Drill 4 holes and insert wall anchors
Connect telephone cable to SET connector and telephone line cable to LINE connector (through the desired wiring cable entry).
D-300885
1
Release
screws
4
Figure 3.1 – Back Unit Mounting
PHONE WIRING
PHONE WIRING IN NORTH AMERICA
Back unit
3
Mark 4 drilling points on mounting surface
5
Fasten the back unit with 4 screws
8-POSITION
RJ-31X PLUG
BROWN
RED
GREEN
GRAY
RJ-31X
CORD
RJ-31X JACK
GRAY
RED
2
3 4
1
LINE
HOUSE
FROM
RJ-31X
PHONES
STREET
5
7
6
GRN
BROWN
5
