Summary of Contents for Volvo S40

Page 1 VOLVO S40 Owner's manual Web Edition...
Page 3 Welcome to the world-wide family of Volvo owners. We trust that you vehicle if you may be affected by alcohol, medication or any impair- will enjoy many years of safe driving in your Volvo, an automobile ment that could hinder your ability to drive.
Page 4: Table Of Contents
Contents 00 Introduction 01 Safety 02 Instruments and controls Important information....... 10 Occupant safety........18 Instrument overview........54 Environment..........14 Seat belts..........20 Instrument panel........56 Important warnings........15 Supplemental Restraint System....23 Indicator and warning symbols....58 Occupant Weight Sensor (OWS)....28 Symbols –...
Page 5 Contents 03 Climate 04 Interior 05 Locks and alarm General information........94 Front seats..........106 Remote key and key blade..... 122 Air vents............ 96 Interior lighting........110 Valet locking ........... 126 Manual climate control......97 Storage compartments......112 Keyless drive*.......... 127 Electronic Climate Control (ECC)*..
Page 6 Contents 06 Starting and driving 07 Wheels and tires 08 Car care General information........ 140 General information........ 176 Washing and cleaning the car....206 Fuel requirements........144 Tire inflation..........179 Paint touch up......... 210 Ignition switch......... 147 Inflation pressure—U.S. models .... 181 Starting the vehicle.........
Page 7 Contents 09 Maintenance and servicing 10 Audio 11 Specifications Volvo maintenance........214 Introduction ..........242 Label information........268 Maintaining your car....... 215 Audio functions........243 Dimensions and weights......270 Hood............217 Radio functions........248 Fuel, oils, and fluids........ 273 Engine compartment....... 218 CD player..........
Page 8 Contents 12 Index Index............284...
Page 9 Contents...
Page 10: Introduction
• Before you operate your vehicle for the first whose purpose is to provide important infor- Volvo Cars of North America, LLC time, please familiarize yourself with the mation in a clear and concise way. The impor- information found in the chapters "Instru-...
Page 11 Introduction Important information Risk of damage to the vehicle Information Types of lists used in the manual Procedures Procedures (step-by-step instructions), or actions that must be carried out in a certain order, are arranged in numbered lists in this manual. If there is a series of illustrations associated with step-by-step instructions, each step in the procedure is numbered in the same...
Page 12 Cali- fornia to cause cancer, and birth defects or • • Volvo reserves the right to make model Coolant other reproductive harm. In addition, certain changes at any time, or to change spec- •...
Page 13 • Do not export your Volvo to another coun- of the gear selector and move the selector from normal vehicle operation or in a crash or near- try before investigating that country's P (Park).
Page 14: Environment
Recycling ventional gasoline-powered internal combus- As part of Volvo’s commitment to the environ- Volvo is committed to the well being of its cus- tion engines, Volvo is actively looking at ment, it is essential for the vehicle to be recy- tomers.
Page 15: Important Warnings
Your new ted, or if you allow accessories to be instal- quicker and simpler. Volvo is, or can be, equipped with many fea- led by someone unfamiliar with your vehi- • Never use portable computers or personal ture-rich entertainment and communication cle.
Page 16 Occupant safety..................18 Seat belts....................20 Supplemental Restraint System.............. 23 Occupant Weight Sensor (OWS)............. 28 Side impact protection airbags............... 31 Inflatable Curtain (IC)................33 Whiplash Protection System..............35 Crash mode.................... 37 Child safety..................... 38 Child restraint systems................40 Infant seats....................42 Convertible seats..................
Page 17 S A F E T Y...
Page 18: 01 Safety
Safety is Volvo's cornerstone. Our concern If you are taking any medication, consult involved in individual problems dates back to 1927 when the first Volvo rolled your physician about its potential effects between you, your retailer, or Volvo on your driving abilities.
Page 19 If you believe your vehicle has a defect that could cause a crash or could cause injury or death, you should immediately inform Trans- port Canada in addition to notifying Volvo Cars of Canada Corp. To contact Transport Canada, call (800) 333-0510, or (613) 993-9851 if you are calling from the Ottawa region.
Page 20: Seat Belts
Locking Retractor (ALR/ELR) is acti- • Make sure that the shoulder belt is rolled Volvo also believes no child should sit in the vated up into its retractor and that the shoulder front seat of a vehicle.
Page 21 WARNING • Never repair the belt yourself; have this work done by a trained and qualified Volvo service technician only. • Any device used to induce slack into the The seat belt should always be worn during shoulder belt portion of the three-point pregnancy.
Page 22 01 Safety Seat belts seat belts. The audible signal and warning light by pressing the READ button to display stored will be on for a total of 6 seconds from the time messages. the ignition is switched on, regardless of whether or not the seat belts are fastened.
Page 23: Supplemental Restraint System
As an enhancement to the three-point seat 1. Switch off the ignition for at least ence in the system could cause mal- belts, your Volvo is equipped with a Supple- 10 minutes and disconnect the battery. function and serious injury. All work on mental Restraint System (SRS).
Page 24 01 Safety Supplemental Restraint System • The front airbag system The driver's side front airbag is folded and located in the steering wheel hub. • The passenger's side front airbag is folded behind a panel located above the glove compartment. WARNING •...
Page 25 01 Safety Supplemental Restraint System Front airbag deployment Volvo Cars of North America, LLC NOTE • The front airbags are designed to deploy Customer Care Center • Deployment of front airbags occurs only during certain frontal or front-angular col- one time during an accident. In a colli-...
Page 26 01 Safety Supplemental Restraint System WARNING • Do not use child safety seats or child booster cushions/backrests in the front passenger's seat. We also recommend that occupants under 4 feet 7 inches (140 cm) in height who have outgrown these devices sit in the rear seat with the seat belt fastened •...
Page 27 • Feet must be on the floor, e.g., not on side dashboard. This should only be the dash, seat or out of the window. done by a trained and qualified Volvo service technician. • Failure to follow these instructions can...
Page 28: Occupant Weight Sensor (Ows)
Occupant Weight Sensor (OWS) indicator light come on and stay on installed according to the manufacturer's Volvo recommends that ALL occupants (adults instructions, The message PASS. AIRBAG OFF SERVICE and children) shorter than 4 feet 7 inches •...
Page 29 Volvo recommends that children always be properly restrained in appropriate child restraints in the rear seats. Do The OWS is designed to disable (will not inflate)
Page 30 If a child is system's function and result in serious injury seated in the front passenger's seat Volvo Cars of North America, LLC to the occupant of the front passenger's with any additional weight, this extra seat:...
Page 31: Side Impact Protection Airbags
01 Safety Side impact protection airbags Side impact airbags – front seats only NOTE SIPS airbag deployment (one airbag) occurs only on the side of the vehicle affected by the impact. The airbags are not designed to deploy in all side impact situations. Components in the SIPS airbag system This SIPS airbag system consists of gas gen- erators and side airbag modules built into the...
Page 32 Never try to open or repair any compo- nents of the SIPS airbag system. This should be done only by a trained and qualified Volvo service technician. • In order for the SIPS airbag to provide its best protection, both front seat occupants should sit in an upright posi- tion with the seat belt properly fastened.
Page 33: Inflatable Curtain (Ic)
In certain side impacts, both the Inflatable Cur- done only by a trained and qualified tain (IC) and the Side Impact Airbag System Volvo service technician. (SIPS airbag) will deploy. The IC and the SIPS • Never hang heavy items from the ceiling airbag deploy simultaneously.
Page 34: Inflatable Curtain (Ic)
01 Safety Inflatable Curtain (IC) WARNING In order for the VIC to provide its best pro- tection, both front seat occupants and both outboard rear seat occupants should sit in an upright position with the seat belt prop- erly fastened; adults using the seat belt and children using the proper child restraint sys- tem.
Page 35: Whiplash Protection System
Volvo service technician, even ward. This movement helps absorb some of depending on the crash severity, angle if the seats appear to be undamaged.
Page 36 01 Safety Whiplash Protection System Certain components in the WHIPS sys- WARNING WARNING tem may need to be replaced. • Boxes, suitcases, etc. wedged behind the Any contact between the front seat • Do not attempt to service any compo- front seats could impede the function of the backrests and the folded rear seat nent in the WHIPS system yourself.
Page 37: Crash Mode
WARNING ing mode should only be done by a Even if the vehicle appears to be drivable trained and qualified Volvo service tech- after CRASH MODE has been set, it should nician. not be driven or towed (pulled by another •...
Page 38: Child Safety
When a child has outgrown the child safety or increasing the injury of a child. seat, you should use the rear seat with the Volvo recommends the proper use of restraint standard seat belt fastened. The best way to systems for all occupants including children.
