freeConnect
24-port 10/100Mbps
Rackmount Switch
freeConnect 2400 > 24-port 10/100Mbps
rackmount switch
Networking switch: Simple - reliable
The freeConnect 2400 provides a simple and cost effective
solution to expand a network. Providing 24 ports in a compact
1U rackmount chassis, this switch is ideal for departments,
workgroups and basic server rooms.
With automatic MDI/MDIX detection, you will no longer have
to worry about when to use a straight-through cable and
when to use a crossover cable, the freeConnect 2400 will
compensate automatically. This feature, combined with
automatic speed and duplex detection, makes the device truly
"plug and play". The LEDs on the front panel provide detailed
diagnostics of the unit's activity and status, allowing you to
monitor the freeConnect 2400 with a quick glance.
Specifications
Standards
Ports
Transfer Rate
Power
Power Consumption
Network Cables
Filtering Address Table
Switching Fabric
Dimensions (w x h x d)
Temperature
Humidity
EMI
Model Numbers
Model Name
Description
Part Number
Revision 2.0 Specifications are subject to change without notice. Copyright 2007 Freedom9 Inc.
2400
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3x full-duplex flow control
24 x RJ-45 Auto-MDIX ports
Ethernet 10Mbps/20Mbps Full-duplex
Fast Ethernet 100Mbps/200Mbps full-duplex
100-240 VAC, 50/60 Hz
10W (Max.)
Ethernet - Cat 3, 4, 5, 6 UTP
Fast Ethernet - Cat 5, 6 UTP
8K entries
Wire-speed non-blocking
17.3" x 1.7" x 5.5" (440 x 44 x 140 mm)
Operating 32°F - 104°F (0°C - 40°C)
Storage 14°F - 158°F (-10°C - 70°C)
Operating 10% - 90% RH
Storage 5% - 90% RH
FCC Class A/CE Mark A/VCCI-A
freeConnect 2400
24-port 10/100Mbps Rackmount Switch
S002410000
Features:
• 24 10/100Mbps Auto-Negotiation Ethernet
ports
• Supports Auto-MDI/MDIX for each port
• Supports Full/Half-Duplex transfer mode
for 10 and 100Mbps
• Full wire speed reception and transmission
• Store-and-Forward switching method
• Supports 8K MAC addresses
• Supports 2.5Mbytes RAM for data
buffering
• Extensive front panel diagnostic LEDs
• IEEE 802.3x Flow Control for Full-Duplex
• Back pressure Flow Control for
Half-Duplex
www.freedom9.com
1-888-998-9189
