MAIN PAGE
EQ on/off
Band
Parameter
EQ
Select EQ by pressing the BLOCK keys.
Basic operation
Press PARAMETER keys to select frequency/gain/bandwidth/slope.
Turn ADJUST wheel to change values.
Press BAND keys to jump between the five bands.
EQ Ranges
Low Shelve
Bell-shaped filter 1
Bell-shaped filter 2
Bell-shaped filter 3
High Shelve
Output Gain
EQ Bypass
Press the blue BLOCK on/off key to bypass the EQ section.
Reset all filters by pressing both page keys simultaneously.
EQ
Black box indicates selected block
Frequency
Frequency Gain
19.95 Hz to 5.01 kHz +/- 12 dB
19.95 Hz to 20 kHz +/- 12 dB
19.95 Hz to 20 kHz +/- 12 dB
19.95 Hz to 20 kHz +/- 12 dB
501.2 Hz to 20 kHz +/- 12 dB
- +/- 12 dB
Gain Bandwidth/Slope
Bandwidth/Slope
3, 6, 9, 12 dB/Oct
0.1 Oct to 4.0 Oct
0.1 Oct to 4.0 Oct
0.1 Oct to 4.0 Oct
3, 6, 9, 12 dB/Oct
-
Effects blocks
Selected band
Output Level bar
