Table of Contents

Advertisement

Quick Links

PX3TS Transfer Switch

User Guide

Xerus
Firmware v3.4.0
™
Copyright © 2018 Raritan, Inc.
PX3TS-1B-v3.4.0-E
January 2018
255-80-0033-00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PX3TS and is the answer not in the manual?

Questions and answers

Related Manuals for Raritan PX3TS

Summary of Contents for Raritan PX3TS

  • Page 1: User Guide

    PX3TS Transfer Switch User Guide Xerus Firmware v3.4.0 ™ Copyright © 2018 Raritan, Inc. PX3TS-1B-v3.4.0-E January 2018 255-80-0033-00...

  • Page 2: Safety Guidelines

    60950-1 or equivalent rating. Attempting to power non-rated devices may result in electric shock, fire, personal injury and death. WARNING! Do not use a Raritan product containing outlet relays to power large inductive loads such as motors or compressors. Attempting to power a large inductive load may result in damage to the relay.

  • Page 3: Safety Instructions

    Tip 1: The outlet (socket) shall be installed near the equipment and shall be easily accessible. Tip 2: For detailed information on any Raritan PDU's overcurrent protectors' design, refer to that model's product specification on Raritan website's PDU Product Selector page https://www.raritan.com/product-selector...
  • Page 4 Raritan, Inc. © Copyright 2018 Raritan, Inc. All third-party software and hardware mentioned in this document are registered trademarks or trademarks of and are the property of their respective holders.

  • Page 6: Table Of Contents

    Connecting the PX3TS to Your Network..................15   USB Wireless LAN Adapters....................17   Supported Wireless LAN Configuration ................17   Dual Ethernet Connection (for iX7™ Only)................18   Configuring the PX3TS........................19   Connecting a Mobile Device to PX3TS ................. 20...
  • Page 7   Connecting the PX3TS to a Computer ................. 24   Bulk Configuration Methods ......................27   Cascading Multiple PX3TS Devices for Sharing Ethernet Connectivity......... 28   Cascading PX3TS via USB....................30   Extended Cascading with PX3TS-iX7 Models ..............33  ...
  • Page 8 PX3TS-iX7 Connection Ports....................94   Connection Port Functions ....................95   Front LCD Display........................... 97   PX3TS Character LCD Display ..................... 98   PX3TS-iX7 Dot-Matrix LCD Display ................... 112   Reset Buttons ..........................132   Fuses for the Inlet Transfer Switch ..................... 133  ...
  • Page 9 Power Quality Settings....................... 174   PDU ............................... 176   Internal Beeper State ......................181   PX3TS Latching Relay Behavior..................182   Options for Outlet State on Startup ................... 182   Initialization Delay Use Cases.................... 183   Inrush Current and Inrush Guard Delay................183  ...
  • Page 10 Device Information......................405   Viewing Connected Users ....................410   Viewing or Clearing the Local Event Log................412   Updating the PX3TS Firmware ..................413   Viewing Firmware Update History ..................417   Bulk Configuration ......................418   Backup and Restore of Device Settings................425  ...
  • Page 11 Contents   A Note about Enabling Thresholds ..................460 Chapter 8 Using the Command Line Interface     About the Interface ........................462   Logging in to CLI........................... 462   With HyperTerminal......................462   With SSH or Telnet......................463   With an Analog Modem ......................
  • Page 12 Clearing WLAN Log......................500   Entering Configuration Mode ....................... 500   Quitting Configuration Mode ......................501   PX3TS Control and Configuration ....................501   Controlling the Transfer Switch ..................501   PDU Configuration Commands..................506   Network Configuration Commands................... 514  ...
  • Page 13 Contents   Network Troubleshooting......................645   Entering Diagnostic Mode....................645   Quitting Diagnostic Mode....................646   Diagnostic Commands ....................... 646   Retrieving Previous Commands....................648   Automatically Completing a Command ..................648   Logging out of CLI......................... 649 Chapter 9 Using SCP Commands  ...
  • Page 14   Step B. Configure User Groups on the AD Server ............... 706   Step C. Configure LDAP Authentication on the PX3TS Device ............ 707   Step D. Configure Roles on the PX3TS Device ................708 Appendix G Updating the LDAP Schema  ...
  • Page 15 Contents   AD-Related Configuration ......................750 Appendix I Additional PX3TS Information     SecureLock™ Outlets and Cords ....................754   RJ45-to-DB9 Cable Requirements for Modem Connections (for iX7™ Only) ......756   Reserving IP Addresses in DHCP Servers ................... 757  ...
  • Page 16 Contents Index   xvii...

  • Page 17: Applicable Models

    PX3TS with iX7 Generation ™ Any PX3TS Generations can be associated with existing metering families called “Series”, including 200R series, 1000 series and 5000 series. For example, PX3TS-1000, and PX3TS-iX7-1000 series are all inlet metered models with receptacles, but have different controller generations.
  • Page 18 Applicable Models Comparison between PX3TS and PX3TS-iX7: Product models PX3TS Series PX3TS with iX7 ™ Controller Character LCD Dot-matrix LCD display Front panel display Outlet latching relays Number of USB-A ports 12 Mbps 480 Mbps Maximum USB rate Number of LAN ports...
  • Page 19 What's New in the PX3TS User Guide The following sections have changed or information has been added to the PX3TS User Guide based on enhancements and changes to the equipment and/or user documentation. Applicable Models (on page xviii) Introduction (on page 1)
  • Page 20 What's New in the PX3TS User Guide PX3TS Connection Ports (on page 94) PX3TS-iX7 Connection Ports (on page 94) Connection Port Functions (on page 95) Front LCD Display (on page 97) PX3TS Character LCD Display (on page 98) PX3TS-iX7 Dot-Matrix LCD Display...
  • Page 21 Chapter 1: What's New in the PX3TS User Guide (on page 119) Z Coordinate Format (on page 184) Inlets (on page 186) Individual Inlet Pages (on page 188) Load Shedding Mode (on page 199) Individual OCP Pages (on page 211)
  • Page 22 What's New in the PX3TS User Guide Bulk Configuration (on page 418) Bulk Configuration Restrictions (on page 419) Customizing Bulk Configuration Profiles (on page 421) Performing Bulk Configuration (on page 422) Modifying or Removing Bulk Profiles (on page 424) Backup and Restore of Device Settings...
  • Page 23 Chapter 1: What's New in the PX3TS User Guide Changing the LAN Interface Speed (on page 525) Changing the LAN Duplex Mode (on page 526) Setting NTP Parameters (on page 544) Enabling or Disabling Front Panel Actuator Control (on page 566)
  • Page 24 What's New in the PX3TS User Guide Default Voltage and Current Thresholds (on page 769) Possible Root Causes (on page 773) The Ping Tool (on page 776) Device-Specific Settings (on page 782) TLS Certificate Chain (on page 783) What is a Certificate Chain...

  • Page 25: Product Models

    APIPA and Link-Local Addressing ..............7 Before You Begin..................8 Product Models The PX3TS comes in several models that are built to stock and can be obtained almost immediately. Raritan also offers custom models that are built to order and can only be obtained on request.

  • Page 26: Px3Ts Overview

    This section introduces the components shown on the front and rear panels of a PX3TS device. Front View When PX3TS or PX3TS-iX7 models are rated over 20A (North America) or 16A (international), they have overcurrent protectors for controlling the current flowing through outlets.
  • Page 27  Active inlet indicator lamps 4. Transfer switch alarm indicators 5. Transfer switch control buttons 6. Overcurrent protectors - one for each bank of outlets (available on some models only) PX3TS-iX7 Models 1U models: 2U models: 1. Eight connection ports...

  • Page 28: Rear View

    7. Overcurrent protectors - one for each bank of outlets (available on some models only) Rear View Available connection ports are the same between PX3TS and PX3TS-iX7 models. PX3TS Models Inlets, outlets and fuses for the inlet transfer switch are located on the rear panel.
  • Page 29 2. Two fuses for the inlet transfer switch - one per inlet 3. Outlets 4. Two connection ports  USB-A port  CONSOLE port PX3TS-iX7 Models Inlets, outlets and fuses for the inlet transfer switch are located on the rear panel. 1U models:...

  • Page 30: Package Contents

    Warranty card  Two replacement fuses for the inlet transfer switch Note: Depending on your PX3TS' ratings, appropriate fuse types vary. You can order additional fuses from Raritan. See Technical (on page 656) in the User Guide for appropriate fuse Specifications types and Raritan part numbers for these fuses.

  • Page 31: Apipa And Link-Local Addressing

    APIPA and the link-local address is replaced by the DHCP-assigned address. Scenarios where APIPA applies:  DHCP is enabled on the PX3TS, but no IP address is assigned to the PX3TS. This may be caused by the absence or malfunction of DHCP servers in the network.

  • Page 32: Before You Begin

    Raritan's Technical Support Department for assistance. 4. Verify that all circuit breakers on the PX3TS device are set to ON. If not, turn them ON. Or make sure that all fuses are inserted and seated properly. If there are any fuse covers, ensure that they are closed.

  • Page 33: Filling Out The Equipment Setup Worksheet

    Chapter 1: Introduction Filling Out the Equipment Setup Worksheet An Equipment Setup Worksheet is provided in this User Guide. See Equipment Setup Worksheet (on page 662). Use this worksheet to record the model, serial number, and use of each IT device connected to the PDU.

  • Page 34: Chapter 2 Rackmount, Inlet And Outlet Connections

    Mounting a PX3TS Device Using appropriate brackets and tools, fasten the 1U or 2U PX3TS device to the rack or cabinet. The way to install a PX3TS device varies according to the device length. To mount a PX3TS device which is long: 1.
  • Page 35 Chapter 2: Rackmount, Inlet and Outlet Connections 2. Adjust slide-rail assemblies to match your rack posts and fasten them to the rack using your own fasteners. 3. Line up the mounting brackets with slide-rails and push this product into rails.
  • Page 36 4. Fasten front mounting ears to the rack using your own fasteners. To mount a PX3TS device which is short: 1. Attach a rackmount bracket to both sides of the PX3TS with the provided screws. For a 1U model, the total number and locations of screw holes are different from the following 2U diagram.

  • Page 37: Inlet And Outlet Power Connections

    The PX3TS connects to two different, but identically rated, branch circuits. The PX3TS will operate when the branch circuit voltages are out of phase, but works most reliably and fastest when in phase. The front panel Phase Sync lamp lights if inlets are out of phase.

