Troubleshooting The Installation - Intergraph Intense3D Wildcat 3510 Hardware User's Manual

8
Click Yes when asked if you want to install a third-party driver. The files are copied from the
9.
directory on your workstation's primary hard disk drive.
NOTE If the driver files were delivered on two floppy diskettes, you will be prompted to key
in the path for the driver files from the second diskette. The files are copied from the
directory on your workstation's primary hard disk drive.
10. After the driver files are successfully copied, a message that the driver successfully installed
displays. Click OK.
11. Click Close to exit the Display Type dialog.
12. Click Close to exit the Display Properties dialog.
13. When told that the workstation must be restarted for the new settings to take effect, remove
the diskette from the workstation's floppy disk drive, if applicable. Click Yes to restart the
workstation.
14. After the system restarts and you log in, a message displays. The message states that a new
display driver has been installed, and that you should use the Display option in the Control
Panel to select the preferred display resolution. (See the section on monitor resolutions in
Chapter 3.) Click OK.
NOTE Two Intense3D tabs appear in the Display Properties Dialog: Intense3D Settings and
Intense3D Monitor. Use the Intense3D Settings tab to select graphics performance
and stereo settings. Use the Intense3D Monitor Type to select your monitor type and
review the supported DDC timings (if you have selected a DDC monitor).
15. Test your selected resolution by checking the Test option in the Display Properties dialog.
16. To change the display resolution or other display settings, see the section on configuring the
video display in Chapter 1. For more detailed installation information, refer to the
.
README TXT
CAUTION When you select Display in the Windows NT Control Panel, a message displays.
Click OK to close the message. The message displays every time you select Display
unless you clear the Show warning checkbox at startup.

Troubleshooting the Installation

The following table lists some common video configuration problems.
Problem
Display is black, not synchronized, or
distorted.
Monitor does not support a selected resolution
or refresh rate.
file located on the delivery media.
Action
Restart Windows NT in VGA mode and select a
supported resolution and refresh rate.
Restart Windows NT in VGA mode and select a
supported resolution and refresh rate.
