Page 2 We hope you will enjoy many years of driving pleasure in your Volvo. The car has been designed for the safety and comfort of you and your passengers. Volvo is one of the safest cars in the world. Your Volvo has also been designed to satisfy all current safety and environmental requirements.
Page 3: Table Of Contents
01 Safety 02 Instruments and controls Important information......... 8 Seatbelts........... 16 Overview, left-hand drive cars....42 Volvo and the environment....... 11 Airbag system........... 19 Overview, right-hand drive cars....44 Airbags (SRS)..........20 Driver's door control panel....... 46 Activating/deactivating the airbag (SRS)*. 23 Combined instrument panel......
Page 4 Table of contents 03 Climate control 04 Interior 05 Locks and alarm General information on climate control..84 Front seats..........100 Remote control key with key blade..114 Manual climate control, AC....... 86 Interior lighting........102 Privacy locking*........117 Electronic climate control, ECC*....89 Storage spaces in the passenger com- Active locks..........
Page 5 Table of contents 06 Starting and driving 07 Wheels and tyres 08 Car care General............ 132 General............ 172 Cleaning..........190 Refuelling..........134 Tyre pressure.......... 176 Touching up paintwork......193 Starting the engine........135 Warning triangle* and spare wheel* ..179 Rustproofing...........
Page 6 Table of contents 09 Maintenance and service 10 Infotainment system 11 Specifications Volvo service........... 198 General............ 226 Type designation........258 Self-maintenance........199 Audio functions........228 Dimensions and weights......261 Bonnet and engine compartment... 200 Radio functions........232 Engine specifications......264 Oils and fluids.........
Page 7: Table Of Contents
Table of contents 12 Alphabetical Index Alphabetical Index........282...
Page 8 Table of contents...
Page 9: Introduction
Volvo dealer. are designed to convey important information IMPORTANT Volvo cars are adapted for the varying require- in a simple and clear manner. The decals in the Important texts advise of a risk of material...
Page 10 Introduction Important information Warning for personal injury Risk of property damage Information Black ISO symbols on yellow warning field, White ISO symbols and white text/image on White ISO symbols and white text/image on white text/image on black message field. Used black or blue warning field and message field.
Page 11 The driving and safety systems in the car use an authorised Volvo workshop before installing Arrows appear numbered and unnum- computers which check and share information accessories which are connected to or affect bered and are used to illustrate a move- with each other on the car's function.
Page 12: Volvo And The Environment
Introduction Volvo and the environment Volvo Cars' environmental philosophy Environmental care is one of Volvo Car Corpo- many cases the exhaust emissions are well Fuel consumption ration's core values which influence all opera- below the applicable standards. Volvo cars have competitive fuel consumption tions.
Page 13 Textile standard You can easily help reduce environmental to local regulations. Switch off the engine The interior of a Volvo is designed to be plea- impact, for example, by driving economically when stationary for longer periods. sant and comfortable, even for people with and by servicing and maintaining the car •...
Page 14 Introduction Volvo and the environment The owner's manual and the environment The FSC symbol shows that the paper pulp in this publication comes from FSC certified for- ests or other controlled sources.
Page 15 Seatbelts....................16 Airbag system..................19 Airbags (SRS)..................20 Activating/deactivating the airbag (SRS)*..........23 Side airbags (SIPS bags)................ 25 Inflatable Curtain (IC)................27 WHIPS..................... 28 When the systems deploy............... 30 Crash mode.................... 31 Child safety..................... 32 Option/accessory, for more information, see Introduction.
Page 16 S A F E T Y...
Page 17: 01 Safety
The seatbelt locks and cannot be withdrawn: Never modify or repair the seatbelt yourself. • if it is pulled out too quickly. Volvo recommends that you contact an • during braking and acceleration. authorised Volvo workshop. If the seatbelt has been subjected to a major load, such as •...
Page 18 01 Safety Seatbelts Seatbelts and pregnancy vehicle as they drive (which means that they Rear seat must be able to easily operate the foot pedals The seatbelt reminder in the rear seat has two and steering wheel). They should strive to posi- subfunctions: tion the seat with as large a distance as possi- •...
Page 19 01 Safety Seatbelts Seatbelt tensioner The front seatbelts and the two for the outer rear seats are equipped with seatbelt tension- ers. A mechanism in the seatbelt tensioner tightens the seatbelt in the event of a suffi- ciently violent collision. The seatbelt then pro- vides more effective restraint for occupants.
Page 20: Airbag System
The airbag system is continually monitored by tem, SIPS, SRS or the IC system. Volvo rec- the system's control module. The warning ommends that you contact an authorised symbol in the combined instrument panel illu- Volvo workshop immediately.
Page 21: Airbags (Srs)
01 Safety Airbags (SRS) Airbag system WARNING NOTE Volvo recommends that you contact an The sensors react differently depending on authorised Volvo workshop for repair. the course of the collision and whether or Defective work in the airbag system could...
Page 22 01 Safety Airbags (SRS) Airbag (SRS) on the driver's side Passenger airbag (SRS) Location of the passenger airbag in left-hand drive and right-hand drive cars. The car has an SRS airbag (Supplemental The car has an airbag to supplement the pro- Restraint System) to supplement the protec- tection afforded by the seatbelt on the passen- WARNING...
Page 23 01 Safety Airbags (SRS) WARNING Never place a child in a child seat or on a booster cushion in the front seat if the airbag (SRS) is activated. Never allow a child to stand or sit in front of the front passenger seat. Children under 140 cm must never sit in the front passenger seat if the airbag (SRS) is activated.
Page 24: Activating/Deactivating The Airbag (Srs)
Switch location. Volvo recommends that you visit an author- ised Volvo workshop as soon as possible. The airbag is activated. With the switch in For information on the key blade, see this position, children taller than 140 cm page 115.
Page 25 01 Safety Activating/deactivating the airbag (SRS)* A text message and a symbol in the roof panel WARNING NOTE indicate that the airbag (SRS) for the front pas- Activated airbag (passenger seat): When the remote control key is turned to senger seat is deactivated (see preceding illus- ignition position II or III the warning symbol tration).
Page 26: Side Airbags (Sips Bags)
• Volvo recommends the use only of car seat covers approved by Volvo. Other seat covers may impede the operation of the side airbags.
Page 27: Side Airbags (Sips Bags)
01 Safety Side airbags (SIPS bags) Label, side airbag Front passenger seat, left-hand drive. Location of decal for side airbag, driver's side, The SIPS bag system consists of side airbags front, left-hand drive car. and sensors. A sufficiently violent collision trips the sensors and the side airbags are inflated.
Page 28: Inflatable Curtain (Ic)
This could compromise the intended pro- heads on the inside of the car during a collision. WARNING tection. Volvo recommends that you only ever use Volvo genuine parts that are The inflatable curtain is a supplement to the approved for placement in these areas. seatbelts.
Page 29: Whips
Never modify or repair the seat or WHIPS the seat with as little space as possible The WHIPS system is a supplement to the system yourself. Volvo recommends that between the head and the head restraint. seatbelts. Always use a seatbelt. you contact an authorised Volvo workshop.
Page 30 WARNING If a seat has been subjected to extreme forces, such as due to a rear-end collision, the WHIPS system must be checked. Volvo recommends that it is checked by an authorised Volvo workshop. Part of the WHIPS system's protective capacity may have been lost even if the seats appear to be undamaged.
Page 31: When The Systems Deploy
Do not attempt to • Always contact a doctor. start the car since the airbags may deploy. Recovering the car. Volvo recommends that you have it conveyed to an authorised Volvo workshop.
Page 32: Crash Mode
If the car is in crash mode it must not be towed. It must be transported from its loca- Moving the car tion. Volvo recommends that you have it NORMAL MODE CRASH is shown after conveyed to an authorised Volvo workshop.
Page 33: Child Safety
Child seats and airbags are not compatible. Volvo's own child safety equipment is Volvo has child safety products that are WARNING designed for your car. Volvo recommends that designed for and tested by Volvo.
Page 34 01 Safety Child safety Label Airbag WARNING Booster cushions/child seats with steel braces or some other design that could rest on the seatbelt buckle's opening button must not be used, as they could cause the seatbelt buckle to open accidentally. Do not allow the upper section of the child Label located on instrument panel end face.
Page 35 Outer rear seat Centre rear seat Front seat Group 0 Volvo Child seat – rear-facing child Volvo Child seat – rear-facing child Volvo Child seat – rear-facing child seat, secured with the car's seatbelt seat, secured with the car's seatbelt, seat, secured with the car's seat- max.
Page 36 Outer rear seat Centre rear seat Front seat Group 1 Volvo Child seat – rear-facing child Volvo Child seat – rear-facing child Volvo Child seat – rear-facing child seat, secured with the car's seatbelt seat, secured with the car's seatbelt, seat, secured with the car's seat- 9 –...
Page 37 Child safety Weight/age Outer rear seat Centre rear seat Front seat Group 2/3 Volvo Booster cushion – with or with- Volvo Booster cushion – with or with- Volvo Booster cushion – with or out backrest. out backrest. without backrest. 15 – 36 kg...
Page 38 Volvo recommends ion. outer rear seats is specially designed to pro- that you contact an authorised Volvo work- vide optimum safety for children. Combined Grasp the cushion with both hands and shop. Do not make any modifications or with the regular seatbelts the integrated additions to the booster cushion yourself.