  • Page 38: Chapter 3 Initial Installation And Configuration

    Your PX3TS may have fuses and/or circuit breakers. Verify that all are firmly seated or set to ON before connecting power. The PX3TS inlets are labeled INLET 1 (I1) and INLET 2 (I2). INLET 1 is the factory default preferred inlet, and INLET 2 is the factory default alternate inlet.

  • Page 39: Connecting The Px3Ts To Your Network

    To remotely administer the PX3TS, you must connect the PX3TS to your local area network (LAN). PX3TS can be connected to a wired or wireless network. Note: If your PX3TS will work as a master device in the bridging mode, you must make a wired connection. See Cascading PX3TS via USB page 30).
  • Page 40 Plug a supported USB wireless LAN adapter into the USB-A port on your PX3TS.  Connect a USB hub to the USB-A port on the PX3TS. Then plug the supported USB wireless LAN adapter into the appropriate USB port on the hub.

  • Page 41: Usb Wireless Lan Adapters

    TP-Link TL-WDN3200 v1 A/B/G/N Raritan USB WIFI A/B/G/N Note: To use the Edimax EW-7722UnD or Raritan USB WIFI wireless LAN adapter to connect to an wireless network, the handshake 802.11n timeout setting must be changed to 500 or greater, or the wireless connection will fail.

  • Page 42: Dual Ethernet Connection (For Ix7™ Only)

    Exception: A USB-cascading chain must connect to "only one" network. Do NOT connect both Ethernet ports of an iX7 master or slave device to ™ the LAN. See Cascading Multiple PX3TS Devices for Sharing Ethernet (on page 28). Connectivity Check list when connecting both ports to the networks: ...

  • Page 43: Configuring The Px3Ts

    Chapter 3: Initial Installation and Configuration Configuring the PX3TS You can initially configure the PX3TS via one of the following:  A TCP/IP network that supports DHCP  A mobile device with PDView installed  A computer physically connected to the PX3TS...

  • Page 44: Connecting A Mobile Device To Px3Ts

    1. Get an appropriate USB cable for your mobile device.  : Use the regular USB cable shipped with your iOS mobile device.  Android : Use an USB OTG adapter cable. 2. Connect the mobile device to the appropriate USB port on the PX3TS.  : USB-A port.
  • Page 45 Chapter 3: Initial Installation and Configuration  Android : USB-B port Step 3: Launch PDView to access the PX3TS 1. Launch the PDView app from your mobile device. Below illustrate iPad's PDView screens. a. The "Disconnected" message displays first when PDView has not detected the PX3TS yet.
  • Page 46 The PDView shows the "Connected" message when it detects the connected PX3TS. 2. If the factory-default user credentials "admin/raritan" remain unchanged, PDView automatically logs in to the PX3TS web interface. If they have been changed, the login screen displays instead and you must enter appropriate user credentials for login.
  • Page 47 The following procedure illustrates iPad only, but the procedure applies to any iOS or Android mobile devices. To save user credentials in PDView: 1. Make sure your mobile device is NOT connected to the PX3TS so that PDView does NOT perform the automatic login feature after it is launched.

  • Page 48: Connecting The Px3Ts To A Computer

    4. The user credentials setup page opens. 5. Type the desired user credentials, and tap Save. Connecting the PX3TS to a Computer The PX3TS can be connected to a computer for configuration via one of the following ports.  ETHERNET port ...
  • Page 49 Chapter 3: Initial Installation and Configuration  PX3TS-iX7 front panel ports: The PX3TS has two RS-232 serial ports on its front and back panels respectively. Both ports are functionally identical.   PX3TS 1U back panel RS-232 port: PX3TS-iX7 1U back panel RS-232 port: To use the command line interface (CLI) for configuration, establish an RS-232 or USB connection.
  • Page 50 Installing the USB-to-Serial before connecting the USB cable. See Driver (Optional) (on page 776). 2. Connect a USB cable between the PX3TS device's USB-B port and a computer's USB-A port. Initial Network Configuration via CLI 3. Perform (on page 777).

  • Page 51: Bulk Configuration Methods

    Modem Connections (for iX7 Only) ™ Bulk Configuration Methods If you have to set up multiple PX3TS devices, you can use one of the following configuration methods to save your time. Use a bulk configuration file:  Requirement: All PX3TS devices to configure are of the same model and firmware.

  • Page 52: Cascading Multiple Px3Ts Devices For Sharing Ethernet Connectivity

     Procedure: Plug this USB drive into the PX3TS. When a happy smiley is shown on the front panel display, press and hold one of the control buttons on the front panel until the display turns blank.
  • Page 53  The cascading mode of all devices in the chain must be the same.  (WIFI only) You must use Raritan's USB WIFI wireless LAN adapter instead of other WIFI adapters for wireless network connection. Troubleshooting: When a networking issue occurs, check the cascading connection and/or Cascading software settings of all devices in the chain.

  • Page 54: Cascading Px3Ts Via Usb

    Setting the Cascading Mode (on page 282). Any certified USB 2.0 cable up to 5 meters (16 feet) long can be used. Both cascading modes support a maximum of 16 devices in a chain. The following diagram illustrates PX3TS devices cascaded via USB.
  • Page 55 5. Connect the USB-A port of the master device to the USB-B port of an additional PX3TS via a USB cable. This additional device is Slave 1. 6. Connect Slave 1's USB-A port to the USB-B port of an additional PX3TS via another USB cable.
  • Page 56 Port Forwarding mode: Only the master device's network settings should be configured. A tip for USB cascading: The "USB-cascading" chain can be a combination of diverse Raritan products that support the USB-cascading feature, including PX2, PX3, PX3-iX7, transfer switch, BCM and EMX.

  • Page 57: Extended Cascading With Px3Ts-Ix7 Models

    Chapter 3: Initial Installation and Configuration Extended Cascading with PX3TS-iX7 Models Only PX3TS-iX7 supports cascading via either Ethernet or USB ports because they have two Ethernet ports and two USB-A ports. You can use either Ethernet port on the iX7 device for cascading.
  • Page 58 1000 Mbps. To cascade iX7 PDUs via Ethernet ports: ™ 1. Make sure all Raritan devices are running firmware version 3.3.10 or later. 2. Choose one iX7 PDU as the master device. ™...
  • Page 59 Chapter 3: Initial Installation and Configuration 6. Connect Slave 1's available Ethernet port to either Ethernet port of another iX7 via a standard network patch cable. The second ™ additional device is Slave 2. 7. Repeat the same step to connect more iX7 devices.

  • Page 60: Unsupported Cascading Connections For Port Forwarding

    USB and Ethernet cables between two cascaded devices. The following diagrams illustrate cascading connections that are NOT supported. Note: These diagrams are based on Raritan's PX3-iX7 Zero U PDUs, but the same guidelines apply to other Raritan iX7 products. ™...
  • Page 61 Chapter 3: Initial Installation and Configuration  One cascaded device has two upstream devices via Ethernet and USB cables.  One cascaded device has two downstream devices.

  • Page 62: Power-Sharing Restrictions And Connection (For Ix7™ Only)

    Chapter 3: Initial Installation and Configuration  One device is connected to another device via two cascading cables - USB and Ethernet cables. Power-Sharing Restrictions and Connection (for iX7™ Only) Two iX7 devices can share power supply to their controllers via ™...

  • Page 63: Making A Power-Sharing Connection

    Note: Outlet switching is not available because all outlets lose power.  Monitor the status of connected Raritan environmental sensor packages, or configure/control their settings.  Operate the front panel display. Events that occur when entering the power-sharing mode: ...

  • Page 64: Power-Sharing Configurations And Restrictions

    Chapter 3: Initial Installation and Configuration  Note that the EXPANSION port location on your iX7 may differ ™ from the following images. Power-Sharing Configurations and Restrictions When either iX7 PDU enters the power-sharing mode, BOTH PDUs ™ involved in the power-sharing connection support "less" external equipment than usual.

  • Page 65: Supported Sensor Configurations For Power Sharing

    All information and restrictions described in this section apply to BOTH PDUs involved in the power-sharing configuration, unless otherwise specified. There are no limitations for connecting Raritan's DPX or DPX2 environmental sensor packages to an iX7 PDU in the power-sharing ™...
  • Page 66 BOTH PDUs. Warning: The in-rush current of a newly added sensor package may cause both PDUs to reboot. For information on Raritan's sensor packages or hubs, see Connecting Environmental Sensor Packages (on page 43).

  • Page 67: Chapter 4 Connecting External Equipment (Optional)

    An environmental sensor package may comprise sensors only or a combination of sensors and actuators. The PX3TS can manage a maximum of 32 sensors and/or actuators. The supported maximum cabling distance is 98 feet (30 m), except for DPX sensor packages.

  • Page 68: Identifying The Sensor Port

    Chapter 4: Connecting External Equipment (Optional) Identifying the Sensor Port Warning: If you purchase Raritan's environmental sensor packages, make sure you connect them to the correct port on the PX3TS, or damages may be caused to the PX3TS and/or connected sensor packages.

  • Page 69: Dpx Sensor Packages

    Connect the adapter's RJ-45 connector to the RJ-45 SENSOR port of the PX3TS. To directly connect a differential air pressure sensor: 1. Connect a Raritan-provided phone cable to the IN port of a differential air pressure sensor. 2. Get an RJ-12 to RJ-45 adapter. Connect the adapter's RJ-12 connector to the other end of the phone cable.
  • Page 70 Optionally, you can connect a Raritan DPX-ENVHUB4 sensor hub to the PX3TS. This allows you to connect up to four DPX sensor packages to the PX3TS via the hub. This sensor hub supports DPX sensor packages only. Do NOT connect DPX2, DPX3 or DX sensor packages to it.
  • Page 71 SENSOR port. 2. Connect DPX sensor packages to any of the four OUT ports on the hub. This diagram illustrates a configuration with a sensor hub connected. The PX3TS device RJ-12 to RJ-45 adapter Raritan-provided phone cable DPX-ENVHUB4 sensor hub...
  • Page 72 Chapter 4: Connecting External Equipment (Optional) b. Connect the adapter's RJ-45 connector to the RJ-45 SENSOR port on the PX3TS. 2. The cable has two RJ-12 sensor ports. Connect DPX sensor packages to the cable's sensor ports. 3. Repeat the above steps if there are additional SENSOR ports on your...
  • Page 73 PX3TS and the sensor hub is up to 33' (10 m). Maximum distance illustration: The following illustrates the maximum distance when connecting DPX sensor packages with a maximum 16' (5 m) sensor cable to a PX3TS via a sensor hub. ...