Page 39 Volvo's recommendations seat: • Why does Volvo believe that no child should sit Drive safely! 1. Attach the seat belt to the child seat in the front seat of a car? It's quite simple really. according to the child seat manufacturer's A front airbag is a very powerful device instructions.
Page 40: Child Restraint Systems
01 Safety Child restraint systems Child restraints Convertible seat WARNING Infant seat WARNING There are three main types of child restraint Always refer to the child restraint manufac- A child seat should never be used in the turer's instructions for detailed information systems: infant seats, convertible seats, and front passenger seat of any vehicle with a on securing the restraint.
Page 41 • A small child's head represents a con- siderable part of its total weight and its neck is still very weak. Volvo recom- mends that children up to age 4 travel, properly restrained, facing rearward. In addition, Volvo recommends that chil- dren should ride rearward facing, prop- erly restrained, as long as possible.
Page 42: Infant Seats
01 Safety Infant seats Securing an infant seat with a seat belt WARNING • An infant seat must be in the rear-facing position only. • The infant seat should not be positioned behind the driver's seat unless there is adequate space for safe installation. 1.
Page 43 01 Safety Infant seats and is normal. The seat belt should now be locked in place. Pull out the shoulder section of the seat belt 4. Pull the shoulder section of the seat belt out as far as possible to activate the belt's Ensure that the seat is securely in place automatic locking function.
Page 44: Convertible Seats
See the con- able part of its total weight and its neck is vertible seat manufacturer's recommenda- still very weak. Volvo recommends that chil- tions. dren up to age 4 travel, properly restrained, facing rearward.
Page 45 01 Safety Convertible seats NOTE WARNING The locking retractor will automatically It should not be possible to move the child release when the seat belt is unbuckled and restraint (child seat) more than 1 in. (2.5 cm) allowed to retract fully. in any direction along the seat belt path.
Page 46: Booster Cushions
01 Safety Booster cushions Securing a booster cushion Booster cushions are recommended for chil- dren who have outgrown convertible seats. 1. Place the booster cushion in the rear seat of the vehicle. 2. With the child properly seated on the booster cushion, attach the seat belt to or around the cushion according to the man- ufacturer's instructions.
Page 47: Isofix/Latch Lower Anchors
(see the illustration). WARNING To access the anchors: 1. Put the child restraint in position. Volvo's ISOFIX/LATCH anchors conform to Fasten the attachment correctly to the ISOFIX/ FMVSS/CMVSS standards. Always refer to 2. Kneel on the child restraint to press down...
Page 48 01 Safety ISOFIX/LATCH lower anchors WARNING Be sure to fasten the attachment correctly to the anchor (see the illustration). If the attachment is not correctly fastened, the child restraint may not be properly secured in the event of a collision.
Page 49: Top Tether Anchors
Top tether anchorage points WARNING seat belts are installed to them. An adult Volvo vehicles are equipped with child restraint who uses a belt anchored in a child Be sure to fasten the child tether attachment top tether anchorages in the rear seating posi- restraint anchorage runs a great risk of correctly to the anchor.
Page 50: Child Restraint Registration And Recalls
01 Safety Child restraint registration and recalls Registering a child restraint Child restraints could be recalled for safety reasons. You must register your child restraint to be reached in a recall. To stay informed about child safety seat recalls, be sure to fill out and return the registration card that comes with new child restraints.
Page 51 01 Safety...
Page 52 Instrument overview................54 Instrument panel..................56 Indicator and warning symbols............... 58 Symbols – instrument panel..............60 Information display.................. 63 12-volt sockets..................65 Lighting panel..................66 Left-side steering wheel lever..............69 Trip computer..................71 Cruise control*..................73 Right-side steering wheel lever............... 75 Steering wheel adjustment, Hazard warning flashers......
Page 53 I N S T R U M E N T S A N D C O N T R O L S...
Page 54: 02 Instruments And Controls
02 Instruments and controls Instrument overview...
Page 55 02 Instruments and controls Instrument overview Steering wheel adjustment Courtesy lighting switch Position for optional equipment Hood opener Driver's side reading light Position for optional equipment Controls in front doors Passenger's side reading light Control panel in driver's door Left steering wheel lever Seat belt reminder and Occupant Weight Sensor indicator Lighting panel, fuel filler door opener...
Page 56: Instrument Panel
02 Instruments and controls Instrument panel Instrument panel Speedometer the temperature readings may be slightly sively high engines speeds. This will be higher than the actual ambient tempera- noticeable as a pronounced unevenness in Turn signal, left ture. engine speed. Warning symbol –...
Page 57 02 Instruments and controls Instrument panel odometer, trip odometers, optional rain sensor, and cruise control. Trip odometer reset button – The trip odometers are used to measure short dis- tances. Press the button briefly to switch between the odometer for the car's total mileage and the two trip odometers, T1 and T2.
Page 58: Indicator And Warning Symbols
3. Follow the instructions provided, or con- When the engine starts, all sym- tact a trained and qualified Volvo service bols go out. If the engine is not technician. Erase the message by pressing started within 5 seconds, all of the READ, see page 63.
Page 59 02 Instruments and controls Indicator and warning symbols This symbol may also light up in combination with other indicator or warning symbols. NOTE The car can still be driven after the informa- tion symbol has come on. The car can be driven for 1–2 weeks after service-related information has been displayed.
Page 60: Symbols - Instrument Panel
The CHECK ENGINE light will light up if the Canadian models are equipped with the computer senses a condition that potentially second symbol. may need correcting. When this happens, please have your car checked by a trained and qualified Volvo service technician as soon as possible.
Page 61 Volvo service technician. After hard driv- ing, the light may come on occasionally when the engine is idling. This is normal, provided it goes off when the engine speed is increased.
Page 62 DO NOT DRIVE. Have the information display indicating which door(s), car towed to a trained and qualified Volvo etc is not completely closed. service technician and have the brake sys- tem inspected.
Page 63: Information Display
..SERVICE Take your car to a using the trip computer, this message must trained and qualified REQUIRED be read before you can access the trip com- Volvo service techni- puter. cian for inspection as soon as possible (but Message Meaning...
Page 64 02 Instruments and controls Information display Message Meaning TIME FOR This message is affec- ted by the number of REGULAR miles/km driven, by the MAINTE- number of months, or NANCE by the number of engine hours since the service reminder was reset at the most recent regu- larly scheduled service.
Page 65: 12-Volt Sockets
The cover should be kept on when the aux- iliary socket is not in use. Auxiliary equipment The buttons to the left of the 12-volt socket can be used for Volvo-installed optional or auxiliary equipment. 12-volt socket (rear seat) 12-volt socket, auxiliary equipment...
Page 66: Lighting Panel
02 Instruments and controls Lighting panel Parking lights Active Bending Lights (ABL)* Pos. Lighting Daytime running lights off. High beam flash only. Parking lights Daytime running lights. High beams and high beam flash can be used in this position. The front and rear parking lights can be turned on even when the ignition is switched off.
Page 67 02 Instruments and controls Lighting panel Brake lights NOTE The brake lights come on automatically when The rear fog lights are considerably brighter the brakes are applied. than the normal taillights and should be used only when conditions such as fog, rain, snow, smoke or dust reduce visibility for Fog lights other vehicles to less than 500 ft.
Page 68 02 Instruments and controls Lighting panel Unlocking the fuel filler door With the ignition switched off, press button (4) to unlock the fuel filler door. Please note that the fuel filler door will remain unlocked until the car begins to move forward. An audible click will be heard when the fuel filler door re-locks.
Page 69: Left-Side Steering Wheel Lever
02 Instruments and controls Left-side steering wheel lever Lever positions Turn signals High/low beam headlights When turning Continuous high beams ± Move the lever as far up or down as pos- 1. Turn the ignition key to position II. sible (to position 2) to start the turn signals. 2.
Page 70 02 Instruments and controls Left-side steering wheel lever preferences by using the Personal Settings function, see page 85 for more information.
Page 71: Trip Computer
02 Instruments and controls Trip computer • --- MPH ACTUAL SPEED (current speed 1. Select one of these functions. in mph, Canadian models only) 2. Press RESET (3). • STC/DSTC-related information, see --- MILES TO EMPTY TANK page 158 This function shows the approximate distance that can be driven on the fuel remaining in the NOTE tank.
Page 72 02 Instruments and controls Trip computer stored and remains in system memory until the RESET (button 3) is pressed again. MPH ACTUAL SPEED (Canadian models only) This function provides the driver with an instan- taneous conversion of the car's current speed from km/h to mph.
Page 73: Cruise Control
02 Instruments and controls Cruise control* Engaging the cruise control function Increasing or decreasing speed NOTE • Cruise control will not function at speeds below 20 mph (30 km/h). • Momentary acceleration, for less than 1 minute (e.g. when passing another car), does not affect cruise control oper- ation.
