Speco OIPC72B7G Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
'
'
O
I
P
C
7
2
B
7
G
O
w
n
e
r
s
O
I
P
C
7
2
B
7
G
O
w
n
e
r
s
M
a
n
u
a
l
M
a
n
u
a
l
OIPC72B7G
Owner's Manual
Rev.1.2 (Oct. 2012)
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OIPC72B7G and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Speco OIPC72B7G

Summary of Contents for Speco OIPC72B7G

  • Page 1 Owner’s Manual ’ ’ OIPC72B7G Rev.1.2 (Oct. 2012)
  • Page 2 ’ ’ Directions Be careful not to cause any physical damage by dropping or throwing OIPC72B7G. Especially keep the device out of reach from children. Do not disassemble OIPC72B7G. No After Service is assumed when disassembled. Use only the power adapter provided with OIPC72B7G.
  • Page 3 ’ ’ Caution Any changes or modifications in construction of this device which are not explicitly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Revision History Date Revision Details 2012-09-01 First manual revision creation. Rev.1.2 (Oct.

  • Page 4: Table Of Contents

    Contents ......................4 1. Introduction ....................6 1.1. Overview ........................6 1.2. Specification ....................... 7 1.3. Applications of OIPC72B7G ..................9 2. Product Description ..................10 2.1. Contents ........................10 2.2. Product Preview ....................... 11 2.3. Physical description ....................12 2.4.
  • Page 5 ’ ’ 5.2. Cannot connect to the Video .......... Error! Bookmark not defined. 5.3. Windows Vista or Windows 7 ......... Error! Bookmark not defined. 5.4. Technical Assistance ............Error! Bookmark not defined. Rev.1.2 (Oct. 2012)

  • Page 6: Introduction

    It enables real time transmission of synchronized video of up to D1 and audio data. Remote clients can connect to OIPC72B7G for the real time video data through various client solutions running on PC or mobile phones.

  • Page 7: Specification

    Remote administration over IP network Web Viewer Simple viewing over internet explorer Client & Viewer Speco-NVR Standard CMS software 3rd Party CMS Ask SPECO for details Dynamic IP support DDNS support Supported Video/Audio stream encryption Security ID and Password protection...
  • Page 8 ’ ’ IP filtering for restricting administrative access for audio and bi-audio Sync to PC Synchronize to PC Manual Manual time setting Time management Internet Time Server Synchronize to Time Server Day light saving Active-X SDK support HTTP Source filter Rev.1.2 (Oct.

  • Page 9: Applications Of Oipc72B7G

    ’ ’ 1.3. Applications of OIPC72B7G  Security surveillance (buildings, stores, manufacturing facilities, parking lots, banks, government facilities, military, etc.)  Remote monitoring (hospitals, kindergartens, traffic, public areas, etc.)  Teleconference (Bi-directional audio conference). Remote Learning, Internet broadcasting  Weather and environmental observation...

  • Page 10: Product Description

    ’ 2. Product Description 2.1. Contents The product package contains followings : Contents Description Remarks OIPC72B7G IP camera OIPC72B7G main unit Power Adaptor 12VDC Adaptor Optional item Software & User’s Guide Quick Reference Guide Quick installation guide Rev.1.2 (Oct. 2012)

  • Page 11: Product Preview

    ’ ’ 2.2. Product Preview 2.2.1. Preview CMS Software OIPC72B7G IP-Installer (Speco-NVR) PC software to view and record the A/V streaming data transmitted PC software to allocate an IP IP Camera from IP camera. address to the IP Camera (Simultaneous support of up to 64 IP cameras) Rev.1.2 (Oct.

  • Page 12: Physical Description

     100Base-T 100Mbps Ethernet connector (RJ-45). 2 LEDs on the Ethernet connector shows the status of OIPC72B7G as the followings: Status LED (Dual Color - Red/Green) : It will be lit in green or red depending on the status.
  • Page 13 Off state indicates that there is trouble in network connection.  ALARM IN/OUT and Composite Video Output Figure 2-3 ALARM IN/OUT and Composite Video Output Terminal of OIPC72B7G Used for connecting P/T device, sensor, and composite video output. Pin assignments are as follows.
  • Page 14 A switch provided for returning the IP camera to factory default state. Open the cover to access the switch. Press the switch for a few seconds while power is applied. Figure 2-6 Factory Default switch of OIPC72B7G Caution: Restoring the factory default will erase all settings.

