Page 10: Introduction
Important information Reading the Owner's Manual In the event of uncertainty over what is stand- lighted in the owner's manual by means of the ard or an option/accessory, contact a Volvo text being slightly larger and printed in grey. Introduction dealer.
Page 11 Introduction Important information warning is ignored, may result in serious per- Information Procedure lists sonal injury or fatality. Procedures where action must be taken in a certain sequence are numbered in the owner's Risk of property damage manual. When there is a series of illustrations for step-by-step instructions each step is numbered in the same way as the corres- ponding illustration.
Page 12 If the car has Volvo On Call and there is a or others who may assert a legal right to have so that Volvo can fulfil legal requirements and change of owner, it is very important that these access to it.
Page 13 Introduction Important information Information on the Internet At www.volvocars.com there is further infor- mation concerning your car.
Page 14: Volvo And The Environment
Introduction Volvo and the environment Volvo Cars' environmental philosophy Environmental care is one of Volvo Car Corpo- Fuel consumption many cases the exhaust emissions are well ration's core values which influence all opera- below the applicable standards. Volvo cars have competitive fuel consumption tions.
Page 15 Interior • If the car is equipped with an engine block The interior of a Volvo is designed to be plea- The owner's manual and the heater*, use it before starting from cold - it sant and comfortable, even for people with...
Page 16 Seatbelts....................18 Airbag system..................21 Airbags....................22 Activating/deactivating the airbag*............24 Side airbags (SIPS bags)................ 26 Inflatable Curtain (IC)................28 WHIPS..................... 29 When the systems deploy............... 31 Crash mode.................... 32 Child safety..................... 33 Option/accessory, for more information, see Introduction.
Page 17 S A F E T Y...
Page 18: 01 Safety
WARNING The seatbelt locks and cannot be with- drawn: Never modify or repair the seatbelt yourself. Volvo recommends that you contact an • if it is pulled out too quickly authorised Volvo workshop. If the seatbelt •...
Page 19 01 Safety Seatbelts Seatbelts and pregnancy such that they can easily maintain control of the Child seats are not covered by the seatbelt vehicle as they drive (which means that they reminder system. must be able to easily operate the foot pedals Rear seat and steering wheel).
Page 20 01 Safety Seatbelts Seatbelt tensioner The front seatbelts and the two for the outer rear seats are equipped with seatbelt tension- ers. A mechanism in the seatbelt tensioner tightens the seatbelt in the event of a suffi- ciently violent collision. The seatbelt then pro- vides more effective restraint for occupants.
Page 21: Airbag System
The symbol indi- cates a fault in the seatbelt tensioner sys- The warning symbol in the combined instru- tem, SIPS, SRS or the IC system. Volvo rec- ment panel illuminates when the remote con- ommends that you contact an authorised trol key is turned to key position I, II or III.
Page 22: Airbags
01 Safety Airbags Airbag system WARNING NOTE Volvo recommends that you contact an The sensors react differently depending on authorised Volvo workshop for repair. the course of the collision and whether or Defective work in the airbag system could not the seatbelts on the driver's side and cause malfunction and result in serious per- passenger side are used.
Page 23 01 Safety Airbags Airbag on the driver's side WARNING The car has an airbag to supplement the pro- Never place a child in a child seat or on a tection afforded by the seatbelt on the driver's booster cushion in the front seat if the airbag side.
Page 24: Activating/Deactivating The Airbag
Check that the switch is in the required posi- Switch location recommends that you visit an authorised tion. Volvo recommends that the key blade is Volvo workshop as soon as possible. The airbag is activated. With the switch in used to change position.
Page 25 01 Safety Activating/deactivating the airbag* A text message and a symbol in the roof panel WARNING NOTE indicate that the airbag for the front passenger Activated airbag (passenger seat): When the remote control key is turned to seat is deactivated (see preceding illustration). key position II or III the warning symbol for Never place a child in a child seat or on a the airbag is displayed on the combined...
Page 26: Side Airbags (Sips Bags)
• Volvo recommends the use only of car seat covers approved by Volvo. Other seat covers may impede the operation of the side airbags.
Page 27 01 Safety Side airbags (SIPS bags) Front passenger seat, left-hand drive. The SIPS bag system consists of side airbags and sensors. A sufficiently violent collision trips the sensors and the side airbags are inflated. The airbag inflates between the occupant and the door panel and thereby cushions the initial impact.
Page 28: Inflatable Curtain (Ic)
This could compromise the intended pro- on the inside of the car during a collision. WARNING tection. Volvo recommends that you only ever use Volvo genuine parts that are The inflatable curtain is a supplement to the approved for placement in these areas. seatbelts.
Page 29: Whips
Never modify or repair the seat or WHIPS the seat with as little space as possible system yourself. Volvo recommends that The WHIPS system is a supplement to the between the head and the head restraint. seatbelts. Always use a seatbelt. you contact an authorised Volvo workshop.
Page 30 WARNING If a seat has been subjected to extreme forces, such as due to a rear-end collision, the WHIPS system must be checked. Volvo recommends that it is checked by an authorised Volvo workshop. Part of the WHIPS system's protective capacity may have been lost even if the seats appear to be undamaged.
Page 31: When The Systems Deploy
Do not • Always contact a doctor. attempt to start the car since the airbags may deploy. Recovering the car. Volvo rec- ommends that you have it conveyed to an authorised Volvo workshop.
Page 32: Crash Mode
If the car is in crash mode it must not be towed. It must be transported from its loca- Moving the car tion. Volvo recommends that you have it NORMAL MODE is shown after CRASH conveyed to an authorised Volvo workshop.
Page 33: Child Safety
In the event of questions when fitting child beams under the seat. Sharp edges can dam- Volvo recommends that children travel in rear- safety products, contact the manufacturer age the straps. facing child seats until as late an age as pos- for clearer instructions.
Page 34 01 Safety Child safety Label Airbag WARNING WARNING Never place a child in a child seat or on a Booster cushions/child seats with steel booster cushion in the front seat if the airbag braces or some other design that could rest on the seatbelt buckle's opening button is activated must not be used, as they could cause the...
Page 35 Weight Outer rear seat Centre rear seat Front seat Group 0 Volvo infant seat (Volvo Infant Seat) - Volvo infant seat (Volvo Infant Seat) - rear-facing child seat, secured with the rear-facing child seat, secured with the max. 10 kg ISOFIX fixture system.
Page 36 Front seat Group 1 Volvo rear-facing/turnable child seat Volvo rear-facing/turnable child seat (Volvo Convertible Child Seat) - rear-fac- (Volvo Convertible Child Seat) - rear-fac- 9 – 18 kg ing child seat, secured with the car's ing child seat, secured with the car's seatbelt and straps.
Page 37 Front seat Group 2 Volvo rear-facing/turnable child seat Volvo rear-facing/turnable child seat (Volvo Convertible Child Seat) - rear-fac- (Volvo Convertible Child Seat) - rear-fac- 15-25 kg ing child seat, secured with the car's ing child seat, secured with the car's...
Page 38 Weight Outer rear seat Centre rear seat Front seat Group 2/3 Volvo booster seat with backrest (Volvo Volvo booster seat with backrest (Volvo Volvo booster seat with backrest (Volvo Booster Seat with backrest). Booster Seat with backrest). Booster Seat with backrest).
Page 39 Grasp the cushion with both hands and push it backwards. Push until it locks in place. Volvo’s integrated booster cushion for the outer rear seats is specially designed to pro- For information on activating/deactivating the airbag (SRS), see page 24.
Page 40 Volvo recommends can be blocked from opening from the inside. that you contact an authorised Volvo work- For more information see page 135. shop. Do not make any modifications or additions to the booster cushion yourself.
Page 41 (see the following table). Volvo recommends that you contact an Transverse infant seat, left- authorised Volvo dealer for recommenda- Size Description hand tions about which ISOFIX child seats Volvo class recommends. Transverse infant seat, right- Full size, front-facing child hand seat Reduced size (alt.
Page 42 01 Safety Child safety Types of ISOFIX child seat Type of child seat Weight Size class Passenger seats for ISOFIX installation of child seats Front seat Outer rear seat Infant seat transverse max. 10 kg Infant seat, rear-facing max. 10 kg (IL) Infant seat, rear-facing max.
Page 43: Child Safety
IUF: Suitable for front-facing ISOFIX child seats that are universally approved in this weight class. In order to be able to fit the infant/child seat in the rear seat, the front passenger seat has been adjusted to a location in front of centre position. Volvo recommends rear-facing child seats for this group.
Page 44 Volvo recommends that small children should ment point. sit in rear-facing child seats to as late an age as possible.
Page 45 01 Safety...
Page 46 Overview, left-hand drive cars..............48 Overview, right-hand drive cars.............. 50 Driver's door control panel..............52 Combined instrument panel..............53 Indicator and warning symbols............... 54 Information display.................. 58 Electrical socket..................60 Lighting panel..................62 Left-hand stalk switch................65 Right-hand stalk switch................68 Cruise control*..................
Page 47 I N S T R U M E N T S A N D C O N T R O L S...
Page 48: 02 Instruments And Controls
02 Instruments and controls Overview, left-hand drive cars...
Page 49 02 Instruments and controls Overview, left-hand drive cars Steering wheel adjustment Reading lamp, right-hand side Bonnet release Seatbelt reminder and passenger seat air- bag indicator Control panel Interior rearview mirror Direction indicators, main beam, trip com- Display for climate control and infotain- puter ment system Lighting, fuel filler flap opener...
Page 50: Overview, Right-Hand Drive Cars
02 Instruments and controls Overview, right-hand drive cars...