Page 39 01 Safety Child safety ISOFIX fixture system for child seats* Lowering the booster cushion Pull the handle. Mounting points for the ISOFIX fixture system are concealed behind the lower section of the Lower the seat and press until it locks. rear seat backrest, in the outer seats.
Page 40 01 Safety...
Page 41 Overview, left-hand drive cars..............42 Overview, right-hand drive cars.............. 44 Driver's door control panel..............46 Combined instrument panel..............47 Indicator and warning symbols............... 48 Information display.................. 52 Electrical socket..................54 Lighting panel..................55 Left-hand stalk switch................58 Right-hand stalk switch................61 Cruise control*..................
Page 42 I N S T R U M E N T S A N D C O N T R O L S...
Page 43: 02 Instruments And Controls
02 Instruments and controls Overview, left-hand drive cars...
Page 44 02 Instruments and controls Overview, left-hand drive cars Steering wheel adjustment Reading lamp, right-hand side Bonnet release Seatbelt reminder and passenger seat air- bag indicator Control panel Interior rearview mirror Direction indicators, main beam, trip com- Display for climate control and infotain- puter ment system Lighting, fuel filler flap opener...
Page 45: Overview, Right-Hand Drive Cars
02 Instruments and controls Overview, right-hand drive cars...
Page 46 02 Instruments and controls Overview, right-hand drive cars Electrical socket, cigarette lighter Reading lamp, right-hand side Blind Spot Information System, BLIS No function Switch, optional equipment No function Parking brake Sunroof controls Control panel Ignition switch Glovebox Windscreen wipers and washers, head- lamp washers Door handle Cruise control...
Page 47: Driver's Door Control Panel
02 Instruments and controls Driver's door control panel Driver's door control panel Disengaging the rear power windows. Electric child safety lock* Power windows Door mirror, left-hand side Door mirrors, setting Door mirror, right-hand side Option/accessory, for more information, see Introduction.
Page 48: Combined Instrument Panel
02 Instruments and controls Combined instrument panel Speedometer. Tachometer – Indicates engine speed in Button for trip meter – Used to measure thousands of revolutions per minute (rpm). short distances. Short presses on the but- Direction indicators, left. ton switches between the two trip meters Indicator and warning symbols.
Page 49: Indicator And Warning Symbols
02 Instruments and controls Indicator and warning symbols Functionality check, symbols Symbols in the centre of the instrument When the symbol illuminates: panel All indicator and warning symbols illuminate 1. Stop in a safe manner. Do not drive the car when the remote control key is turned to posi- further.
Page 50 ABS fault 3. Drive to a workshop to have the ABS sys- tem checked if the symbol remains lit. Rear fog lamp Volvo recommends that you seek assis- Stability system STC or DSTC tance from an authorised Volvo workshop. No function...
Page 51 If the faulty. symbol illuminates and the oil level is normal Volvo recommends that you contact an author- Parking brake applied ised Volvo workshop. The symbol illuminates when the parking brake is applied.
Page 52 02 Instruments and controls Indicator and warning symbols Stop the car in a safe place and check the have the brake system checked. Volvo rec- Low speed level in the brake fluid reservoir, see ommends that you seek assistance from If the car moves at a speed less page 206.
Page 53: Information Display
Specification Message Specification Stop the car in a safe TIME FOR REGU- Time for regular STOP SAFELY manner and turn off service. Volvo rec- LAR SERVICE the engine. Serious ommends that an risk of damage. authorised Volvo workshop carries SERVICE Volvo recommends out the service.
Page 54 144. run the engine at information on idling speed until the If shown repeatedly checking the oil message clears. For then Volvo recom- level, see page 203. more information, mends that an see page 144. authorised Volvo Diesel particle filter...
Page 55: 12 V Electrical Socket
02 Instruments and controls Electrical socket 12 V electrical socket Electrical socket in the rear seat WARNING Always leave the plug in the socket when the socket is not in use. The electrical socket can be used for various The electrical socket can be used for 12 V accessories, such as mobile phone chargers accessories, such as mobile phone chargers and coolers.
Page 56: Lighting Panel
Thumbwheel for headlamp levelling centre position. If necessary, the automatic the height of the beam. dipped beam can be deactivated. Volvo rec- Light switches 1. Turn the remote control key to position II. ommends that this is performed by an author- Thumbwheel for adjusting display and ised Volvo workshop.
Page 57: Lighting Panel
02 Instruments and controls Lighting panel The lamps are switched off automatically when Fog lamps Fuel filler flap the remote control key is turned to position I or Press button (5) to open the fuel filler flap when NOTE the car is unlocked, see page 123. Regulations for use of fog lamps vary from Instrument lighting country to country.
Page 58 02 Instruments and controls Lighting panel event of a malfunction. The function is only Brake light active in twilight or darkness and only when the The brake light automatically comes on during car is moving. braking. The function can be deactivated/activated with Emergency brake light and automatic the headlamp control.
Page 59: Left-Hand Stalk Switch
02 Instruments and controls Left-hand stalk switch Stalk switch positions Direction indicators Switching, main and dipped beam The remote control key must be in position II Continuous flash sequence and the headlamp control in end position, see Move the stalk switch up or down to page 55, for main beam to be switched on.
Page 60 02 Instruments and controls Left-hand stalk switch Trip computer* updated every couple of seconds. When the NOTE car is stationary, " --.- " appears on the display. If a warning message interrupts while you During the period for regeneration fuel con- are using the trip computer, this message sumption may increase, see page 276.
Page 61 02 Instruments and controls Left-hand stalk switch Resetting 1. Select AVERAGE SPEED AVERAGE 2. Reset with one press on the RESET but- ton. Press and hold the RESET button for at least five seconds to reset the average speed and average consumption at the same time.
Page 62: Right-Hand Stalk Switch
02 Instruments and controls Right-hand stalk switch Windscreen wipers Windscreen/headlamp washer Single sweep Raise the stalk switch to make a Move the stalk switch toward the steering single sweep. wheel to start the windscreen and headlamp washers. The wipers will make several more sweeps once the stalk switch is released.
Page 63 02 Instruments and controls Right-hand stalk switch Rain sensor* Activating the rain sensor: selected, or the sensitivity to rain when the rain sensor is selected. Press the button (B), see page 61. A display symbol shows that the rain sensor is active.
Page 64: Cruise Control
02 Instruments and controls Cruise control* Activating Increasing or decreasing speed NOTE A temporary increase in speed (less than one minute) using the accelerator, such as while overtaking, does not affect the cruise control setting. When you release the accel- erator, the car will return to the programmed speed.
Page 65 02 Instruments and controls Cruise control* Return to the set speed – Press this button to resume the CRUISE previously set speed. appears on the combined instrument panel. Disengaging Press CRUISE to disengage the cruise CRUISE ON control. clears on the com- bined instrument panel.
Page 66: Keypad In The Steering Wheel
02 Instruments and controls Keypad in the steering wheel* Button functions The four buttons at the bottom of the steering wheel keypad control the radio and the phone. The function of a button depends on which system is active. The steering wheel keypad can be used to scroll between preset stations, change CD tracks and adjust the volume.
Page 67: Steering Wheel Adjustment, Hazard Warning Flashers
02 Instruments and controls Steering wheel adjustment, hazard warning flashers Steering wheel adjustment WARNING NOTE Adjust the steering wheel before driving off, Regulations regarding the use of hazard never while driving. Before driving, check warning flashers vary from country to coun- that the steering wheel is fixed in position.
Page 68: Parking Brake
02 Instruments and controls Parking brake Parking brake (handbrake) How to Apply the parking brake 1. Fully depress the foot brake pedal. 2. Pull the lever firmly. 3. Release the foot brake pedal and make sure that the car is at a standstill position. 4.
Page 69: Power Windows
02 Instruments and controls Power windows Operation The windows can be opened and closed in two WARNING ways: The power windows are operated using the Make sure that children and other passen- controls in the doors. The ignition key must be gers cannot be trapped in any way when Manual operation in position I or II for the power windows to...
Page 70 02 Instruments and controls Power windows Blocking power windows in the rear Rear power windows NOTE doors If the car has electric child safety locks on the rear doors, the light indicates that these are also activated. The doors then cannot be opened from the inside.
Page 71: Windows, Rearview And Door Mirrors
02 Instruments and controls Windows, rearview and door mirrors Interior rearview mirror Interior rearview mirror with Calibrating the compass compass.* The earth is divided into 15 magnetic zones. Bright light from behind could be reflected in The compass is set for the geographic area to the rearview mirror and dazzle the driver.
Page 72 02 Instruments and controls Windows, rearview and door mirrors 4. Press the button (1) repeatedly until the number for the required magnetic zone ( 1– ) is shown, refer to the map of magnetic zones for the compass. 5. Wait until the display resumes showing the character 6.
Page 73 02 Instruments and controls Windows, rearview and door mirrors Door mirrors Retractable power door mirrors* NOTE The mirrors can be retracted for parking/driving The door mirrors will not be extended auto- in narrow spaces. This can be carried out in matically during unlocking if they were ignition position I and II.
