Raritan PARAGON II Brochure

Specs
Paragon II Main Description Dimensions
Switching Units
P2-UMT1664M 16 users x 64 server ports, expansion slot, 17.32" (W) x 11.41" (D) x 3.5" (H)
stacking port, network port 440mm (W) x 290mm (D) x 89mm (H)
P2-UMT832M 8 users x 32 server ports, expansion slot, 17.32" (W) x 11.41" (D) x 1.75" (H)
stacking port, network port 440mm (W) x 290mm (D) x 44mm (H)
P2-UMT442 4 users x 42 server ports, expansion slot, 17.32" (W) x 11.41" (D) x 1.75" (H)
network port 440mm (W) x 290mm (D) x 44mm (H)
P2-UMT242 2 users x 42 server ports, 17.32" (W) x 11.41" (D) x 1.75" (H)
network port 440mm (W) x 290mm (D) x 44mm (H)
Paragon II Description Dimensions
Stacking Units
P2-UMT1664S 64 expansion server ports for stacking 17.32" (W) x 11.41" (D) x 3.5" (H)
with P2-UMT1664M 290mm (W) x 440mm (D) x 89mm (H)
P2-UMT832S 32 expansion server ports for stacking 17.32" (W) x 11.41" (D) x 1.75" (H)
with P2-UMT832M unit 290mm (W) x 440mm (D) x 44mm (H)
Paragon II Description Dimensions
User Station
P2-UST Analog access point with PS/2, USB and 11.4" (W) x 10.1" (D) x 1.75" (H)
Sun console 290mm (W) x 255mm (D) x 44mm (H)
Paragon CIMs Description Dimensions
P2CIM-PS2 CIM for PS/2 1.3" (W) x 3.0" (D) x 0.6" (H)
32mm (W) x 77.4mm (D) x 15.6mm (H)
P2CIM-SUN CIM for SUN 1.3" (W) x 3.0" (D) x 0.6" (H)
32mm (W) x 77.4mm (D) x 15.6mm (H)
P2CIM-USB CIM for USB 1.3" (W) x 3.0" (D) x 0.6" (H)
32mm (W) x 77.4mm (D) x 15.6mm (H)
P2CIM-SUSB CIM for SUN USB 1.3" (W) x 3.0" (D) x 0.6" (H)
32mm (W) x 77.4mm (D) x 15.6mm (H)
P2CIM-PS2DUAL CIM for PS/2 provides 2 separate channel 1.42" (W) x 3.39" (D) x 0.65" (H)
ports 36mm (W) x 86mm (D) x 16.5mm (H)
©2004 Raritan Computer, Inc. Raritan and Paragon are registered trademarks of Raritan Computer, Inc.; CommandCenter, IP-Reach and Paragon Manager are trademarks of
Raritan Computer, Inc.; Sun is a registered trademark of Sun Microsystems, Inc.; Microsoft and Windows are registered trademarks of Microsoft Corp.; Novell is a registered
trademark of Novell, Inc..; UNIX is a registered trademark of UNIX System Laboratories, Inc.; PS/2, pSeries and RS/6000 are registered trademarks of IBM Corporation, HP9000 is a
registered trademark of Hewlett-Packard Development Company, L.P.; SGI is a registered trademark of Silicon Graphics, Inc.
*To qualify for advanced replacement under the standard warranty, you must register the product at http://www.raritan.com/standard_warranty.
Raritan Computer Inc. / 400 Cottontail Lane / Somerset, NJ 08873 / raritan.com
Weight Power
12.52 lbs 100V/240V
5.68 kg 50/60 Hz 0.6A
9.83 lbs 100V/240V
4.46 kg 50/60 Hz 0.6A
10.13 lbs 100V/240V
4.59 kg 50/60 Hz 0.6A
10.03 lbs 100V/240V
4.54 kg 50/60 Hz 0.6A
Weight Power
11.99 lbs 100V/240V
5.44 kg 50/60 Hz 0.6A
8.99 lbs 100V/240V
4.08 kg 50/60 Hz 0.6A
Weight Power
4.3 lbs 100V/240V
1.9 kg 50/60 Hz 0.6A
Weight Power
0.20 lb n/a
0.07 kg
0.13 lb n/a
0.06 kg
0.20 lb n/a
0.07 kg
0.148 lb n/a
0.067 kg
0.177 lb n/a
0.08 kg
Paragon ® II
The Cat5 Enterprise-Class
KVM Solution
Paragon II Proven Paragon Analog Technology with Stacking,
Optional Integrated KVM-Over-IP Access and Superior
Paragon II is a stackable, Cat5
KVM switch that allows IT staff
Management Capabilities
to manage up to 128 ports per
Paragon II, the industry's best stackable Cat5 KVM (Keyboard, Video, Mouse) solution,
switch.
gives IT professionals the power to access and control servers and other network devices
UMT242
anytime, anywhere. With Paragon II, you can stack up to 128 ports per switch and add
up to 10,000 ports via multi-dimensional expansion. Paragon II has superior KVM
– 2-user
– Up to 42 ports switch technology that dramatically reduces equipment costs and optimizes space
utilization. What's more, this generation of Paragon provides the highest levels of
UMT442
manageability, security and superior video quality to simplify the management of
– 4-user
business-critical data centers.
– Up to 42 ports
Innovative Modular Architecture
UMT832M
Paragon II distributes KVM switching and control functions across modular, intelligent
– 8-user
components:
– Up to 32 ports
Main Switching Unit -
UMT832S
users to servers. Its stackable architecture provides the industry's highest port density
– UMT832M Stacking unit
making it ideal for large data centers with densely packed racks.
– Stack an additional 32 ports
Stacking Unit -
UMT1664M add up to 128 non-blocked ports per switch with 90% less cable than cascading.
Stacking units are compatible with Paragon II models UMT832M and UMT1664M.
– 16-user
These units:
– Up to 64 ports
Reduce the burden of multiple cables between tiers.
UMT1664S
Reduce Total Cost of Ownership (TCO) by more than 30%.
– UMT1664M Stacking unit
Save up to one-third of rack space and HVAC resources.
– Stack an additional 64 ports
User Station - Designed to fit conveniently under the user's monitor, the Paragon II
User Station includes an intuitive On-Screen User Interface (OSUI) for easy access to
attached servers.
Connects to USB, Sun
Computer Interface Modules (CIMs) -
at the server. Just plug a CIM into a server's keyboard, monitor and mouse ports and
connect it to Paragon II with a single UTP (Cat5/5e/6) cable. New small and slim
Paragon II CIMs provide the added convenience of firmware upgradeability without
interrupting the installed configuration.
A secure, intelligent, non-blocked control unit that connects
A cost-effective, space-saving expansion unit that allows you to easily
® and PS/2 ® .
Provide 'keep-alive' keyboard/mouse emulation
800.724.8090 / +1 732.764.8886 / Fax +1 732.764.8887 / sales@raritan.com