  • Page 74: Dpx2 Sensor Packages

    RJ-12 connector and one to three head connectors. You have to connect DPX2 sensor packages to the sensor cable. For more information on DPX2 sensor packages, access the Environmental Sensors and Actuators Guide (or Online Help) on Raritan Support page http://www.raritan.com/support/...
  • Page 75 NOT work properly. Therefore, always occupy all head connectors prior to the final sensor package with a DPX2 sensor package. To connect DPX2 sensor packages to the PX3TS: 1. Connect a DPX2 sensor package to the first head connector of the DPX2 sensor cable.

  • Page 76: Dpx3 Sensor Packages

    DPX3 sensor package. LED for indicating the sensor status. To connect DPX3 sensor packages to the PX3TS: 1. Connect a standard network patch cable (CAT5e or higher) to either RJ-45 port on the DPX3 sensor package.
  • Page 77 Chapter 4: Connecting External Equipment (Optional) Repeat the same steps to cascade more DPX3 sensor packages. 3. Connect the first DPX3 sensor package to the PX3TS by plugging its cable's connector into the RJ-45 SENSOR port of the PX3TS. Connecting a DPX2 Sensor Package to DPX3 You can connect only one DPX2 sensor package to the "end"...

  • Page 78: Dx Or Dx2 Sensor Packages

    32 sensors and/or actuators. If there are more than 32 sensors and/or actuators connected, every sensor and/or actuator after the 32nd one is NOT managed by the PX3TS. For example, if you cascade 12 DX packages, and each package contains...
  • Page 79 Exception: You CANNOT cascade DX-PD2C5 sensor packages. A PX3TS device supports only one DX-PD2C5. 3. Connect the first DX sensor package to the PX3TS by plugging its cable's connector into the RJ-45 SENSOR port of the PX3TS. 4. If needed, connect a DPX2 sensor package to the end of the DX chain.
  • Page 80 Chapter 4: Connecting External Equipment (Optional) Connecting a DPX2 Sensor Package to DX You can connect only one DPX2 sensor package to the "end" of a DX sensor chain. It is strongly recommended to use an RJ-12 to RJ-45 adapter for connecting the DPX2 to the final DX in the chain. The maximum number of DX sensor packages in the chain must be less than 12 when a DPX2 sensor package is involved.

  • Page 81: Using An Optional Dpx3-Envhub4 Sensor Hub

    Plug one end of the cable into the IN port (Port 1) of the hub. b. Plug the other end of the cable into the RJ-45 SENSOR port of the PX3TS. 2. Connect the Raritan sensor packages to any of the four OUT ports on the hub. ...

  • Page 82: Mixing Diverse Sensor Types

    DPX3-ENVHUB4 sensor hub Any Raritan sensor packages Mixing Diverse Sensor Types You can mix DPX, DPX2, DPX3 and DX sensor packages on one PX3TS according to the following sensor combinations. In some scenarios, the DPX3-ENVHUB4 sensor hub is required. The PX3TS does NOT support any other sensor-mixing combinations than those described in this section.
  • Page 83 Chapter 4: Connecting External Equipment (Optional)  A DPX2 sensor package  A DPX sensor package...
  • Page 84 Chapter 4: Connecting External Equipment (Optional)  An RJ-12 to RJ-45 adapter is recommended to connect a DPX or DPX2 sensor package to DPX3-ENVHUB4.  In the following diagrams, the sensor package in "green" can be replaced by a DPX2 sensor package. The sensor package in "blue" can be one DPX2, DPX3 or DX sensor package.
  • Page 85 Chapter 4: Connecting External Equipment (Optional)
  • Page 86 Chapter 4: Connecting External Equipment (Optional) Mix DPX3 and DX in a sensor chain: Any DX sensor package in a chain can be replaced by a DPX3 sensor package, or vice versa. The total number of sensor packages in this chain cannot exceed 12.

  • Page 87: Before Connecting Equipment To Feature Port

    Chapter 4: Connecting External Equipment (Optional) Before Connecting Equipment to Feature Port PX3TS models have a cap plugged into the FEATURE port when shipping out of the factory. The cap is intended to protect the port from connecting to inappropriate equipment. Remove this cap when you need to connect equipment to this port.

  • Page 88: Combining Regular Asset Strips

    The difference between the master and slave asset strips is that the master asset strip has an RJ-45 connector while the slave does not. The following diagram illustrates some asset strips. Note that Raritan provides more types of asset strips than the diagram.
  • Page 89 Chapter 4: Connecting External Equipment (Optional)  Make sure that the U-shaped sheet metal adjacent to the male DIN connector is inserted into the rear slot of the master strip. Screw up the U-shaped sheet metal to reinforce the connection. 2.

  • Page 90: Introduction To Asset Tags

    IT device at one end and plugged in to an asset strip at the other. The asset strip is connected to the PX3TS, and the asset tag transmits the ID and positioning information to the asset strip.
  • Page 91 All LEDs on the asset strip assembly may cycle through different colors during the power-on process if the asset strip's firmware is being upgraded by the PX3TS. After the power-on or firmware upgrade process completes, the LEDs show solid colors.

  • Page 92: Connecting Blade Extension Strips

    For blade servers, which are contained in a single chassis, you can use a blade extension strip to track individual blade servers. Raritan's blade extension strip functions similar to a Raritan asset strip but requires a tag connector cable for connecting it to a tag port on the regular or composite asset strip.
  • Page 93 Cable socket(s) for connecting the tag connector cable Note: Each tag port on the blade extension strip is labeled a number, which is displayed as the slot number in the PX3TS device's web interface. To install a blade extension strip: 1.
  • Page 94 Up to 128 asset tags on blade extension strips are supported per FEATURE port. Note: If you need to temporarily disconnect the blade extension strip from the asset strip, wait at least 1 second before re-connecting it back, or the PX3TS device may not detect it.

  • Page 95: Connecting Composite Asset Strips (Ams-Mx-Z)

    If there are only 2 or 3 IT devices to track, you can connect only one AMS-M2-Z or AMS-M3-Z to the PX3TS device. In this case, go to step 2. If there are more than 2 or 3 IT devices, you need to daisy chain multiple composite asset strips and start from step 1.
  • Page 96 Note: Different types of composite asset strips can be mixed in a chain as of release 3.3.0. 2. Connect the composite asset strip(s) to the PX3TS device via a standard network patch cable (CAT5e or higher). a. Connect one end of the cable to the RJ-45 port labeled "Input" on the composite asset strip.
  • Page 97 PMC (BCM2 series) Note for PX3TS-iX7 only: In case you hot swap or hot plug any AMS-Mx-Z in a chain, causing the FEATURE port of the PX3TS-iX7 to malfunction, you can power cycle or reset the PX3TS to restore the FEATURE port.

  • Page 98: Connecting A Logitech Webcam

    Chapter 4: Connecting External Equipment (Optional) Connecting a Logitech Webcam Connect webcams to PX3TS in order to view videos or snapshots of the webcam's surrounding area. The following USB Video Class (UVC) compliant webcam is supported:  Logitech Webcam Pro 9000, Model 960-000048 ®...

  • Page 99: Connecting An Analog Modem

    The PX3TS supports remote dial-in communications to access the CLI through an analog modem. This dial-in feature provides an additional alternative to access the PX3TS when the LAN access is not available. To dial in to the PX3TS, the remote computer must have a modem connected and dial the correct phone number.

  • Page 100: Connecting An External Beeper

     Mallory Sonalert MODEL SNP2R After having an external beeper connected, you can create event rules for the PX3TS to switch on or off the external beeper when specific Event Rules and Actions events occur. See (on page 329).

  • Page 101: Chapter 5 Using The Px3Ts

    Short Circuit Detection................92 Outlets ....................... 92 Connection Ports ..................93 Front LCD Display ..................97 Reset Buttons ..................132 Fuses for the Inlet Transfer Switch ............133 Overcurrent Protectors for Outlets............137 Beeper ..................... 138 Power Cycling the PX3TS ................ 138...

  • Page 102: Power Transfer

    Chapter 5: Using the PX3TS Power Transfer The PX3TS has two inlets: INLET 1 and INLET 2. These inlets are to connect to diverse power sources. One inlet is configured as the primary (preferred), and the other is configured as the standby (alternate). The factory default preferred power source is Inlet 1, and the default alternate source is Inlet 2.

  • Page 103: Automatic Transfer

    The preferred inlet's power quality (voltage or frequency) enters the critical level. Power quality is indicated through the Power Quality indicator lamps. Power Quality Indicator Lamps (on page 87). The table below indicates which inlet the PX3TS selects when the power quality changes. Inlet power quality Active inlet Preferred...
  • Page 104 Chapter 5: Using the PX3TS ALTERNATE INLET STATES PREFERRED Power Normal Power Warning Power Critical Phase Sync Overload INLET STATES (green lamp) (orange lamp) (red lamp) alarm Power Critical (red lamp) Power Warning (orange lamp) Switch Open fault MOV surge...
  • Page 105 Chapter 5: Using the PX3TS ALTERNATE INLET STATES PREFERRED INLET STATES Switch open Switch short MOV fault Fuse alarm 12V SMPS fault fault fault Power Critical (red lamp) Power Warning (orange lamp) Switch Open fault MOV surge protector fault Fuse alarm...

  • Page 106: Automatic Retransfer

     An internal hardware malfunction on the preferred inlet's circuitry may lead to a less reliable power state. Note: The PX3TS indicates an alarm through the Alarm indicator lamps. (on page 89). Alarm Indicator Lamps Tip: Per default the automatic retransfer can be performed only when both inlets are in phase.
  • Page 107 Chapter 5: Using the PX3TS Tip: To remotely perform manual transfer using the web interface, see Transfer Switch (on page 162). To transfer using the CLI, see Performing Manual Transfer (on page 502). A manual transfer using the front panel button is prevented if: ...
  • Page 108 Fuse alarm 12V SMPS fault Whenever the PX3TS prevents a manual transfer from being performed, it is disabled across all interfaces, including the front panel button, web interface and CLI command. Note: Switch open/short, MOV, 12V SMPS faults are internal transfer switch faults, causing the Internal Failure indicator lamp on the front panel to turn on.

