Certification:
5C FCC Part 15 Class C, RSS 210, iCES 003, C-
Tick, CISPR 22, CE EN55022, EN55024, TELE, CE, VCCI
5E2/5P FCC: Part 15, Class B, CE:EN55024:2003, ICES-003 Class B, CISPR 22,
AS 3548, C-TICK: s.182, RoHS, 21CFR1040.10, 21CFR1040.11
5X/5XRx FCC: Part 15, Class B, CE:EN55024:2003, C-TICK: s.182, RoHS
Software Included:
Universal Installer
SocketScan keyboard wedge software
Socket Floating Trigger
Decode Zones:
The decode zones for the CF Scan Cards are shown in the following pages. The
minimum element width ("X Dimension" or barcode "size") is the width in
thousandths of an inch (mils) of the narrowest element (bar or space) in the
symbol. The figures shown are the typical scanning distances (depths of field) for
selected barcode sizes. The maximum usable length of a barcode symbol (Width
of Field) at any given range is also shown below.
A A: P
PPENDIX RODUCT
S
PECIFICATIONS
21