Page 74 02 Instruments and controls Windows, rearview and door mirrors Blind Spot Information System, BLIS* BLIS is an information system that under cer- tain conditions can help to draw the driver's attention to vehicles moving in the same direc- tion in the so-called "blind spot", see page 153.
Page 75: Power Sunroof
02 Instruments and controls Power sunroof* Open positions Ventilation position WARNING Open: If there are children in the car: Press the rear edge of the control (5) Switch off the supply to the power sunroof upward. by removing the remote control key if the driver leaves the car.
Page 76: Power Sunroof
02 Instruments and controls Power sunroof* closed position as long as the button is If you need to interrupt closing: kept depressed. Press the lock button again. WARNING WARNING The sunroof's pinch-protection function Make sure that children or other passengers only operates during automatic closing, not are not in danger of becoming trapped in manual closing.
Page 77: Personal Preferences
02 Instruments and controls Personal preferences Possible settings Display Clock, adjustment Personal preferences can be set for some of The hour and minute are each adjusted sepa- MENU the car's functions. This applies to locks, cli- rately. mate control and audio functions. For audio EXIT 1.
Page 78: Personal Preferences
02 Instruments and controls Personal preferences On/Off central locking button, as well as the outside Select depending on whether or Doors – auto lock not you wish the recirculation timer to be door handle button on cars with the keyless When the speed of the car exceeds 7 km/h the active.
Page 79: Homelink
02 Instruments and controls HomeLink * General The original remote controls can of course be NOTE used in parallel with HomeLink . HomeLink is designed to be inoperable if the car is locked from the outside. WARNING Save the original remote controls for future If HomeLink is used to operate a garage programming (e.g.
Page 80 02 Instruments and controls HomeLink * • 2. Position the original remote control Glow not constant: The indicator lamp Programming individual buttons flashes quickly for approx. 2 seconds 5-30 cm from HomeLink . Monitor the indi- To reprogram an individual button, proceed in and then changes over to a constant cator lamp.
Page 81 02 Instruments and controls HomeLink * • Constant glow: The indicator lamp illu- 7. Depress the programmed button on minates with a constant glow when the HomeLink , while the "programming but- button is kept depressed, this indicates ton" is still flashing, keep it depressed for that the programming is complete.
Page 82 02 Instruments and controls...
Page 83 General information on climate control........... 84 Manual climate control, AC..............86 Electronic climate control, ECC*............. 89 Air distribution..................92 Fuel-driven engine block heater and passenger compartment heater*............. 93 Fuel-driven auxiliary heater* (diesel)............96 Option/accessory, for more information, see Introduction.
Page 84 C L I M A T E C O N T R O L...
Page 85: 03 Climate Control
Fault tracing and repair Display The climate control system cools or heats as Volvo recommends that you only entrust fault There is a display above the climate control well as dehumidifies the air in the passenger tracing and repair of the climate control system panel.
Page 86: Climate Control
03 Climate control General information on climate control Air vents in the dashboard ECC* Side windows and sunroof To ensure that the air conditioning works sat- Actual temperature isfactorily, close all side windows and the sun- The temperature you select corresponds to the roof (if fitted).
Page 87: Manual Climate Control, Ac
03 Climate control Manual climate control, AC Control panel Functions 2. Recirculation Recirculation can be used to 1. Fan Recirculation shut out bad air, exhaust Increase or decrease the fan fumes, etc. from the passen- Defroster speed by turning the knob. ger compartment.
Page 88 03 Climate control Manual climate control, AC Timer 4. Air distribution 6. and 7. Heated front seats* The timer function reduces the risk of icing, The airflow can be distributed misting and bad air (if recirculation is selected). to the windows, dashboard See page 76, for activating/deactivating the vents or floor by pressing the function.
Page 89 03 Climate control Manual climate control, AC on the button. Automatic switching off discon- nects the rear window and door mirrors after 12 – 20 minutes depending on outside tem- perature. During cold weather the defrosting* also con- tinues after 20 minutes in order to keep the rear window and door mirrors free of ice and mist.
Page 90: Electronic Climate Control, Ecc
03 Climate control Electronic climate control, ECC* Control panel AUTO Functions 2. Fan Turn the knob to increase or 1. AUTO decrease fan speed. If AUTO The AUTO function automat- is selected then fan speed is Recirculation/Air quality system ically regulates climate con- regulated automatically.
Page 91 03 Climate control Electronic climate control, ECC* • The air quality system consists of a multi-filter The defroster functions for the front, side 3. Recirculation and rear windows can be used to demist and a sensor. The filter separates gases and The function is selected to the windows.
Page 92 03 Climate control Electronic climate control, ECC* A symbol on the display above the climate con- on the button. Automatic switching off discon- 7 and 8. Heated front seats* trol panel and an illuminated light in the relevant nects the rear window and door mirrors after To activate front seat heating: button indicate which function has been 12 –...
Page 93: Air Distribution
03 Climate control Air distribution Air distribution Use: Air distribution Use: Air to windows. Some air to remove ice and Air to the floor and windows. to ensure comfortable flows from the air vents. The misting quickly. Some air flows from the dash- conditions and good air is not recirculated.
Page 94: Fuel-Driven Engine Block Heater And Passenger Compartment Heater
03 Climate control Fuel-driven engine block heater and passenger compartment heater* General information about heaters Refuelling Battery and fuel If the battery has insufficient charge or the fuel The parking heater heats the engine and pas- level is too low, the parking heater is switched senger compartment and can be started off automatically and a message appears on directly or with the timer.
Page 95 03 Climate control Fuel-driven engine block heater and passenger compartment heater* Activating the heater Symbols and display messages Display Specification When one of the timer's settings or HEATER STOP- The heater has been DIRECT START is activated, the stopped by the car's PED - LOW BAT- information symbol in the com- electronics in order...
Page 96 03 Climate control Fuel-driven engine block heater and passenger compartment heater* Heating of the passenger compartment will TIMER 1 After setting a second start time can NOTE begin as soon as the engine coolant has be programmed with TIMER 2 by scrolling with All timer programming will be cleared if the reached the correct temperature.
Page 97: Fuel-Driven Auxiliary Heater* (Diesel)
03 Climate control Fuel-driven auxiliary heater* (diesel) Auxiliary heater (diesel) In diesel-engined cars the auxiliary heater may be required for achieving the correct tempera- ture in the engine and passenger compartment during cold weather. The heater starts automatically when extra heat is required when the engine is running.
Page 98 03 Climate control...
Page 99 Front seats.................... 100 Interior lighting..................102 Storage spaces in the passenger compartment........104 Rear seat....................108 Cargo area.................... 110...
Page 100 I N T E R I O R...
Page 101: 04 Interior
"locks" in under the glovebox. Check that the seat is locked in position. Floor mats* Volvo supplies floor carpets which are espe- Tipping the front seat backrest* cially produced for your car. The driver's and passenger seats can be...
Page 102 04 Interior Front seats Power seat* the seat again. Only one of the seat's settings Emergency stop can be adjusted at a time. If the seat accidentally begins to move, press any of the buttons to stop the function. Memory function WARNING Risk of crushing.
Page 103: Interior Lighting
04 Interior Interior lighting Reading lamps and interior lighting Vanity mirror* Front roof lighting The front reading lamps are switched on or off by pressing the relevant button in the roof con- sole. Rear roof lighting Controls in roof console for front reading lamps The lamp is automatically switched on and off and passenger compartment lighting.
Page 104 04 Interior Interior lighting Automatic lighting Passenger compartment lighting comes on and remains on for 5 minutes if one of the doors Using the switch (2), see page 102, three posi- is open. tions can be selected for the lighting the pas- senger compartment: If any lighting is switched on manually and the car is locked then it will be switched off auto-...
Page 105: Storage Spaces In The Passenger Compartment
04 Interior Storage spaces in the passenger compartment Storage spaces...
Page 106 04 Interior Storage spaces in the passenger compartment Storage pocket on rear of front seats. Glovebox Coat hanger Storage compartment in door panel with cup holder. Ticket clip Storage pocket on front edge of front seat cushions. Glovebox Storage compartment (e.g. for CD discs and cup holder, *) and storage compart- ment behind the centre console.
Page 107 04 Interior Storage spaces in the passenger compartment Storage under the front armrest Cup holder in centre console In the deeper compartment there is space for 10 normal CD cases. The cases must be stored There is a storage space under the armrest. There is space for a double cup holder under vertically on the top edge for all 10 to have There is also a smaller storage space in the...
Page 108 04 Interior Storage spaces in the passenger compartment Storage compartment behind the gear Bottle holder* Ashtray* lever A bottle holder for larger bottles is located on An ashtray is located towards the rear of the When there are no buttons for parking assis- the rear of the tunnel console.
Page 109: Rear Seat
04 Interior Rear seat Head restraint, rear Tipping the rear seat backrest The rear seat backrests can be tipped forwards Lowering the backrest. together, or individually, to make it easier to All head restraints can be adjusted vertically to Rear edge of seat cushion transport long objects.