  • Page 109: Transfer Switch Indicator Lamps

    Manual transfer is prevented when the PX3TS enters an alarm state, such as the Phase Sync alarm. In certain scenarios, you still can force the PX3TS to perform a manual transfer by holding the Alarm Override Manual Transfer button while pressing the Manual Transfer button. See Scenarios (on page 84).
  • Page 110 Chapter 5: Using the PX3TS These lamps are divided into 3 sections to indicate the inlet power status or configuration. Section Lamp type Function Power Inlet power quality is shown using a tricolor LED. Quality Power Quality Indicator Lamps For details, see (on page 87).

  • Page 111: Power Quality Indicator Lamps

    Chapter 5: Using the PX3TS Power Quality Indicator Lamps The PX3TS monitors AC voltage and frequency of both inlets and rates the power quality into 3 categories. When the power quality of any inlet changes, the corresponding Power Quality lamp, which is a tricolor LED, changes its colors.

  • Page 112: Inlet Configuration Indicator Lamps

    A green LED indicates which inlet is preferred. The default is Inlet 1. A "Preferred" inlet is the power source that you prefer using for powering the PX3TS as long as this inlet's power is available and power quality is good. The other inlet is the "Alternate" inlet.

  • Page 113: Alarm Indicator Lamps

    Chapter 5: Using the PX3TS Alarm Indicator Lamps The PX3TS provides five Alarm indicator lamps, which are lit to alert you when the PX3TS detects unusual or abnormal transfer switch conditions. Indicator lamps Meaning when the lamp is on Manual Disabled The front panel Manual Transfer button is disabled.

  • Page 114: Control Push Buttons

    Short Circuit Detection (on page 92). Control Push Buttons The PX3TS provides three buttons on the front panel to perform manual transfer or verify the transfer switch indicator lamps. The table describes each button's function. Button...

  • Page 115: Testing Indicator Lamps

    Chapter 5: Using the PX3TS Button Description Lamp Test Turns on all transfer switch indicator lamps. Power Quality LEDs turn orange. Testing Indicator Lamps (on page 91). Manual Transfer Transfers power to the other inlet. Newly-activated inlet becomes the preferred inlet.

  • Page 116: Short Circuit Detection

    A short circuit in the load results in a power failure on the active inlet. The PX3TS monitors load current and does NOT perform an automatic power transfer if power fails because of an overload. Instead, the PX3TS Alarm activates the Overload alarm and turns on the Overload lamp. See Indicator Lamps (on page 89).

  • Page 117: Px3Ts-200 R Series

    (on page 92). The major difference between PX3TS-200 R and PX3TS-1000 is that a PX3TS-200 R model has cable glands in place of regular outlets, so that you can use wanted power cords to connect IT devices to PX3TS. Connection Ports The total number of ports depends on the PX3TS generation -- PX3TS or PX3TS-iX7.

  • Page 118: Px3Ts Connection Ports

    Chapter 5: Using the PX3TS PX3TS Connection Ports The PX3TS generation has 8 connection ports on the front and back panels respectively. Front panel ports:  1 Console/Modem (DB9)  1 Sensor (yellow)  1 USB-B  1 USB-A ...

  • Page 119: Connection Port Functions

    USB-B Cascading PX3TS via USB (on page 30).  Establishing a USB connection between a computer and the PX3TS for using the command line interface or performing the disaster recovery. For disaster recovery instructions, contact Raritan Technical Support. USB-A This is a "host" port, which is powered, per USB 2.0 specifications.
  • Page 120 MODEM modem. (DB9) This is a standard DTE RS-232 port. You can use a null-modem cable with two DB9 connectors on both ends to connect the PX3TS to the computer. SENSOR Connection to one of the following devices:  (RJ-45) Raritan's environmental sensor package(s).

  • Page 121: Front Lcd Display

    It consists of:  An LCD display  Four control buttons Depending on your PX3TS generation, the front panel display type of your PX3TS differs. Operation ways of diverse front panel displays are also different.  PX3TS Character LCD Display (on page 98) ...

  • Page 122: Px3Ts Character Lcd Display

    During the firmware upgrade, "FUP" is displayed. Two types of information may be displayed:  The "ALARM" status of the selected target.  The selected inlet line number if your PX3TS is a 3-phase model. The measurement unit of the displayed data, such as %...
  • Page 123 Chapter 5: Using the PX3TS Section Information shown This section indicates:  The Asset Strip mode if an asset strip has been connected to the PX3TS.  MASTER The device's USB-cascading state - SLAVE . If it is a standalone device, neither MASTER nor SLAVE is displayed.
  • Page 124 2. On a multi-inlet model, press the Up or Down button until the desired inlet's number is displayed at the top. 3. If your PX3TS is a 3-phase model, the selected inlet line is indicated below the reading. Press the Up or Down button until the desired inlet line's number (L1, L2, L3, L1-L2, L2-L3 or L3-L1) is shown.
  • Page 125 Chapter 5: Using the PX3TS Outlet Information The outlet mode is NOT available for PX3TS-1000 series. The Outlet mode is displayed as "OUTLET" on the LCD display. By default the PX3TS displays the current reading of OUTLET 1. Below illustrates the outlet information shown on the LCD display.
  • Page 126 This circuit breaker's current reading is 0 amps. The word "CLOSE" indicates that the state of the selected circuit breaker is closed. The word "MASTER" indicates the PX3TS is the master device in a cascading chain. For a slave device, it shows "SLAVE" instead.
  • Page 127 "i4" indicates that the IP address shown on the LCD display is an IPv4 address. The word "MASTER" indicates the PX3TS is the master device in a cascading chain. For a slave device, it shows "SLAVE" instead. Note: As of release 3.3.10, the "MASTER/SLAVE"...
  • Page 128 Chapter 5: Using the PX3TS If you connect your PX3TS to the wireless network, a Wi-Fi icon is displayed at the bottom-right corner. To retrieve the "IPv4" address on PX3TS: 1. Press the MODE button to enter the Device mode, indicated by an alphabet "d"...
  • Page 129 Chapter 5: Using the PX3TS Section Example information The LCD display is showing "03," which is part of the MAC address. To display the MAC address: 1. Press the MODE button to enter the Device mode, indicated by a 'd' in at the top left of the display.
  • Page 130 Chapter 5: Using the PX3TS Number Example information The word "MASTER" indicates the PX3TS is the master device in a cascading chain. For a slave device, it shows "SLAVE" instead. Note: As of release 3.3.10, the "MASTER/SLAVE" information is no longer available in the Bridging mode, but remains available in the Port Forwarding mode.
  • Page 131 Chapter 5: Using the PX3TS States Description Alarmed state.  This state is accompanied with the word "ALARM" below it.  Available states for a dry contact signal actuator (DX sensor series): States Description The actuator is turned on. The actuator is turned off.
  • Page 132 Chapter 5: Using the PX3TS 7. Press the FUNC button to display the serial number of the sensor, which is shown as "s:XX," where XX are two digits of the serial number. The LCD will cycle through the serial number from the first two digits to the final two.
  • Page 133 Chapter 5: Using the PX3TS To cancel the outlet switching operation, press the FUNC button again. 4. To turn on the outlet, press the Up button. The "on?" confirmation message displays. To turn off the outlet, press the Down button. The "oF?" confirmation message displays.
  • Page 134 Chapter 5: Using the PX3TS Asset Strip Information If there is any asset strip connected to the PX3TS, you can enter the Asset Strip mode to show the asset tag state of each rack unit on the asset strip. A rack unit refers to a tag port on the asset strips.
  • Page 135 "d" means the LCD display has entered the Device mode. "CA" indicates that the cascading information is being displayed. "SLAVE" indicates that this PX3TS is a slave device. Note: For a master device, it shows the word "MASTER" instead. The number 1 means the device position is Slave 1.

