9. Remove the PDA from the connection cable/cradle. Soft reset the PDA by pressing the
reset button.
IMPORTANT! Soft reset your PDA, or some icons will not appear properly.
STEP 3: A T
SSIGN A RIGGER
Refer to your PDA manual for complete instructions.
Note: Alternatively, you can use the SocketScan Trigger software to set up a soft
trigger on the screen. See Chapter 4.
1. Tap Start | Settings | Buttons.
2. Select a button to trigger the CF Scan Card. In the drop-down menu, select
SocketScan. When done, tap ok.
For comfort, choose the button located under your thumb or forefinger when you hold the
PDA.
IMPORTANT! Be sure to select SocketScan. Do not select the programs Socket Read RFID,
Socket Read Barcode or Socket Trigger Select, which are not for the CF Scan Card.
STEP 4: S S
TART OCKET
1. Press the trigger button you just assigned. This is a quick way to launch SocketScan.
Alternatively, tap Start | Programs | SocketScan.
2. When SocketScan is running, a SocketScan icon will appear at the bottom of the
Today screen.
Icon Meaning
No scanner detected. The scanner is missing, damaged, or improperly inserted.
CF Scan Card 5C/5E2/5P detected. SocketScan detects the scanner and is ready to scan.
CF Scan Card 5X/5XRx detected. SocketScan detects the scanner and is ready to scan.
STEP 5: I CF S
NSERT THE
1. Insert the CF Scan Card into the card slot of your PDA.
Be sure to insert the card all the way into the slot.
Do not insert the card backwards.
Do not push the card in too hard, or you can damage the card or the card slot of your
PDA.
2. Make sure the proper "CF Scan Card detected" icon appears.
30