Page 74 02 Instruments and controls Cruise control* • During wheel spin or wheel lock-up. • If the vehicle's speed is increased by using the accelerator pedal for more than 1 minute. Returning to the set speed Press the button to resume the previously set speed.
Page 75: Right-Side Steering Wheel Lever
02 Instruments and controls Right-side steering wheel lever Windshield wipers Manual wiper function CAUTION From position 0, move the lever • Use ample washer fluid when washing upward. The windshield wipers will the windshield. The windshield should sweep one stroke at a time for as be thoroughly wet when the wipers are long as the lever is held up.
Page 76 02 Instruments and controls Right-side steering wheel lever – Rain sensor* 3. Press button B (see page 75). The rain sen- – Thumb wheel sor symbol will appear in the lower display. The thumb wheel is used to set the wiper inter- val when intermittent wiping is selected, or the Manual deactivation sensitivity to the amount of rain on the wind-...
Page 77: Steering Wheel Adjustment, Hazard Warning Flashers
02 Instruments and controls Steering wheel adjustment, Hazard warning flashers Steering wheel adjustment Check that the steering wheel is locked in the 2. Press the button again to turn off the flash- new position. ers. WARNING NOTE Never adjust the steering wheel while driv- •...
Page 78: Power Windows
02 Instruments and controls Power windows Operation Opening a window to close a window to the position of your choice. Lightly press down the front edge of any of the buttons (A or B) to the first detent ("stop") to 2.
Page 79 02 Instruments and controls Power windows buttons on the rear door armrests or with the Power window controls – rear doors buttons on the driver's door armrest. If the light in the switch is ON: The rear door windows can only be raised or lowered with the buttons on the driver's door.
Page 80: Mirrors
02 Instruments and controls Mirrors Rearview mirror Rearview mirror with compass* Calibrating the compass Day/night control The earth is divided into 15 magnetic zones. The upper right-hand corner of the rearview The compass is initially set for the zone to mirror has an integrated display that shows the Normal position which the car was delivered, and should...
Page 81 02 Instruments and controls Mirrors Power door mirrors Use this control to adjust the driver's door mirror. Passenger's door mirror: 1. Press the R switch (a light in the switch will go on) to activate the adjustment control. Use this control to adjust the passenger's door mirror.
Page 82 02 Instruments and controls Mirrors Folding the mirrors out 1. Fold in the mirrors by pressing the L and R mirror control buttons on the driver's Fold out the mirrors by pressing down the L door at the same time. and R buttons at the same time.
Page 83: Power Moonroof
02 Instruments and controls Power moonroof* Operating the moonroof Sliding moonroof Auto open/close Open: Pull the switch as far back as possible (to position 1) and release it to automatically slide open the moonroof. Close: Push the switch as far forward as pos- sible (to position 4) and release it to automati- cally close the moonroof.
Page 84 02 Instruments and controls Power moonroof* Visor Wind blocker CAUTION • Remove ice and snow before opening the moonroof. • Do not operate the moonroof if it is fro- zen closed. • Never place heavy objects on the moonroof. WARNING •...
Page 85: Personal Settings
02 Instruments and controls Personal settings Control panel Personal settings can be made for some of the 2. Select hour(s) or minute(s) to be changed car's functions, such as the central locking with the left/right arrow keys. system, climate control, and the audio system. 3.
Page 86 02 Instruments and controls Personal settings • Global (All doors) – unlocks all doors and Temporarily turning off the alarm Information the trunk with one press on the remote key. • VIN number – The VIN (Vehicle Identifica- sensor(s) tion Number) is the car's unique identity •...
Page 87 02 Instruments and controls Personal settings • Both front doors – both front doors are unlocked together. • One front door – either of the front doors can be unlocked separately Reset to factory settings Use this alternative to return to the default cli- mate system settings.
Page 88: Homelink® Wireless Control System
02 Instruments and controls HomeLink® Wireless Control System* Introduction Programming HomeLink WARNING • If you use HomeLink to open a garage NOTE door or gate, be sure no one is near the gate or door while it is in motion. Some vehicles may require the ignition switch to be turned on or to the second •...
Page 89 02 Instruments and controls HomeLink® Wireless Control System* found where the hanging antenna wire is cedures, replace “Programming HomeLink” NOTE attached to the motor-head unit. step 2 with the following: Some devices may require you to replace • 5. Firmly press and release the “learn” or Continue to press and hold the HomeLink this Programming Step 2 with procedures button while you press and release -...
Page 90 02 Instruments and controls HomeLink® Wireless Control System* Erasing HomeLink Buttons For questions or comments, contact HomeLink at: www.homelink.com or 1–800–355–3515. To erase programming from the three Home- Link buttons (individual buttons cannot be This device complies with FCC rules part 15 erased but can be “reprogrammed”...
Page 91 02 Instruments and controls...
Page 92 General information................. 94 Air vents....................96 Manual climate control................97 Electronic Climate Control (ECC)*............100 Air distribution..................103 Option/accessory, for more information, see Introduction.
Page 93 C L I M A T E...
Page 94: 03 Climate
Work of this type should only be done NOTE NOTE by a trained and qualified Volvo service tech- nician. There are different types of cabin air filters. In warm weather, a small amount of water Ensure that the correct type is installed.
Page 95 03 Climate General information For information about how to make these set- closed. If you drive with the windows or moon- tings, see the Personal settings section on roof open, it may be preferable to manually page 85. adjust the temperature and blower control (the LED in the AUTO switch should be off).
Page 96: Air Vents
03 Climate Air vents Air vents in the dashboard Open Closed Horizontal air flow Vertical air flow Direct the outer air vents toward the side win- dows to defrost.
Page 97: Manual Climate Control
03 Climate Manual climate control Climate system control panel Blower speed Manual climate system functions 2. Recirculation This function can be used to Recirculation 1. Blower shut out exhaust fumes, The blower speed can be smoke, etc from the passen- Defroster increased or decreased by ger compartment.
Page 98 03 Climate Manual climate control ± Timer 4. Airflow controls Press the button once – both LEDs light up. The timer function minimizes the risk of mist- Press one of the three buttons Reduced heating: ing, or stale air when the recirculation function in the illustration to activate ±...
Page 99 03 Climate Manual climate control 9. Temperature selector The knob with the thermome- ter symbol is used to select cooling or heating for both the driver's and passenger's sides of the car.
Page 100: Electronic Climate Control (Ecc)
03 Climate Electronic Climate Control (ECC)* Auto – On/Off ECC functions NOTE Blower speed • The sunlight sensor on the upper side of 1. Auto – On/Off the dashboard and the passenger com- The AUTO function automat- Recirculation partment temperature sensor, located ically regulates climate con- behind the climate system control Defroster...
Page 101 03 Climate Electronic Climate Control (ECC)* 2. Blower speed Timer 5. Airflow controls The blower speed can be The timer function minimizes the risk of fogging Press one of the three buttons increased or decreased by or stale air when the recirculation function is in the illustration to activate turning the knob.
Page 102 03 Climate Electronic Climate Control (ECC)* 7 and 8. Heated front seats* once. The defrost function is active if the LED 1. Press the knob once. The LED for one side in the switch is illuminated. of the car will light up. Turn the knob to adjust the temperature.
Page 103: Air Distribution
03 Climate Air distribution Air distribution Use: Air distribution Use: Defroster. Defrost/de-fog the wind- Air to the floor and win- For comfortable condi- shield and front side win- dows. tions and good defrosting Air is not recirculated in dows. in cold weather. this mode.
Page 104 Front seats.................... 106 Interior lighting..................110 Storage compartments................. 112 Rear seat....................115 Trunk ....................118...
Page 105 I N T E R I O R...
Page 106: 04 Interior
04 Interior Front seats Manual seat adjustment Turn this knob to adjust the backrest tilt. Power seats* The power driver's seat can be adjusted: Control panel for the optional power seats. • If the ignition key is in position I or II. •...
Page 107 04 Interior Front seats Adjusting the seat Programming the seat memory, driver's NOTE seat only* Both front seats are equipped with head restraints that can be adjusted vertically to suit the height of the passenger. The upper edge of the head restraint should be at least on a level with the upper-most point of the seat occupant's ear (see the section "Adjusting the front seat head restraints"...
Page 108 04 Interior Front seats 1. Adjust the seat to the desired position. the doors were most recently locked with Adjusting the front seat head restraints the same remote key. 2. Press and hold down the "M" (Memory) button. NOTE 3. With the "M" button depressed, press The memory function in the remote key memory button 1 to store the seat's current operates independently the memory func-...
Page 109 04 Interior Front seats The head restraints should be put in the upper WARNING WARNING or lower position according to the height of the After adjusting the head restraint, be sure • If a front seat head restraint has been occupant of the seat.