Page 51 02 Instruments and controls Overview, right-hand drive cars Electrical socket, cigarette lighter Reading lamp, right-hand side Blind Spot Information System, BLIS No function Switch, optional equipment No function Parking brake Sunroof controls Control panel Ignition switch Glovebox Windscreen wipers and washers, head- lamp washers Door handle Cruise control...
Page 52: Driver's Door Control Panel
02 Instruments and controls Driver's door control panel Driver's door control panel Disengaging the rear power windows. Electric child safety lock* Power windows Door mirror, left-hand side Door mirrors, setting Door mirror, right-hand side Option/accessory, for more information, see Introduction.
Page 53: Combined Instrument Panel
02 Instruments and controls Combined instrument panel Speedometer. Tachometer – Indicates engine speed in Button for trip meter – Used to measure thousands of revolutions per minute (rpm). short distances. Short presses on the but- Direction indicators, left. ton switches between the two trip meters Indicator and warning symbols.
Page 54: Indicator And Warning Symbols
02 Instruments and controls Indicator and warning symbols Functionality check, symbols Symbols in the centre of the instrument When the symbol illuminates: panel All indicator and warning symbols illuminate 1. Stop in a safe manner. Do not drive the car when the remote control key is turned to posi- further.
Page 55 ABS fault 3. Drive to a workshop to have the ABS sys- tem checked if the symbol remains lit. Rear fog lamp Volvo recommends that you seek assis- Stability system DSTC tance from an authorised Volvo workshop. No function Rear fog lamp...
Page 56 If the faulty. symbol illuminates and the oil level is normal Volvo recommends that you contact an author- Parking brake applied ised Volvo workshop. The symbol illuminates when the parking brake is applied.
Page 57 02 Instruments and controls Indicator and warning symbols ± Stop the car in a safe place and check the have the brake system checked. Volvo rec- Low speed level in the brake fluid reservoir, see ommends that you seek assistance from If the car moves at a speed less page 225.
Page 58: Information Display
Specification Message Specification STOP SAFELY Stop the car in a safe TIME FOR REGU- Time for regular manner and turn off service. Volvo rec- LAR SERVICE the engine. Serious ommends that an risk of damage. authorised Volvo workshop carries SERVICE Volvo recommends out the service.
Page 59 161. run the engine at information on idling speed until the If shown repeatedly checking the oil message clears. For then Volvo recom- level, see page 221. more information, mends that an see page 161. authorised Volvo SOOT FILTER...
Page 60: 12 V Electrical Socket
02 Instruments and controls Electrical socket 12 V electrical socket Electrical socket in the rear seat WARNING Always leave the plug in the socket when the socket is not in use. NOTE Optional equipment and accessories - e.g. TV screens, music players and mobile phones - which are connected to one of the passenger compartment's 12V electrical sockets, could be activated by the climate...
Page 61 02 Instruments and controls Electrical socket WARNING Always leave the plug in the socket when the socket is not in use.
Page 62: Lighting Panel
Thumbwheel for headlamp levelling centre position. If necessary, the automatic the height of the beam. dipped beam can be deactivated. Volvo rec- Light switches 1. Turn the remote control key to position II. ommends that this is performed by an author- Thumbwheel for adjusting display and ised Volvo workshop.
Page 63 02 Instruments and controls Lighting panel The lamps are switched off automatically when Fog lamps Fuel filler flap the remote control key is turned to position I or Press button (5) to open the fuel filler flap when NOTE the car is unlocked, see page 132. Regulations for use of fog lamps vary from Instrument lighting country to country.
Page 64 02 Instruments and controls Lighting panel event of a malfunction. The function is only Daytime running lights - DRL* NOTE active in twilight or darkness and only when the To save fuel, daytime running lights (Daytime To achieve minimal energy consumption, car is moving.
Page 65: Left-Hand Stalk Switch
02 Instruments and controls Left-hand stalk switch Stalk switch positions Direction indicators Switching, main and dipped beam The remote control key must be in position II Continuous flash sequence and the headlamp control in end position, see ± Move the stalk switch up or down to page 62, for main beam to be switched on.
Page 66 02 Instruments and controls Left-hand stalk switch Trip computer* car is stationary, " --.- " appears on the display. NOTE During the period for regeneration fuel con- If a warning message interrupts while you sumption may increase, see page 146. are using the trip computer, this message AVERAGE must be acknowledged.
Page 67 02 Instruments and controls Left-hand stalk switch MPH ACTUAL SPEED. Current speed is displayed in mph. Resetting 1. Select --- KM/H AVERAGE SPEED --.- L/100 KM AVERAGE 2. Reset with one press on the RESET but- ton. Press and hold the RESET button for at least five seconds to reset the average speed and average consumption at the same time.
Page 68: Right-Hand Stalk Switch
02 Instruments and controls Right-hand stalk switch Windscreen wipers Single sweep Windscreen/headlamp washer Raise the stalk switch to make a Move the stalk switch toward the steering single sweep. wheel to start the windscreen and headlamp washers. The wipers will make several more sweeps once the stalk switch is released.
Page 69 02 Instruments and controls Right-hand stalk switch Rain sensor* Activating the rain sensor: selected, or the sensitivity to rain when the rain sensor is selected. ± Press the button (B), see page 68. A display symbol shows that the rain sensor is active.
Page 70: Cruise Control
02 Instruments and controls Cruise control* Activating Increasing or decreasing speed NOTE A temporary increase in speed (less than one minute) using the accelerator, such as while overtaking, does not affect the cruise control setting. When you release the accel- erator, the car will return to the programmed speed.
Page 71 02 Instruments and controls Cruise control* Return to the set speed – Press this button to resume the previously set speed. CRUISE appears on the combined instrument panel. Disengaging ± Press CRUISE to disengage the cruise control. CRUISE ON clears on the com- bined instrument panel.
Page 72: Keypad In The Steering Wheel
02 Instruments and controls Keypad in the steering wheel* Button functions in order to enable control of the phone system with the arrow keys. To return to Audio only, press EXIT.. To return to the phone menu, press EXIT once again. With the ENTER button you can select, acti- vate and deactivate options in menus.
Page 73: Steering Wheel Adjustment, Hazard Warning Flashers
02 Instruments and controls Steering wheel adjustment, hazard warning flashers Steering wheel adjustment WARNING NOTE Adjust the steering wheel before driving off, Regulations regarding the use of hazard never while driving. Before driving, check warning flashers vary from country to coun- that the steering wheel is fixed in position.
Page 74: Parking Brake
02 Instruments and controls Parking brake Handbrake > The instrument panel's warning symbol Disengaging the parking brake is illuminated. 1. Press the foot brake pedal down firmly. 2. Pull the parking brake lever up slightly, NOTE press the button, lower the parking brake lever and release the button.
Page 75: Power Windows
02 Instruments and controls Power windows Operation The windows can be opened and closed in two WARNING ways: The power windows are operated using the Make sure that children and other passen- controls in the doors. The ignition key must be gers cannot be trapped in any way when Manual operation in position I or II for the power windows to...
Page 76 02 Instruments and controls Power windows Blocking power windows in the rear Rear power windows NOTE doors If the car has electric child safety locks on the rear doors, the light indicates that these are also activated. The doors then cannot be opened from the inside.
Page 77: Windows, Rearview And Door Mirrors
02 Instruments and controls Windows, rearview and door mirrors Interior rearview mirror Interior rearview mirror with compass* Calibrating the compass The earth is divided into 15 magnetic zones. Bright light from behind could be reflected in The upper right-hand corner of the rearview The compass is set for the geographical area the rearview mirror and dazzle the driver.
Page 78 02 Instruments and controls Windows, rearview and door mirrors 4. Press the button (1) repeatedly until the 1– number for the required magnetic zone ( ) is shown, refer to the map of magnetic zones for the compass. 5. Wait until the display returns to showing the character 6.
Page 79 02 Instruments and controls Windows, rearview and door mirrors Sun blind* Door mirrors Retractable power door mirrors* The mirrors can be retracted for parking/driving in narrow spaces. This can be carried out in ignition position I and II. Retracting the mirrors 1.
Page 80 02 Instruments and controls Windows, rearview and door mirrors Blind Spot Information System, BLIS* NOTE BLIS is an information system that under cer- The door mirrors will not be extended auto- tain conditions can help to draw the driver's matically during unlocking if they were attention to vehicles moving in the same direc- retracted using the controls in the door.
Page 81: Power Sunroof
02 Instruments and controls Power sunroof* Open positions Ventilation position WARNING Open: If there are children in the car: ± Press the rear edge of the control (5) Switch off the supply to the power sunroof upward. by removing the remote control key if the driver leaves the car.
Page 82 02 Instruments and controls Power sunroof* closed position as long as the button is If you need to interrupt closing: Wind deflector kept depressed. ± Press the lock button again. WARNING WARNING The sunroof's pinch-protection function Make sure that children or other passengers only operates during automatic closing, not are not in danger of becoming trapped in manual closing.
Page 83: Personal Preferences
02 Instruments and controls Personal preferences Possible settings Display Clock, adjustment Personal preferences can be set for some of The hour and minute are each adjusted sepa- MENU the car's functions. This applies to locks, cli- rately. mate control and audio functions. For audio EXIT 1.
Page 84 02 Instruments and controls Personal preferences ± Select On/Off depending on whether or not Doors – auto lock central locking button, as well as the outside you wish the recirculation timer to be door handle button on cars with the keyless When the speed of the car exceeds 7 km/h the active.
Page 85 02 Instruments and controls Personal preferences • 30 seconds • 60 seconds • 90 seconds Information • VIN number… - (Vehicle Identification Number) is the car's unique identity num- ber. • Number of keys… - The number of keys registered for the car is shown.
Page 86: Homelink