  • Page 136: Px3Ts-Ix7 Dot-Matrix Lcd Display

    Slave 1 Slave 9 Slave 2 Slave 10 Slave 3 Slave 11 Slave 4 Slave 12 Slave 5 Slave 13 Slave 6 Slave 14 Slave 7 Slave 15 PX3TS-iX7 Dot-Matrix LCD Display A PX3TS-iX7 model comes with a dot-matrix LCD display.
  • Page 137 Chapter 5: Using the PX3TS Automatic and Manual Modes After powering on or resetting the PX3TS, the front panel LCD display first shows the dots, then Raritan logo and finally enters the automatic mode. Automatic mode without alerts available: In this mode, the LCD display cycles through the transfer switch/inlet information as long as there are no alerts.
  • Page 138 Chapter 5: Using the PX3TS Control Buttons Use the control buttons to navigate to the menu in the manual mode. Button Function Down Back -- OR -- Switch between automatic and manual modes...
  • Page 139 Enter manual mode when you want to operate the dot-matrix LCD display. You can use the dot-matrix LCD display to:  Show information of the PX3TS device, built-in components, or connected peripheral devices  Control outlets if your model supports outlet-switching ...
  • Page 140 Chapter 5: Using the PX3TS Main Menu The Main Menu contains 6 to 8 menu commands, depending on the model. Tip: The top-right number in the corner of the display indicates the total number of menu commands. For example, there are 7 menu commands in total in the diagram below.
  • Page 141 This menu command is only available on outlet-switching capable models, such as PX3TS-5000 series. Shows each outlet's information. Outlets If your PX3TS supports outlet-switching, you can turn on, off or power cycle an outlet. Outlets (on page 122). Shows the information of connected Raritan environmental sensors or actuators, such as the temperature sensor.
  • Page 142 Chapter 5: Using the PX3TS Alerts The "Alerts" menu command shows a list of the following alerted sensors, including both internal and external sensors.  Any numeric sensor that enters the warning or critical range if the thresholds have been enabled ...
  • Page 143 In the Active state, the reason of turning on the beeper is indicated, and the top/bottom bars turn red. 3. If your PX3TS is a PX3TS-5000 model, it supports the active energy pulse output. Press to enter the Energy Pulse page.
  • Page 144 Chapter 5: Using the PX3TS 5. To return to the Main Menu, press Transfer Switch The "Transfer Switch" pages show both the transfer switch- and inlets-related data, which is separated into two or three pages. Page numbers are indicated in the top-right corner of the LCD display.
  • Page 145 Chapter 5: Using the PX3TS  Inlets page: This page indicates the active and preferred inlet, each inlet's and each fuse's status.  Transfer Log page: This page is available only after at least a power transfer event has occurred.
  • Page 146 With the front panel display, you can do the following for outlets:  Show each outlet's information.  Turn on, off or power cycle an individual outlet if your PX3TS is outlet-switching capable. To do this, you must first enable the front Miscellaneous panel outlet control function. See (on page 402).
  • Page 147 Chapter 5: Using the PX3TS Power Control This section applies to outlet-switching capable models only. That is, PX3TS-5000 series. The front panel outlet control must be enabled for performing this power control function. The default is to disable this function. See Miscellaneous (on page 402).
  • Page 148 Menu is shown. Peripherals If there are no Raritan environmental sensor packages connected to your PX3TS, the LCD display shows the message "No managed devices" for the "Peripherals" menu command. If you have enabled the front panel actuator control function, you can switch on or off a connected actuator using the LCD display.
  • Page 149 4. Verify that the actuator status shown on the LCD display has been changed. Assets If there are no Raritan asset management strips connected, the LCD display shows the message "No asset strips connected" for the "Assets" menu command. After connecting asset strips, only the information of the rack units where asset tags have been detected is shown on the LCD display.
  • Page 150 Chapter 5: Using the PX3TS  Asset Strip Numbering - the numbering mode. See (on page 239).  Offset - the starting number of the rack unit numbering.  Orientation - the strip's orientation. 4. Press again to show a list of available tags and their information.
  • Page 151 Chapter 5: Using the PX3TS Number Description Firmware version, model name and serial number. Device ratings, including rated voltage, frequency, current and power. 3. Press to show the Network Common page. Number Description DNS servers. Default gateways. 4. Press to show the Network Cascading page.
  • Page 152 Chapter 5: Using the PX3TS Number Description Cascading status, which can be one of the following:  No Cascading: This device's cascading mode is set to None. See Setting the Cascading Mode (on page 282).  Network Bridge Enabled: This device's cascading mode is set to Bridging.
  • Page 153 Chapter 5: Using the PX3TS  For PX3TS-iX7, there are two Ethernet pages -- ETH1 and ETH2. Number Description Ethernet interface information, including:  MAC address.  Speed.  Full or half duplex. IPv4/IPv6 network information, including:  Network configuration: DHCP (or Automatic), or Static. Static represents Static IP.
  • Page 154 Chapter 5: Using the PX3TS Number Description Wireless network information, if enabled, such as SSID. 7. To return to the Main Menu, press Alerts Notice in a Yellow or Red Screen In the automatic mode, if an alert occurs, the LCD display automatically shows a yellow or red screen which indicates the total number of alerted sensors and information of the latest transitions.
  • Page 155  To return to the Alerts Notice screen, press Showing the Firmware Upgrade Progress When upgrading the PX3TS, the firmware upgrade progress will be displayed as a percentage on the LCD display, similar to the following diagram. In the end, a message appears, indicating whether the firmware upgrade...

  • Page 156: Reset Buttons

    The RESET button resets the control board associated with front panel connection ports and the LCD display. The PX3TS device can be reset to its factory default values using this button when a serial connection is available. See Resetting to Factory Defaults (on page 702, on page 645).

  • Page 157: Fuses For The Inlet Transfer Switch

    Fuses for the Inlet Transfer Switch PX3TS models always contain two fuses for protecting the inlet transfer switch. These fuses blow when the current flowing through them exceeds the fuse rating.

  • Page 158: Replacing A Fuse On 1U Models

    Overcurrent Protector Information (on page 102) or Checking Inlet Component Status. 2. Examine your PX3TS and the connected equipment to remove or resolve the cause that results in the overload or short circuit. This step is required, or you cannot proceed with the next step.

  • Page 159: Replacing A Fuse On 2U Models

    7. Insert a new fuse into the holder. Make sure the new fuse is identical to the original one. 8. Install back the fuse holder to the PX3TS and turn it clockwise until it is tightened properly. 9. Reconnect the inlet with the fuse replaced to power, if it was disconnected in Step 4.
  • Page 160 Chapter 5: Using the PX3TS 4. This step is recommended but not required -- disconnect the inlet with the bad fuse from power. 5. Locate the bad fuse's holder on the rear panel. 6. Open the fuse cover. 7. Remove the fuse inside the holder and re-install a new one. Make sure the new fuse is identical to the original one.

  • Page 161: Overcurrent Protectors For Outlets

    1. Locate the breaker whose ON button is up, indicating that the breaker has tripped. 2. Examine your PX3TS and the connected equipment to remove or resolve the cause that results in the overload or short circuit. This step is required, or you cannot proceed with the next step.

  • Page 162: Beeper

    Tip: To remotely check this beeper's state via the web interface, see (on page 176). Power Cycling the PX3TS There is no power switch on the PX3TS device. To power cycle the PX3TS, both turn OFF branch circuits supplying power to the PX3TS, wait 10...

  • Page 163: Chapter 6 Using The Web Interface

    Chapter 6 Using the Web Interface This chapter explains how to use the web interface to administer a PX3TS. In This Chapter Supported Web Browsers ............... 139 Login, Logout and Password Change ............. 140 Web Interface Overview................144 Dashboard ....................150 Transfer Switch ..................

  • Page 164: Login, Logout And Password Change

    Chapter 6: Using the Web Interface Login, Logout and Password Change The first time you log in to the PX3TS, use the factory default "admin" user credentials. For details, see the Quick Setup Guide accompanying the product. After login, you can create user accounts for other users. See...
  • Page 165 Enabling the Restricted Service Agreement (on page 323). 5. Click Login or press Enter. The PX3TS web interface opens. The PX3TS web interface similar to the following image opens. Depending on your hardware configuration, your web interface shown onscreen may look slightly different from the image below.

  • Page 166: Changing Your Password

    Chapter 6: Using the Web Interface Changing Your Password You must have the Change Own Password permission to change your own password. See Creating Roles (on page 262). You must have Administrator Privileges to change other users' Editing or Deleting Users passwords.

  • Page 167: Remembering User Names And Passwords

    To log out without closing the web browser:  Click "Logout" on the top-right corner. -- OR --  Close the PX3TS tab while there are other tabs available in the browser. To log out by closing the web browser:  Click on the top-right corner of the window.

  • Page 168: Web Interface Overview

    Chapter 6: Using the Web Interface Web Interface Overview The web interface consists of four areas as shown below. Operation: 1. Click any menu or submenu item in the area of 2. That item's data/setup page is then opened in the area of 3.
  • Page 169  Date and time of your user account's last login. - Click Last Login to view your login history.  PX3TS system time, which is converted to the time zone of your computer or mobile device. - Click Device Time to open the Date/Time setup page.

  • Page 170: Menu

    Menu Information shown Dashboard Summary of the PX3TS status, including a list of alerted sensors and alarms, if any. Dashboard (on page 150). Device data and settings, such as the device name and MAC address.

  • Page 171: Ocps

    Either or both menu items appear only when you connect the equipment -- and/or -- included in a Raritan's SmartLock kit to PX3TS. For details, refer to the Card Readers user documentation accompanying the SmartLock kit or download it from Support page http://www.raritan.com/support/...

  • Page 172: Device Settings

    Chapter 6: Using the Web Interface Menu Information shown Device Settings Device-related settings, including network, security, system time, event rules and more. Device Settings (on page 267). Maintenance Device information and maintenance commands, such as firmware upgrade, device backup and reset. Maintenance (on page 403).

  • Page 173: Quick Access To A Specific Page

    Chapter 6: Using the Web Interface Quick Access to a Specific Page If you often visit a specific page in the PX3TS web interface, you can note down its URL or bookmark it with your web browser. Next time, you can simply enter its URL in the address bar of the browser prior to login.

  • Page 174: Dashboard

    Chapter 6: Using the Web Interface 3. The arrow turns to , indicating the list is sorted in the "ascending" order. 4. To resort the list based on a different column, click a different column header. In this example, the 'Event Class' column is clicked. 5.
  • Page 175 The chart of the inlet's active power history is displayed by default. Inlet History You can make it show a different data type. Dashboard - Inlet History (on page 156). This section is available only when your PX3TS contains Overcurrent overcurrent protectors (OCPs). Protectors  Overview of each OCP's status ...

  • Page 176: Dashboard - Transfer Switch

    Chapter 6: Using the Web Interface Dashboard - Transfer Switch Link to the Transfer Switch page: To view more information or configure the transfer switch, click its Transfer Switch section's title 'Transfer Switch' to go to that page. See (on page 162). Generic power data of the transfer switch: Available data includes: ...

  • Page 177: Dashboard - Inlet 1/2

    Chapter 6: Using the Web Interface Dashboard - Inlet 1/2 States of Inlet 1 and Inlet 2, including fuse states, preferred inlet and active inlet, are all available on the Dashboard page. Link to the Inlet 1/2 pages: To view more information or configure the inlet(s), click each inlet's section title 'Inlet 1' or 'Inlet 2' to go to each inlet's setup page.

  • Page 178: Dashboard - Alerted Sensors

    Dashboard - Alerted Sensors When any internal sensors or environmental sensor packages connected to the PX3TS enter an abnormal state, the Alerted Sensors section in the Dashboard show them for alerting users. This section also lists tripped circuit breakers or blown fuses, if available.
  • Page 179 Chapter 6: Using the Web Interface Summary in the section title: Information in parentheses adjacent to the title is the total number of alerted sensors. For example:  1 Critical: 1 sensor enters the critical or alarmed state. - Numeric sensors enter the critical state. - State sensors enter the alarmed state.

  • Page 180: Dashboard - Inlet History

    Chapter 6: Using the Web Interface Dashboard - Inlet History The power chart for the inlet helps you observe whether there were abnormal events within the past tens of minutes. The default is to show the inlet's active power data. You can have it show the chart of other inlet power data.
  • Page 181 Chapter 6: Using the Web Interface To show the charts of both inlets or the other inlet: The default is to show the power chart of Inlet 1. You can have it show the other inlet's or both inlets' data by selecting the checkbox(es) of the desired inlet(s).
  • Page 182 Chapter 6: Using the Web Interface  To retrieve the exact data at a particular time, hover your mouse over the data line in the chart. Both the time and data are displayed as illustrated below.  When both inlets are shown in the chart, simply hover your mouse over either inlet's data line.