Page 110 04 Interior Rear seat 4. Fold the backrests (3) forward halfway and remove the head restraints on the outside seats. The centre seat's head restraint must be removed for a fully level floor. 5. Place the head restraints in the plastic sleeves on the undersides (4) of the raised seat cushions.
Page 111: Cargo Area
04 Interior Cargo area Load retaining eyelets Electrical socket in cargo area* Bag holder* The load retaining eyelets are used to fasten Fold down the cover to access the electrical The bag holder holds shopping bags in place straps or nets to anchor items in the cargo socket.
Page 112 04 Interior...
Page 113 Remote control key with key blade............114 Privacy locking*..................117 Active locks................... 118 Keyless drive*..................119 Battery in remote control key..............122 Locking and unlocking................123 Child safety locks.................. 126 Alarm*....................127 Option/accessory, for more information, see Introduction.
Page 114 L O C K S A N D A L A R M...
Page 115: 05 Locks And Alarm
The remote control keys contain detachable If you lose a remote control key, take the car metal key blades for mechanical locking/ and the other remote control keys to a Volvo unlocking of the driver's door and glovebox. workshop - an authorised Volvo workshop is The key blades' unique code is available at recommended.
Page 116 05 Locks and alarm Remote control key with key blade 30, 60 or 90 seconds. For information on Detachable key blade Pull out the key blade at the same time. setting the delay time, see page 77. Inserting the key blade Boot lid - Press the button once to unlock Be careful when inserting the key blade into the the boot lid only.
Page 117 05 Locks and alarm Remote control key with key blade Locking the glovebox NOTE The remote control key cannot unlock the glovebox without the key blade. This function is particularly useful for when the car is left for service, at a hotel or similar. The glovebox can only be locked/unlocked using the remote control key's detachable key blade.
Page 118: Privacy Locking
05 Locks and alarm Privacy locking* Locking Insert the key blade in the glovebox lock. For information on locking the glovebox only, see page 116. Turn the key blade 180 degrees clockwise. The keyhole is vertical in the locked posi- tion for privacy locking.
Page 119: Active Locks
05 Locks and alarm Active locks Active locks for remote control key with key blade. Active locks for remote control key with key blade removed and with privacy lock- ing activated.
Page 120: Keyless Drive
05 Locks and alarm Keyless drive* • Keyless lock and ignition system the READ button has been pressed. Remote control key max. 1.5 m from the Never leave any remote control key in the In order to open a door or the boot lid, a remote control key must be no more than approx.
Page 121 05 Locks and alarm Keyless drive* Locking Unlocking doors with the key blade NOTE On cars with the keyless drive system and automatic transmission the gear selector must be moved to the P position and the ignition dial turned to the 0 position. Other- wise the car cannot be locked or alarmed.
Page 122 05 Locks and alarm Keyless drive* Door handle, right-hand rear NOTE Centre console, under the rear section When the driver's door is unlocked using the key blade and is opened, the alarm is trig- Centre console, under the front section gered.
Page 123: Battery In Remote Control Key
05 Locks and alarm Battery in remote control key Low battery in remote control key 1. Place the remote control key with the key- pad downward and prize up the cover When the battery runs down and full function- using a small screwdriver. ality cannot be guaranteed, the information KEY BATTERY symbol...
Page 124: Locking And Unlocking
05 Locks and alarm Locking and unlocking Locking/unlocking the car from Automatic relocking WARNING outside If none of the doors or the boot lid is opened Be aware that you can be locked in the car For cars with the Keyless system, see within 2 minutes of unlocking, all are locked if it is locked from the outside with the again automatically (does not apply to locking...
Page 125 05 Locks and alarm Locking and unlocking Automatic locking Unlocking Temporary deactivation Press the upper section of the central lock- When the speed of the car exceeds 7 km/h the ing button doors and boot lid are locked automatically. A long press (at least 4 seconds) also When the function is activated and the doors have been locked they can be opened in two opens all the side windows simultaneously...
Page 126 05 Locks and alarm Locking and unlocking If someone is going to stay in the car but the Full guard sage at which the deadlocks func- doors must be locked from the outside, then tion and the alarm's movement and tilt detec- the deadlocks function can be temporarily tors* are re-engaged.
Page 127: Child Safety Locks
05 Locks and alarm Child safety locks Manual select, child lock, rear doors Electrical locking of the rear doors and The lamp in the button illuminates when the power windows* lock is active. NOTE Cars with electric child safety locks do not also have manual child locks.
Page 128: Alarm
– the alarm has been triggered. If there is a fault in the alarm system, a message appears on the display. At which point you should contact a workshop - an authorised Volvo workshop is recommended. Option/accessory, for more information, see Introduction.
Page 129 05 Locks and alarm Alarm* Automatic re-arming of the alarm Remote control key not working Reduced alarm level This function prevents you accidentally leaving the car without the alarm on. If none of the doors or the tailgate are opened within two minutes of disarming the alarm (and the car has been unlocked with the remote control key), the alarm is automatically...
Page 130 05 Locks and alarm Alarm* To avoid inadvertently triggering of the alarm - the instrument panel display shows the mes- 4. Open one of the doors. A siren should for example when leaving a dog in the car or sage Full guard at which the movement and sound and all direction indicators should...
Page 131 General....................132 Refuelling....................134 Starting the engine................135 Starting the engine – Flexifuel............... 137 Keyless drive*..................139 Manual gearbox..................140 Automatic gearbox................142 All-wheel drive..................146 Brake system..................147 DSTC – Stability and traction control system*........149 Park Assist*................... 151 BLIS* –...
Page 132 S T A R T I N G A N D D R I V I N G...
Page 133: 06 Starting And Driving
06 Starting and driving General Economical driving Slippery driving conditions Open boot lid Driving economically means driving smoothly Practise driving on slippery surfaces under Avoid driving with the boot lid open. If it is nec- while thinking ahead and adjusting your driving controlled conditions to learn how the car essary to drive with the tailgate open for a short style and speed to the prevailing conditions.
Page 134 06 Starting and driving General • When driving in water, maintain a low speed ventilation fan and do not stop the car. When the water has • windscreen wipers been passed, depress the brake pedal lightly • audio equipment (high volume) and check that full brake function is achieved.
Page 135: Refuelling
Do not add cleaning additives to the petrol, Excess fuel in the tank can overflow in hot Don not forget to switch off the fuel-driven heater unless recommended by Volvo. weather. before refuelling! Open the fuel filler flap with the button on the...
Page 136: Starting The Engine
06 Starting and driving Starting the engine Before starting the engine Starting the engine Key positions Apply the parking brake. Petrol 0 – Locked position Turn the remote control key to key position The steering lock is activated Automatic gearbox III.
Page 137 06 Starting and driving Starting the engine III – Start position WARNING The starter motor is engaged. Always remove the remote control key from When the remote control key the ignition switch when leaving the car, is released it springs back especially if there are children in the car.
Page 138: Starting The Engine - Flexifuel
III. connections must only be carried out by a workshop - an authorised Volvo workshop 3. When the engine has started, ease the is recommended. accelerator pedal gradually as the engine speed increases.
Page 139 06 Starting and driving Starting the engine – Flexifuel If the battery has been discharged or discon- NOTE nected then a slightly longer period of driving Points to remember for carrying reserve is required for the adaptation as the memory fuel: for the electronics has been cleared.
Page 140: Keyless Drive
06 Starting and driving Keyless drive* General Starting the car Starting with the remote control key Depress the clutch pedal (cars with manual gearbox) or brake pedal (cars with auto- matic gearbox). Petrol engine Press in and turn the ignition dial to key position III.
Page 141: Manual Gearbox
06 Starting and driving Manual gearbox • Gear positions - five-speed To engage reverse gear, the gear lever Gear shift indicator - GSI* must first be put in position N. Reverse GSI - Gear Shift Indicator - gear cannot therefore be engaged directly advises the driver of the opti- from fifth gear due to the reverse gear mum time to change gear.
Page 142 06 Starting and driving Manual gearbox It may be difficult to find the positions for fifth Reverse gear inhibitor - six-speed NOTE and sixth gear when the car is stationary as the (diesel) Reverse gear is electronically blocked if the reverse gear inhibitor (which blocks sideways car is travelling faster than movement towards reverse) is then not acti-...
Page 143: Automatic Gearbox
06 Starting and driving Automatic gearbox Geartronic automatic gear positions Geartronic manual gear positions NOTE The driver can also change gear manually The brake pedal must be depressed to using the Geartronic automatic gearbox. The move the gear lever from the P position. car engine-brakes when the accelerator pedal is released.
Page 144 06 Starting and driving Automatic gearbox immediately engaged. This is known as kick- Mechanical gear selector inhibitor Automatic gear selector inhibitor down. Cars with an automatic gearbox have special safety systems: If the accelerator is released from the kick- down position, the gearbox automatically Keylock changes up.
Page 145 06 Starting and driving Automatic gearbox Disengaging the gear selector inhibitor the battery is flat. Proceed as follows to move to the gearbox oil's viscosity at low tempera- the car: tures. To reduce engine emissions, the gear- box shifts up later than normal when the engine 1.
