Many-To-One Control - ADDER AdderLink Infinity User Manual

Many-to-one control

When using Infinity units in a many-to-one configuration, the RX unit can switch
between the various TX units that are connected to different computer systems.
In a many-to-one installation, the RX unit can switch
INFINITY TX
between many different TX units and their computers.
IP: 192.168.16.129
INFINITY TX
IP: 192.168.16.131
INFINITY TX
IP: 192.168.16.133
INFINITY RX
IP: 192.168.16.127
Gigabit
Ethernet
To switch between systems
1 Run a web browser and enter the IP address of your local Infinity RX
unit, (e.g. http://192.168.16.127) - this can be done through the remote
computer that you are using via the Infinity system, provided that it is linked
via its own connection to the network.
2 In the System
Configuration page,
within the Remote
Unit Settings section,
change the current
IP address to the
address of the new
TX unit.
Note: If you need to
connect video, audio
and USB to separate
TX units, click the
blue arrow to reveal
the individual video,
audio and USB IP
addresses.
3 Click the Update Now button. The chosen connection(s) will be broken with
the current TX unit and initiated with the newly selected TX unit(s).
See Important Information on page 2.
