Obtaining a Device's IP Address Information

To obtain IP address information for a device, do the
following:
1. Select Addresses Used to display the following:
Figure 4-7. Addresses Used Screen
The Addresses Used screen enables you to verify a
devices' IP address information. This screen also
displays the best-discovered name for the device as
well as its IP, IPX, and MAC address.
4-6
2. CDP (Cisco Discovery Protocol) information, if found,
is also given on this screen. Press the Down
arrow key to locate the CDP section, as shown in
Figure 4-8:
CDP information is reported for the most recently
received CDP advertisement on that side. This
information is updated every two seconds.
When plugged into a switch VLAN port, information
for Native VLAN and Appliance (phone) VLAN are
also given.
Figure 4-8. CDP Information
