Serial Port Connection

The recommended speed setting for the serial
port is 115200.
A serial port connection enables you to:
•
Download software (see "Updating the Software")
•
Enable options
•
Save screens
•
Upload and download PING catalogs
•
Upload Report data.
Use the Link Utility programs supplied on the CD-ROM
(see "PC/NetTool Link Utility Programs").
2-8
Note
To connect NetTool, use the supplied serial cable. As
shown in Figure 2-7, connect one end of the cable to the
serial port on the PC and the other end to the serial port
on the right side of NetTool.
Figure 2-7. Connecting NetTool to the Serial Port
ahn019f.eps