Page 110: Interior Lighting
04 Interior Interior lighting ± Interior lighting Neutral position: the interior courtesy light- 5 minutes after the engine has been switched ing comes on when a door is opened, and off. is switched off 10 seconds after the door is Footwell lighting closed.
Page 111 04 Interior Interior lighting function if the ignition key is in positions I, II, or if the engine is running. The courtesy lighting can be switched on or off within 30 minutes after the engine has been switched off, or after a door has been opened or closed.
Page 112: Storage Compartments
04 Interior Storage compartments...
Page 113 04 Interior Storage compartments Storage pocket (on the rear side of the front Glove compartment Storage under the front, center armrest seats) Compartment in door panel Storage pocket (on the front side of the front seat cushion) Glove compartment Storage compartment for e.g., CDs and cup holders Rear seat storage compartment and cup holders...
Page 114 04 Interior Storage compartments CD storage Cup holders in the center console Storage compartment behind the gear lever The deep storage compartment has room for Two cup holders are located under the sliding 10 CD jewel cases. These cases must be cover in the center console.
Page 115: Rear Seat
04 Interior Rear seat Rear seat head restraints Each of the rear seating positions is equipped WARNING with a head restraint that can be adjusted ver- If a head restraint has been removed, it must tically to suit the height of the passenger. The be put properly back in place and it must upper edge of the head restraint should be at lock (click) into one of the available adjust-...
Page 116 04 Interior Rear seat 3. Fold the backrest down partially and CAUTION remove the outboard head restraints. • When the backrests are folded down, Press the center head restraint down com- the head restraints may be damaged if pletely or remove it. they are not removed.
Page 117 04 Interior Rear seat WARNING • The red lock indicator is VISIBLE when the backrest is NOT locked in position and hidden when the backrest is cor- rectly locked in place. When the back- rest is in the upright position, push and pull it to make sure that it is correctly locked in place.
Page 118: Trunk
04 Interior Trunk Load anchoring eyelets The eyelets in the trunk can be used to fasten accessory load and lashing straps, load nets, and other load anchors.
Page 119 04 Interior...
Page 120 Remote key and key blade..............122 Valet locking ..................126 Keyless drive*..................127 Locking and unlocking................131 Child safety locks.................. 133 Alarm*....................134 Option/accessory, for more information, see Introduction.
Page 121 L O C K S A N D A L A R M...
Page 122: 05 Locks And Alarm
If either of the remote keys is lost, the other programmed and used for one car. ence that may cause undesired operation. should be taken with the car to a Volvo retailer. As an anti-theft measure, the code of the lost Canada – IC: 3659A-WFS125VO remote key must be erased from the system.
Page 123 05 Locks and alarm Remote key and key blade Remote key functions Unlock – Press the Unlock button on the 2 minutes unless a door or the trunk has been opened. remote once to unlock the driver's door. After a short pause, press the Unlock but- •...
Page 124 Information symbol in the instrument panel at a recycling center or by a trained and quali- fied Volvo service technician. tions. To activate the panic alarm, press (see page 58) lights up and KEY BATTERY...
Page 125 05 Locks and alarm Remote key and key blade While holding the catch, pull the key blade Locking the doors with the detached key out of the remote key. blade 1. Lock the other door(s) by pressing the lock Reinserting the key blade in the remote button on each door.
Page 126: Valet Locking
05 Locks and alarm Valet locking Locking points Turn the key blade 180° clockwise to lock the glove compartment and disconnect the trunk from the central locking system (a mes- sage appears in the information display) remote key: Locking/unlocking points with key blade removed (with valet locking activated) remote key: Normal locking/unlocking points Give the parking attendant or service person-...
Page 127: Keyless Drive
05 Locks and alarm Keyless drive* Keyless locking and unlocking Both of the remote keys provided with the vehi- Locking the vehicle cle have the keyless function, and additional remotes can be ordered. The system can accommodate up to six keyless drive remote keys.
Page 128 05 Locks and alarm Keyless drive* Locking or unlocking the vehicle with the to unlock the driver's door only. This will NOTE trigger the alarm. key blade If several people carrying keyless drive • To disable the alarm: Press the Unlock remote keys approach the vehicle at the button on the keyless drive remote key.
Page 129 05 Locks and alarm Keyless drive* KR55WK48964 Location of the keyless drive antennas CAUTION NOTE • Keyless drive remote keys should never This device complies with part 15 of the FCC be left in the vehicle. In the event of a Rules.
Page 130 05 Locks and alarm Keyless drive* WARNING People with implanted pacemakers should not allow the pacemaker to come closer than 9 inches (22 cm) to any of the keyless drive system's antennas. This is to help pre- vent interference between the pacemaker and the keylesss drive system.
Page 131: Locking And Unlocking
05 Locks and alarm Locking and unlocking Locking/unlocking the vehicle from the Opening the trunk from the inside NOTE inside • The ignition key must be in position I or higher (see page 147) before all side windows can be opened using the switches in the front doors.
Page 132 05 Locks and alarm Locking and unlocking Locking the glove compartment The glove compartment can only be locked and unlocked using the detachable key blade on the remote key, see page 124 for informa- tion on removing the key blade from the remote key.
Page 133: Child Safety Locks
05 Locks and alarm Child safety locks Manual child safety locks, rear doors The controls are located on the rear inside edges of the doors, and are only accessible when the doors are open. 1. Remove the key blade from the remote key, see page 124.
Page 134: Alarm
The alarm is automatically armed whenever the sage will be shown in the information dis- car is locked with the remote key, or if a front play. Contact your Volvo retailer to have lock button is depressed. the alarm system inspected and repaired if When armed, the alarm continuously monitors necessary.
Page 135 05 Locks and alarm Alarm* Turning off (stopping) the alarm Temporarily turning off the accessory In certain situations it may be desirable to turn off the accessory inclination and movement alarm sensor(s) If the alarm is sounding, it can be stopped by alarm sensors if, for example, you drive your pressing the UNLOCK button on the remote vehicle onto a ferry where the rocking of the...
Page 136 05 Locks and alarm Alarm* The next time the ignition key is turned to posi- interference that may cause undesired opera- tion II, the sensors will be reactivated and tion of the device. FULL GUARD will displayed. • If you do not wish to deactivate the sen- sors, do not choose an alternative and lock the vehicle or press EXIT and lock the vehi- cle.
Page 137 05 Locks and alarm...
Page 138 General information................140 Fuel requirements................. 144 Ignition switch..................147 Starting the vehicle................148 Starting the vehicle with keyless drive*..........150 Automatic transmission................ 151 Shiftlock override.................. 153 Brake system..................154 Parking brake..................157 Stability system..................158 Towing....................160 Jump starting..................162 Towing a trailer..................
Page 139 S T A R T I N G A N D D R I V I N G...
Page 140: 06 Starting And Driving
06 Starting and driving General information • Economical driving conserves natural Note that roof racks, ski racks, etc, WARNING increase air resistance and also fuel con- resources Driving with the trunk open: Driving with sumption. Better driving economy may be obtained by the trunk open could lead to poisonous •...
Page 141 "recycled" antifreeze is not approved by Synthetic oil is not used when the oil is changed at the normal maintenance intervals except at owner request and at additional charge. Please consult your Volvo retailer.
Page 142 Have the transmission oil level checked • Check condition of drive belts. To prevent injury from contact with hot surfaces, do not inspect your vehicle's transmission fluid yourself. Have your vehicle's transmission fluid level inspected by a qualified Volvo service technician.
Page 143 • Reflective warning triangles are legally required in some states/provinces. • Have a word with your Volvo retailer if you intend to drive in countries where it may be difficult to obtain the correct fuel. • Consider your destination. If you will be driving through an area where snow or ice are likely to occur, consider snow tires.
Page 144: Fuel Requirements
Typical pump octane label injury. strongly linked to certain forms of cancer. Volvo recommends premium fuel for best per- Many fuels contain benzene as a solvent. formance, but using 87 octane or above will...
Page 145 "oxygenated" fuel. Volvo allows the unlocked.
Page 146 If the fuel filler cap is not closed tightly or if the engine is running when the vehicle is refueled, the Check Engine Light (malfunction indicator lamp) may indicate a fault. However, your vehicle’s performance will not be affected. Use only Volvo original or approved fuel filler caps.
Page 147: Ignition Switch
06 Starting and driving Ignition switch Ignition switch positions II – Drive position The key's position when driv- 0 – Locked position ing. The vehicle's entire elec- Remove the key to lock the trical system is activated. steering wheel . Never turn the key to position 0 while driving or when the vehicle is being towed.