  • Page 183: Dashboard - Alarms

    Chapter 6: Using the Web Interface Dashboard - Alarms If configuring any event rules which require users to take the acknowledgment action, the Alarms section will list any event which no one acknowledges yet since event occurrence. Note: For information on event rules, see Event Rules and Actions page 329).
  • Page 184 Tip: The date and time shown on the PX3TS web interface are automatically converted to your computer's time zone. To avoid any time confusion, you can apply the same time zone settings as those of PX3TS to your computer.

  • Page 185: Dashboard - Ocp

    NOT the fuses for protecting the inlet transfer switch. Each overcurrent protector on the PX3TS draws power from the active inlet and delivers power to associated outlets. These overcurrent protectors prevent outlets from overload by controlling the input current flowing through associated outlets.

  • Page 186: Transfer Switch

    Determine the power quality thresholds of voltage and frequency.  Perform manual power transfer or retransfer Note: Whenever the PX3TS prevents a manual transfer from being performed, it is disabled across all interfaces, including the front panel button, web interface and CLI command.
  • Page 187 Chapter 6: Using the Web Interface  Indicate which one is the 'preferred' inlet by showing on either inlet's section For detailed information, see Transfer Switch and Inlet Status (on page 169). The same information is also available on the Dashboard page. See Dashboard - Transfer Switch Dashboard - Inlet 1/2 (on page 152) and...
  • Page 188 Chapter 6: Using the Web Interface 3. Verify both the icons are transferred to the other inlet, indicating that inlet becomes the active and preferred inlet now. Icon Description Preferred inlet, which is the first priority to power outlets in the normal state. Active inlet, which is the inlet being powering outlets.
  • Page 189 To configure inlet phase angles settings (optional): If thresholds for inlet phase angle difference are enabled/configured, the PX3TS reports its values and states whenever a specific threshold is hit. For example, if the upper warning threshold is enabled and reached, you will see the upper warning alarm and values of inlet phase angle difference in the Dashboard's Alerted Sensors list or event log.
  • Page 190 Chapter 6: Using the Web Interface 2. Select Threshold Setup. The "Edit Thresholds for Inlet Phase Angle" dialog appears. 3. Make changes as needed.  To enable any threshold, select the corresponding checkbox.  Type a new value in the accompanying text box. For concepts of thresholds, deassertion hysteresis and assertion Sensor Threshold Settings timeout, see...
  • Page 191 Chapter 6: Using the Web Interface Number Description Note Voltage (V) blue line Time (ms) Current (A) red line  To retrieve the exact data at a particular time, hover your mouse over the line of either voltage or current waveform. The time, voltage value (blue) and current value (red) are all displayed as illustrated below.
  • Page 192 Chapter 6: Using the Web Interface To view the transfer log: The transfer log lists the last 10 power transfer events only, including automatic or manual transfer events.  To view the waveform or additional details of any transfer event, click that event in the transfer log.

  • Page 193: Transfer Switch And Inlet Status

    Chapter 6: Using the Web Interface Transfer Switch and Inlet Status On the Transfer Switch page, a normal state's text color is black, a warning state's is yellow, and a critical state's is red. See Transfer Switch (on page 162). Status of the transfer switch: One or some of the following messages are displayed for indicating the transfer switch state.
  • Page 194 Status An overload is present. Overload Detected  When the PX3TS device detects an overload condition on the outlet, it shuts down the outlet completely to protect the inlets.  The state of the switch remains off as long as the overload alarm is present.
  • Page 195 Chapter 6: Using the Web Interface It may not be a problem when the inlets are out of sync. The PX3TS device can still work fine in that state. However, depending on your transfer settings, the 'out of sync' state may prevent an automatic retransfer from the standby inlet to the preferred inlet.
  • Page 196 When this occurs, replace the fuse. See Fuses for the Inlet Transfer Switch page 133).  unavailable : The PX3TS cannot determine the fuse's status. For example, "unavailable" is shown when there is no inlet power available. MOV Status Indicates whether each inlet's MOV surge protector works properly.

  • Page 197: Power Transfer Settings

    Perform automatic retransfer only when inlets are in phase. These default behaviors can be changed by modifying the following fields. Field Description Name Customize the PX3TS device name. Allow Front Panel Enable/disable the front panel Manual Transfer Transfer button. If the Manual Transfer button is disabled, the Manual Disabled indicator lamp on the front panel is lit.

  • Page 198: Power Quality Settings

    If either is warning, quality is warning. When both are normal, power quality is normal. PX3TS transfers to standby operation when preferred inlet power quality goes critical and retransfers to normal operation when power quality returns to normal.
  • Page 199 Chapter 6: Using the Web Interface  Enter upper and lower thresholds for Warning and Critical power quality states.  "To Assert" and Assertion Enter assertion times (seconds). See Timeout (on page 764).  Enter deassertion hysteresis values. To disable the deassertion "To De-assert"...

  • Page 200: Pdu

    Chapter 6: Using the Web Interface The PX3TS device's generic information and PDU-level global settings are available on the PDU page. Menu To open the PDU page, click 'PDU' in the (on page 146). Device information shown:  Firmware version ...
  • Page 201  After removing power from the *Outlet state on Determines the initial power state of PDU, you must wait for a minimum device startup ALL outlets after the PX3TS device of 10 seconds before powering it powers up. up again. Otherwise, the default ...
  • Page 202 The default is to enable it.  The device's altitude is associated Altitude Specifies the PX3TS device's altitude with the altitude correction factor. above sea level when a Raritan's DPX Altitude Correction Factors differential air pressure sensor is (on page 771). attached.
  • Page 203 To reset ALL active energy counters: An active energy reading is a value of total accumulated energy, which is never reset, even if the power fails or the PX3TS is rebooted. However, you can manually reset this reading to restart the energy accumulation process.
  • Page 204 Chapter 6: Using the Web Interface To view the active power's chart: You can check whether there were abnormal events through the device's active power chart.  To retrieve the exact data at a particular time, hover your mouse over the data line in the chart. Both the time and data are displayed as illustrated below.

  • Page 205: Internal Beeper State

    "XXX," the activation reason looks like: Event Action triggered by rule: XXX Scenarios when the beeper sounds an alarm:  Any overcurrent protector on the PX3TS, including fuses and circuit Beeper breakers, has tripped or blown. See (on page 138). ...

  • Page 206: Px3Ts Latching Relay Behavior

    Unlike non-latching relays, latching relays do NOT require power to keep their contacts closed. PX3TS outlet switching can be configured to operate as a true latching relay or to simulate a non-latching relay. The operating mode determines the latching relay behavior when PDU power is lost.

  • Page 207: Initialization Delay Use Cases

    Chapter 6: Using the Web Interface If you are configuring an individual outlet on Individual Outlet Pages page 201), there is one more outlet state option. Additional Function option PDU defined Follows the global outlet state setting, which is set (xxx) (on page 176).

  • Page 208: Z Coordinate Format

    (on page 176). After enabling the automatic management function: When the total number of managed sensors and actuators has not reached the upper limit yet, the PX3TS automatically brings newly-connected environmental sensors and actuators under management after detecting them. A PX3TS can manage up to 32 sensors/actuators.

  • Page 209: Time Units

    You can enable and set them so that you are alerted when the total active energy or total active power hits a certain level. For a regular PX3TS model with multiple inlets:  Total active energy = sum of all inlets' active energy values ...

  • Page 210: Inlets

    Chapter 6: Using the Web Interface 3. Click the desired sensor (required), and then click Edit Thresholds. 4. Make changes as needed.  To enable any threshold, select the corresponding checkbox.  Type a new value in the accompanying text box. Note: For concepts of thresholds, deassertion hysteresis and assertion timeout, see (on page 761).
  • Page 211 Chapter 6: Using the Web Interface  Active power (kW or W)  Apparent power (kVA or VA)  Active energy (kWh or Wh)  Power factor  Line frequency (Hz) Menu To open this page, click 'Inlets' in the (on page 146).

  • Page 212: Individual Inlet Pages

    Inlet thresholds, when enabled, help you identify whether the inlet enters the warning or critical level. In addition, you can have the PX3TS automatically generate alert notifications for any warning or critical Event Rules and Actions status.
  • Page 213 Chapter 6: Using the Web Interface This inlet's active energy reading is then reset to zero. Tip: To reset ALL active energy counters on the PX3TS, see (on page 176). To configure inlet thresholds: Per default, there are pre-defined RMS voltage and current threshold values in related fields.

  • Page 214: Outlets

    Chapter 6: Using the Web Interface  Type a new value in the accompanying text box. For concepts of thresholds, deassertion hysteresis and assertion Sensor Threshold Settings timeout, see (on page 761). Warning: The thresholds of voltage and line frequency of each inlet impact the power quality levels.
  • Page 215 Chapter 6: Using the Web Interface  Perform actions on all or multiple outlets simultaneously by using the setup/power-control icons on the top-right corner. Note that only outlet-switching capable models show the power-control buttons, and you must have the Switch Outlet permission for performing outlet-switching operations.
  • Page 216 Chapter 6: Using the Web Interface If wanted, you can resort the list by clicking the desired column header. Sorting a List (on page 149). To show or hide specific columns on the outlets overview page: 1. Click to show a list of outlet data types. 2.
  • Page 217 Confirm the operation when prompted. Tip: To reset ALL active energy counters on the PX3TS, see page 176). You can also power control an outlet or reset its active energy from (on page 201).

  • Page 218: Available Data Of The Outlets Overview Page

    Chapter 6: Using the Web Interface  If needed, click to stop the outlet-switching operation. Available Data of the Outlets Overview Page All or some of the following outlet data is displayed on the outlets overview page based on your model and selection. To show or hide specific data, click .

  • Page 219: Bulk Configuration For Outlet Thresholds

    Outlet thresholds, if enabled, help you identify whether any outlet enters Yellow- or Red-Highlighted Sensors the warning or critical level. See (on page 224). In addition, you can have the PX3TS automatically Event generate alert notifications for any warning or critical status. See Rules and Actions (on page 329).

  • Page 220: Setting Outlet Power-On Sequence And Delay

    For example, if the power-on sequence is Outlet 1 through Outlet 8, and you want the PX3TS to wait for 5 seconds after turning on Outlet 3 before turning on Outlet 4, assign a delay of 5 seconds to Outlet 3.