02 Instruments and controls HomeLink * General NOTE WARNING HomeLink is designed not to work if the car If HomeLink is used to operate a garage is locked from the outside. door or gate, ensure that nobody is in the vicinity of the door or gate while it is in Save the original remote controls for future motion.
Page 87 02 Instruments and controls HomeLink * The particular distance that is required ess is repeated for approx. 20 seconds Programming individual buttons and indicates that the device has a "roll- between the original remote control and To reprogram an individual button, proceed in ing code".
Page 88 02 Instruments and controls HomeLink * • Constant glow: The indicator lamp illu- 7. Depress the programmed button on minates with a constant glow when the HomeLink , while the "programming but- button is kept depressed, this indicates ton" is still flashing, keep it depressed for that the programming is complete.
Page 89 02 Instruments and controls...
Page 90 General information on climate control........... 92 Manual climate control, AC..............94 Electronic climate control, ECC*............. 97 Air distribution..................100 Fuel-driven engine block heater and passenger compartment heater*........... 101 Fuel-driven auxiliary heater* (diesel)............. 104 Option/accessory, for more information, see Introduction.
Page 91 C L I M A T E C O N T R O L...
Page 92: 03 Climate Control
Fault tracing and repair Display The climate control system cools or heats as Volvo recommends that you only entrust fault There is a display above the climate control well as dehumidifies the air in the passenger tracing and repair of the climate control system panel.
Page 93: Climate Control
03 Climate control General information on climate control Air vents in the dashboard ECC* Side windows and sunroof To ensure that the air conditioning works sat- Actual temperature isfactorily, close all side windows and the sun- The temperature you select corresponds to the roof (if fitted).
Page 94: Manual Climate Control, Ac
03 Climate control Manual climate control, AC Control panel Functions 2. Recirculation Recirculation can be used to 1. Fan Recirculation shut out bad air, exhaust Increase or decrease the fan fumes, etc. from the passen- Defroster speed by turning the knob. ger compartment.
Page 95 03 Climate control Manual climate control, AC Timer 4. Air distribution 6. and 7. Heated front seats* The timer function reduces the risk of icing, The airflow can be distributed misting and bad air (if recirculation is selected). to the windows, dashboard See page 83, for activating/deactivating the vents or floor by pressing the function.
Page 96 03 Climate control Manual climate control, AC on the button. Automatic switching off discon- nects the rear window and door mirrors after 12 – 20 minutes depending on outside tem- perature. During cold weather the defrosting* also con- tinues after 20 minutes in order to keep the rear window and door mirrors free of ice and mist.
Page 97: Electronic Climate Control, Ecc
03 Climate control Electronic climate control, ECC* Control panel AUTO Functions 2. Fan Turn the knob to increase or 1. AUTO decrease fan speed. If AUTO The AUTO function automat- is selected then fan speed is Recirculation/Air quality system ically regulates climate con- regulated automatically.
Page 98 03 Climate control Electronic climate control, ECC* • 3. Recirculation The air quality system consists of a multi-filter The defroster functions for the front, side and rear windows can be used to demist and a sensor. The filter separates gases and The function is selected to the windows.
Page 99 03 Climate control Electronic climate control, ECC* A symbol on the display above the climate con- 7 and 8. Heated front seats* on the button. Automatic switching off discon- trol panel and an illuminated light in the relevant nects the rear window and door mirrors after To activate front seat heating: button indicate which function has been 12 –...
Page 100: Air Distribution
03 Climate control Air distribution Air distribution Use: Air distribution Use: Air to windows. Some air to remove ice and Air to the floor and windows. to ensure comfortable flows from the air vents. The misting quickly. Some air flows from the dash- conditions and good air is not recirculated.
Page 101: Fuel-Driven Engine Block Heater And Passenger Compartment Heater
03 Climate control Fuel-driven engine block heater and passenger compartment heater* General information about heaters Refuelling Battery and fuel If the battery has insufficient charge or the fuel The parking heater heats the engine and pas- level is too low, the parking heater is switched senger compartment and can be started off automatically and a message appears on directly or with the timer.
Page 102 03 Climate control Fuel-driven engine block heater and passenger compartment heater* Activating the heater Symbols and display messages Display Specification When one of the timer's settings or HEATER STOP- The heater has been Direct start is activated, the infor- stopped by the car's PED LOW BAT- mation symbol in the combined electronics in order...
Page 103 03 Climate control Fuel-driven engine block heater and passenger compartment heater* Heating of the passenger compartment will After setting TIMER 1 a second start time can NOTE begin as soon as the engine coolant has be programmed with TIMER 2 by scrolling with All timer programming will be cleared if the reached the correct temperature.
Page 104: Fuel-Driven Auxiliary Heater* (Diesel)
03 Climate control Fuel-driven auxiliary heater* (diesel) Auxiliary heater (diesel) In diesel-engined cars the auxiliary heater may be required for achieving the correct tempera- ture in the engine and passenger compartment during cold weather. The heater starts automatically when extra heat is required when the engine is running.
Page 105 03 Climate control...
Page 106 Front seats.................... 108 Interior lighting..................110 Storage spaces in the passenger compartment ........112 Rear seat....................116 Cargo area.................... 118...
Page 107 I N T E R I O R...
Page 108: 04 Interior
04 Interior Front seats Seating position, manual seat The seats can be adjusted for a certain time Lumbar support (driver's and passenger after unlocking the door with the remote con- seat*), turn the wheel. trol key without the key being inserted into the Backrest rake: turn the wheel.
Page 109 Using a stored setting Inlaid mats* Press one of the memory buttons 1–3 until the Volvo supplies inlay mats which are especially seat stops. If you release the button then the produced for your car. movement of the seat will stop.
Page 110: Interior Lighting
04 Interior Interior lighting Reading lamps and interior lighting Front roof lighting Vanity mirror* The front reading lamps are switched on or off by pressing the relevant button in the roof con- sole. Rear roof lighting Controls in roof console for front reading lamps The lamp is automatically switched on and off and passenger compartment lighting.
Page 111 04 Interior Interior lighting Automatic lighting Passenger compartment lighting comes on and remains on for 5 minutes if one of the doors Using the switch (2), see page 110, three posi- is open. tions can be selected for the lighting the pas- senger compartment: If any lighting is switched on manually and the car is locked then it will be switched off auto-...
Page 112: Storage Spaces In The Passenger Compartment
04 Interior Storage spaces in the passenger compartment Storage spaces...
Page 113 04 Interior Storage spaces in the passenger compartment Storage pocket on rear of front seats. Glovebox Coat hanger Storage compartment in door panel with cup holder. Ticket clip Storage pocket on front edge of front seat cushions. Glovebox Storage compartment (e.g. for CD discs and cup holder, *) and storage compart- ment behind the centre console.
Page 114 04 Interior Storage spaces in the passenger compartment Storage under the front armrest Cup holder in centre console In the deeper compartment there is space for 10 normal CD cases. The cases must be stored There is a storage space under the armrest. There is space for a double cup holder under vertically on the top edge for all 10 to have There is also a smaller storage space in the...
Page 115 04 Interior Storage spaces in the passenger compartment Storage compartment behind the gear Bottle holder* Ashtray* lever A bottle holder for larger bottles is located on An ashtray is located towards the rear of the the rear of the tunnel console. tunnel console.
Page 116: Rear Seat
04 Interior Rear seat Head restraint, rear Tipping the rear seat backrest IMPORTANT The head restraints could be damaged if IMPORTANT they are not removed for loading. The head restraint in the centre must also be removed There must be no objects on the rear seat for heavy loads.
Page 117 04 Interior Rear seat 2. Lift the rear edge of the seat cushion (1) to fold the seat cushions forward. 3. Pull the lock (2) catch up and forward to release the backrest. A red indicator on the lock catch shows that the backrest is no longer locked in place.
Page 118: Cargo Area
04 Interior Cargo area Load retaining eyelets Electrical socket in cargo area* Bag holder* The load retaining eyelets are used to fasten Fold down the cover to access the electrical The bag holder holds shopping bags in place straps or nets to anchor items in the cargo socket.
Page 119 04 Interior...
Page 120 Remote control key with key blade............122 Active locks................... 125 Privacy locking*..................126 Keyless drive*..................128 Battery in remote control key..............131 Locking and unlocking................132 Child safety locks.................. 135 Alarm*....................136 Option/accessory, for more information, see Introduction.
Page 121 L O C K S A N D A L A R M...
Page 122: 05 Locks And Alarm
The car is supplied with 2 remote control keys. If you lose a remote control key, take the car and the other remote control keys to a Volvo The remote control keys contain detachable workshop - an authorised Volvo workshop is metal key blades for mechanical locking/ recommended.
Page 123 05 Locks and alarm Remote control key with key blade Approach lighting – Switches on the light- Detachable key blade Removing the key blade ing at a distance – lights up the area around To remove the key blade from the remote con- a car parked in a dark location.
Page 124 05 Locks and alarm Remote control key with key blade Turn the key blade 90 degrees clockwise. NOTE The keyhole is horizontal in the locked When the driver's door is unlocked using the position. key blade and is opened, the alarm is trig- gered.
Page 125: Active Locks
05 Locks and alarm Active locks Active locks for remote control key with key blade. Active locks for remote control key with- out key blade and with privacy locking activated.
Page 126: Privacy Locking
