Speco CLPR67B4B Installation Instructions

License Plate Camera
CLPR67B4B

Installation Precautions

1.
Avoid installing camera where there are frequent vibrations or shocks.
2. Please keep the glass in front of the camera clean. Do not touch it directly.
Use a soft cloth with alcohol to wipe glass if necessary.
3.
The available IR range of this camera is shown in the specification.
Please be sure to place the camera within the specified range
4. In order to prevent damage to the camera, please do not loosen any screws or
covers unless modifying settings.
5. Please do not operate camera beyond conditions listed in the specification.
Use 12V DC regulated power supply to avoid damaging camera.

Included Accessories

1.
2.
3.
4.
5.
6.
7.

Specifications

IP Rating
Type
Signal System
Pick Up Device
Picture Elements
Resolution
LEDs
Vertical Frequency
Horizontal Frequency
Clock Frequency
Scanning System
S/N Ratio
Lens
Video Output
Power Supply
.
Current Consumption
Recommended IR Range
Dimension
Weight
Storage Temperature
Operating Temperature
We reserve the right to modify product design and specification without notice and without incurring any obligation
User Manual x1
Screws x4
Anchors x4
Adaptor x1
Hex shape Wrench x2
DC Connector x1
Mounting template x1
ITEM
IP66
Monochrome
NTSC/PAL
1/3" Sony High Resolution CCD
NTSC: 811H×508V; PAL: 795H×596V
550 TV Lines
Super High Power LED
20
NTSC: 60Hz;
NTSC: 15.734KHz; PAL: 15.625KHz
NTSC: 28.636MHz; PAL: 28.375MHz
2:1 Interlace
≥50dB
10-40mm Varifocal Auto Iris IR Lens
,75Ω
1V
p-p
DC12V ± 10%
1300mA (Max)
16.3ft – 98.3ft (5m – 30m)
18.23" × 9.45" × 5.51" (463 × 240 × 140mm)
88.2oz (2500g)
～
-22 140°F (-30
～
-22 104°F (-30
CLPR67B4B
s
PAL: 50Hz
～
60°C)
～
40°C)