Page 146 06 Starting and driving Automatic gearbox Symbol Display Driving characteristics Action TRANSM. OVERHEAT BRAKE TO Difficulty in maintaining even speed at con- Gearbox overheated. Keep the car station- stant engine speed. HOLD ary using the foot brake Significant pulling in the car's traction. Gearbox overheated.
Page 147: All-Wheel Drive
06 Starting and driving All-wheel drive All-wheel drive – AWD* All-wheel drive is always engaged. All-wheel drive means that all four road wheels are driven at the same time. Power is automat- ically distributed between front and rear wheels. An electronically controlled clutch sys- tem distributes the power to the pair of wheels that grips best.
Page 148: Brake System
06 Starting and driving Brake system Brake servo Bear in mind that driving with a trailer puts an Dampness can affect braking additional load on the car's brakes. characteristics If the car is rolling or is being towed with the Brake components become wet when the car engine turned off, the brake pedal must be is driven in heavy rain, through pools of water...
Page 149 - an author- ised Volvo workshop is recommended. If the brake fluid is under the MIN level in the brake fluid reservoir, do not drive further before topping up the brake fluid.
Page 150: Dstc - Stability And Traction Control System
06 Starting and driving DSTC – Stability and traction control system* General The stability system is activated automatically Spin Control each time the car is started. The function prevents the driving wheels from The stability and traction control system, STC/ spinning against the road surface during accel- DSTC (Dynamic Stability and Traction Control) System operation during skidding and accel-...
Page 151 If the message remains when the engine is while driving means that there is a fault in restarted, drive to a workshop - an authorised the STC/DSTC system. Volvo workshop is recommended. • Constant glow after deactivation reminds that the STC/DSTC system has been reduced.
Page 152: Park Assist
Rear parking assistance is deactivated then this is automatically lowered. automatically when towing a trailer if a Volvo The tone becomes constant at a distance of genuine trailer cable is used. about 30 cm. If there are obstacles within this...
Page 153 Front parking assistance is active at speeds attention, contact a workshop - an authorised below 15 km/h. The system is deactivated at Volvo workshop is recommended. higher speeds. When the speed is below 10 km/h the system is reactivated. IMPORTANT...
Page 154: Blis* - Blind Spot Information System
06 Starting and driving BLIS* – Blind Spot Information System General BLIS is an information system that under cer- Blind spots tain conditions can help to draw the driver's attention to vehicles moving in the same direc- tion in the so-called "blind spot". The system is designed to work most effec- tively when driving in dense traffic on multi-lane highways.
Page 155 06 Starting and driving BLIS* – Blind Spot Information System Activating/deactivating WARNING WARNING BLIS does not work in sharp bends. The system does not react to bicycles or mopeds. BLIS does not work when the car is revers- ing. The BLIS cameras can be disrupted by intensive light or when driving in the dark A wide trailer coupled to the car can conceal when there are no light sources (e.g.
Page 156 Repair of the BLIS system components REQUIRED The camera resets must only be performed by a workshop - an itself when the envi- authorised Volvo workshop is recom- ronment has Here are several examples of situations where mended. returned to normal.
Page 157 06 Starting and driving BLIS* – Blind Spot Information System Own shadow on large, light, smooth surface, e.g. noise barrier or concrete road surface. Low sun in the camera. Option/accessory, for more information, see Introduction.
Page 158: Towing And Recovery
06 Starting and driving Towing and recovery Start assistance WARNING IMPORTANT Use a donor battery if the battery is discharged The steering lock remains in the position it Note that the car must always be towed with and the engine does not start. Do not tow the was in when the power was cut off.
Page 159 06 Starting and driving Towing and recovery • After use, unscrew the towing eye and Towing eye return it to its place. • Refit the cover on the bumper. IMPORTANT The towing eye is only designed for towing on roads, not for pulling the car unstuck or out of a ditch.
Page 160: Start Assistance
06 Starting and driving Start assistance Starting with a donor battery 3. If the donor battery is in another car, switch WARNING off the engine in the other car and ensure The battery can generate oxyhydrogen gas, that the cars do not touch one another. which is highly explosive.
Page 161: Driving With A Trailer
If the towing bracket is fitted by an authorised weather. If the temperature gauge for the sudden movement and braking. Volvo workshop, then the car is delivered with engine's cooling system goes into the red the necessary equipment for driving with a zone, stop and let the engine idle for a few trailer.
Page 162 If the car is driven with a major load in a hot climate, the engine cooling fan can be replaced with one of a greater capacity than the stand- ard model. Check with your nearest Volvo dealer regarding the options for your car.
Page 163: Towing Equipment
If the car is equipped with a detachable towbar, the towball mounting instructions must be fol- lowed carefully, see page 164. WARNING If the car is fitted with a Volvo detachable towbar: • Follow the assembly instructions for the towball section carefully.
Page 164 06 Starting and driving Towing equipment* Specifications Dimensions for mounting points (mm) Fixed or detachable towbar standard 1070 Side member Ball centre Option/accessory, for more information, see Introduction.
Page 165: Detachable Towbar
06 Starting and driving Detachable towbar* Fitting the towball 2. Ensure that the mechanism is in the 3. Check that the indicator window (3) shows unlocked position by turning the key clock- red. If the window does not show red, 1.
Page 166 06 Starting and driving Detachable towbar* 4. Insert the towball section until your hear a 5. Check that the indicator window shows 6. Turn the key anticlockwise to locked posi- click. green. tion. Remove the key from the lock. Option/accessory, for more information, see Introduction.
Page 167 06 Starting and driving Detachable towbar* Removing the towball 7. Check that the towball section is secure by 8. Safety cable. pulling it up, down and back. 1. Insert the key and turn it clockwise to the WARNING unlocked position. WARNING Be sure to attach the trailer's safety cable to the correct place.
Page 168 06 Starting and driving Detachable towbar* 2. Push in the locking wheel 3. Turn the locking wheel down fully, until it 4. Push on the protective cover. and turn it comes to a stop. Hold it in this position anticlockwise until you hear a click.
Page 169: Loading
For more detailed infor- for your car by Volvo. mation on weights, see page 261. • Secure all loads to the load retaining eye- Carefully follow the mounting instructions sup- lets with straps or web lashings.
Page 170: Adjusting Headlamp Pattern
On cars with Dual Xenon headlamps, Dual dazzling oncoming motorists. Xenon lamp replacement must be carried out at a workshop - an authorised Volvo The correct pattern will also better illuminate workshop is recommended. The headlamps the verge.
Page 171 General....................172 Tyre pressure..................176 Warning triangle* and spare wheel* ............. 179 Changing wheels................... 182 Emergency puncture repair*..............184 Option/accessory, for more information, see Introduction.
Page 172 W H E E L S A N D T Y R E S...
Page 173: 07 Wheels And Tyres
07 Wheels and tyres General Driving characteristics and tyres Speed ratings New tyres The tyres greatly affect the car's driving cha- The car is approved as a whole, which means Tyres are perishable. After a racteristics. The type of tyre, dimensions, tyre that dimensions and speed ratings must not few years they begin to pressure and speed rating are important for...
Page 174 5000 km Studded tyres Use Volvo genuine snow chains or equiva- and then at 10000 km intervals. Volvo recom- Studded winter tyres should be run in gently for lent chains designed specifically for the car...
Page 175 These differ markedly from Only use wheel rims that are tested and other nut types as they have a rotating conical approved by Volvo and which are included in washer. the Volvo genuine accessories range. There are two types of wheel nut, depending...
Page 176 (to decrease the risk of skidding). Volvo recommends that you contact an author- ised Volvo workshop for checking if you are uncertain about tread depth. The arrow shows the tyre's direction of rotation.
Page 177: Tyre Pressure
07 Wheels and tyres Tyre pressure Recommended tyre pressure Stated on the label: pressure that is too low can also result in the tyres overheating and disintegrating. • Tyre pressure for the car's recommended tyre size For information on the correct tyre pressure, refer to the tyre pressure table.
Page 178 07 Wheels and tyres Tyre pressure Tyre pressure table Variant Tyre size Speed Load, 1 - 3 persons Max. load (km/h) Rear Front Rear (kPa) ECO pres- Front (kPa) (kPa) (kPa) sure 195/65 R15 0-160 205/55 R16 160+ 1.8F 205/50 R17 0-160 215/45 R18 160+...
Page 179 07 Wheels and tyres Tyre pressure Variant Tyre size Speed Load, 1 - 3 persons Max. load (km/h) Rear Front Rear (kPa) ECO pres- Front (kPa) (kPa) (kPa) sure 205/55 R16 0-160 205/50 R17 160+ 215/45 R18 Spare T125/85 R16 0-80 wheel In certain countries there is the "bar"...
Page 180: Warning Triangle* And Spare Wheel
07 Wheels and tyres Warning triangle* and spare wheel* Warning triangle The warning triangle is fitted on the inside of the boot lid with two clips. Follow the regulations in force for the use of a warning triangle*. Place the warning triangle in a suitable place with regard to the traffic.
Page 181 NOTE 2. Fold in the handle (6) and place the wheel ture repair kit, the jack must be fully Volvo recommends only using the jack* that wrench (2) on the jack. cranked together and returned into the belongs to the car model in question.