05 Locks and alarm Privacy locking* General information on privacy locking Activate privacy locking Rear seat backrests The privacy locking function is intended for NOTE when the car is left for service, with a hotel parking valet or similar. The glovebox is then Do not forget to lock the rear seat backrest.
Page 127 05 Locks and alarm Privacy locking* trolled by the remote control key and the cen- tral locking button on the driver's door. For information on locking the glovebox only, see page 124. Option/accessory, for more information, see Introduction.
Page 128: Keyless Drive
05 Locks and alarm Keyless drive* • Keyless lock and ignition system Remote control key max. 1.5 m from the the READ button has been pressed. Never leave any remote control key in the In order to open a door or the boot lid, a remote control key must be no more than approx.
Page 129 05 Locks and alarm Keyless drive* Locking Unlocking doors with the key blade NOTE On cars with the keyless drive system and automatic transmission the gear selector must be moved to the P position and the ignition dial turned to the 0 position. Other- wise the car cannot be locked or alarmed.
Page 130 05 Locks and alarm Keyless drive* Door handle, right-hand rear NOTE Centre console, under the rear section When the driver's door is unlocked using the key blade and is opened, the alarm is trig- Centre console, under the front section gered.
Page 131: Battery In Remote Control Key
05 Locks and alarm Battery in remote control key Low battery in remote control key 1. Place the remote control key with the key- pad downward and prize up the cover When the battery runs down and full function- using a small screwdriver. ality cannot be guaranteed, the information symbol and display show...
Page 132: Locking And Unlocking
05 Locks and alarm Locking and unlocking Locking/unlocking the car from Automatic relocking WARNING outside If none of the doors or the boot lid is opened Be aware of the risk of being locked in the within 2 minutes of unlocking, all are locked For cars with the Keyless system, see car when it is locked from the outside using page 128.
Page 133 05 Locks and alarm Locking and unlocking ± Press the upper section of the central lock- Automatic locking WARNING ing button When the speed of the car exceeds 7 km/h the Do not allow anyone to remain in the car doors and boot lid are locked automatically.
Page 134 05 Locks and alarm Locking and unlocking Deactivation is carried out as follows: The next time the remote control key is turned to key position II the system is reset to zero and 1. Access the menu system under the instrument panel display shows the mes- SETTINGS (for a detailed description of sage...
Page 135: Child Safety Locks
05 Locks and alarm Child safety locks Manual select, child lock, rear doors Electrical locking of the rear doors and The lamp in the button illuminates when the lock is active. power windows* NOTE Cars with electric child safety locks do not also have manual child locks.
Page 136: Alarm
– the alarm has been triggered. If there is a fault in the alarm system, a message appears on the display. At which point you should contact a workshop - an authorised Volvo workshop is recommended. Option/accessory, for more information, see Introduction.
Page 137 05 Locks and alarm Alarm* Automatic re-arming of the alarm Remote control key not working Alarm signals This function prevents the car being left with When the alarm is triggered, the following hap- the alarm disarmed unintentionally. pens: • If the car is unlocked with the remote control A siren sounds for 25 seconds or until the alarm is deactivated.
Page 138 05 Locks and alarm Alarm* 4. Test the movement detector by lifting out 4. Open the bonnet with the handle under the a bag from a seat for example. dashboard. > A siren should sound and all direction > A siren should sound and all direction indicators should flash.
Page 139 05 Locks and alarm...
Page 140 General....................142 Refuelling....................144 Alcoguard*.................... 148 Starting the engine................152 Starting the engine – Flexifuel............... 154 Keyless drive*..................156 Manual gearbox..................157 Automatic gearbox................158 DRIVe Start-Stop*................. 163 Brake system..................167 DSTC – Stability and traction control system*........169 Park Assist*................... 171 BLIS* –...
Page 141 S T A R T I N G A N D D R I V I N G...
Page 142: 06 Starting And Driving
06 Starting and driving General Economical driving For more information and further advice, see brake linings wet resulting in delayed brake the pages 15 and 293. function. Driving economically means driving smoothly while thinking ahead and adjusting your driving • Clean the electric contacts of the electric WARNING style and speed to the prevailing conditions.
Page 143 Do not use functions one of a greater capacity than the standard which use a lot of power when the engine is model. Check with your nearest Volvo dealer switched off. Examples of such functions are: regarding the options for your car.
Page 144: Refuelling
06 Starting and driving Refuelling Opening the fuel filler flap 3. Take out the cap. General information on fuel 4. Hang up the cap on the inside of the fuel WARNING filler flap. Always avoid inhaling fuel vapour and get- NOTE ting fuel splashes in the eyes.
Page 145 Mixing different types of fuel or the use of adjusted. These adjustments create optimal nents, and do not replace components with fuel not recommended invalidates Volvo's conditions for efficient combustion of harmful parts that are not specifically designed for use...
Page 146 IMPORTANT specified in the Service and Warranty Booklet damage that is not covered by the Volvo or if you suspect that the car has been filled warranty. The sulphur content must be a maximum of with contaminated fuel.
Page 147 06 Starting and driving Refuelling called "regeneration" is started in order to burn way. The car should then be driven for approx- away the particles and empty the filter. This imately 20 minutes more. requires the engine to have reached normal NOTE operating temperature.
Page 148: Alcoguard
06 Starting and driving Alcoguard* General information on the Alcolock Functions Operation The function of the Alcolock is to prevent the Battery car from being driven by individuals under the Alcolock indicator lamp (4) shows battery sta- influence of alcohol. Before the engine can be tus: started the driver must take a breath test that verifies that he/she is not under the influence...
Page 149 30 minutes within these 30 days then normal engine star- without a new breath test. ting will be blocked - only starting with the An authorised Volvo workshop is recommended. Option/accessory, for more information, see Introduction.
Page 150 This setting can be nect the power supply cable from the glovebox changed afterwards at a workshop and wait until indicator lamp (6) is green. An authorised Volvo workshop is recommended. Option/accessory, for more information, see Introduction.
Page 151 Test failed - take a INVALID TEST new breath test. ALCOGUARD Blowing too short - blow for longer. BLOW LONGER ALCOGUARD Blowing too hard - blow more gently. BLOW SOFTER An authorised Volvo workshop is recommended. Option/accessory, for more information, see Introduction.
Page 152: Starting The Engine
06 Starting and driving Starting the engine ± Before starting the engine Turn the ignition key to the start position NOTE III and just release it - the starter motor ± Apply the parking brake. The idling speed can be noticeably higher then works automatically until the engine than normal for certain engine types during Note that if the car is equipped with an alcolock...
Page 153 06 Starting and driving Starting the engine II – Driving position 2. Hold the steering wheel in this position. Reinsert the key and make a new attempt The remote control key's to start the car. position when driving. The whole electrical system is engaged.
Page 154: Starting The Engine - Flexifuel
1. Depress the accelerator pedal 1/3 to 1/2. workshop - an authorised Volvo workshop is recommended. 2. Turn the remote control key/ignition dial to key position III.
Page 155 06 Starting and driving Starting the engine – Flexifuel For more information on Flexifuel's bioethanol E85 fuel, see page 145. Fuel adaptation If the fuel tank is filled with petrol after the car has been driven on bioethanol E85 (or vice versa) then the engine may run slightly unevenly for a time.
Page 156: Keyless Drive
06 Starting and driving Keyless drive* General Starting the car Starting with the remote control key ± Depress the clutch pedal (cars with manual gearbox) or brake pedal (cars with auto- matic gearbox). Petrol engine ± Press in and turn the ignition dial to key position III.
Page 157: Manual Gearbox
06 Starting and driving Manual gearbox Gear positions Gear shift indicator - GSI* GSI - Gear Shift Indicator - advises the driver of the opti- mum time to change gear. The indication is given with an arrow for up and down shift- ing respectively in the lower information display of the combined instrument panel, see page 53.
Page 158: Automatic Gearbox
06 Starting and driving Automatic gearbox Geartronic automatic gear positions Geartronic manual gear positions (+/-) NOTE The driver can also change gear manually The brake pedal must be depressed in order using the Geartronic automatic gearbox. The to be able to disengage the gear lever from car engine-brakes when the accelerator pedal the P position.
Page 159 06 Starting and driving Automatic gearbox Kick-down Mechanical gear selector inhibitor Automatic gear selector inhibitor When the accelerator pedal is pressed all the Cars with an automatic gearbox have special way to the floor (beyond the position normally safety systems: regarded as full acceleration) a lower gear is Keylock immediately engaged.
Page 160 06 Starting and driving Automatic gearbox Disengaging the gear selector inhibitor Cold start Automatic gearbox, Powershift* When starting in low temperatures, the gear changes can sometimes feel hard. This is due to the gearbox oil's viscosity at low tempera- tures. To reduce engine emissions, the gear- box shifts up later than normal when the engine is started at low temperatures.
Page 161 06 Starting and driving Automatic gearbox In the event of uncertainty as to whether or not message. The transmission can also overheat For important information regarding Powershift the car is equipped with Powershift transmis- during slow driving in queues (10 km/h or transmission and towing - see page 176.
Page 162 06 Starting and driving Automatic gearbox Symbol Display Driving characteristics Action TRANSM. OVERHEAT BRAKE TO Difficulty in maintaining even speed at con- Gearbox overheated. Keep the car station- stant engine speed. HOLD ary using the foot brake TRANSM. OVERHEAT PARK SAFELY Significant pulling in the car's traction.
Page 163: Drive Start-Stop
