- Page 1 USER MANUAL MODEL 1092A High Speed, 2-Wire/4-Wire, Sync & Async Short Range Modem SALES OFFICE Part# 07M1092A-E Doc# 033031UD (301)975-1000 Revised 03/29/00 TECHNICAL SUPPORT (301)975-1007 An ISO-9001 http://www.patton.com Certified Company...
-
Page 2: Table Of Contents
The Model 1092A has been tested and found to comply with the limits for a Class A computing device in accordance... -
Page 3: Service
Patton Electronics' technical staff is also available to answer any questions that might arise concerning the installation or use of your Model 1092A. Technical Service hours: 8AM to 5PM EST, Monday through Friday. 2.0 GENERAL INFORMATION Thank you for your purchase of this Patton Electronics product. -
Page 4: Snmp
Back Figure 2. Underside of Model 1092A, Showing Location of DIP Switches The two sets of DIP switches on the underside of the Model 1092A will be referred to as S1 and S2. As Figure 3 shows the orientation of all DIP switches is the same with respect to “ON”... -
Page 5: Configuration Dip Switch Set "S1
Switches S1-1 and S1-2: Data Rate Use Switches S1-1 and S1-2 with Switch S2-1 to configure the Async or Sync bit rate for Model 1092A. The following table summarizes default positions of DIP Switch S2. Detailed descriptions of each switch follow the table. -
Page 6: Configuration Dip Switch Set "S2
Use Switch S1-8 to allow Model 1092A to enter the Remote Digital Loopback diagnostic test when requested to do so by the far end Model 1092A For example, when Switch S1-8 is set to “ON”, it will enter RDL mode (See Section 5.3.2) when requested to do so by the remote Model 1092A. -
Page 7: Configuring The Software Switches
CONFIGURING THE SOFTWARE SWITCHES The Model 1092A features a menu-driven command system that allows you to configure the local 1092A. Follow the instructions below to configure the Model 1092A using the software switches: Connect the serial RS-232 port of a V100 or similar DTE with terminal emulation to the EIA/TIA-561l port of the Model 1092A. - Page 8 7. DTE controlled Digital Loop 8. 4-Wire/2-Wire selection ******************************************************** Enter your selection (1-7)> 1. DTE Rate Select Option 1 in the SOFTWARE CONFIGURATION menu to select the async. or sync. DTE Rate of the Model 1092A. The selections are shown below.
- Page 9 Line Loop test mode (below). 5. Response to Remote Digital Loop Select Option 5 in the SOFTWARE CONFIGURATION Menu to instruct the Model 1092A to either respond or ignore the Remote Digital Loop request from the remote 1092A. 6. DTE Controlled Local Line Loop...
- Page 10 NOTE: Test Mode options 2,3,7,8 and 9 require the 1092A to be in Data Mode with the remote 1092A. Handshaking - This status occurs when the 1092A is in the process of establishing a link with another 1092A.
-
Page 11: Installation
The Model 1092A Test Modes are described on the following page. To run or terminate a particular test, key in the option to get to that screen menu. Terminates all tests Initiates the built-in test pattern generator and detector. 511 with Errors Initiates the built-in test pattern generator and detector. -
Page 12: Connecting The Serial Port
Model 1092A. SIGNAL 4.2.1 Changing QuikConnect™ Modules When you purchase a particular version of the Model 1092A, it should be shipped to you with the appropriate QuikConnect™ Module already installed. If you need to install a different QuikConnect™... -
Page 13: Connecting To A "Dte" Device
1092A. 3) While keeping the module’s faceplate parallel with the Model 1092A rear panel, slide the module straight in – so that the card edge contacts line up with the socket inside the chassis. NOTE: The card edge connector should meet the socket when it is almost all the way into the chassis. -
Page 14: Connecting To A Dc Power Source
LED status monitors, and using the built-in loopback test modes. 5.1 POWER-UP To apply power to the Model 1092A, first be sure that you have read Section 4.3, and that the unit is connected to the appropriate power source. Then power-up the unit using the rear power switch. -
Page 15: Test Modes
The Local Line Loopback (LLB) test checks the operation of the local Model 1092A, and is performed separately on each unit. Any data sent to the local Model 1092A in this test mode will be echoed (returned) back to the user device (see Figure 7, below). For example,... -
Page 16: Using The V.52 (Ber) Test Pattern Generator
Locate the “511/511E” toggle switch on the front panel of the 1092A and move it UP. This activates the V.52 BER test mode and transmits a “511” test pattern into the loop. If any errors are present, the local modem’s red “ER” LED will blink sporadically. - Page 17 APPENDIX B PATTON ELECTRONICS MODEL 1092A FACTORY REPLACEMENT PARTS AND ACCESSORIES Patton Electronics Model # Description IM1/A...V.24 with DB25F IM1/B ...RS422/RS530 with DB25F IM1/C...V.35 with M34F IM1/D...X.21 with DB15F IM1/E ...V.35 with DB25F IM1/F ...64KG.703 with RJ45 IM1/I ...10BT with RJ45 IM1/JO...Voice Data Module...
- Page 18 APPENDIX C PATTON ELECTRONICS MODEL 1092A INTERFACE PIN ASSIGNMENT (Continued) V.35 Interface (M/34F Female Connector) (DCE Configuration) Pin # Signal B ...SGND (Signal Ground) C ...RTS (Request to Send) D ...CTS (Clear to Send) E ...DSR (Data Set Ready) F...CD (Carrier Detect) H ...DTR...
-
Page 19: Appendix D - Control Port Pin Assignment
APPENDIX D APPENDIX D PATTON ELECTRONICS MODEL 1092A CONTROL PORT PIN ASSIGNMENT The 1092A control port is an 8 position connector, compliant with EIA/TIA-561. Pin Function RJ45 Pin No. Ground Receive data (to DTE) Transmit data (from DTE) MASTER UNIT SETTINGS...