  • Page 221: Setting Non-Critical Outlets

    Down Bottom Restores to the default sequence Next time when power cycling the PX3TS, it will turn on all outlets based on the new outlet order. The new order also applies when performing the power-on or power-cycling operation on partial outlets.
  • Page 222 Chapter 6: Using the Web Interface  To select ALL outlets, select the topmost checkbox in the header row. 3. To turn non-critical outlets into critical ones, deselect their checkboxes.  To deselect ALL outlets, deselect the topmost checkbox in the header row.

  • Page 223: Load Shedding Mode

    Chapter 6: Using the Web Interface Load Shedding Mode When a UPS supplying power to the PX3TS switches into battery backup operation, it may be desirable to switch off non-critical outlets to conserve UPS battery life. This feature is known as load shedding.
  • Page 224 Now you can turn on/off any outlets. Tip -- automatic load shedding via contact closure sensors: If you have connected a contact closure sensor to PX3TS, you can set up an event rule so that the status change of this sensor automatically activates or deactivates the load shedding mode.

  • Page 225: Individual Outlet Pages

    Chapter 6: Using the Web Interface Individual Outlet Pages An outlet's data/setup page is opened after clicking the outlet's name on the Outlets overview page. See Outlets (on page 190). The individual outlet's page shows this outlet's detailed information. See Detailed Information on Outlet Pages (on page 207).
  • Page 226 Type an outlet name up to 64 characters long. *State on device Click this field to select this outlet's initial startup power state after the PX3TS powers up.  Options: last known PDU defined Options for Outlet State on Startup page 182).
  • Page 227 Chapter 6: Using the Web Interface Field Descriptions *Power off period Select an option to determine how long this during power cycle outlet is turned off before turing back on.  Options: PDU defined or customized time. Power-Off Period Options for Individual Outlets (on page 208).
  • Page 228 Chapter 6: Using the Web Interface Tip: To reset ALL active energy counters on the PX3TS, see (on page 176). To view this outlet's power chart: By default this outlet's active power data within the past tens of minutes is shown in the power chart.
  • Page 229 Chapter 6: Using the Web Interface  To retrieve the exact data at a particular time, hover your mouse over the data line in the chart. Both the time and data are displayed as illustrated below. To configure this outlet's threshold settings: Per default, there are pre-defined RMS voltage and current threshold Default Voltage and Current Thresholds values in related fields.
  • Page 230 Chapter 6: Using the Web Interface 3. Make changes as needed.  To enable any threshold, select the corresponding checkbox.  Type a new value in the accompanying text box. For concepts of thresholds, deassertion hysteresis and assertion Sensor Threshold Settings timeout, see (on page 761).
  • Page 231 On or Off Receptacle Type This outlet's receptacle type Lines Lines associated with this outlet Overcurrent Protector This information is available only when your PX3TS has overcurrent protectors. Overcurrent protector associated with this outlet Sensors section:  RMS current (A) ...
  • Page 232 Chapter 6: Using the Web Interface Power-Off Period Options for Individual Outlets There are two options for setting the power-off period during the power cycle on each individual outlet's page. See Individual Outlet Pages page 201). Option Function PDU defined Follows the global power-off period setting, which is (xxx) set on...

  • Page 233: Ocps

    Chapter 6: Using the Web Interface OCPs The OCPs page is available only when your PX3TS has overcurrent protectors, such as circuit breakers. Note that the Overcurrent Protectors section shows information of the circuit breakers for protecting outlets, NOT the fuses for protecting the inlet transfer switch.
  • Page 234 OCP thresholds, when enabled, help you identify the OCP whose RMS current enters the warning or critical level with the yellow or red color. In addition, you can have the PX3TS automatically generate alert Event Rules and notifications for any warning or critical status. See Actions (on page 329).

  • Page 235: Individual Ocp Pages

    Label This OCP's physical number. Status open or closed.  When an OCP trips (open), if your PX3TS is an outlet-metered model that supports "outlet peak current" sensors, a message will show up, indicating which outlet is likely to trigger the OCP-tripped event.
  • Page 236 Chapter 6: Using the Web Interface Field Description Inlet Inlet associated with this OCP. RMS current This OCP's current state and readings, including current drawn and current remaining. To customize this OCP's name: 1. Click Edit Settings. 2. Type a name. 3.
  • Page 237 Chapter 6: Using the Web Interface  To retrieve the exact data at a particular time, hover your mouse over the data line in the chart. Both the time and data are displayed as illustrated below. To configure this OCP's threshold settings: By default, upper thresholds of an OCP's RMS current have been Default Voltage and Current Thresholds configured.
  • Page 238 Chapter 6: Using the Web Interface  Type a new value in the accompanying text box. For concepts of thresholds, deassertion hysteresis and assertion Sensor Threshold Settings timeout, see (on page 761). 4. Click Save.
  • Page 239 Chapter 6: Using the Web Interface Other operations:  You can go to another OCP's data/setup page by clicking the OCP selector on the top-left corner.  You can go to the associated Inlet's data page by clicking the Inlet link in the Details section.

  • Page 240: Possible Ocp-Tripped Root Cause

    Chapter 6: Using the Web Interface Possible OCP-Tripped Root Cause This feature applies to PX3TS-5000 models only. As of release 3.4.0, outlet-metered models that support "outlet peak current" sensors can detect which outlet is LIKELY to cause the associated OCP to trip, and indicate it on several user interfaces, including the web interface, front panel display, and command line interface (CLI).
  • Page 241 Chapter 6: Using the Web Interface Front panel display: Only a dot-matrix LCD display can show this message, but a character LCD display cannot. The 'Likely trip cause' message will be displayed for an "open" OCP, OCPs indicating which outlet may cause the OCP-tripped event. See page 121).

  • Page 242: Peripherals

    Chapter 6: Using the Web Interface Peripherals If there are Raritan environmental sensor packages connected to the Connecting PX3TS, they are listed on the Peripherals page. See Environmental Sensor Packages (on page 43). An environmental sensor package comprises one or some of the following sensors/actuators: ...
  • Page 243 (on page 224). An actuator is never highlighted. Column Description Name By default the PX3TS assigns a name comprising the following two elements to a newly-managed sensor/actuator.  Sensor/actuator type, such as "Temperature" or "Dry Contact."  Sequential number of the same sensor/actuator type, like 1, 2, 3 and so on.
  • Page 244 Chapter 6: Using the Web Interface Column Description Serial Number This is the serial number printed on the sensor package's label. It helps to identify your Raritan Finding the Sensor's Serial sensors/actuators. See Number (on page 228). Position The data indicates where this sensor or actuator is located in the sensor chain.
  • Page 245 Chapter 6: Using the Web Interface  To select ALL sensors/actuators, select the topmost checkbox in the header row. Figure 1: Select all checkboxes 3. To release selected ones, click > Release. To manage them, click > Manage.  The management action triggers a "Manage peripheral device" multiple dialog.
  • Page 246 Chapter 6: Using the Web Interface To configure default threshold settings: Note that any changes made to default threshold settings not only re-determine the initial threshold values applying to newly-added sensors but also the threshold values of the already-managed sensors Individual where default thresholds are being used.
  • Page 247 Chapter 6: Using the Web Interface For concepts of thresholds, deassertion hysteresis and assertion Sensor Threshold Settings timeout, see (on page 761). 4. Click Save. Tip: To customize the threshold settings on a per-sensor basis, go to (on page 232). Individual Sensor/Actuator Pages To turn on or off any actuator(s): in the same status...

  • Page 248: Yellow- Or Red-Highlighted Sensors

    Chapter 6: Using the Web Interface Yellow- or Red-Highlighted Sensors The PX3TS highlights those sensors that enter the abnormal state with a yellow or red color. Note that numeric sensors can change colors only after you have enabled their thresholds.

  • Page 249: Managed Vs Unmanaged Sensors/Actuators

    To manually manage or unmanage/release a sensor or actuator, see Peripherals (on page 218). Managed sensors/actuators:  The PX3TS communicates with managed sensors/actuators and retrieves their data.  Managed sensors/actuators are always listed on the Peripheral Devices page no matter they are physically connected or not.

  • Page 250: Sensor/Actuator States

    The PX3TS neither communicates with unmanaged sensors/actuators nor retrieves their data.  Unmanaged sensors/actuators are listed only when they are physically connected to the PX3TS. They disappear when they are no longer connected.  They do have an ID number.
  • Page 251 Sensors or actuators are physically connected to the PX3TS but not managed yet. Note: Unmanaged sensors or actuators will disappear from the web interface after they are no longer physically connected to the PX3TS. To manage a sensor/actuator, go to (on page 218).

  • Page 252: Finding The Sensor's Serial Number

    The serial number for each sensor or actuator appears listed in the web interface after each sensor or actuator is detected by the PX3TS. Match the serial number from the tag to those listed in the sensor table.

  • Page 253: Identifying The Sensor Position And Channel

    Raritan has developed four types of environmental sensor packages - DPX, DPX2, DPX3 and DX series. Only DPX2, DPX3 and DX sensor packages can be daisy chained. The PX3TS can indicate where each sensor or actuator is connected on the Peripheral Devices page. ...

  • Page 254: Managing One Sensor Or Actuator

    Chapter 6: Using the Web Interface Example Physical position Connected to the sensor port #1. Port 1  Connected to the sensor port #1. Port 1,  The sensor/actuator is the 2nd channel of the sensor package. Channel 2  Connected to the sensor port #1. Port 1, ...
  • Page 255 Chapter 6: Using the Web Interface 2. The "Manage peripheral device" dialog appears.  To let the PX3TS randomly assign an ID number to it, select "Automatically assign a sensor number." This method does not release any managed sensor or actuator.

  • Page 256: Individual Sensor/Actuator Pages

    To configure a numeric sensor's threshold settings: 1. Click Edit Thresholds. Tip: The date and time shown on the PX3TS web interface are automatically converted to your computer's time zone. To avoid any time confusion, you can apply the same time zone settings as those...
  • Page 257 Chapter 6: Using the Web Interface 2. Select or deselect Use Default Thresholds according to your needs.  To have this sensor follow the default threshold settings configured for its own sensor type, select the Use Default Thresholds checkbox. The default threshold settings are configured on the page of Peripherals (on page 218).
  • Page 258 This field is available for the DX-PIR presence detector only. Normal Delay It determines the wait time before the PX3TS announces that the presence detector is back to normal after it actually returns to normal. Adjust the value in seconds.
  • Page 259 Chapter 6: Using the Web Interface To view a numeric sensor's chart This sensor's data within the past tens of minutes is shown in the chart. Note that only a numeric sensor has this diagram. State sensors and actuators do not have such data. ...
  • Page 260 Chapter 6: Using the Web Interface To turn on or off an actuator: 1. Click the desired control button. : Turn ON. : Turn OFF. 2. Confirm the operation on the confirmation message. An actuator's state is marked in red when it is turned on. Note: If you try to turn on more than one "powered dry contact"...