Adapted power steering Another DRIVe function is that the power steer- Environmental care is one of Volvo Car Corpo- ing's energy take-off is adapted according to ration's core values and it influences all of our requirements.
Page 164 06 Starting and driving DRIVe Start-Stop* • Function and operation All of the car's normal systems such as lighting, Release the foot brake and let the car roll faster than normal walking pace - the radio, etc. work as normal even with an auto- engine starts.
Page 165 06 Starting and driving DRIVe Start-Stop* Deactivating the Start/Stop function Limitations In the following cases the engine auto-starts even if the driver has not depressed the clutch The engine does not auto-stop pedal in order to engage a gear: Even if the Start/Stop function is activated, the •...
Page 166 If a message does not go out following com- Message opened - a display text prompts the driver pletion of the action then a workshop should to start the engine normally. be contacted - an authorised Volvo workshop AUTO START- Illuminates for is recommended. •...
Page 167: Brake System
06 Starting and driving Brake system Brake servo Dampness can affect braking Bear in mind that driving with a trailer puts an additional load on the car's brakes. characteristics If the car is rolling or is being towed with the Brake components become wet when the car engine turned off, the brake pedal must be is driven in heavy rain, through pools of water...
Page 168 - an author- 10 km/h the brake light returns from flashing to ised Volvo workshop is recommended. the normal constant glow - while at the same time the hazard warning flashers are activated,...
Page 169: Dstc - Stability And Traction Control System
06 Starting and driving DSTC – Stability and traction control system* General Reduced operation Operation 1. Turn the thumbwheel until the DSTC menu The stability and traction control system, DSTC appears. (Dynamic Stability and Traction Control) helps the driver to avoid skidding and improves the DSTC ON means that the system function car's traction.
Page 170 DSTC system. > If the message remains when the engine is restarted, drive to a workshop. An authorised Volvo workshop is recom- mended. Symbols in the combined instrument panel DSTC system Information Option/accessory, for more information, see Introduction.
Page 171: Park Assist
Rear parking assistance is deactivated then this is automatically lowered. automatically when towing a trailer if a Volvo The tone becomes constant at a distance of genuine trailer cable is used. about 30 cm. If there are obstacles within this...
Page 172 Front parking assistance is active at speeds attention, contact a workshop - an authorised below 15 km/h. The system is deactivated at Volvo workshop is recommended. higher speeds. When the speed is below 10 km/h the system is reactivated. IMPORTANT...
Page 173: Blis* - Blind Spot Information System
06 Starting and driving BLIS* – Blind Spot Information System General BLIS is an information system that under cer- Blind spots tain conditions can help to draw the driver's attention to vehicles moving in the same direc- tion in the so-called "blind spot". The system is designed to work most effec- tively when driving in dense traffic on multi-lane highways.
Page 174 06 Starting and driving BLIS* – Blind Spot Information System Activate/deactivate ton to clear the text message. For more infor- WARNING mation on messages, see page 58. BLIS does not work in sharp bends. BLIS system message BLIS does not work when the car is revers- ing.
Page 175 BLIS SERVICE must only be performed by a workshop - an REQUIRED authorised Volvo workshop is recom- mended. Here are several examples of situations where the BLIS indicator lamp may illuminate even if Low sun in the camera.
Page 176: Towing And Recovery
06 Starting and driving Towing and recovery ± Start assistance Move the gear selector to position N and WARNING release the parking brake. Use a donor battery if the battery is discharged The steering lock remains in the position it and the engine does not start.
Page 177 06 Starting and driving Towing and recovery Towing eye turning it outwards. Then turn out the IMPORTANT cover completely and remove it. Avoid towing. • The second variant has a marking along • However, the car can be towed for a one side or in a corner: Press the mark- short distance at low speed to move it ing with a finger and fold out the oppo-...
Page 178 06 Starting and driving Towing and recovery Recovery Call a recovery service for recovery assistance. The car must always be towed with the wheels rolling forward. IMPORTANT Cars with automatic gearbox must only be towed with drive wheels raised from the road.
Page 179: Start Assistance
06 Starting and driving Start assistance Starting with a donor battery 4. Connect one of the red jump lead's clamps IMPORTANT to the donor battery's positive terminal (1). Do not touch the crocodile clips during the start procedure. There is a risk of sparks IMPORTANT forming.
Page 180: Driving With A Trailer
• Avoid driving with a trailer on inclines of If the towing bracket is fitted by an authorised more than 12%. Volvo workshop, then the car is delivered with Overheating • For safety reasons, the maximum permit- the necessary equipment for driving with a...
Page 181 06 Starting and driving Driving with a trailer Automatic gearbox hitched trailer. Always use the parking brake. Overheating • Block the wheels with chocks when park- When driving with a trailer in hilly terrain in a hot ing a car with hitched trailer on a hill. climate there may be a risk of overheating.
Page 182: Towing Equipment
If the car is equipped with a detachable towbar, the installation instructions for the loose sec- tion must be followed carefully, see page 184. WARNING If the car is fitted with a Volvo detachable towbar: • Follow the installation instructions care- fully.
Page 183 06 Starting and driving Towing equipment* Specifications Dimensions for mounting points (mm) Fixed or detachable towbar standard 1070 Side member Ball centre Option/accessory, for more information, see Introduction.
Page 184: Detachable Towbar
06 Starting and driving Detachable towbar* Fitting the towbar 2. Ensure that the mechanism is in the 3. Check that the indicator window (3) shows unlocked position by turning the key clock- red. If the window does not show red, 1.
Page 185 06 Starting and driving Detachable towbar* 5. Check that the indicator window shows green. 4. Insert the towbar until you hear a click. 7. Check that the towbar is secure by pulling it up, down and back. WARNING 6. Turn the key anticlockwise to locked posi- tion.
Page 186 06 Starting and driving Detachable towbar* Removing the towbar 8. Safety cable. 2. Push in the locking wheel and turn it 1. Insert the key and turn it clockwise to the anticlockwise until you hear a click. WARNING unlocked position. Be sure to attach the trailer's safety cable to the correct place.
Page 187 06 Starting and driving Detachable towbar* 3. Turn the locking wheel down fully, until it 4. Push on the protective cover. comes to a stop. Hold it in this position while pulling the towbar rearward and upward. WARNING Secure the towbar safely if it is stored in the car, see page 182.
Page 188: Loading
For more detailed infor- for your car by Volvo. mation on weights, see page 285. • Secure all loads to the load retaining eye- Carefully follow the mounting instructions sup- lets with straps or web lashings.
Page 189: Adjusting Headlamp Pattern
On cars with Xenon headlamps, the dazzling oncoming motorists. replacement of Xenon lamps must be car- ried out at a workshop - an authorised Volvo The correct pattern will also better illuminate workshop is recommended. Working with the verge.
Page 190 General....................192 Tyre pressure..................196 Warning triangle* and spare wheel * ............ 197 Changing wheels................... 200 Emergency puncture repair* ..............202 Option/accessory, for more information, see Introduction.
Page 191 W H E E L S A N D T Y R E S...
Page 192: 07 Wheels And Tyres
07 Wheels and tyres General Driving characteristics and tyres Speed ratings New tyres The tyres greatly affect the car's driving cha- The car is approved as a whole, which means racteristics. The type of tyre, dimensions, tyre that dimensions and speed ratings must not pressure and speed rating are important for differ from those specified on the vehicle reg- how the car performs.
Page 193 A suitable dis- cially the studs, a longer service life. tance for the first change is approx. 5000 km and then at 10 000 km intervals. Volvo recom- NOTE mends that you contact an authorised Volvo Tread wear indicators.
Page 194 1. Tighten the wheel nuts of model (1) to 110 washer. Only use wheel rims that are tested and Nm. Tighten the wheel nuts of model (2) to approved by Volvo and which are included in 130 Nm. NOTE the Volvo genuine accessories range.
Page 195 The spare wheel (Temporary spare) is only Volvo recommends that you contact an author- intended for use temporarily and must be ised Volvo workshop for checking if you are replaced by an ordinary wheel as soon as pos- uncertain about tread depth.
Page 196: Tyre Pressure
07 Wheels and tyres Tyre pressure Recommended tyre pressure DRIVe* NOTE An important detail in connection with environ- Tyre pressure decreases over time, this is a mentally-conscious driving is to use the right natural phenomenon. Tyre pressure also type of tyres and to drive with the correct air varies depending on ambient temperature.
Page 197: Warning Triangle* And Spare Wheel
07 Wheels and tyres Warning triangle* and spare wheel * Warning triangle The warning triangle is fitted on the inside of the boot lid with two clips. Follow the regulations for the use of a warning triangle*. Place the warning triangle in a suita- ble place with regard to the traffic.
Page 198 1. Crank the jack (3) to halfway in order that • For cars equipped with spare wheel, the Volvo recommends only using the jack* that the jack shall fit horizontally in the bracket. jack must be cranked so that it fits into the belongs to the car model in question, which spare wheel.
Page 199 07 Wheels and tyres Warning triangle* and spare wheel * IMPORTANT The tools and jack* must be stored in the intended location in the car's cargo area when not in use. First aid* A case with first aid equipment is located in the cargo area.
Page 200: Changing Wheels
07 Wheels and tyres Changing wheels Removing wheels NOTE Volvo recommends only using the jack* that belongs to the car model in question, which is indicated on the jack's label. The label also indicates the jack's maximum lift capacity at a specified minimum lifting height.
Page 201 07 Wheels and tyres Changing wheels Fitting the wheel 1. Clean the contact surfaces between wheel and hub. 2. Put on the wheel. Tighten the wheel nuts. 3. Lower the car so that the wheel cannot rotate. 4. Tighten the wheel nuts crosswise. It is important that the wheel nuts are tightened properly.
