Freedom9 freeView IP 100 Specifications

freeView IP
Single Port IP KVM
Remote Access Device
freeView IP 100 > Single Port IP KVM Remote
Access Device
The freeView IP 100 defines a new class of remote KVM access
devices. It combines digital remote KVM access via IP networks
through comprehensive and integrated systems management.
The freeView IP 100 offers convenient remote control and
access via IP LAN or Internet.
It captures, digitizes, & compresses the video, keyboard &
mouse signals and transmits them via IP to and from a remote
computer. It provides a truly non-intrusive solution for remote
access and control.
The access & control software runs on its embedded proces-
sors, not on mission-critical computers. Thus, there is no
interference with server operation or impact on network
performance.
Specifications
Host Connections
Connector Type
Keyboard/Mouse
Video
Console Connections
Keyboard/Mouse
Video
LAN Port
Serial Port
LED
Hot Plug
Scan Intervals
VGA Resolution
Power Supply
Housing
Dimensions (H x W x D)
Model Numbers
Model Name
Description
Part Number
Revision 2.0 Specifications are subject to change without notice. Copyright 2007 Freedom9 Inc.
100
1
3-to-3
PS/2 or USB
VGA
1
PS/2
VGA
RJ-45
DB-9 (Male)
Yes
Yes
5-99 Sec
Local: 1920x1440
Remote: 1600x1200
DC 5V, 2.5A
Metal
1.1" x 54.7" x 6.1" in (27 x 139 x 156 mm)
freeView IP 100
Remote System Management
KVM-01IA
Features:
• Manage servers around the world
• KVM access over IP, ISDN or analog
telephone line
• BIOS level access
• SSL encryption
• No impact on server or network
performance
• Automatically senses video resolution for
best possible screen capture
• High-performance mouse tracking and
synchronization
• Port to connect a user console for direct
analog access to KVM switch
• Local mouse suppression (only when using
Sun's Java Virtual Machine)
• Virtual Media allows for file transfers
between local and remote computers
www.freedom9.com
1-888-998-9189
