Quick Installation Guide
Thank you for purchasing the KVM-02 series switch. The KVM-02 series is
designed to save space, and reduce cables and peripherals, thus saving you
money, time, equipment and power.
Controlling 2 PCs/Macs/Sun Microsystems from a single keyboard, mouse, monitor
and audio device has never been more convenient. The keyboard and mouse
emulation allows you to simultaneously boot up multiple computers. In addition to
all the convenient standard features like attached cables, the KVM-02 series also
includes Hot-key and Auto-scan control keyboard commands for greater user
control.
Features
Compact size, elegant design, portable, and no extra cables required
Supports individual USB mouse, USB Keyboard or USB keyboard and mouse
combination on console port (KVM-02U only)
Built-in microphone and speaker jacks for multimedia applications
Supports Windows 98/98SE/2000/ME/XP/NT, Novell Netware/Unix, Linux, Sun Solaris
or later versions
Supports Mac O.S 8.6 or later versions (provided connection is made on USB Mac
systems or USB Sun Microsystems)
Hot Plug - add or remove connected computers for maintenance without powering down
the KVM switch or computers
High performance video resolution - up to 2048X1536, 400MHz bandwidth max.
Auto Scan Mode for monitoring computers
Keyboard and Mouse status restore when switching computers
LED indicators for easy status monitoring
KVM-02 Series
2-port KVM Switch
Rev. 1.0
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Freedom9 KVM-02 Series
Summary of Contents for Freedom9 KVM-02 Series
- Page 1 Quick Installation Guide KVM-02 Series 2-port KVM Switch Thank you for purchasing the KVM-02 series switch. The KVM-02 series is designed to save space, and reduce cables and peripherals, thus saving you money, time, equipment and power. Controlling 2 PCs/Macs/Sun Microsystems from a single keyboard, mouse, monitor and audio device has never been more convenient.
-
Page 2: Package Contents
Package Contents: The KVM-02 series comes in 2 models: KVM-02P 2-port KVM switch with two 6’connecting cables (PS/2 & VGA & PS/2 & Audio & Microphone) Console Connections (PS/2 & VGA & PS/2 & Audio & Microphone) Quick Installation Guide KVM-02U 2-port KVM switch with two 6’... -
Page 3: Technical Specifications
Technical Specifications KVM-02P KVM-02U Function MAX Computer Connections PS/2 Computer Port Video Mouse PS/2 PS/2 Console Port Video Mouse PS/2 Computer selection Hot-Key* Keyboard Command Keyboard Command Audio port AutoScan Intervals 8sec. 5 sec. VGA Resolution 2048x1536 2048x1536 Bandwidth 400MHz 400MHz Power Type Bus Power... -
Page 4: Hardware Installation
Hardware Installation Before starting with the installation process, please TURN OFF all connected peripherals and computers. Windows XP/ME/2000/NT/Server 2003 users: Remark: Windows NT4.0 does not support USB 1. Connect the keyboard, VGA, mouse, and audio cables from the KVM switch into the computer ports. - Page 5 Windows 98/98SE users: (KVM-02U) When you use Windows 98/98SE with the USB KVM Switch (KVM-02U), please use the following set up procedures: 1st Step: 1. Connect KVM USB type A cable to PC. 2. Connect KVM HDDB15 pin Male video cable to PC. 3.
- Page 6 Mac O.S. and Sun Micro Systems Keyboard Mapping The following diagram indexes the Hotkey combination that emulates Mac O.S. and Sun Micro keyboard commands. This feature is only available on the PS/2 keyboard attached to the KVM, and is not available on the USB keyboard. Left Windows Key = L_Win...
-
Page 7: Keyboard Hot Key Commands
Usage The LEDs on the KVM top surface represents the number of the active computer supported. When using the Hot-Key commands, the indicators light up to specify the connected/monitored computer. Only one LED indicator lights up at a time. Keyboard Hot Key Commands: You can conveniently instruct the KVM to switch ports through simple key sequences. - Page 8 “female to male” KVM cable for remote connection. The maximum extended length of cable is 20 feet and it is recommended that you use high quality cable(s). Remember to check our website at www.freedom9.com for the latest manuals and support information.
- Page 9 Such repair or replacement will be rendered by freedom9 at an authorized freedom9 service office. The replacement Hardware need not be new or have an identical make, model or part. freedom9 may in its sole discretion replace the defective Hardware (or any part thereof) with any reconditioned product that freedom9 reasonably determines is substantially equivalent (or superior) in all material respects to the defective Hardware.
