Raritan PARAGON II Series Quick Installation And Setup Manual
Hide thumbs
Also See for PARAGON II Series:
- User manual (258 pages) ,
- Specifications (4 pages) ,
- Brochure (2 pages)
Advertisement
Quick Links
Paragon® II
Quick Installation and Setup Guide
Congratulations on your purchase of Paragon II devices comprising of analog Keyboard/Video/Mouse (KVM) switches and
accessory devices that enable users to access and control multiple servers from a set of keyboard, mouse and monitor.
The document provides instructions for basic installation, initial login and channel access. For more detailed information on
the Paragon II products, consult the User Guide accessible from the accompanying User Manuals and Quick Setup
Guides CD or Raritan website's Firmware and Documentation webpage
(http://www.raritan.com/support/firmware-and-documentation/).
Note: The Ethernet port on the Paragon switch is hard coded (not configurable) and supports only 10-BaseT/half duplex.
Paragon II cover 4 basic types of devices:
Main Switching Unit (Main Unit)
Models: P2‐UMT242, P2‐UMT442, P2‐UMT832M, P2‐UMT1664M
User Station
Models: P2‐UST, P2‐EUST, P2‐EUST/C
Paragon II QSG
QSG-P2-0J-v4.5-E 255-30-6010-00
Stacking Unit
Models: P2‐UMT832S, P2‐UMT1664S
Computer Interface Module (CIM)
Models: P2CIM‐APS2, P2CIM‐AUSB, P2CIM‐ASUN, and more
1
