Alone/Wiegand Keypad
with Proximity Reader
SK-2612-SPQ
Installation Manual
The ENFORCER Outdoor Stand-Alone / Wiegand Keypad with Proximity Reader is an advanced
security solution that offers both efficiency and convenience. This versatile device can function as a
stand-alone controller or a Wiegand reader. The keypad's unique feature of adding multiple cards
in bulk at once significantly streamlines access control management in large organizations.
1,000 Users (up to 987 common, 1 super, 2 duress, and 10 visitors)
12~18 VDC Operation
Low current draw – 150mA max.
Form C relay output – 2A@12VDC
Adjustable output – 1~99 seconds or toggle
Built-in tamper alarm and external alarm output
Door-propped-open / door-forced-open alarm
Can serve as Wiegand output reader or controller, output and input – 26~44 bits
EM 125kHz Proximity card reader
Easy duplication of users to additional devices
Bulk adding of multiple cards at a time
Backlit keypad programmable to ON, OFF, or standby OFF automatically ON with keypress
2-Door interlock
Outdoor rated – IP66 weatherproof
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SECO-LARM ENFORCER SK-2612-SPQ
Summary of Contents for SECO-LARM ENFORCER SK-2612-SPQ
- Page 1 Outdoor Stand- Alone/Wiegand Keypad with Proximity Reader SK-2612-SPQ Installation Manual The ENFORCER Outdoor Stand-Alone / Wiegand Keypad with Proximity Reader is an advanced security solution that offers both efficiency and convenience. This versatile device can function as a stand-alone controller or a Wiegand reader. The keypad’s unique feature of adding multiple cards in bulk at once significantly streamlines access control management in large organizations.
-
Page 2: Parts List
N.C. Ground Card type EM125 Enclosure material Black ABS plastic Operating temperature -40°~140° F (-40°~60° C) Operating humidity 0~98% non-condensing Dimensions "x4 "x " (49x120x24 mm) Weight 5.8-oz (165g) Overview " (120mm) " (850mm) " " (49mm) (24mm) SECO-LARM U.S.A., Inc. -
Page 3: Mounting Diagram
AC powered locks and for electromagnetic locks unless your (MOV, not supplied) lock has a diode/MOV built in (all SECO-LARM electromagnetic locks have built-in protection). Do not install both diode and MOV. Failure to use these as directed will void the warranty. -
Page 4: Programming Tips
5. Set the output time (skip this step if the default value of 5 seconds is acceptable): (1~99) NOTE: The delay time is 1~99 seconds 6. Exit programming mode: NOTE: One short beep indicates that the keypad has exited programming mode. SECO-LARM U.S.A., Inc. -
Page 5: Table Of Contents
3. All wiring and programming should be done by a professional installer to reduce the risk of improper installation. 4. The user's operating guide for this keypad is located on pg. 19 of this manual. Be sure to store this manual in a safe place for future reference. SECO-LARM U.S.A., Inc. -
Page 6: Led Indicators And Device Sounds
AC-powered locks and for electromagnetic locks unless your lock has a diode/MOV built in (all SECO-LARM electromagnetic locks have built-in protection). Do not install both diode and MOV. Failure to use these as directed will void the warranty. -
Page 7: Programming Functions And Defaults
A steady orange LED indicates that the reader is in a function programming mode. Do not disconnect the keypad from power while in programming mode. Doing so may cause a memory error. SECO-LARM U.S.A., Inc. -
Page 8: Enter And Exit Base Programming Mode
Where 2~9 is the number of users required in order to gain access. In multi-user mode, the elapsed time between each user input must not exceed 5 seconds, otherwise the device will return to standby, and the process must start again. 3. Exit programming mode: SECO-LARM U.S.A., Inc. -
Page 9: Adding Users
PIN: 4~6 digits. Not recommended if you want to record user IDs since PINs will be assigned the next available user ID. Additional PINs can be added in succession. NOTE: 3. Add PIN using specific ID: (user ID) (PIN) user ID: any number 0~986 4. Exit programming mode: SECO-LARM U.S.A., Inc. -
Page 10: Adding A Card + Pin User
2. Add card: (988 or 989) (8 or 10-digit card number or read card) NOTE: When entering ENFORCER proximity card numbers, use the 8-digit number. NOTE: Add PIN: (988 or 989) (PIN) PIN: 4~6 digits 3. Exit programming mode: SECO-LARM U.S.A., Inc. -
Page 11: Adding A Super User
Delete by Card: (read card) Delete by Card Number: (8 or 10-digit card number) NOTE: When entering ENFORCER proximity card numbers, use the 8-digit number. Delete by PIN: (PIN) Delete all users: (master code) 3. Exit programming mode: SECO-LARM U.S.A., Inc. -
Page 12: Adding/Deleting Users With The Master Card
4. Backlight always OFF: Sound ON: [default] Backlight always ON: NOTE: Notification sounds refer only to the keypad's sounds (including Backlight automatically ON/OFF: card entry, door-propped-open / forced-open, wrong-code) and [default] not the external alarm. 5. Exit programming mode: SECO-LARM U.S.A., Inc. -
Page 13: Programming The External Alarm Output
The alarm duration will follow the global alarm settings, duration [default: 1 min]. However, if the global settings are set to OFF (i.e. duration: 0), those settings will override this and the alarm will not sound (see Programming the External Alarm Output, pg. 13) 3. Exit programming mode: SECO-LARM U.S.A., Inc. -
Page 14: Door-Propped-Open / Door-Forced-Open Alarm
While Card Collection Mode is enabled, any card will trigger the relay and will be entered into the system as a user. Therefore, it is crucial to remember to disable this mode after initial programming is completed. SECO-LARM U.S.A., Inc. -
Page 15: Setting Up A Two-Door Interlock System With Two Keypads
AC powered locks and for electromagnetic locks unless your (MOV, not supplied) lock has a diode/MOV built in (all SECO-LARM electromagnetic locks have built-in protection). Do not install both diode and MOV. Failure to use these as directed will void the warranty. -
Page 16: Duplicating Users To Another Keypad
LED will turn red. 3. Exit programming mode: NOTES: Both keypads must support the data transfer function and have the same master programming code. Any user data existing on the second device will be overwritten. SECO-LARM U.S.A., Inc. -
Page 17: Setting Up The Wiegand Controller Mode
AC powered locks and for electromagnetic locks unless your lock has a diode/MOV built in (all SECO-LARM electromagnetic locks have protection built- in). Do not install both diode and MOV. Failure to use as directed will void the warranty. -
Page 18: Setting Up The Wiegand Reader Mode
Set the Wiegand output bits/format according to the input format of the controller. 1. Enter programming mode: (master code) 2. Set output format: (26~44) [default: 26] 3. Disable parity bits: Enable parity bits: [default] 4. Exit programming mode: SECO-LARM U.S.A., Inc. -
Page 19: Resetting The Keypad To Factory Default
(Master code) Scanning the master card Scanning a valid user card Entering a valid user PIN (unless Access Mode is set to Card+PIN or Multi-User Access). Accessories Proximity Key fobs Proximity Cards PR-K1K1-AQ PR-K1S1-A SECO-LARM U.S.A., Inc. -
Page 20: Troubleshooting
SECO-LARM’s obligation is limited to the repair or replacement of any defective part if the unit is returned, transportation prepaid, to SECO-LARM. This Warranty is void if damage is caused by or attributed to acts of God, physical or electrical misuse or abuse, neglect, repair or alteration, improper or abnormal usage, or faulty installation, or if for any other reason SECO-LARM determines that such equipment is not operating properly as a result of causes other than defects in material and workmanship.
