TC Electronic Finalizer User Manual page 29

TOOLS Flow
Internal levels (ppm)
TOOLS Peak-Hold Meter
Flow
In the Flow Meter, you have six small peak meters,
representing the level in the different sections of
the Finalizer.
This can be very helpful in a number of situations.
I.e. you have an overload indication on the front,
but you do not know in which section the overload
is located: now you simply press TOOLS and select
the Flow meter, and you have instant view of all
levels and possible overloads in the Finalizer.
Peak
The Peak-Hold Meter is an output meter with infi-
nite hold. It is possible to see the level of the maxi-
mum peak in 0.10 dB precision.
Press OK to reset the meter.
Numeric readout of peak values
29