Page 202: Emergency Puncture Repair
It consists of a compressor used. Volvo recommends that you visit an Decal, maximum permitted speed and a bottle with sealing fluid. The kit works as authorised Volvo workshop for inspection of a temporary repair.
Page 203 07 Wheels and tyres Emergency puncture repair* Sealing fluid bottle WARNING WARNING Pressure gauge The sealing fluid can irritate the skin. In the Do not leave children in the car without case of contact with skin, wash away the supervision when the engine is running. fluid with soap and water.
Page 204 Never leave the engine run- 3. If it is below 1.3 bar then the tyre is insuf- 7. Volvo recommends that you drive to the ning in sealed areas or areas that lack suf- ficiently sealed. The journey should not be nearest authorised Volvo workshop for the ficient ventilation.
Page 205 07 Wheels and tyres Emergency puncture repair* Changing the sealing fluid canister WARNING Replace the bottle before the expiration date Do not leave children in the car without has passed. Treat the old bottle as environ- supervision when the engine is running. mentally hazardous waste.
Page 206 Cleaning....................208 Touching up paintwork................. 212 Rustproofing..................213...
Page 207 C A R C A R E...
Page 208: 08 Car Care
08 Car care Cleaning Washing the car Chromed wheels NOTE Wash the car as soon as it becomes dirty. Use Outside lighting such as headlamps, fog IMPORTANT car shampoo. Dirt and road salt can lead to lamps and rear lamps may temporarily have corrosion.
Page 209 Only paint treatment recommended by When using a pressure washer: Make sure rubber. Volvo should be used. Other treatment such that the nozzle of the pressure washer is not as preserving, sealing, protection, lustre When using degreasant on plastic and rub- closer than 30 cm to the bodywork.
Page 210 (or more if A special fabric cleaning agent, available from ucts recommended by Volvo. Clean regularly necessary). The Volvo Leather Care kit is avail- authorised Volvo dealers, is recommended to and follow the instructions included with the able from your Volvo dealer.
Page 211 • Leather needs to breathe. Never cover the Volvo dealer. Make sure the seatbelt is dry leather steering wheel with protective plas- before allowing it to retract. tic.
Page 212: Touching Up Paintwork
08 Car care Touching up paintwork Paintwork Stone chips and scratches If the stone chip has penetrated to the bare metal Paint is an important part of the car's rust- 1. Apply a piece of masking tape over the proofing and should therefore be checked reg- damaged surface.
Page 213: Rustproofing
The car's rustproofing does not normally require treatment for approximately 12 years. After this period, it should be treated at three- year intervals. If the car needs further treat- ment, Volvo recommends that you engage an authorised Volvo workshop for assistance.
Page 214 Volvo service..................216 Self-maintenance.................. 217 Bonnet and engine compartment............218 Oils and fluids..................220 Wiper blades..................226 Battery....................227 Replacing bulbs..................231 Fuses..................... 237...
Page 215 M A I N T E N A N C E A N D S E R V I C E...
Page 216: 09 Maintenance And Service
It was checked again in accord- ance with Volvo Car Corporation regulations before it was handed over to you. To keep your Volvo as safe and reliable as pos- sible, follow the Volvo service programme specified in the Service and Warranty Booklet.
Page 217: Self-Maintenance
NOTE filled. Use washer antifreeze at tempera- High output from the ignition system. The Volvo recommends only using the jack that voltage in the ignition system is highly dan- tures around freezing. belongs to the car model in question. If a gerous.
Page 218: Bonnet And Engine Compartment
09 Maintenance and service Bonnet and engine compartment Opening the bonnet The illustration shows a left-hand drive car. 1. Pull the handle on the far left under the Engine oil dipstick WARNING instrument panel. (In right-hand drive cars Radiator Check that the bonnet locks properly when the handle is on the far right.) You will hear closed.
Page 219 09 Maintenance and service Bonnet and engine compartment Battery Relay and fuse box, engine compartment Air filter Engines with electronic oil level sensor have no dipstick (5-cyl. diesel).
Page 220: Oils And Fluids
Using oil of a higher than specified grade is permitted. If the car is driven in adverse con- ditions, Volvo recommends using an oil of a higher grade than that specified on the decal, see page 288.
Page 221: Maintenance And Service
The 1. Ensure that the car is level. After switching ried out at a workshop - an authorised Volvo dipstick will indicate that the level is too low off the engine it is important to wait workshop is recommended.
Page 222 09 Maintenance and service Oils and fluids 5. If the level is close to MIN then 0.5 litres For engines with electronic oil level should be added. If the level is significantly sensor below, then an additional amount is required. 6.
Page 223 09 Maintenance and service Oils and fluids Measuring the oil level Washer fluid, topping up IMPORTANT If the oil level needs to be checked then it Engine oil In the event of the message should be carried out in accordance with the level Fill with 0.5 l oil , only fill with 0.5 litres.
Page 224 • Mix the coolant with approved quality overpressure. tap water. In the event of any doubt about water quality, used ready-mixed coolant in accordance with Volvo rec- NOTE ommendations. The engine must only be run with a well- • When changing coolant/replacing cool- filled cooling system.
Page 225 09 Maintenance and service Oils and fluids Checking and topping up the brake and WARNING clutch fluid If the brake fluid is under the MIN level in the brake fluid reservoir, do not drive further before topping up the brake fluid. The reason for the loss of brake fluid must be investigated.
Page 226: Wiper Blades
09 Maintenance and service Wiper blades Wiper blades Replacing the wiper blades, windscreen 1. Turn up the wiper arm. 2. Press the button located on the wiper blade mounting and pull straight out (1), parallel with the wiper arm. 3. Slide in (2) the new wiper blade until a "click"...
Page 227: Battery
09 Maintenance and service Battery Operation Symbols on the battery NOTE The service life and function of the battery is Use protective goggles. The life of the battery is shortened if it influenced by factors such as the number of becomes discharged repeatedly.
Page 228 09 Maintenance and service Battery Changing the battery 2. Tighten the clamp that holds the battery. Avoid sparks and naked flames. 3. Connect the ventilation hose. Removal > Check that it is correctly connected to 1. Remove the remote control key from the both battery and outlet in the body.
Page 229 A workshop should be contacted in fallen below the lowest permissible level the event of questions or problems - an author- then the Start/Stop function is disen- ised Volvo workshop is recommended. gaged. Temporarily reduced Start/Stop function due to high current take-off means: Auto-start can only take place if the gear lever is in neutral position.
Page 230 09 Maintenance and service Battery NOTE If the battery has become so discharged that everything is "black" and in principle the car does not have all the normal electri- cal functions and the engine is subsequently started using an external battery or battery charger, then the Start/Stop function will be activated.
Page 231: Replacing Bulbs
WARNING On cars with Xenon headlamps, the replacement of Xenon lamps must be car- ried out at a workshop - an authorised Volvo workshop is recommended. Working with All front bulbs (except for fog lamps) are Xenon lamps demands extreme caution...
Page 232 09 Maintenance and service Replacing bulbs Fitting the lamp housing 2. Bend aside the catches and remove the 5. Refit the lamp housing, see page 231. cover. 1. Plug in the connector and refit the lamp housing and locking pin. Check that the pin 3.
Page 233 09 Maintenance and service Replacing bulbs 4. Withdraw the bulb holder and change the 3. Withdraw the bulb holder and change the Direction indicators bulb. bulb. 5. Refit the bulb holder. It can only be refitted 4. Press the bulb holder back on. A "click" is in one position.
Page 234 09 Maintenance and service Replacing bulbs Side marker lamps Front fog lamps 6. Fit a new bulb by turning clockwise. (The profile of the bulb holder corresponds to the profile of the foot of the bulb.) 7. Refit the bulb holder. The TOP mark on the bulb holder must always be upward.
Page 235 Number plate lighting NOTE If an error message remains after the broken bulb has been replaced then we recom- mend that you visit an authorised Volvo workshop. Bulb holder. IMPORTANT The cable to the brake light's LED lamps is fastened with clips in the bulb holder.
Page 236 09 Maintenance and service Replacing bulbs 4. Replace the bulb. Vanity mirror lighting* Fitting the mirror glass 1. First, press the three lugs at top edge of 5. Insert the connector and turn clockwise. mirror glass back into position. 6. Refit the entire lamp housing and screw it 2.
Page 237: Fuses
Each fuse box has space for several spare fuses. If the same fuse fails repeatedly then there is a fault in the component. In which case, Volvo recommends that you visit an authorised Volvo workshop for this to be checked.
Page 238 • Fuses 19-36 are of the "Mini Fuse" type. and fitting of fuses. • Fuses 7-18 are of the "JCASE" type and should be replaced by a workshop. An authorised Volvo workshop is recommended.
Page 239 09 Maintenance and service Fuses Cooling fan 50 A ABS valves 20 A Infotainment system 30 A Power steering 80 A Engine functions 30 A Windscreen wipers 30 A Supply to passenger com- Ventilation fan 40 A Supply to passenger com- partment fuse box 60 A partment fuse box...
Page 240 09 Maintenance and service Fuses Engine control module (5-cyl. Injectors (5-cyl. petrol), Turbo Relay coil, relay, climate con- petrol), Transmission control control valve (5-cyl. diesel), trol system, PTC element, oil module (5-cyl.) 10 A Oil level sensor (5-cyl. diesel) trap (5-cyl. petrol), Mass air flow sensor (5-cyl.
Page 241 09 Maintenance and service Fuses DRIVe Start/Stop* For more information on DRIVe Start/Stop - see page 163. Location of fuses for the Start/Stop function. Component 11M/1 Engine compartment, electrical distribution unit 11M/2 Sensor, battery monitor- Central electronic mod- ule (CEM) (Reference voltage standby bat- tery), diesel engine Option/accessory, for more information, see Introduction.
Page 242 09 Maintenance and service Fuses Relay/Fuse box in the passenger compartment The fuse box has 50 fuse positions. The fuses completely. The fuse box can be fully are located under the glovebox. The box also unhooked. provides space for several spare fuses. Tools 4.
