Using Hot Key
Scroll Lock NOTE: 1. If you enable the scan mode command, the KVM switch will issue one Beep for confirma- tion each time one of the KVM ports hop to the next KVM port. 2. To get out of Auto Scan Mode, press any key or Space bar. - Page 16 Chapter 3: Console Operation Selecting Computer through Hot Key - Example Example: To access a computer attached to Port 2 of Bank 3. You can press through hot key as below: Scroll lock + Scroll lock + 3 + 0 + 2 To access a computer attached to next Bank, You can press through hot key as below: Scroll lock + Scroll lock + Page Down NOTE:...
-
Page 17: Hot Plug
Chapter 3: Console Operation Hot Plug Function KVM switch supports “ Hot Plug ” function. When mouse/keyboard connection has been changed from one port to the other, it is not necessary to reboot the managed computer for the change to take effect. -
Page 18: Osd Operation Details
KVM’s computer system name list. You will find the system number list from 01 to 08. You can define your system name with a maximum of 8 levels. The factory default of the 8 port KVM (or 16 for KVM-16H) switch is “SYSTEM 01”, “SYSTEM 02”,…, “SYSTEM 08”. - Page 19 Use up arrow key “ ” or down arrow key “ name. After selecting the KVM port you want, press the ENTER Key to immediately switch to that KVM port. Use “PgUp” or “PgDn” key for selecting previous or next Bank No.
- Page 20 KVM switch authentication, the CONSOLE will be set to ON. After you finish using the KVM switch, please do not forget to set the CONSOLE ON state to OFF for password authentication. ( Note: If you reset the KVM switch, or there is a power failure, the CONSOLE will be set at the OFF state.
-
Page 21: Chapter 4: Troubleshooting
• Avoiding switching ports during shutting down the computer process. • When you switch one computer port to another, please set the scan time for 5 sec at least. Normally, it takes one or tow seconds for the VGA monitor to change from one resolution mode to another. -
Page 22: Chapter 5 Certifications
Certifications This equipment has been tested and found to comply with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference (2) This device must accept any interference received. Including interference that may cause undesired operation. - Page 24 © 2005 freedom9 Inc.
