Summary of Contents for Patton electronics IM2RC/F-128K
- Page 1 USER M A N UA L MODEL IM2RC/F-128K Co-Directional Rack Mount Modem Rear Card Part# 07MIM2RC/F128-A SALES OFFICE Doc# 078541UA (301) 975-1000 Revised 07/27/99 TECHNICAL SUPPORT (301) 975-1007 http://www.patton.com An ISO-9001 Certified Company...
-
Page 2: Table Of Contents
If 5.2 Operating Instructions the Model IM2RC/F-128K does cause interference to radio or television reception, which can be determined by disconnecting the unit, the user is encouraged to try to correct the interference by one or more of the Appendix A - Specifications............15... -
Page 3: General Information
G.703 network extension, dedicated high speed internet access, remote LAN access,...the possibilities are endless! Supporting 128kbps clear channel, the IM2RC/F-128K can set its own clock or it take clock- ing from the G.703 network. The Model IM2RC/F-128K meets baseband modem function cards such as 1094ARC and 1095RC in the mid-plane of Patton’s 2U (3.5”) -
Page 4: Configuration
The IM2RC/F-128K card contains sensitive inte- Clear Channel grated circuitry. Failure to ground yourself during configuration Timing Mode Network Timing may result in damage to the IM2RC/F-128K card or the front func- Reserved for Future Use tion card. Reserved for Future Use G.703 Transmit Octet Injected BPVs 3.1 CONFIGURING THE IM2RC/F-128K HARDWARE SWITCHES... -
Page 5: Connecting The Interface Driver Board
Follow the instructions below to connect the interface driver board external to the the IM2RC/F-128K. Use Switch S6 to configure the unit to the front function card: to transmit G.703 data to the network with or without BPVs. -
Page 6: Installation
19” rack. Sturdy front handles allow the Model 1000R16 to be extract- connectors. Use the following steps as a guideline for installing each ed and transported conveniently. Model IM2RC/F-128K and its function card mate into the rack chassis: WARNING! The IM2RC/F-128K card contains sensitive inte- grated circuitry. -
Page 7: Making Interface Connections
4.3 MAKING INTERFACE CONNECTIONS 1 (RX) 2 (RX) The Model IM2RC/F-128K is designed to provide access to a 64 3 (N/C) kbps co-directional G.703 PCM network. Figure 5 shows the position 4 (TX) of the G.703 interface and the line interface of the IM2RC/F-128K. -
Page 8: Two-Wire And Four-Wire Cable Connection Via
5.2 OPERATING INSTRUCTIONS user manual to determine the correct pin assignments. In order to operate, the Model IM2RC/F-128K must be installed in the rear of a Patton 16 port rack or a 2, 4, or 8 port ClusterBox™ chas- sis. A front function card, such as a baseband modem, CSU/DSU, or HDSL modem meets the IM2RC/F-128K rear card in the mid-plane of the chassis. -
Page 9: Appendix A - Specifications
APPENDIX A APPENDIX B PATTON ELECTRONICS MODEL IM2RC/F-128K PATTON ELECTRONICS MODEL IM2RC/F-128K SPECIFICATIONS CABLE RECOMMENDATIONS Applications: 128kbps G.703 PCM network extension All Patton Electronics Company Baseband Modems, CSU/DSUs and Short Range Modem are tested to the distances published in our G.703 Interfaces:... -
Page 10: Appendix D - 120 Ohm G.703 Interface Pin Assignment
APPENDIX C APPENDIX D PATTON ELECTRONICS IM2RC/F-128K PATTON ELECTRONICS IM2RC/F-128K FACTORY REPLACEMENT PARTS AND ACCESSORIES 120 OHM G.703 INTERFACE PIN ASSIGNMENT Patton Model # Description (RJ45 Female Connector) Pin Number Signal 1000RCM12592..Rear card w/DB25F & RJ45 (V.24 interface) 1000RCM12492..Rear card w/ M/34F & RJ45 (V.35 interface) 1........... - Page 11 APPENDIX E PATTON ELECTRONICS IM2RC/F-128K LINE INTERFACE PIN ASSIGNMENT (RJ45 Female Connector) Pin Number Signal 1........... 4-Wire RX 2 ..........4-Wire RX 3 ..........no connection 4...........2-Wire TIP/4-Wire TX 5 ..........2-Wire RING/4-Wire TX 6 ..........no connection 7 ..........no connection 8 ..........no connection...
