SECO-LARM SK-1123-SQ Manual

Digital Access Keypad Manual

User Operation for the SK-1123-SQ

1. Using the User Codes:
A. User codes operate the door (4-8 digits long).
Press
u u u u
B. The # key must be pressed also if the keypad is in manual-entry mode.
Press
#
u u u u
2. Using the Master Code:
The Master Code can be used to operate the door or program the keypad (4-8 digits long, see pt. 5 below).
Press X X X X # 1 (Relay output #1)
Press (Relay output #2)
X X X X # 2
3. Using the Inhibit/Lockout Code:
Please contact your installer for an explanation of inhibit mode and its operation.
4. Using Duress Codes:
For a full explanation of duress codes and their uses, see pg. 12.
5. Delete/Add/Change User and Master Code:
WARNING -- Press the correct option key. If the option key is not used and a "0" is pressed after
entering the Master Code, it could accidentally reprogram the Master Code.
A. Enter the Master Code first, followed by the
(If you forgot the master code, see page 15 for more information.
Press
X X X X *
B. Changing/Adding Users:
Press 00-99 (user ID) u u u u
1
Press 2 0-9 (user ID) u u u u
C. Deleting Individual Users:
Press 00-99 (user ID) # (for relay output #1)
1
Press 0-9 (user ID) (for relay output #2)
2 #
D. Changing the Master Code:
Press #
0 X X X X
E. To exit programming mode, press the *
WARRANTY This SECO-LARM product is warranted against defects in material and workmanship while used in normal
service for a period of one (1) year from the date of sale to the original consumer customer. SECO-LARM's obligation is
limited to the repair or replacement of any defective part if the unit is returned, transportation prepaid, to SECO-LARM.
This Warranty is void if damage is caused by or attributed to acts of God, physical or electrical misuse or abuse, neglect,
repair, or alteration, improper or abnormal usage, or faulty installation, or if for any other reason SECO-LARM determines
that such equipment is not operating properly as a result of causes other than defects in material and workmanship.
The sole obligation of SECO-LARM, and the purchaser's exclusive remedy, shall be limited to replacement or repair only, at
SECO-LARM's option. In no event shall SECO-LARM be liable for any special, collateral, incidental, or consequential
personal or property damages of any kind to the purchaser or anyone else.
NOTICE: The information and specifications printed in this manual are current at the time of publication. However, the
SECO-LARM policy is one of continual development and improvement. For this reason, SECO-LARM reserves the right
to change specifications without notice. SECO-LARM is also not responsible for misprints or typographical errors.
Copyright © 2009 SECO-LARM U.S.A., Inc. All rights reserved. This material may not be reproduced or copied, in
whole or in part, without the written permission of SECO-LARM.
SECO-LARM ® U.S.A., Inc.
16842 Millikan Avenue, Irvine, CA 92606
Tel: 800-662-0800 / 949-261-2999 Fax: 949-261-7326
Page 16
Note: u u u u
the user code.
Note: X X X X
the master code.
key
*
(user code, 4-8 digits) (for relay output #1)
#
(user code, 4-8 digits) # (for relay output #2)
key.
Website: www.seco-larm.com
E-mail: sales@seco-larm.com
SECO-LARM U.S.A., Inc.
indicates
indicates
®
PIHAK1
SECO-LARM SECO-LARM SECO-LARM SECO-LARM SECO-LARM
MiSK-1123-SQ_0905.pmd
MANUAL
SK-1123-SQ
Outdoor Digital Access
Keypad with 2 Outputs
® ® ® ® ®
®