Page 148: Starting The Vehicle
06 Starting and driving Starting the vehicle To start the engine ate automatically (for up to ten seconds) NOTE until the engine starts. If the engine fails to WARNING • Immobilizer: If two of the keys to your start, repeat this step. vehicle are close together, e.g., on the Before starting, check that the seat, steering 4.
Page 149 06 Starting and driving Starting the vehicle WARNING • Volvo's floor mats are specially manu- factured for your car. They must be firmly secured in the clips on the floor so that they cannot slide and become trap- ped under the pedals on the driver's side.
Page 150: Starting The Vehicle With Keyless Drive
06 Starting and driving Starting the vehicle with keyless drive* Starting a vehicle with keyless drive 1. Press the brake pedal. 2. Press in the keyless drive start control and turn it to position III. NOTE The vehicle is equipped with an autostart function that makes it possible to start the engine without holding the start control in position III.
Page 151: Automatic Transmission
06 Starting and driving Automatic transmission Shiftgate positions Gear selector positions R – Reverse The car must be stationary when shifting to P – Park position R. Select the P position when starting or parking. N – Neutral In P, the transmission is mechanically blocked N is the neutral position.
Page 152 06 Starting and driving Automatic transmission based on the level of acceleration and speed. time and will utilize the braking power of Kickdown will not occur if the driver attempts the engine. If the current speed is too high The car must be at a standstill when shifting to to use this function when engine speeds are for using a lower gear, the downshift will too high.
Page 153: Shiftlock Override
06 Starting and driving Shiftlock override Overriding the shiftlock system 4. Insert the key blade, see page 124, into the opening and press it down until it bottoms. 5. With the key blade pressed down, move the gear selector out of the P position. Shiftlock prevents the gear selector from being moved out of the P position unless the ignition key is in position II and the brake pedal is...
Page 154: Brake System
This will cause a DRIVE. Have the vehicle towed to a Volvo braking force on the vehicle is reduced. delay in braking effect when the pedal is retailer and have the brake system inspec- depressed.
Page 155 Volvo service technician to have the brake system level roads. To reduce the strain on the brakes, Electronic Brake Force Distribution checked.
Page 156 06 Starting and driving Brake system NOTE • When the EBA system is activated, the brake pedal will go down and pressure in the brake system immediately increa- ses to the maximum level. You must maintain full pressure on the brake pedal in order to utilize the system com- pletely.
Page 157: Parking Brake
06 Starting and driving Parking brake Parking brake (hand brake) 4. If the vehicle rolls, the parking brake lever must be pulled more firmly. 5. When parking a vehicle always put the gear selector in P. Parking on a hill •...
Page 158: Stability System
06 Starting and driving Stability system Stability Traction Control (STC)/ Temporarily switching off Spin control Dynamic Stability Traction Control 1. Turn the thumbwheel (A) on the left-side (DSTC) steering wheel lever until the STC/DSTC menu is displayed. The stability system consists of a number of functions designed help reduce wheel spin, 2.
Page 159 A trained and qualified may be a fault in the stability system. Con- Volvo service technician should check the sult a trained and qualified Volvo service system. technician. •...
Page 160: Towing
6. When towing has been completed, return WARNING the gear selector to Park and apply the parking brake. Volvo does not recommend towing a disa- bled vehicle behind another vehicle. Signif- The following points should also be icant difficulty in steering and braking, com-...
Page 161 06 Starting and driving Towing Towing vehicles with front wheel drive WARNING WARNING Volvo recommends the use of flat bed equip- • • Never allow a vehicle to be towed with- Remember that the power brakes and ment for towing vehicles with front wheel drive.
Page 162: Jump Starting
06 Starting and driving Jump starting Jump starting the vehicle your vehicle's battery (2), marked with a WARNING "+" sign. • Do not connect the jumper cable to any 3. Connect the auxiliary battery's negative (–) part of the fuel system or to any moving terminal (3) to the ground point in your parts.
Page 163: Towing A Trailer
General information Engine and transmission are subject to WARNING increased loads. Therefore, engine coolant • Volvo recommends the use of Volvo trailer • Bumper-attached trailer hitches must temperature should be closely watched hitches that are specially designed for the not be used on Volvos, nor should when driving in hot climates or hilly terrain.
Page 164 (using too high a gear). • The drawbar assembly/trailer hitch may be rated for trailers heavier than the vehicle is designed to tow. Please adhere to Volvo's recommended trailer weights. • Avoid driving with a trailer on inclines exceeding 15%.
Page 165: Detachable Trailer Hitch
06 Starting and driving Detachable trailer hitch Installing the ball holder 4. Slide the locking bolt through the hitch assembly/ball holder. 5. Insert the cotter pin in the hole at the end of the locking bolt. Removing the ball holder 1.
Page 166: Transporting Loads
To avoid damaging your car and to achieve seat backrest. maximum safety when driving, we recom- • Load heavy cargo as low as possible. mend using the load carriers that Volvo has • Center wide loads. developed especially for your car. •...
Page 167: Blind Spot Information System (Blis)
If your vehicle is The BLIS system should only be repaired by passed on both sides at the same time, both a trained and qualified Volvo service tech- lights will illuminate. nician. Option/accessory, for more information, see Introduction.
Page 168 06 Starting and driving Blind Spot Information System (BLIS)* When does BLIS function Darkness NOTE BLIS reacts to the headlights of surrounding The system functions when your vehicle is If the BLIS indicator lights illuminate occa- vehicles. In order to be detected by BLIS, a moving at speeds above 6 mph (10 km/h).
Page 169 System status a highway display BLIS not functioning BLIS SERVICE REQUIRED properly. Contact an authorized Volvo serv- ice technician. BLIS camera obscured. BLIS CAMERA BLOCKED Clean the lenses. Sunlight directly in the camera when the sun is low on the horizon...
Page 170 06 Starting and driving Blind Spot Information System (BLIS)* Text in the System status display BLIS OFF BLIS system off BLIS REDUCED The BLIS cameras' function has been FUNCTION reduced due to weak or impaired data transfer between the BLIS sys- tem's cameras and the vehicle's electrical sys- tem.
Page 171: Rear Park Assist
The system is activated automatically when the Rear park assist is deactivated automati- you when driving into parking spaces, garages, vehicle is started. cally when towing a trailer if Volvo genuine etc. It utilizes four ultrasound sensors located ± trailer wiring is used.
Page 172 The sensors must be cleaned regularly to Consult a Volvo retailer or authorized Volvo ensure that they work properly. Clean them service technician. with water and a suitable car washing deter- gent.
Page 173 06 Starting and driving...
Page 174 General information................176 Tire inflation................... 179 Inflation pressure—U.S. models ............181 Inflation pressure—Canadian models ..........182 Tire designations................... 183 Glossary of tire terminology..............185 Vehicle loading..................186 Uniform tire quality gradings..............188 Snow chains, snow tires, studded tires..........189 Temporary spare................... 190 Wheel nuts....................
Page 175 W H E E L S A N D T I R E S...
Page 176: 07 Wheels And Tires
Otherwise there is a risk of altering at 6-year intervals, even if it has never been the car's roadholding and handling characte- Some Volvo models are equipped with an used. ristics. Ultra High Performance tire and wheel com-...
Page 177 • The wheel and tire sizes for your Volvo wheels to reduce the chance of oversteer aside rain, snow and slush. are specified to meet stringent stability during hard braking.
Page 178 Tire rotation is not included in regularly scheduled maintenance and is performed only at customer request, at additional charge. Your Volvo retailer can also provide guidance based on your particular driving circumstan- The tires have wear indicator strips running ces.
Page 179: Tire Inflation
07 Wheels and tires Tire inflation Inflation placard your tire pressures frequently and adjust them NOTE to the proper pressure, which can be found on The placards shown indicate inflation pres- the vehicle's tire information placard or certifi- sure for the tires installed on the car at the cation label.
Page 180 07 Wheels and tires Tire inflation To check inflation pressure: Load ratings 1. Remove the cap from the valve on one tire, See page 183 for an explanation of the load then firmly press the tire gauge onto the rating on the sidewall of the tire. valve.
Page 181: Inflation Pressure-U.s. Models
The following tire pressures are recommended your vehicle at the factory. by Volvo for your vehicle. Refer to the tire infla- Tire size Cold tire pressure up to five persons psi (kPa) Front...
Page 182: Inflation Pressure-Canadian Models
(see page 179 for its location) for information specific to the tires installed on The following tire pressures are recommended your vehicle at the factory. by Volvo for your vehicle. Refer to the tire infla- Tire size Cold tire pressures Optional pressure...
Page 183: Tire Designations
07 Wheels and tires Tire designations Tire designations 215: The width of the tire (in millimeters) M+S or M/S = Mud and Snow, AT = All from sidewall edge to sidewall edge. The Terrain, AS = All Season larger the number, the wider the tire. U.S.