Page 182 07 Wheels and tyres Warning triangle* and spare wheel* IMPORTANT Tools and jack* must be stored in the intended location in the car's cargo area when not in use. First aid* A case with first aid equipment is located in the cargo area.
Page 183: Changing Wheels
Prize off the wheel cover with the Volvo recommends only using the jack* that ground. Check that the jack is seated cor- end of the wheel wrench, or pull it off by belongs to the car model in question.
Page 184 07 Wheels and tyres Changing wheels 7. Lift the car so that the wheel is free. Remove the wheel nuts and lift off the wheel. Fitting the wheel 1. Clean the contract surfaces on the wheel and hub. 2. Put on the wheel. Tighten the wheel nuts. 3.
Page 185: Emergency Puncture Repair
The emergency puncture repair kit is used to after the emergency tyre repair kit has been seal a puncture as well as to check and adjust used. Volvo recommends that you visit an the tyre pressure. It consists of a compressor authorised Volvo workshop for inspection of and a bottle with sealing fluid.
Page 186 07 Wheels and tyres Emergency puncture repair* Sealing punctured tyres 3. Check that the switch is in position 0 and WARNING locate the cable and the air hose. Never stand next to the tyre when the com- pressor is operating. If cracks or uneven- NOTE ness arise then the compressor must be switched off immediately.
Page 187 Contact a tyre centre. 7. Volvo recommends that you drive to the 4. If the tyre pressure is higher than 1.3 bar, nearest authorised Volvo workshop for the...
Page 188 07 Wheels and tyres Emergency puncture repair* Changing the sealing fluid canister WARNING Replace the bottle before the expiration date Do not leave children in the car without has passed. Treat the old bottle as environ- supervision when the engine is running. mentally hazardous waste.
Page 189 Cleaning....................190 Touching up paintwork................. 193 Rustproofing..................194...
Page 190 C A R C A R E...
Page 191: 08 Car Care
08 Car care Cleaning Washing the car Chromed wheels NOTE Wash the car as soon as it becomes dirty. Use Outside lighting such as headlamps, fog IMPORTANT car shampoo. Dirt and road salt can lead to lamps and rear lamps may temporarily have corrosion.
Page 192 NOTE begin polishing or waxing. Clean off asphalt Exterior plastic, rubber and trim and tar stains using Volvo tar remover or white Treatment with a special finishing agent components spirit. More stubborn stains can be removed available from Volvo dealers is recom-...
Page 193 2. Work the dirt away with gentle circular hensive product for the cleaning and treatment Volvo dealer. Make sure the seatbelt is dry of leather upholstery which, when used in movements. before allowing it to retract.
Page 194: Touching Up Paintwork
08 Car care Touching up paintwork Paintwork Stone chips and scratches If the stone chip has penetrated to the bare metal Paint is an important part of the car's rust- 1. Apply a piece of masking tape over the proofing and should therefore be checked reg- damaged surface.
Page 195: Rustproofing
The car's rustproofing does not normally require treatment for approximately 12 years. After this period, it should be treated at three- year intervals. If the car needs further treat- ment, Volvo recommends that you engage an authorised Volvo workshop for assistance.
Page 196 08 Car care...
Page 197 Volvo service..................198 Self-maintenance.................. 199 Bonnet and engine compartment............200 Oils and fluids..................202 Wiper blades..................207 Battery....................208 Replacing bulbs..................210 Fuses..................... 216...
Page 198 M A I N T E N A N C E A N D S E R V I C E...
Page 199: 09 Maintenance And Service
It was checked again in accord- ance with Volvo Car Corporation regulations before it was handed over to you. To keep your Volvo as safe and reliable as pos- sible, follow the Volvo service programme specified in the Service and Warranty Booklet.
Page 200: Self-Maintenance
NOTE filled. Use washer antifreeze at tempera- High output from the ignition system. The Volvo recommends only using the jack that tures around freezing. voltage in the ignition system is highly dan- belongs to the car model in question. If a gerous.
Page 201: Bonnet And Engine Compartment
09 Maintenance and service Bonnet and engine compartment Opening the bonnet The illustration shows a left-hand drive car. 1. Pull the handle on the far left under the Engine oil dipstick WARNING instrument panel. (In right-hand drive cars Radiator Check that the bonnet locks properly when the handle is on the far right.) You will hear closed.
Page 202 09 Maintenance and service Bonnet and engine compartment Battery Relay and fuse box Air filter The location varies depending on engine alternative...
Page 203: Oils And Fluids
Using oil of a higher than specified grade is permitted. If the car is driven in adverse con- ditions, Volvo recommends using an oil of a higher grade than that specified on the decal, see page 267.
Page 204: Maintenance And Service
3. Check the oil level using the dipstick. The Volvo uses different systems for warning of low level must be between the MIN and MAX oil level or low oil pressure. Certain variants marks.
Page 205 09 Maintenance and service Oils and fluids Washer fluid, topping up WARNING NOTE Do not spill oil onto the hot exhaust manifold The oil level is only updated by the system due to the risk of fire. during driving. The system cannot detect changes when oil is filled or drained.
Page 206 TIP! Clean the wiper blades when topping up Always use coolant with anti-corrosion WARNING washer fluid. agent as recommended by Volvo. Coolant can be very hot. If the coolant • Ensure that the coolant mixture is 50% requires topping up when the engine is at water and 50% coolant.
Page 207 09 Maintenance and service Oils and fluids Checking and topping up the brake and WARNING clutch fluid If the brake fluid is under the MIN level in the brake fluid reservoir, do not drive further before topping up the brake fluid. The reason for the loss of brake fluid must be investigated.
Page 208: Wiper Blades
09 Maintenance and service Wiper blades Wiper blades 1. Turn up the wiper arm. Replacing the wiper blades, windscreen 2. Press the button located on the wiper blade mounting and pull straight out (1), parallel with the wiper arm. 3. Slide in (2) the new wiper blade until a "click"...
Page 209: Battery
09 Maintenance and service Battery Battery care Symbols on the battery NOTE The service life and function of the battery is Use protective goggles. The life of the battery is shortened if it influenced by factors such as the number of becomes discharged repeatedly.
Page 210 09 Maintenance and service Battery 8. Remove the battery. Avoid sparks and naked flames. Fitting the battery 1. Fit the battery into position. 2. Fit the clamp securing the battery. 3. Reinstall the front wall of the battery box. Risk of explosion. 4.
Page 211: Replacing Bulbs
All front bulbs (except for fog lamps) are Xenon lamp replacement must be carried changed by first removing the lamp housing out at a workshop - an authorised Volvo from the engine compartment. workshop is recommended. The headlamps must be handled with extreme caution due Removing the lamp housing to the Dual Xenon lamp's high-voltage unit.
Page 212 09 Maintenance and service Replacing bulbs on or the remote control key inserted into the Main beam, Halogen ignition switch. Dipped beam Fitting a new bulb The illustration shows a halogen bulb. 1. Fit the new bulb. It can only fit in one posi- 1.
Page 213 09 Maintenance and service Replacing bulbs 5. Refit the bulb holder. It can only be refitted 4. Press the bulb holder back on. A "click" is 2. Twist the bulb holder anticlockwise and in one position. heard when the bulb holder is fitted cor- remove it.
Page 214 NOTE If the error message remains after a faulty bulb has been replaced then we recom- mend that you visit an authorised Volvo workshop. 1. Switch off all lights and turn the remote control key to position 0.
Page 215 09 Maintenance and service Replacing bulbs Location of the bulbs in the rear light Reversing lamp Courtesy lighting cluster Number plate lighting There is courtesy lighting under the instrument Bulb holder. panel on the driver and passenger sides. 1. Insert a screwdriver and gently turn so that IMPORTANT 1.
Page 216 09 Maintenance and service Replacing bulbs Cargo area Vanity mirror lighting* Fitting the mirror glass 1. First, press the three lugs at top edge of mirror glass back into position. 2. Then press the three lower lugs back into position. 1.
Page 217: Fuses
Each fuse box has space for several spare fuses. If the same fuse fails repeatedly then there is a fault in the component. In which case, Volvo recommends that you visit an authorised Volvo workshop for this to be checked.
Page 218 Volvo workshop. • 1–6 are of the "Midi Fuse" type and must only be replaced by a workshop. Volvo rec- ommends an authorised Volvo workshop. On the inside of the cover are tweezers to assist removing and fitting fuses.
Page 219 09 Maintenance and service Fuses Radiator fan 50 A ABS pump 30 A Supply to infotainment sys- 30 A Power steering (excl. 1.6 litre ABS valves 20 A engine) 80 A Windscreen wipers 30 A Engine functions 30 A Supply to passenger com- Supply to passenger com- Ventilation fan 40 A...
Page 220 09 Maintenance and service Fuses Engine control module ECM Lambda-sond and vacuum (5-cyl. petrol), Transmission pump (5-cyl. petrol), engine (TCM) (5-cyl auto) 10 A control module (5-cyl. diesel), diesel filter heater (4-cyl. die- Transmission (TCM) (4-cyl. sel) 20 A auto.) 15 A Ignition coils (petrol), injectors Heated fuel filter, PTC ele-...
Page 221: Relay/Fuse Box In Passenger Compartment
09 Maintenance and service Fuses Relay/Fuse box in the passenger compartment The fuse box has 50 fuse positions. The fuses completely. The fuse box can be fully are located under the glovebox. The box also unhooked. provides space for several spare fuses. Tools 4.
Page 222 09 Maintenance and service Fuses Phone, audio system, Reserve – Remote control module, RTI*, Bluetooth* 15 A siren control module 10 A Additional heater for the SRS system, engine con- passenger compartment, Data link connector trol module ECM (5-cyl.) 10 A AWD, fuel filter relay, (DLC), brake light switch 15 A...
Page 223 09 Maintenance and service Fuses Supply to rear right door 20 A Electrical socket in cargo area, accessory elec- Reserve – tronic module (AEM) 15 A Infotainment system Reserve – Infotainment control Reversing lamp module (ICM), climate control 10 A Reserve –...