  • Page 15: On Site Installation

    ’ ’ 3. On Site Installation 3.1. Please follow through the procedures in the order of the numbers for each procedure. 1. Open dome cover as following. 2. Fix the product using 3 screws and anchors Rev.1.2 (Oct. 2012)
  • Page 16 ’ ’ 3. Combine dome cover. Rev.1.2 (Oct. 2012)

  • Page 17: Getting Started

    Brief information for first time operation of OIPC72B7G is provided in this chapter. 4.1. PC Requirement Video streaming data received from OIPC72B7G can be displayed or stored in a PC running client programs. Minimum requirement of the PC is described below:...

  • Page 18: Quick Installation Guide

    Insert the CD provided with product into the PC. Install WinPcap and IP Installer in sequence. Make sure that IP Installer can’t run without WinPcap. IP installer Ver. 3.0.1 or later is needed in the configuration of OIPC72B7G. Follow the sequence below for setting the IP parameter Run IP installer >...
  • Page 19 ’ ’ 2. Install Speco-NVR Speco-NVR is a multi-channel CMS program for to IP camera or Video server. Install Speco-NVR on remote PC to connect to these products. It is needed to assign connection information to Speco-NVR program before connection.
  • Page 20 ’ ’ Click on the field in ③ for sorting and rearranging the list. Select network mode that best suits from the drop down list in ⑤. You can choose either Static or ADSL and Auto (DHCP), respectively. If ADSL and Auto are selected, the fields in ⑥ is deactivated.
  • Page 21 Note : Active-X module should be installed on your PC before actual connection. If your PC is not connected to the internet, you cannot download Active-X module. Most convenient way of installing the Active-X module is installing Speco-NVR which is available from the CD or our web site.
  • Page 22 SAVE button. You can see the live video when you click the live view button as below. When you exit Speco-NVR, you have to input the ID/PW, admin/1234. Details for the Speco-NVR can be found in [Speco-NVR User’s Guide].
  • Page 23 ’ ’ 4. Additional settings through connection to the Admin Page All the parameters of new IP camera follows factory default values. For more sophisticated target application it is needed to change parameters. The admin page can be connected through ”http://IP_address:HTTP_port_number”/admin.htm It is needed to enter ID and password of the administrator.

  • Page 24: Trouble Shooting

    ’ ’ 5. Trouble Shooting 5.1. No power is applied  In case of DC adaptor If PoE is not applied, the power and network connection should be made through separate cables. It is recommended to use DC adaptor supplied by provider for the feeding of the power. In case of replacing the DC power supply, make sure that the power supply meets with the power requirement of the IP camera to prevent damage or malfunction.
  • Page 25 ’ ’ 5.2. Cannot connect to the Video Check the status of the network connection through PING test. Try the following on your PC : Start > Run > Cmd > Ping IP address (Ex : Ping 172.16.42.51) If “Reply from ~”...

  • Page 26: Windows Vista

    5.3. Windows Vista or Windows 7 Windows Vista and Windows 7 users need to configure UAC (User Access Control) and Privilege Level for proper recording and still video capture in Speco-NVR and Web Viewer. <Windows Vista> 1. UAC (User Access Control) configuration 1) Double-click “User Accounts”...
  • Page 27 ’ ’ <Windows 7> 1. UAC (User Access Control) configuration 1) Double-click “User Accounts” in control panel 2) Double-click “Change User Account Control setting” 3) Set to “Never notify” Rev.1.2 (Oct. 2012)
  • Page 28 ’ ’ 2. Privilege Level Control 1) Select “NVR” icon on the desktop 2) Click right mouse button and select “properties” 3) Check “Privilege Level” in “Compatibility” tab Rev.1.2 (Oct. 2012)
  • Page 29 ’ ’ 5.4. Technical Assistance If you need any technical assistance, please contact your dealer. For immediate service please provide the following information. 1. Model name 2. MAC address and Registration number 3. Purchase date 4. Description of the problem 5.