Page 184 07 Wheels and tires Tire designations Treadwear, Traction, and Temperature grades: See page 188 for more informa- tion. Maximum permissible inflation pres- sure: The greatest amount of air pressure that should ever be put in the tire. This limit is set by the tire manufacturer. The tire suppliers may have additional mark- ings, notes or warnings such as standard load, radial tubeless, etc.
Page 185: Glossary Of Tire Terminology
41 psi [43 psi (2.9 bar) for Metric • Recommended tire inflation pressure: tires]. Increasing the inflation pressure inflation pressure, established by Volvo, beyond this pressure will not increase the which is based on the type of tires that are tires load carrying capability.
Page 186: Vehicle Loading
07 Wheels and tires Vehicle loading Loading the vehicle Motor Vehicle Safety Standards (FMVSS/ 3. Subtract the combined weight of the driver CMVSS) label. The total load on each axle must and passengers from XXX kilograms or Before loading your vehicle, familiarize yourself never exceed its maximum permissible weight.
Page 187 Do not use replacement tires with lower load carrying capacities than the tires that were original equipment on the vehicle because this will lower the vehi- cle's GVW rating. Use only tires with the correct load carrying capacity. Consult your Volvo retailer for information.
Page 188: Uniform Tire Quality Gradings
07 Wheels and tires Uniform tire quality gradings Uniform tire quality gradings faces of asphalt and concrete. A tire marked C WARNING may have poor traction performance. The trac- ALL PASSENGER VEHICLE TIRES MUST The temperature grade for this tire is estab- tion grade assigned to this tire is based on CONFORM TO FEDERAL SAFETY lished for a tire that is properly inflated and...
Page 189: Snow Chains, Snow Tires, Studded Tires
Snow chains, snow tires, studded tires Snow chains ure to do so could reduce traction to an CAUTION unsafe level or adversely affect handling. Snow chains can be used on your Volvo with • Check local regulations regarding the • the following restrictions: Do not mix tires of different design as this use of snow chains before installing.
Page 190: Temporary Spare
In the event of damage to this tire, a new one can be purchased from your Volvo retailer. WARNING Current legislation prohibits the use of the "Temporary Spare"...
Page 191: Wheel Nuts
07 Wheels and tires Wheel nuts Wheel nuts Steel rims – type 1 wheel nuts Steel rims are normally secured using type 1 wheel nuts, although these rims may also be secured with type 2 nuts. WARNING Never use type 1 wheel nuts for aluminum wheels.
Page 192: Spare Tire And Jack
07 Wheels and tires Spare tire and jack Accessing the spare tire and jack Spare tire 2. Fold the crank and place it and the lug Taking out the spare tire wrench on the jack. 1. Lift the rear edge of the floor in the trunk. Lug wrench 3.
Page 193: Tire Sealing System
120 miles (200 km). 2. Lift out the tire sealing system. • Have the tire inspected by a trained and qualified Volvo service technician as NOTE soon as possible to determine if it can be permanently repaired or must be •...
Page 194 07 Wheels and tires Tire Sealing System* • Tire sealing system–overview Inhalation: Move the person to fresh air. WARNING If irritation persists, get medical atten- Please keep the following points in mind tion. when using the tire sealing system: • The sealing compound bottle (no.
Page 195 3. Ensure that the on/off switch is in posi- tle cannot be unscrewed. This must be done tion 0 (the 0 side of the switch should be by a trained and qualified Volvo service technician. pressed down). Option/accessory, for more information, see Introduction.
Page 196 Consult a trained and qualified should not be driven. WARNING Volvo service technician to have the bottle removed and properly disposed If you interrupt your trip for more than 1 hour, check the inflation pressure in the damaged tire again before continuing.
Page 197 6. Start the vehicle’s engine. 9. Turn off the compressor (press the on/off a Volvo retailer or a recycling station switch to position 0) when the correct infla- that can properly dispose of harmful WARNING tion pressure has been reached.
Page 198: Changing A Wheel
07 Wheels and tires Changing a wheel Removing the wheel 6. There are two jack attachment points on WARNING each side of the car. Position the jack cor- See page 192 for information on accessing the • The jack must correctly engage the jack rectly in the attachment (see the illustration) jack and tools for changing a wheel.
Page 199 07 Wheels and tires Changing a wheel Installing the wheel 1. Clean the contact surfaces between the wheel and hub. 2. Lift the wheel and place it on the hub. 3. Install the wheel nuts and hand-tighten them. Using the lug wrench, tighten cross- wise until all nuts are snug.
Page 200: Tire Pressure Monitoring System (Tpms)
07 Wheels and tires Tire Pressure Monitoring System (TPMS) Introduction Please note that the TPMS is not a substitute NOTE for proper tire maintenance, and it is the driv- The tire pressure monitoring system uses sen- If a fault occurs in TPMS, the tire pressure er's responsibility to maintain correct tire pres- sors mounted in the tire valves to check infla- warning light will flash for approximately...
Page 201 20 mph (30 km/h) or faster. This • Volvo recommends that TPMS sensors be In certain cases, it may be necessary to reca- fitted on all wheels used on the vehicle. librate TPMS to conform to Volvo's recom-...
Page 202 07 Wheels and tires Tire Pressure Monitoring System (TPMS) mended tire inflation pressures (see the infla- tion pressure table on page 182), for example, if higher inflation pressure is necessary when transporting heavy loads, etc. To recalibrate: 1. Switch off the engine. 2.
Page 203 07 Wheels and tires...
Page 204 Washing and cleaning the car............... 206 Paint touch up..................210...
Page 205 C A R C A R E...
Page 206: 08 Car Care
Exterior components to the vehicle than 13" (30 cm). Do not scratching, use lukewarm water to soften Volvo recommends the use of special cleaning spray into the locks. the dirt before you wash with a soft products, available at your Volvo retailer, for •...
Page 207 Volvo does not recommend the use of long- headlights, fog lights, or taillights. This is nor- life or durable paint protection coatings,...
Page 208 08 Car care Washing and cleaning the car Upholstery care Volvo also offers a special leather softener that This will help the leather resist staining and should be applied after the cleaner and pro- protect against sunlight's harmful UV rays.
Page 209 Spots on textile mats can be removed with a mild deter- gent. For best protection in winter, Volvo rec- ommends the use of Volvo rubber floor mats. Consult your Volvo retailer.
Page 210: Paint Touch Up
• Masking tape paint remains, the touch-up paint can be skill. Contact a trained and authorized Volvo applied as soon as the spot has been service technician for any extensive damage. cleaned.
Page 211 08 Car care...
Page 212 Volvo maintenance................214 Maintaining your car................215 Hood..................... 217 Engine compartment................218 Engine oil....................219 Fluids..................... 221 Wiper blades..................223 Battery....................224 Replacing bulbs..................226 Fuses..................... 233...
Page 213 M A I N T E N A N C E A N D S E R V I C I N G...
Page 214: 09 Maintenance And Servicing
Records Information booklet provides a com- qualified technician. To keep your Volvo in top sion maintenance be retained in case ques- prehensive periodic maintenance schedule up condition, specify time-tested and proven tions arise concerning maintenance.
Page 215: Maintaining Your Car
Corrosion may indicate a loose ter- may be permanent or temporary. OBD II will minal connector, or a battery near the end store a message about any fault. of its useful service life. Consult a trained and qualified Volvo service technician for additional information.
Page 216 How Can My Vehicle Fail OBD II Emission way driving is typically needed to allow OBD II to reach readiness. Your Volvo Inspection? retailer can provide you with more infor- Your vehicle can fail OBD II emission inspec- mation on planning a trip.
Page 217: Hood
09 Maintenance and servicing Hood Opening the hood To open the hood: 1. Pull the lever located under the left side of the dash to release the hood lock. 2. Lift the hood slightly. 3. Press up the release control located under the front edge of the hood (at the center) up to the right, and lift the hood.
Page 218: Engine Compartment
09 Maintenance and servicing Engine compartment Cooling system expansion tank Relay/fuse box Power steering fluid reservoir (concealed Air cleaner behind the headlight) Dipstick – engine oil WARNING Radiator The cooling fan may start or continue to operate (for up to 6 minutes) after the engine Cooling fan has been switched off.
Page 219: Engine Oil
Volvo recommends Castrol. NOTE • Volvo does not recommend the use of oil additives. • Synthetic oil is not used when the oil is changed at the normal maintenance intervals except at owner request and at additional charge.
Page 220 Do not allow oil to spill onto or come into contact with hot exhaust pipe surfaces NOTE Volvo uses different systems to indicate a low oil level or pressure. Some models have an oil pressure sensor, in which case a warning symbol (see page 60) is used to indicate low oil pressure.
Page 221: Fluids
If the system must be drained, con- Check coolant regularly! 4.2 US qts (4 liters). During cold weather, the sult a trained and qualified Volvo service tech- reservoir should be filled with windshield nician. •...
Page 222 Replace: The fluid should be replaced accord- engine is warm. Wait until the vehicle cools. ing to the intervals specified in the Warranty Fluid type: Volvo power steering fluid or equiv- If it is necessary to top off the coolant when and Service Records Information booklet.
Page 223: Wiper Blades