Page 224 09 Maintenance and service...
Page 225 General....................226 Audio functions..................228 Radio functions..................232 CD functions..................237 Menu structure – audio system............. 240 Phone functions*................... 241 Menu structure – phone*............... 248 Bluetooth handsfree*................251 Option/accessory, for more information, see Introduction.
Page 226 I N F O T A I N M E N T S Y S T E M...
Page 227: General
10 Infotainment system General • Infotainment system trol panel or the steering wheel keypad*, see EXIT (6) leads back one step in the menu structure. A long press on EXIT will exit the page 65. The display (2) shows messages and menu system.
Page 228: Infotainment System
10 Infotainment system General Dolby Surround Pro Logic II System is man- ufactured under license from Dolby Laboratories Licensing Corporation.
Page 229: Audio Functions
10 Infotainment system Audio functions Audio controls ume adjusts automatically depending on vehi- The AUX and USB inputs enable the connec- cle speed, see page 231. tion of an external audio source, e.g. an iPod or MP3 player. Audio source selection If you choose to connect an iPod , MP3 player Repeatedly pressing AM/FM switches or a USB memory stick to the USB connection...
Page 230 10 Infotainment system Audio functions 2. or use the navigation control's (4) right or sory manual for USB and iPod Music Inter- NOTE left-hand button to scroll to the required face. The system supports removable media track. which is compatible with USB 2.0 and the It is also possible to change track using the Sometimes the AUX external audio source can FAT32 file system, and can handle a maxi-...
Page 231 10 Infotainment system Audio functions • SUBWOOFER * - Bass speaker level. Sub- Surround Equalizer front/rear woofer must be activated before adjust- Surround settings govern the spatial The equalizer can be used to adjust different ment is possible, see under the heading perception of the sound.
Page 232 10 Infotainment system Audio functions are only intended for the user to be able to Automatic volume control adapt the sound reproduction according to The auto volume control function allows the personal taste. audio volume to increase as the speed of the car increases.
Page 233: Radio Functions
10 Infotainment system Radio functions Radio controls Tuning 2. Hold a station preset button depressed until the message Station stored appears Automatic tuning on the display. 1. Select wavelength using AM/FM (1). Automatic storage of stations 2. Give a brief press on AUTO (7) seeks out the ten strongest radio sta- tions and stores them automatically in a sepa- Manual tuning...
Page 234: Radio Functions
10 Infotainment system Radio functions > The radio remains in Auto mode until it Programme functions Storing a station is exited by a brief press on AUTO (7), A selected station can be stored as a preset In FM mode, the radio can search for stations EXIT (6) or AM/FM (1).
Page 235 10 Infotainment system Radio functions ALARM! 3. Scroll to Advanced radio settings… message appears on the display Activating/deactivating TP search when an alarm message is transmitted. press ENTER. TP search is useful during long journeys while an audio source other than the radio is being 4.
Page 236 10 Infotainment system Radio functions 5. Select the desired programme types or 3. Scroll to Show PTY Regional radio programmes – REG and press ENTER. Clear all PTY… This function causes the radio to con- tinue with a regional transmitter even Search PTY Radio text if its signal strength is low.
Page 237 10 Infotainment system Radio functions Activating/deactivating EON 1. Press MENU and then ENTER. 2. Scroll to Advanced radio settings… press ENTER. 3. Scroll to EON… and press ENTER. 4. Scroll to Local Distant and press ENTER. Resetting RDS functions Resets all radio settings to the original factory settings.
Page 238: Cd Functions
10 Infotainment system CD functions CD function controls automatically. Otherwise, load a disc and Pause change to CD mode by pressing MODE. If the volume is turned down completely, the CD player is stopped. The player is restarted Starting playback (CD changer*) when volume is increased.
Page 239 10 Infotainment system CD functions matically when all files in the current directory Different messages appear on the display 3. Scroll to Single disc All discs and press have been played back. depending on which random function has been ENTER. selected.
Page 240 10 Infotainment system CD functions IMPORTANT Only use standard discs (12 cm in diameter). Do not use CD discs with adhesive disc labels. The heat in the CD player may cause the label to come off, damaging the CD player.
Page 241: Menu Structure - Audio System
10 Infotainment system Menu structure – audio system Overview AUX menu FM menu 1. AUX volume 1. News 2. News 2. TP 3. TP 3. PTY 4. Audio settings* 4. Radio text 5. Advanced radio settings 6. Audio settings* AM menu 1.
Page 242: Phone Functions
10 Infotainment system Phone functions* Overview - Phone system components Option/accessory, for more information, see Introduction.
Page 243 Contact your network operator if you • Switch off the system near blasting work. need to change your SIM card. • Volvo recommends that an authorised Volvo workshop carries out phone system servicing. Option/accessory, for more information, see Introduction.
Page 244 10 Infotainment system Phone functions* Phone controls Steering wheel keypad Double SIM cards Many network operators offer two SIM cards for the same phone number. The extra SIM card can be used in the car. Inserting the SIM card 1. Switch off the phone and open the glove- box.
Page 245 10 Infotainment system Phone functions* On/Off Activating from standby mode Call waiting Press PHONE. A two-tone signal during a phone call indicates A handset appears in the display when the Answer? that there is another incoming call. phone system is active or in standby mode appears on the display.
Page 246 6 ñ ö ò Ø see menu 5.4.3, on page 250. This function tact information then this is shown in the dis- only applies to the Volvo integrated phone sys- play. Contact information can be stored on the p q r s 7 ß...
Page 247 10 Infotainment system Phone functions* 6. Scroll to Delete Searching for contacts in the phone book and press ENTER. Calling using speed dial Use the down arrow of the navigation button Briefly press the required keypad button, Erase all contacts instead of MENU for direct access to the followed by ENTER.
Page 248 10 Infotainment system Phone functions* SMS - Short Message Service IMEI number NOTE To block the phone, you must provide your Hold in the required letter/button in the key- Reading SMS network operator with the phone's IMEI num- pad for about 2 seconds to reach the cor- 1.
Page 249: Menu Structure - Phone
10 Infotainment system Menu structure – phone* Phone menu 2.4. Speed dial 4.6.3. Not answered Call register 2.4.1. Active 4.6.4. Not reachable 1.1. Missed calls 2.4.2. Select numbers 4.6.5. Fax calls 1.2. Received calls 2.5. Erase SIM 4.6.6. Data calls 1.3.
Page 250 10 Infotainment system Menu structure – phone* Factory settings 1.5.3. Total time 3. Messages 1.5.4. Reset timers 3.1. Read Received text messages. Select whether to Description of menu options erase, forward, change or save the entire mes- 2. Phone book sage or parts of it.
Page 251 10 Infotainment system Menu structure – phone* 5.1.2. Manual select 4.3. Auto answer 5.5. IDIS Automatically answers incoming calls. If the IDIS function is deactivated, incoming 5.2. SIM security calls are not delayed, regardless of the driving 4.4. Auto redial Select if the PIN code should be on, off or if the situation.
Page 252: Bluetooth Handsfree
Alternative 1 - via the car's menu system compatible with the handsfree function. Volvo recommends that you seek assis- 1. Make the mobile phone detectable/visible tance from an authorised Volvo dealer or via Bluetooth , see the mobile phone's www.volvocars.com for information on manual or www.volvocars.com.
Page 253 10 Infotainment system Bluetooth handsfree* Alternative 2 - via the phone's menu system To call NOTE 1. Make sure that the text PHONE is shown 1. Activate the handsfree function with Some mobile phones require that the at the top of the display and that the PHONE.
Page 254 10 Infotainment system Bluetooth handsfree* More on registering and connecting Phone settings Sounds and volume NOTE Mute radio. A maximum of five mobile phones can be reg- With certain mobile phones the connection istered. Registration is performed once per is terminated when the privacy function is Ring volume phone.
Page 255 10 Infotainment system Bluetooth handsfree* Phonebook the steering wheel keypad. The search can also Inputting text be performed from the phone book's Search Input text using the keypad in the centre con- All use of the phone book presupposes that the menu under Phonebook Search:...
Page 256 10 Infotainment system Bluetooth handsfree* Phone settings 6.1. Call options 6.1.1. Auto reply 6.1.2. Voice mail number 6.2. Sounds and volume 6.3. Synchronise phone book Option/accessory, for more information, see Introduction.
Page 257 Type designation................... 258 Dimensions and weights............... 261 Engine specifications................264 Engine oil....................266 Fluids and lubricants................270 Fuel....................... 273 Catalytic converter................278 Electrical system................... 279 Type approval..................281...
Page 258 S P E C I F I C A T I O N S...
Page 259: 11 Specifications
11 Specifications Type designation...
Page 260 11 Specifications Type designation Knowing the car's type designation, vehicle identification and engine numbers can facili- tate all contact with a Volvo dealer regarding the car and when ordering spare parts and accessories. Type designation, vehicle identification number, maximum permissible weights, codes for colour and upholstery and type approval number.
Page 261 11 Specifications Type designation NOTE The labels shown in the owner's manual are not provided as exact reproductions of those in the car. The purpose is to show their approximate appearance and location in the car. The information that applies to your car in particular is available on the label in question in your car.
Page 262: Dimensions And Weights