Page 243 09 Maintenance and service Fuses Telematics*, Audio sys- Washer 15 A Parking assistance*, tem, RTI*, Bluetooth* 15 A Xenon* 10 A SRS system 10 A SRS system, Engine con- Control module Keyless* 20 A Reserve – trol module (5-cyl, DRIVe) 10 A Remote control receiver, PTC element, air pre-...
Page 244 09 Maintenance and service Fuses Seat heating (driver's Sunroof*, Overhead con- Power seat, driver 25 A side) 15 A sole for interior lighting, Interior lighting, cargo Seatbelt reminder, rear, Seat heating (passenger area lighting, power Dimming, interior rear- side) 15 A seats, fuel level display view mirror* (2.0F)
Page 245 09 Maintenance and service...
Page 246 General....................248 Audio functions..................250 Radio functions..................255 CD functions..................260 Menu structure – audio system............. 263 Phone functions*................... 264 Menu structure – phone*............... 271 Bluetooth handsfree*................274 Option/accessory, for more information, see Introduction.
Page 247 I N F O T A I N M E N T S Y S T E M...
Page 248: 10 Infotainment System
10 Infotainment system General • Infotainment system system can be easily operated using the con- EXIT (6) leads back one step in the menu structure. A long press on EXIT will exit the trol panel or the steering wheel keypad*, see menu system.
Page 249: Infotainment System
10 Infotainment system General Dolby Surround Pro Logic II Dolby Surround Pro Logic II distributes the two stereo audio channels to left, centre, right and rear speakers. This provides a more real- istic sound quality than that provided by stand- ard two-channel stereo.
Page 250: Audio Functions
10 Infotainment system Audio functions Audio controls ume adjusts automatically depending on vehi- External audio sources cle speed, see page 253. AUX, USB* Audio source selection General Repeatedly pressing AM/FM switches between FM1, FM2 and AM. Repeatedly pressing MODE changes between CD, USB, AUX and BT.
Page 251 10 Infotainment system Audio functions Use the MODE button to select the external iPod NOTE audio source you wish to use. An iPod is charged and supplied with power The system supports the playback of music by the USB connection via the player's con- 1.
Page 252 Bluetooth function in the car's audio sys- free* and a mobile phone is connected then the the following options. Adjust by turning tem. Volvo recommends that you contact an audio system can wirelessly play back stream- TUNING. authorised Volvo dealer or visit ing audio files from the mobile phone.
Page 253 10 Infotainment system Audio functions Activating/deactivating the subwoofer 3. Scroll to Surround FM… Surround Automatic volume control • Press MENU and then ENTER. AM… Surround CD… Surround The auto volume control function allows the AUX… and press ENTER. • audio volume to increase as the speed of the Scroll to Audio settings…...
Page 254 10 Infotainment system Audio functions There is a also a dynamic calibration that takes into account the position of the volume control, radio reception and vehicle speed. The controls explained in these operating instructions, e.g. bass, treble and equalizer* are only intended for the user to be able to adapt the sound reproduction according to personal taste.
Page 255: Radio Functions
10 Infotainment system Radio functions Radio controls Tuning Storing stations Ten station presets can be stored per wave- Automatic tuning length. FM has two memories for presets: 1. Select wavelength using AM/FM (1). . Preset stations are selected 2. Give a brief press on using the preset buttons (2) or the steering wheel keypad.
Page 256 10 Infotainment system Radio functions Selecting an auto-stored preset Scanning RDS functions Allowing the radio to remain in Auto mode pro- SCAN (4) automatically searches through a Radio Data System - RDS links FM transmitters vides access to the autostored presets. wavelength for strong stations.
Page 257 10 Infotainment system Radio functions gramme types ( ) interrupt one another in TP from current station/all stations News order of priority, where alarm has the highest The radio can interrupt with traffic information This function allows news broad- priority and programme types has the lowest. from only the set (current) station or from all casts within a set station's stations.
Page 258 10 Infotainment system Radio functions Programme types – PTY 4. Scroll to Search PTY and press ENTER. Automatic frequency update – AF The PTY function can be used to The AF function selects one of the strongest If the radio finds any of the selected pro- select different programme types, transmitters for a set station.
Page 259 10 Infotainment system Radio functions Enhanced Other Networks – EON Resetting RDS functions The EON function is especially useful in urban Resets all radio settings to the original factory areas with many regional radio stations. It settings. allows the distance between the car and the 1.
Page 260: Cd Functions
10 Infotainment system CD functions CD function controls automatically. Otherwise, load a disc and Pause change to CD mode by pressing MODE. If the volume is turned down completely, the CD player is stopped. The player is restarted Start playback (CD changer*) when volume is increased.
Page 261 10 Infotainment system CD functions cally when all files in the current folder have Activating/deactivating, random (CD NOTE been played back. changer) It is only possible to scroll between random If a normal music CD is being played: Press left/right on the navigation button if the CD tracks on the current disc.
Page 262 10 Infotainment system CD functions Using low quality CD discs could result in poor or non-existent sound. IMPORTANT Only use standard discs (12 cm in diameter). Do not use CD discs with adhesive disc labels. The heat in the CD player may cause the label to come off, damaging the CD player.
Page 263: Menu Structure - Audio System
10 Infotainment system Menu structure – audio system Overview News AUX MENU FM MENU AUX input volume… News Disc text News Audio settings… PTY… CD MENU Audio settings… Radio text For CD changer* with CD disc USB MENU* selected. Advanced radio settings… Playlist Random…...
Page 264: Phone Functions
10 Infotainment system Phone functions* Phone system components. Option/accessory, for more information, see Introduction.
Page 265 SIM card. • Volvo recommends that an authorised delayed 5 seconds before they are diverted. If Volvo workshop carries out phone system the current traffic situation still requires a high NOTE servicing. level of attention from the driver then the The built-in phone cannot read 3G type SIM incoming call is diverted to the voice mail.
Page 266 10 Infotainment system Phone functions* Extra SIM card Phone controls Steering wheel keypad Many network operators offer two SIM cards for the same phone number. The extra SIM card can be used in the car. Inserting the SIM card 1. Switch off the phone and open the glove- box.
Page 267 10 Infotainment system Phone functions* On/Off Activating from standby mode 2. Scroll to Hold Resume and press ± ENTER. Press PHONE. A handset appears in the display when the phone system is active or in standby mode Dialling a third party (standby).
Page 268 If the phone book contains a live caller's con- see menu 6.4.3, on page 271. This function tact information then this is shown in the dis- only applies to the Volvo integrated phone sys- play. Contact information can be stored on the tem.
Page 269 10 Infotainment system Phone functions* 6. Scroll to SIM card Phone memory 4. Enter the first few letters of the item and 6. Enter the first few letters of the item and press ENTER, or simply press ENTER. press ENTER, or simply press ENTER. press ENTER.
Page 270 10 Infotainment system Phone functions* SMS - Short Message Service IMEI number NOTE To block the phone, you must provide your Press ENTER to dial. Reading SMS network operator with the phone's IMEI num- 1. Press MENU. ber. This is a 15 digit serial number that is pro- NOTE 2.
Page 271: Menu Structure - Phone
10 Infotainment system Menu structure – phone* Phone menu 2.4. Speed dial… 4.6.2. When busy Call register… 2.4.1. Active 4.6.3. Not answered 1.1. Last 10 missed calls 2.4.2. Select numbers 4.6.4. Not reachable 1.2. Last 10 received calls 2.5. Erase SIM 4.6.5.
Page 272 10 Infotainment system Menu structure – phone* 6.2.3. Automatic 1.4.1. All calls 2.4. Speed dial A number stored in the phone book can be 6.3. Edit PIN code 1.4.2. Missed calls stored as a speed dial number. 6.4. Sounds and volume… 1.4.3.
Page 273 10 Infotainment system Menu structure – phone* operator for information on message settings. 4.6.2 When busy 6.1.2. Manual select Normally, these settings should not be altered. 4.6.3. Not answered 6.2. SIM security 3.3.1. SMSC number Select if the PIN code should be on, off or if the 4.6.4.
Page 274: Bluetooth Handsfree
Volvo recommends that you seek assis- Connect mobile phone tance from an authorised Volvo dealer or A mobile phone is connected in different ways visit www.volvocars.com for information on depending on whether or not it has been con- compatible phones.
Page 275 The call is interrupted with EXIT. the mobile phone's manual. Auto answer Disconnecting the mobile phone 3. Select My Volvo Car in the list of units The automatic answer function means that Automatic disconnection takes place if the detected in your mobile phone.
Page 276 10 Infotainment system Bluetooth handsfree* Ring volume More on registering and connecting NOTE Go to Phone Menu… Phone settings… A maximum of three mobile phones can be With certain mobile phones the connection registered. Registration is performed once per Sounds and volume… Ring volume is terminated when the privacy function is phone.
Page 277 List is empty compatible with the voice recognition func- tion. Volvo recommends that you contact an shown when copying is finished. tion is made under Phone Menu… authorised Volvo dealer or visit Bluetooth…...
Page 278 10 Infotainment system Bluetooth handsfree* twice for the second etc. Continue pressing for Bluetooth… Menu structure - Bluetooth more characters, see the table on page 268. handsfree with built-in phone 3.1. Change phone Call register… A short press on EXIT deletes an input char- 3.1.1.
Page 279 10 Infotainment system Bluetooth handsfree* Phone settings… 6.1. Sounds and volume… 6.1.1. Ring volume 6.1.2. Ring signals… 6.1.3. Mute radio 6.2. Synchronise phone book Option/accessory, for more information, see Introduction.
Page 280 Type designation................... 282 Dimensions and weights............... 284 Engine specifications................287 Engine oil....................288 Fluids and lubricants................290 Fuel....................... 293 Wheel and tyres, dimensions and pressure ......... 295 Electrical system................... 298 Type approval..................300 Symbols in the display................301...
Page 281 S P E C I F I C A T I O N S...