09 Maintenance and servicing Wiper blades Replacing windshield wiper blades Keeping the windshield wiper blades clean helps improve visibility and prolongs the serv- ice life of the wiper blades. See page 206 for washing instructions. 1. Fold out the wiper arm. 2.
Page 224: Battery
09 Maintenance and servicing Battery • Battery maintenance To help keep the battery in good condition, Battery symbols the vehicle should be driven for at least 15 Driving habits and conditions, climate, the Wear protection goggles minutes a week or connected to a charger number of starts, etc., all affect the service life with an automatic charging function.
Page 225 Used batteries should be properly disposed 1. Switch off the ignition and remove the key. of at a recycling station or similar facility, or taken to your Volvo retailer. 2. Wait at least 5 minutes after switching off the ignition before disconnecting the bat-...
Page 226: Replacing Bulbs
The optional Active Bending Light bulbs contain trace amounts of mercury. These bulbs should always be disposed of by a trained and qualified Volvo service techni- cian. Certain bulbs should only be replaced by a trained and qualified Volvo service techni- cian: •...
Page 227 Cover with retaining clamps Installing a new bulb bulbs should only be replaced by a trained and qualified Volvo service technician. 1. Open the hood and remove the headlight 1. Insert the new bulb. It can only be installed housing (see page 226 for instructions).
Page 228 WARNING Active Bending Lights* – due to the high voltage used by these headlights, the Active Bending Light bulbs should only be replaced by a trained and qualified Volvo service technician. 4. Driver's side headlight: Turn the bulb holder counterclockwise.
Page 229 09 Maintenance and servicing Replacing bulbs 8. Reinstall the headlight housing. 4. Remove the bulb from the holder by press- 5. Reinstall the headlight housing. ing it in and twisting it counterclockwise. NOTE Front fog lights* 5. Insert a new bulb and reinstall the bulb holder in the headlight housing.
Page 230 09 Maintenance and servicing Replacing bulbs 5. Turn the bulb counterclockwise and All bulbs in the taillight cluster can be replaced Location of taillight bulbs remove it. from the trunk. To access the bulb holders: 6. Insert a new bulb by turning it clockwise 1.
Page 231 6. Reinstall the entire bulb housing and screw These bulbs should only be replaced by a it into place. 3. Install a new bulb. trained and qualified Volvo service technician. 4. Press the lens back into place. Footwell lighting License plate lighting Trunk lighting 1.
Page 232 09 Maintenance and servicing Replacing bulbs 3. Install a new bulb. 4. Remove the defective bulb and replace it with a new one. 4. Press the bulb housing back into place. 5. To reinstall the mirror, begin by pressing the three lugs at the upper edge of the mir- Vanity mirror lighting ror back into place.
Page 233: Fuses
(written on the fuse). If fuses burn out repeatedly, have the electrical system inspected by a trained and qualified Volvo service technician. WARNING Never use metal objects or fuses with higher amperage than those stated on the follow- ing pages.
Page 234 36 fuses. • Fuses 1–18 are relays/circuit breakers and should only be removed or replaced by an authorized Volvo service technician. • Fuses 19–36 may be changed at any time when necessary. Several extra fuses and a fuse removal tool to...
Page 235 09 Maintenance and servicing Fuses Fuses in the engine compartment Coolant fan (radiator) Engine functions Windshield wipers Power steering Climate system blower Feed to passenger com- partment fuse box Feed to passenger com- Headlight washers partment fuse box Not in use Feed to heated rear window Feed to passenger com- Horn...
Page 236 09 Maintenance and servicing Fuses Not in use Not in use Ignition switch A/C compressor Not in use Front fog lights* Not in use Not in use Fuel injectors Heated oxygen sensor, vac- uum pump Ignition coils, climate unit pressure sensor Engine sensor valves, A/C relay, relay coil, PTC ele- ment oil trap, canister, mass...
Page 237 09 Maintenance and servicing Fuses Fuse box in the passenger compartment The fuse box in the passenger compartment is 6. Pull the center pins fully out of the mount- located under the glove compartment. ing clips, secure the upholstery with the mounting clips and press the pins into the To access the fuses: mounting clips again.
Page 238 Fuses in the passenger compartment Fuse 37-42, not in use Interior lighting Park assist*, Active Bending Lights* Audio system, Blue- Windshield washers tooth,Volvo Navigation sys- Not in use Supplemental Restrain Sys- tem* tem (SRS), Occupant Volvo Navigation System Supplemental Restrain Sys-...
Page 239 09 Maintenance and servicing Fuses Heated driver's seat* Not in use Heated passenger's seat* Not in use Moonroof* Auxiliary equipment control module (AEM) Power window and door lock – rear passenger's side Not in use door Back-up lights Sirius satellite radio* Not in use Audio system Power window and door...
Page 240 Introduction ..................242 Audio functions..................243 Radio functions..................248 CD player....................256 Audio menu................... 259 ® Bluetooth hands-free connection............260...
Page 241 A U D I O...
Page 242: 10 Audio
10 Audio Introduction Controls Navigation control: Use the up/down arrows to navigate among menu alterna- tives. EXIT: press to exit the menu system ENTER: press to confirm a selection or activate/deactivate a function The audio system's functions can also be con- trolled from the steering wheel keypad.
Page 243: Audio Functions
10 Audio Audio functions Audio system controls The AUX (auxiliary) port, located under the cen- ter armrest, can be used to connect for exam- ple, an MP3 player. If the player is being charged through a 12-volt socket while it is connect to the AUX port, sound quality may be impaired.
Page 244 10 Audio Audio functions 5. Press MENU on the audio system, and Steering wheel keypad USB/iPod connector* AUX volume AUX input navigate to volume 6. Turn the volume knob to raise or lower the AUX input volume until you hear music at a comfortable level.
Page 245 10 Audio Audio functions The text LOADING will be displayed while the MP3 player NOTE system loads the files (folder structure) on the Many MP3 players have a file indexing system The system supports playback of files in the device. This may take a short time. that is not supported by the vehicle's audio most common versions of formats such as system.
Page 246 10 Audio Audio functions Sound settings Subwoofer (accessory)–set the level for the NOTE subwoofer (bass speaker) • Optimal sound reproduction Dolby Surround Pro Logic II is only CENTER –make settings for the center speaker available on the Premium Sound sys- The audio system is calibrated for optimal tem.
Page 247 10 Audio Audio functions • Activating/deactivating Surround sound Adjust the level with the TUNING dial (4), or use the Up/Down arrows. Additional fre- 1. Press MENU followed by ENTER. quencies can be selected with the Right/ 2. Select SUBWOOFER in the menu and Left arrows.
Page 248: Radio Functions
10 Audio Radio functions Radio function controls EXIT–press to cancel a menu selection or Storing preset stations a selected function Manually storing a station AUTO–search for and store the strongest 1. Tune to the desired station. radio stations in the area in which you are 2.
Page 249 10 Audio Radio functions tions with sufficient signal strength, No AST The radio will then exit auto-store mode and The SCAN function will be deactivated and the the stored station can be selected by pressing station can be selected by pressing the preset found is displayed.
Page 250 93.9 WNYC IBOC or In Band On Channel, which refers to also be available on that particular fre- (Volvo uses the symbol > to indicate there the method of transmitting a digital radio quency. See also the section "Sub-chan-...
Page 251 10 Audio Radio functions channels will be displayed as 93.9 – 2 3. Press ENTER to turn HD off (the X will dis- NOTE WNYC, 93.9 - 3 WNYC, etc. appear from the box on the display screen). There may be a noticeable difference in •...
Page 252 10 Audio Radio functions In many cases, a main HD Radio station (FM Listening to satellite radio NOTE wavebands only) will also have sub-channels The Sirius satellite system consists of a number • When the radio has gone into HD mode, offering additional types of programming or of high elevation satellites in geosynchronous it may take several seconds before the...
Page 253 10 Audio Radio functions played (see also "Selecting a channel" in 5. Use the left or right arrow keys to select a 1. Press MENU and scroll to "Direct channel the right column). channel in the currently chosen category. entry." 2.
Page 254 10 Audio Radio functions preset satellite channel stored on that but- Song seek Advanced settings ton, regardless of the currently selected When a satellite radio channel plays one of the This menu function enables you to make set- channel category. songs stored in the song memory, the listener tings on certain Sirius satellite radio functions.
Page 255 3. The current code will be displayed. NOTE Temp. unlock all ch. Your Volvo retailer can also provide you with This function will temporarily unlock all chan- assistance. All channels are initially unlocked. nels and make them available for selection. The...
Page 256: Cd Player
10 Audio CD player CD function controls CD player When a disc with audio files is inserted in the player, the player scans the disc's folders Playing a CD before it begins playing the files. The length of Start the CD player by pressing the MODE but- time that this takes depends on the quality of ton (5) and inserting a disc in the slot (4).
Page 257 (3.5" discs should never be used). 1. Press MENU followed by ENTER. • Volvo does not recommend the use of 2. Select Random and press ENTER. plastic outer rings on the disc. If a CD with audio files is being played: •...
Page 258 10 Audio CD player • Never attempt to play a damaged CD. • When not in use, the discs should be stored in their covers. Avoid storing discs in excessive heat, direct sunlight or in dusty locations.
