Support for industry-standard monitors

Hardware support for stereoscopic viewing, Display Data Channel (DDC), and Display Power

Management Signaling (DPMS)

Visit http://www.intense3d.com for the latest performance data and other product information.

Hardware

The Wildcat 3510 is a single-card solution that uses one AGP slot in your workstation.

The Wildcat 3510 uses the Intense3D Wildcat video display driver. The video display driver

installs as a standard Windows NT driver, and provides both GDI and OpenGL graphics

compatibility. In a workstation purchased with the Wildcat 3510, the current driver is installed on

your workstation, and is delivered on backup media with the system. You can download updated

drivers from Intergraph Computer Systems' Web pages; see the Preface of this document for more

information.

In a workstation purchased with the Wildcat 3510, the appropriate card is already installed in the

workstation base unit.

To connect monitors to the Wildcat 3510:

Connect the workstation monitor's video cable to the color video output port on the Wildcat

3510 card. See the following figure. (Insert new figure.)

Video Output

Stereo Sync

Port

Output Port