Page 282: 11 Specifications
11 Specifications Type designation...
Page 283 S40 and V50: The label is visible when the right rear door is opened. C30 and C70: The label is visible when the right door is opened.
Page 284: Dimensions And Weights
11 Specifications Dimensions and weights Dimensions Dimensions Dimensions Dimensions Wheelbase 2640 Front track Width including door 1548 mirrors 2022 1535 Length 4476 Width including folded- Rear track 1544 Load length, floor, in door mirrors 1845 folded seat 1745 1531 with 15" wheel Load length, floor with 16"...
Page 285 11 Specifications Dimensions and weights Weights WARNING Kerb weight includes the driver, the fuel tank The car's driving characteristics change 90% full and all fluids. depending on how heavily it is loaded and how the load is distributed. The weight of passengers and accessories, and towball load (when a trailer is hitched, see table) influences the payload and is not included in the kerb weight.
Page 286 11 Specifications Dimensions and weights Towing capacity and towball load Engine Maximum weight, braked trailer (kg) Maximum towball load (kg) 1200 DRIVe 1300 1300 2.0F 1350 1350 others 1500 Engine Maximum weight, unbraked trailer (kg) Maximum towball load (kg) 1.6, 2.0, 2.0F, D2 and DRIVe others...
Page 287: Engine Specifications
11 Specifications Engine specifications Overview NOTE Not all engines are available in all markets. Engine Engine Output Output Torque (Nm/ No. of Bore Stroke Swept Com- (kW/rpm) (hp/rpm) rpm) cylinders (mm) (mm) volume pression code (litres) ratio B4164S3 74/6000 100/6000 150/4000 81.4 1.596...
Page 288: Engine Oil
Volvo Car Corporation disclaims all war- tances at low temperatures. ranty liability if engine oil of the prescribed grade and viscosity is not used. Volvo recommends that oil changes are car- ried out at a workshop - an authorised Volvo workshop is recommended.
Page 289 11 Specifications Engine oil Engine oil grade Engine Engine code Recommended oil grade Volume, incl. oil filter (litres) B4164S3 Oil grade: ACEA A5/B5 approx. 4.0 Viscosity: SAE 5W–30 2.0F B4204S4 approx. 4.3 B4204S3 approx. 4.3 DRIVe D4162T approx. 3.8 D4162T approx.
Page 290: Fluids And Lubricants
Do not mix with any other transmission fluid. If the transmission is topped up with a dif- ferent fluid, contact a workshop nearby for servicing. Volvo recommends that you con- tact an authorised Volvo workshop. Gearbox oil Manual gearbox...
Page 291 Brake system DOT 4+ Power steer- Power steering 1,0 – 1,2 WSS M2C204-A or equivalent product with same specifications. ing fluid Washer fluid 4-cyl. Petrol/Die- Use a washer antifreeze recommended by Volvo, mixed with water for temperatures below freezing. 5-cyl. Petrol/Die-...
Page 292: Fluids And Lubricants
52 DRIVe Diesel: see page 146 Diesel: D3 and D4 approx. 60 Water quality must fulfil the standard STD 1285.1. Refrigerant quantity varies depending on engine variant. Volvo recommends that you contact an authorised Volvo workshop for the correct information.
Page 293: Fuel
11 Specifications Fuel emissions and fuel consumption 2.0F 254 (242 10.9 (14.8 137 (135 5.9 (8.2 180 (174 7.7 (10.6 10.8 13.5 DRIVe...
Page 294 11 Specifications Fuel • el's basic version, then resistance increa- Choice of tyres can affect fuel consump- : gram/km ses. tion - seek advice on suitable tyres from a dealer. • High speed results in increased wind resis- : litre/100 km tance.
Page 295: Wheel And Tyres, Dimensions And Pressure
11 Specifications Wheel and tyres, dimensions and pressure Approved dimensions shows all approved combinations of wheel drive (AWD) and the type of transmission is rims and tyres, and the lowest permitted load needed to read the table. For information with In certain countries not all approved dimen- index (LI) and speed rating (SS).
Page 296 11 Specifications Wheel and tyres, dimensions and pressure Approved tyre pressures Engine Tyre size Speed (km/h) Load, 1 - 3 persons Max. load Max. load Rear (kPa) Front (kPa) Rear (kPa) Front (kPa) ECO pressure 0–160 195/65 R15 160+ 0–160 205/55 R16 DRIVe 160+...
Page 297 11 Specifications Wheel and tyres, dimensions and pressure Engine Tyre size Speed (km/h) Load, 1 - 3 persons Max. load Max. load Rear (kPa) Front (kPa) Rear (kPa) Front (kPa) ECO pressure 205/55 R16 0–160 205/50 R17 160+ 215/45 R18 Temporary Spare Tyre 0–80 In certain countries there is the "bar"...
Page 298: Electrical System
11 Specifications Electrical system General The battery capacity is dependent upon the capacity as the original battery (see the label equipment level in the vehicle. If the starter on the battery). The car has a voltage-regulated AC alternator. battery is replaced, therefore, you must ensure The electrical system is single-pole and uses that you switch to a battery with the same the chassis and engine casing as a conductor.
Page 299 11 Specifications Electrical system Lighting Output (W) Type Position/Parking lamps, front (Dual Xenon/halogen), Side marker lamps, front W5W LL Fog lamps Side direction indicators, door mirrors WY5W LL Front courtesy lighting T10 Socket W2.1x9.5d Glovebox lighting T10 Socket W2.1x9.5d Vanity mirror lighting* Socket SV5.5 Length 35 mm Cargo area lighting Socket SV8.5 Length 38 mm...
Page 300: Type Approval
11 Specifications Type approval Remote control key system Certification of the Keyless Drive system Country and Siemens VDO Automotive A.G. hereby certifies region that this equipment type 5WK4 8952, 5WK48956, 5WK48812 conforms to the A, B, CY, CZ, D, DK, essential characteristic requirements and other E, EST, F, FIN, GB, Delphi hereby...
Page 301: Symbols In The Display
11 Specifications Symbols in the display General Symbols in the display Symbol Meaning Page There are a variety of different symbols in the Indicator and warning symbols in the Stability sys- 55, 169, 170 display in the car. The symbols are divided into combined instrument panel tem, DSTC* warning, indicator and information symbols.
Page 302 11 Specifications Symbols in the display Information symbols in the centre Symbol Meaning Page Symbol Meaning Page console display Low oil pres- 54, 56 Left direction Symbol Meaning Page sure indicators Surround sound (only Premium Sound) Seatbelt 18, 56 Right direc- reminder tion indicators News...
Page 303 11 Specifications Symbols in the display Information symbols in the roof console display Symbol Meaning Page Seatbelt reminder Airbag, passenger 24, 25 seat, activated Airbag, passenger seat, deactivated...
Page 304: Alphabetical Index
12 Alphabetical Index Air quality system, ECC......98 Auto climate..........97 Air vents............. 93 Automatic car washes......208 Alarm............136 Automatic gearbox electronic climate control..... 99 alarm indicator........136 manual gear positions (Geartronic)..158 manual climate control....94, 95 alarm signals........137 towing and recovery......
Page 305 12 Alphabetical Index start assistance........179 Brakes loading..........188 symbols on the battery....... 227 anti-lock braking system, ABS... 167 load retaining eyelets......118 warning symbols......... 227 brake light..........64 Car settings..........84 Emergency Brake Assistance, EBA ... 168 Bioethanol E85........145 Car upholstery.........
Page 306 12 Alphabetical Index size classes for child seats with the ISO- Combined instrument panel...... 53 Disengaging the gear selector inhibitor... 160 FIX fixture system......... 41 Compass........... 77 Display, messages........58 upper mounting points for child seats.. 44 calibration..........77 Display lighting.......... 63 Cigarette lighter socket setting the zone........
Page 307 12 Alphabetical Index Engine oil......... 220, 221, 288 Flexifuel............ 154 adverse driving conditions....288 adaptation........... 155 ECC, electronic climate control....93 capacities........... 288 Floor mats..........109 filter............. 220 Economical driving........142 Fluids, capacities........290 oil grade..........288 ECO pressure.......... 196 Fluids and oils........
Page 308 12 Alphabetical Index Fuses............237 Inflatable Curtain........28 box in the engine compartment..238 Information display........58 changing..........237 Handbrake..........74 Information on fuel........144 general..........237 Hazard warning flashers......73 Infotainment system relay/fuse box in the passenger com- Headlamp pattern adjustment menus..........
Page 309 12 Alphabetical Index automatic lighting, dipped beam..62 Loading bulbs, specifications......298 general..........188 Kerb weight..........285 dipped beam........62 load capacity........188 display lighting........63 load retaining eyelets......118 front fog lamps........63 keyless lock and ignition system..128 Load retaining eyelets......
Page 310 12 Alphabetical Index Manual gearbox........157 Mobile phone Paintwork GSI - Gear shift indicator.... 157, 164 connect..........276 colour code......... 212 towing and recovery......176 handsfree..........274 damage and touch-up......212 register phone........274 Manual gear positions (Geartronic)..158 Parking assistance........171 Mounting points (child seat)......
Page 311 12 Alphabetical Index Phone Power windows......... 75 Reading lamps, see Lighting....110 calling from the phone book....269 blocking..........76 Rear seat ..........116 connect..........276 passenger seat........76 Rearview and door mirrors controls..........266 rear seat..........76 automatic retracting/extending..79, 84 entering text........
Page 312 12 Alphabetical Index Seatbelt reminder........19 SRS system Remote control, HomeLink general..........22 programmable ........86 Seatbelts............ 18 Stability and traction control system..169 Remote control key......... 153 Seats battery replacement......131 head restraints, rear......116 Stains............210 detachable key blade......123 lowering the rear backrest....
Page 313 12 Alphabetical Index pinch protection........82 Tools............198 maintenance........192 sunscreen..........82 pressure........196, 296 Total airing function......... 133 ventilation position........ 81 puncture repair........202 Towbar, see Towing equipment....182 specifications......192, 295 Sunscreen, sunroof........82 Towing............. 176 speed ratings........192 Surround..........
Page 314 12 Alphabetical Index WHIPS child seat/booster cushion....29 Warning lamp whiplash injury........29 stability and traction control system. . 169 Windscreen wipers........68 Warning symbol, airbag system....21 rain sensor..........69 Warning triangle........197 Winter tyres..........195 Washer fluid, filling........223 Wiper blades..........
Page 316 ©...

Volvo S40 Owner's Manual

Introduction

1 Safety

2 Instruments and Controls

3 Climate Control

4 Interior

5 Locks and Alarm

6 Starting and Driving

7 Wheels and Tyres

8 Car Care

9 Maintenance and Service

Infotainment System

11 Specifications

Quick Links

Owners Manual

Related Manuals for Volvo S40

Summary of Contents for Volvo S40

Table of Contents