Page 259: Audio Menu
10 Audio Audio menu FM1/FM2 menu AUX menu Radio text AUX input volume… Audio settings… Audio settings… AM menu USB menu Audio settings… Playlist Random… CD menu Track information For normal music CDs Audio settings… Random Disc text Audio settings… CD menu For CDs containing files in MP3 format Playlist...
Page 260: Bluetooth Hands-Free Connection
Not all cell phones are fully compatible with The procedure for connecting a cell phone var- the hands-free system. A list of compatible phones is available at your Volvo retailer or ies, depending on the phone itself, and on at www.volvocars.us whether or not the phone has been previously connected.
Page 261 10 Audio ® Bluetooth hands-free connection > The audio system will search for cell more information on synchronizing a cell When the cell phone is disconnected from the phones that are in range. This search phone, see page 263. hands-free system, a call in progress can be takes approximately 30 seconds.
Page 262 10 Audio ® Bluetooth hands-free connection • Mute microphone : mute the audio sys- audio system must be switched to one of the If you prefer to use the connected cell phone’s tem’s microphone. other modes (FM, CD, etc). ring tone , go to Phone Menu…...
Page 263 10 Audio ® Bluetooth hands-free connection between cell phones that are already regis- If the phone book contains information about Call options… Voice mail number. If no tered in the hands-free system: someone who is trying to call you, this infor- number has been stored, this menu can be mation will be shown in the display.
Page 264 10 Audio ® Bluetooth hands-free connection the center console to navigate among the char- 5.1.3. Mute radio acters. 5.2. Synchronize phone book ® Bluetooth menus Call register… 1.1. Last 10 missed calls 1.2. Last 10 received calls 1.3. Last 10 dialed calls Call register…...
Page 265 10 Audio...
Page 266 Label information.................. 268 Dimensions and weights............... 270 Fuel, oils, and fluids................273 Engine oil....................274 Engine specifications................275 Electrical system................... 277 Three-way catalytic converter............... 279 Overview of information and warning symbols........280 Volvo programs..................282...
Page 267 S P E C I F I C A T I O N S...
Page 268: 11 Specifications
11 Specifications Label information...
Page 269 B-pillar (the pillar between the front and Vehicle Emission Control Information rear passenger doors) and the rear passeng- Your Volvo is designed to meet all applicable er's door must be open in order to see it. emission standards, as evidenced by the cer- tification label on the underside of the hood.
Page 270: Dimensions And Weights
11 Specifications Dimensions and weights Dimensions Position Dimension Wheelbase 103.9 in. (264 cm) Length 175.9 in. (447 cm) Load length, floor, seatback down 68.7 in. (175 cm) Load length, floor 38.4 in. (98 cm) Load height 17.3 in. (44 cm) Height 57.2 in.
Page 271 11 Specifications Dimensions and weights Position Dimension Track, rear 60.3 in. (153 cm) Load width, floor 40.4 in. (103 cm) Width 69.7 in. (177 cm) Width encl. door mirrors 79.6 in. (202 cm) Weights Category Canada Gross vehicle weight 4320 lbs lbs 1960 kg Capacity weight 800 lbs...
Page 272 11 Specifications Dimensions and weights CAUTION The maximum permissible axle loads and/ or the gross vehicle weight must not be exceeded. WARNING When adding accessories, equipment, lug- gage and other cargo to your vehicle, the total capacity weight must not be exceeded.
Page 273: Fuel, Oils, And Fluids
Automatic transmission oil JWS 3309 8.14 US quarts (7.7 liters) Coolant Volvo original coolant/antifreeze (50/50 mix- 10.5 US quarts (10 liters) – models with automatic ture of water and anti-freeze) transmission Brake fluid DOT 4+ boiling point >536 °F (280 °C), P/N 0.63 US quarts (0.6 liters)
Page 274: Engine Oil
Consult your Volvo to a reference oil. Extreme engine operation retailer or a trained and qualified Volvo service Synthetic oils meeting SAE 0W-30 or 0W-40 technician for recommendations on premium and complying with oil quality requirements are or synthetic oils.
Page 275: Engine Specifications
93.2/3.67 Compression ratio 9.0:1 Spark plugs type Volvo kit no. 30650379 gap inches/mm 0.027 in./0.7mm tightening torque ft. lbs./Nm 22.5 ft. lbs./30 Nm The engine specifications for output and torque listed in this table are based on the use of premium fuel.
Page 276 11 Specifications Engine specifications Fuel system The engine is equipped with a multiport fuel injection system.
Page 277: Electrical System
Wash hands after handling. Reserve capacity (RC) 135 min Capacity (Ah) Models equipped with the Premium Sound audio system, the Volvo Navigation System and/or keyless drive. Bulbs used in the car Bulb Output Type Low beam headlights (models with halogen headlights)
Page 278 Front parking lights and side marker lights Front fog lights* Glove compartment light Festoon NOTE For information regarding any other bulbs not mentioned in this section, please con- tact your Volvo retailer or a trained and authorized Volvo service technician. Option/accessory, for more information, see Introduction.
Page 279: Three-Way Catalytic Converter
11 Specifications Three-way catalytic converter Three-way catalytic converter – components or location, or removing com- ponents, and/the repeated use of leaded general information fuel. • Keep your engine properly tuned. Certain engine malfunctions, particularly involving NOTE the electrical, fuel or distributor ignition systems, may cause unusually high three- Unleaded fuel is required for vehicles with way catalytic converter temperatures.
Page 280: Overview Of Information And Warning Symbols
11 Specifications Overview of information and warning symbols Introduction Symbols in the main instrument panel Symbol Description Page The symbols in the vehicle's various displays Indicator and warning symbols Fuel level warning are divided into three main categories: light Symbol Description Page •...
Page 281 11 Specifications Overview of information and warning symbols Other information symbols Information symbols in the ceiling Symbol Description Page console Symbol Description Page Generator warn- Symbol Description Page ing light Rain sensor* Seat belt reminder Brake failure Cruise control* warning light Occupant weight sensor Information symbols in the center...
Page 282: Volvo Programs
11 Specifications Volvo programs Volvo On Call Roadside Assistance Your new Volvo comes with a four year ON CALL roadside assistance. Additional informa- tion, features, and benefits are described in a separate information package in your glove compartment. If you require assistance, dial: In the U.S.
Page 283 11 Specifications...
Page 284 12 Index 1, 2, 3 ... Audio system AUX port..........243 audio functions........243 Axle weight........186, 271 12-volt sockets.......... 65 automatic sound control..... 247 AUX port..........243 compact disc care......257 Dolby Surround Pro Logic II....246 equalizer..........247 Backrest, rear seat, folding......
Page 285 12 Index fluid............. 222 ISOFIX/LATCH anchors......47 Coolant............ 273 general information......154 top tether anchors........ 49 changing..........221 checking level of......... 221 Bulbs Child safety..........38 headlights........... 226 booster cushions........46 Courtesy lighting........110 list of........... 277 child restraint systems......40 Crash mode..........
Page 286 12 Index specifications........274 Fuel filler door volumes..........273 unlocking..........68 Economical driving........140 Environment..........14 Fuel gauge..........56 Electrical current – conserving....142 Equalizer, audio system......247 Fuel requirements........144 Electrically operated moonroof....83 Eyelets for anchoring loads..... 118 Fuel tank volume........
Page 287 12 Index changing bulbs........226 Inflation pressure table high and low beams......69 Canadian models........ 182 high beam flash........69 US models.......... 181 Key (ignition switch) positions....147 Headlight washers........75 Information and warning symbols, table Key blade......... 124, 128 of..............
Page 288 12 Index Locks, child safety........133 Oil............. 219 Power windows......... 78 changing..........219 Long distance trips........142 Pregnancy, using seat belts during... 21 checking..........219 Lug nuts (wheel nuts)....... 191 Private locking......... 126 On Call Roadside Assistance....282 Opening the hood........217 Opening the trunk from the inside...
Page 289 12 Index Remote key..........122 unbuckling..........20 Storage compartments......112 battery replacement......124 use during pregnancy......21 Studded tires........... 189 functions..........123 Seats, front..........106 Subwoofer..........246 key blade..........124 Shiftlock Sunroof (moonroof)........83 Replacing fuses........233 override..........153 Supplemental restraint system....23 Reporting safety defects Side door mirrors........
Page 290 Volvo and the environment......14 snow........... 189 Trips, long distance......... 142 Volvo maintenance........214 spare........... 190 Trunk Volvo On Call Roadside Assistance..282 spare tire (location)......192 opening from the inside...... 131 speed ratings........180 Turn signals..........69 storing..........177 indicator lights........
Page 291 12 Index Windows power............ 78 Windshield washer fluid reservoir.... 218 Windshield wiper blades......223 Windshield wipers........75 rains sensor.......... 76 Winter tires..........189 Wiper blades replacing windshield wipers....223...
Page 292 12 Index...

Volvo S40 Owner's Manual

Introduction

01 Safety

02 Instruments and Controls

03 Climate

04 Interior

05 Locks and Alarm

06 Starting and Driving

07 Wheels and Tires

08 Car Care

09 Maintenance and Servicing

10 Audio

11 Specifications

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Volvo S40

Summary of Contents for Volvo S40

Table of Contents