11 Specifications Dimensions and weights Dimensions Weights Dimensions Dimensions Kerb weight includes the driver, the fuel tank Wheelbase 2640 Rear track 1531 90% full and all fluids. The weight of passengers and accessories, Length 4476 Load width, floor 1034 and towball load (when a trailer is hitched, see Load length, floor, folded Width 1770...
Page 263 11 Specifications Dimensions and weights Max. total weight NOTE WARNING Max. train weight (car+trailer) The documented kerb weight applies to The car's driving characteristics change cars in the standard version - i.e. a car with- depending on how heavily it is loaded and Max.
Page 264 11 Specifications Dimensions and weights Engine Maximum weight, braked trailer (kg) Maximum towball load (kg) 1300 1.8F 1300 1350 others 1500 Maximum weight, unbraked trailer (kg) Maximum towball load (kg)
Page 265: Engine Specifications
11 Specifications Engine specifications Overview Engine Output Output Torque No. of Bore Stroke Swept Compres- (kW/ (hp/rpm) (Nm/ cylinders (mm) (mm) volume sion ratio rpm) rpm) (litres) B4164S3 74/6000 100/6000 150/4000 81.4 1,596 11.0:1 B4184S11 92/6000 125/6000 165/4000 83.1 1,798 10.8:1 1.8F B4184S8...
Page 266 11 Specifications Engine specifications Engine type designation, component and serial number can be read on the engine, see page 258.
Page 267: Engine Oil
Choose a fully synthetic engine oil for adverse ting characteristics, fuel consumption and environmental impact. driving conditions. It provides extra protection for the engine. Volvo Car Corporation disclaims all war- ranty liability if engine oil of the prescribed grade and viscosity is not used.
Page 268 11 Specifications Engine oil Oil decal Engine oil grade Engine variant Volume between Volume MIN-MAX (litres) (litres) B5244S5 B5244S4 2.4i B5254T7 1.6D D4164T Oil decal location in engine compartment, see page 202. Oil grade: ACEA A3/B3/B4 Viscosity: SAE 0W–30 When driving under adverse conditions, use ACEA A5/B5 SAE 0W-30.
Page 269 11 Specifications Engine oil Engine oil grade Engine variant Volume between Volume MIN-MAX (litres) (litres) B4164S3 0.75 B4184S11 0.75 1.8F B4184S8 0.75 B4204S3 0.75 2.0D D4204T Oil decal location in engine compartment, see page 202. Oil grade: WSS-M2C913-B Viscosity: SAE 5W–30 When driving under adverse conditions, use ACEA A5/B5 SAE 0W-30.
Page 270 11 Specifications Engine oil Engine oil grade Engine variant Volume between Volume MIN-MAX (litres) (litres) B5244S5 2.4i B5244S4 B5254T7 D5244T8 D5244T9 (Only Belgium) Oil decal location in engine compartment, see D5244T13 page 202. Oil grade: ACEA A5/B5 Viscosity: SAE 0W–30 Including filter change Europe only, for other markets see oil ACEA A3/B3/B4...
Page 271: Fluids And Lubricants
Do not mix with any other transmission fluid. If the transmission is topped up with a dif- ferent fluid, contact a workshop nearby for servicing. Volvo recommends that you con- tact an authorised Volvo workshop. Gearbox oil Engine...
Page 272 11 Specifications Fluids and lubricants Engine Gearbox Volume (litres) Prescribed transmission fluid 1.6D diesel Manual 5-speed, MTX75 BOT 350M3 2.0D diesel Manual 6-speed, MMT6 BOT 350M3 2.0D diesel Automatic, MPS6 BOT 341 D5 diesel Manual 6-speed, M66 BOT 350M3 D5 diesel Automatic, AW55-51 JWS 3309 Fluids...
Page 273 Volvo, mixed with water for temper- 5-cyl. Petrol/Diesel atures below freezing. Water quality must fulfil the standard STD 1285.1. Refrigerant quantity varies depending on engine variant. Volvo recommends that you contact an authorised Volvo workshop for the correct information.
Page 274: Fuel
11 Specifications Fuel emissions, fuel consumption and tank volume Engine Gearbox Emissions of car- Consumption Tank volume (litres) bon dioxide CO (litre/100 km) (g/km) B4164S3 Manual 5 speed (IB5) approx. 53 B4184S11 Manual 5 speed (MTX75) approx. 53 B4184S8 Manual 5 speed (MTX75) approx.
Page 275 11 Specifications Fuel Engine Gearbox Emissions of car- Consumption Tank volume (litres) bon dioxide CO (litre/100 km) (g/km) 2.0D D4204T Automatic gearbox (MPS6) approx. 52 D5244T13 Manual 6 speed (M66) approx. 60 D5244T8 Automatic gearbox (AW55-51) approx. 60 D5244T9 Automatic gearbox (AW55-51) approx.
Page 276 Mixing different types of fuel or the use of Always refuel with unleaded petrol so as Ethanol is sensitive to sparks, and explosive fuel not recommended invalidates Volvo's gases could form in the reserve fuel can if it not to damage the catalytic converter.
Page 277 Regeneration in cold weather and generate increased wear and engine or if you suspect that the car has been filled damage that is not covered by the Volvo If the car is frequently driven short distances in with contaminated fuel.
Page 278 11 Specifications Fuel When regeneration is complete the message is cleared automatically. IMPORTANT If the filter fills up it may be incapable of functioning. Then it can be difficult to start the engine and there is a risk that the filter will have to be replaced.
Page 279: Catalytic Converter
11 Specifications Catalytic converter General The purpose of the catalytic converter is to purify exhaust gases. It is located in the flow of exhaust gases close to the engine so that it quickly reaches operating temperature. The catalytic converter consists of a monolith (ceramic or metal) with channels.
Page 280: Electrical System
11 Specifications Electrical system General If the battery is changed, replace it with a bat- tery of the same cold start capacity and reserve 12 V system with a voltage-regulated alterna- capacity as the original (see the decal on the tor.
Page 281 11 Specifications Electrical system Lighting Output (W) Type Front direction indicators (specifically for Dual Xenon and halogen), rear direction indi- PY21W cators Front direction indicators (specifically for ABL, Active Bending Lights) PY24W Rear position/parking and side marker lamps (upper socket) P21/5W Rear position/parking lamps (lower socket) Courtesy lighting, cargo area lighting, number plate lighting...
Page 282: Type Approval
11 Specifications Type approval Remote control key system Certification of the Keyless Drive system Country and Siemens VDO Automotive A.G. hereby certifies region that this equipment type 5WK4 8952, 5WK48956, 5WK48812 conforms to the A, B, CY, CZ, D, DK, essential characteristic requirements and other E, EST, F, FIN, GB, Delphi hereby...
Page 283: Alphabetical Index
12 Alphabetical Index Air quality system, ECC......90 Automatic car washes......190 Air vents............. 85 Automatic gearbox manual gear positions (Geartronic)..142 Alarm............127 electronic climate control..... 91 towing and recovery......157 alarm indicator........127 manual climate control....86, 87 trailer...........
Page 284 12 Alphabetical Index overload..........133 emergency brake lights......57 Car wash..........190 specifications........279 handbrake..........67 Catalytic converter........278 start assistance........159 Brake system........... 147 recovery..........157 symbols on the battery....... 208 Bulb holder CD discs Bioethanol E85........273 removal..........213 storage compartment......
Page 285 12 Alphabetical Index seatbelts..........192 Cruise control..........63 slippery driving conditions....132 upholstery........... 192 with trailer........... 160 Climate control Driving in water........132 general..........84 Driving with a trailer personal preferences......76 towball load........261 Deadlocks..........124 Climate control settings towing capacity........
Page 286 12 Alphabetical Index Emergency equipment fuel consumption, display..... 59 warning triangle........179 fuel economy........176 level indicator........49 Emergency puncture repair..... 184 A/C............86 parking heater........93 Emission control ECC............89 refuelling..........134 fault indicator........49 Fast-wind..........238 Fuses............216 Engine block heater.........
Page 287 12 Alphabetical Index Infotainment system Key blade......... 115, 120 menus..........226 active locks......... 118 Handbrake..........67 Instrument lighting........56 Keyless drive......119, 139, 281 Hazard warning flashers......66 starting the car........139 Instrument overview Headlamps..........55 left-hand drive........42 Keyless entry..........77 right-hand drive........
Page 288 12 Alphabetical Index home safe lighting......58, 72 Locking............ 120 Memory function in seats......101 in passenger compartment....102 unlocking..........123 Menus lighting panel, passenger compart- Locking/unlocking........123 audio system........226 ment............55 inside..........123 Menu structure.......... 76 main/dipped beam......55, 58 outside..........
Page 289 12 Alphabetical Index parking on a hill........93 one-key dial........246 symbols and display messages.... 94 phone book......... 254 News............234 time setting........... 95 phone book, shortcut......254 receiving a call........252 Particle filter..........276 register phone........251 Passenger compartment filter....84 standby, standby mode......
Page 290 12 Alphabetical Index Reduced guard Rustproofing..........194 settings..........77 Radio Refrigerant..........84 EON............ 235 Refuelling frequency update........ 235 fuel cap..........134 news........... 234 Safety fuel filler flap, electrical opening..134 programme types....... 233 safety systems, table......30 refuelling..........134 radio settings........232 Scan Refusing a call.........
Page 291 12 Alphabetical Index SMS............247 Steering wheel read............. 247 cruise control........63 write............ 247 keypad........63, 65, 243 Tailgate steering wheel adjustment....66 locking/unlocking........ 114 Soot filter........... 52, 276 Stone chips and scratches...... 193 Tank volume..........273 Soot filter full..........276 Storage compartment......
Page 292 12 Alphabetical Index removing..........166 Washers specifications........163 headlamps..........61 Unlocking......... 120, 123 washer fluid, filling......204 Towing eye..........158 settings..........77 windscreen........... 61 TP – Traffic information......234 USB, connection........228 Water and dirt-repellent coating....73 Traffic information........234 Water-repellent surface, cleaning....
Page 293 12 Alphabetical Index...
Page 294 Notes...
Page 295 Notes...
Page 296 Notes...
Page 297 Notes...

Volvo S40 Owner's Manual

Introduction

1 Safety

2 Instruments and Controls

3 Climate Control

4 Interior

5 Locks and Alarm

6 Starting and Driving

7 Wheels and Tyres

8 Car Care

9 Maintenance and Service

11 Specifications

Quick Links

Owners Manual

Related Manuals for Volvo S40

Summary of Contents for Volvo S40

Table of Contents
