System Board; System Specifications - Intergraph Zx1 ViZual Workstation System Manual

94

System Board

See the System Board Manual for more information about the system board and its components.
Component
System BIOS
Processors
Processor Chipset
Combo Controller
Bus Controller
Video Display Controller

System Specifications

Item
Dimensions
Weight
AC line voltage (US)
AC line voltage (International)
Power consumption
Recommended room temperature
Recommended room humidity
Heat dissipation
Description
AMI
Intel Pentium III, Single-Edge Connector (SEC) module
Intel 440 BX series
National PC87309 Super I/O
Intel 82371EB PCI/ISA/EIDE/USB Xcelerator (PIIX4E)
Intel 82443BX PCI/AGP
Specifications
21 x 7.6 x 20.5 in (53.3 x 19.3 x 52.1 cm)
55 lb (25 kg) maximum configuration
90-132 VAC, 47-63 Hz, 1 phase, 15A/125 V receptacle
180-264 VAC, 47-63 Hz, 1 phase, 15A/250 V receptacle
285 watts; 3.4 A at 120 VAC maximum configuration
50 to 90 F (10 to 32 C)
20% to 80% (non-condensing)
973 BTU/hr