  • Page 261: Sensor/Actuator Location Example

    This type represents one of the following Raritan products:  Raritan power CIM, D2CIM-PWR. This CIM is used to connect the PX3TS to the Raritan digital KVM switch -- Dominion KX II / III.  Dominion KSX II  Dominion SX or SX II...
  • Page 262 From this page, you can enable or disable this port's detection capability, or force it to show a specific device's data/settings even though no device is detected. Note: You must enable the LHX/SHX support for the PX3TS to detect the presence of a supported Schroff LHX/SHX heat exchanger. See ®...

  • Page 263: Asset Strip

    Miscellaneous (on page 402). Asset Strip After connecting and detecting Raritan asset management strips (asset strips), the PX3TS shows 'Asset Strip' in place of 'Feature Port' in the menu. Note: For connection instructions, see Connecting Asset Management (on page 63).
  • Page 264 8 and 64.  For the current generation of asset strips, which show the suffix "G3" on its hardware label, the PX3TS automatically detects the number of its tag ports (rack units), and you cannot change this value.
  • Page 265 Chapter 6: Using the Web Interface For color settings, there are two ways to set the color.  Click a color in the color palette.  Type the hexadecimal RGB value of the color, such as #00FF00. 3. Click Ok. The rack unit numbering and LED color settings are immediately updated on the Rack Units list illustrated below.
  • Page 266 Chapter 6: Using the Web Interface To customize a single rack unit's settings: You can make a specific rack unit's LED behave differently from the others on the asset strip, including the LED light and color. 1. Click the desired rack unit on the Rack Units list. The setup dialog for the selected one appears.
  • Page 267 Note: If you need to temporarily disconnect the blade extension strip from the asset strip, wait at least 1 second before re-connecting it back, or the PX3TS device may not detect it. 1. Locate the rack unit (tag port) where the blade extension strip is connected.
  • Page 268 Chapter 6: Using the Web Interface 2. All tag ports of the blade extension strip are listed below it. Their port numbers are displayed in the Slot column.  To hide the blade extension slots list, click...
  • Page 269 In addition, you can also customize the ID of a blade extension strip. If a barcode reader is intended, connect it to the computer you use to access the PX3TS. 1. Click Program Asset IDs. 2. In the Asset/ID column, enter the customized asset IDs by typing values or scanning the barcode.
  • Page 270 Chapter 6: Using the Web Interface  An asset ID contains up to 12 characters that comprise only numbers and/or UPPER CASE alphabets. Lower case alphabets are NOT accepted. 3. Verify the correctness of customized asset IDs and modify as needed.
  • Page 271 Tip: Another way to abort changes is to click Rack Units. Refer to the diagram below. Asset Strip Automatic Firmware Upgrade After connecting the asset strip to the PX3TS, it automatically checks its own firmware version against the version of the asset strip firmware stored in the PX3TS firmware.

  • Page 272: External Beeper

    Chapter 6: Using the Web Interface External Beeper After connecting and detecting a supported external beeper, the PX3TS shows 'External Beeper' in place of 'Feature Port' in the menu. Note: For connection instructions, see Connecting an External Beeper (on page 76).

  • Page 273: Schroff Lhx/Shx

    Chapter 6: Using the Web Interface Schroff LHX/SHX You must enable the LHX/SHX support for the PX3TS to detect the presence of a supported Schroff LHX/SHX heat exchanger. See ® Miscellaneous (on page 402). After enabling the LHX/SHX support and connecting a supported Schroff ®...
  • Page 274 Chapter 6: Using the Web Interface Feature For the functionality of this icon on the top-right corner, see Port (on page 237). To view the LHX/SHX device state: The Operation State field indicates whether the device is operating fine, and the Switch State field indicates its power status. If the device does not operate properly, such as some sensor failure, it shows "critical"...
  • Page 275 Chapter 6: Using the Web Interface To configure LHX/SHX settings: 1. Click Edit Settings. 2. Configure the settings as needed.  Provide a customized name.  Specify the desired air outlet setpoint temperature.  Specify the default fan speed. 3. Click Save. To view all sensor data and configure thresholds: 1.
  • Page 276 Chapter 6: Using the Web Interface b. Click Edit Thresholds. c. Enable and set the desired thresholds and deassertion hysteresis. Note that assertion timeout is NOT available on LHX/SHX. d. Click Save. 3. After thresholds are enabled, sensors may be highlighted in yellow Yellow- or or red if they enter the warning or critical range.
  • Page 277 Event Log page. Operation time statistics: This section indicates the accumulative operation hours of the LHX/SHX device and its fans since the device is connected to the PX3TS and turned Available time units in the statistics --  h: hour(s) ...

  • Page 278: Power Cim

    Chapter 6: Using the Web Interface SHX Request Maximum Cooling The PX3TS allows you to remotely activate the Schroff SHX 30's maximum cooling feature. Both LHX 20 and LHX 40 do not support remote activation of maximum cooling. The Request Maximum Cooling feature is available only after the PX3TS detects SHX 30.

  • Page 279: User Management

    'admin' or change its permissions, but you can and should change its password. A "role" determines the tasks/actions a user is permitted to perform on the PX3TS so you must assign one or multiple roles to each user. Menu Click 'User Management' in the (on page 146), and the following submenu displays.

  • Page 280: Creating Users

    Note that you must enter information in the fields showing the message 'required.' User information: Field/setting Description User Name The name the user enters to log in to the PX3TS.  4 to 32 characters  Case sensitive  Spaces are NOT permitted.
  • Page 281 Chapter 6: Using the Web Interface Field/setting Description Force password When selected, a password change request change on next automatically appears when next time the user login logs in. Changing Your Password For details, see page 142). SSH: You need to enter the SSH public key only if the public key authentication Changing SSH Settings for SSH is enabled.
  • Page 282 Chapter 6: Using the Web Interface Field/setting Description Password, Type the authentication password if the 'Same as User Password' checkbox is deselected. Confirm Password The password must consist of 8 to 32 ASCII printable characters.  Privacy Password: This section is configurable only when 'Authentication &...
  • Page 283  Change Own Password  Change Pdu, Inlet, Outlet & Overcurrent Protector Configuration  Switch Outlet (if your PX3TS is outlet-switching capable)  View Event Settings  View Local Event Log Note: With multiple roles selected, a user has the union of all roles'...

  • Page 284: Editing Or Deleting Users

    Chapter 6: Using the Web Interface Editing or Deleting Users To edit or delete users, choose User Management > Users to open the Users page, which lists all users. In the Enabled column:  : The user is enabled.  : The user is disabled.
  • Page 285 Chapter 6: Using the Web Interface  To delete this user, click , and confirm the operation. 3. Click Save. To delete multiple user accounts: 1. On the Users page, click to make checkboxes appear in front of user names. Tip: To delete only one user, you can simply click that user without making the checkboxes appear.

  • Page 286: Creating Roles

    Chapter 6: Using the Web Interface Creating Roles A role is a combination of permissions. Each user must have at least one role. Creating Users The PX3TS provides two built-in roles. See (on page 256). Built-in role Description Admin Provide full permissions.

  • Page 287: Editing Or Deleting Roles

    Chapter 6: Using the Web Interface 5. If any privilege requires the argument setting, the symbol well as the text 'Add XXX' display on that privilege's row, where XXX is the privilege's name. To select such a privilege: a. Click on that privilege's row to display a list of available arguments for this privilege.
  • Page 288 Chapter 6: Using the Web Interface The Admin role is not user-configurable so the lock icon displays, indicating that you are not allowed to configure it. To edit a role: 1. On the Roles page, click the desired role. The Edit Role page opens. 2.

  • Page 289: Setting Your Preferred Measurement Units

    Chapter 6: Using the Web Interface Setting Your Preferred Measurement Units You can change the measurement units shown in the PX3TS user interface according to your own preferences regardless of the permissions you have. Tip: Preferences can also be changed by administrators for specific users on the Edit User page.

  • Page 290: Setting Default Measurement Units

    Chapter 6: Using the Web Interface Setting Default Measurement Units Default measurement units are applied to all PX3TS user interfaces across all users, including users accessing the PX3TS via external authentication servers. For a list of affected user interfaces, see...

  • Page 291: Device Settings

    Chapter 6: Using the Web Interface Device Settings Menu Click 'Device Settings' in the (on page 146), and the following submenu displays. Menu command Submenu command Refer to... Configuring Network Settings Network (on page 269) Changing HTTP(S) Settings Network Services HTTP (on page 292) SNMP...
  • Page 292 Chapter 6: Using the Web Interface Menu command Submenu command Refer to... Configuring SMTP Settings SMTP Server (on page 295) Changing SSH Settings (on page 297) Changing Telnet Settings Telnet (on page 298) Changing Modbus Settings Modbus (on page 298) Enabling Service Advertising Server Advertising (on page 299)

  • Page 293: Configuring Network Settings

    (on page 15). You can enable both the wired and wireless networking on the PX3TS so that it has multiple IP addresses -- wired and wireless IP. For example, you can obtain one IPv4 and/or IPv6 address by enabling one Ethernet interface, and obtain one more IPv4 and/or IPv6 address by enabling/configuring the wireless interface.
  • Page 294 SSL/TLS  SNMP  SysLog Note: The PX3TS supports TLS Wired Network Settings On the Network page, click the ETHERNET section to configure IPv4/IPv6 settings. If the device's cascading mode is set to 'Bridging', the BRIDGE section appears. Then you must click the BRIDGE section for IPv4/IPv6 settings.
  • Page 295 Cascading Mode Leave it to the default "None" unless you are establishing a cascading chain. For more information, refer to:  Cascading Multiple PX3TS Devices for Sharing Ethernet Connectivity (on page 28)  Setting the Cascading Mode (on page 282)
  • Page 296 Route' to add static routes. Static Route Examples (on page 278). Ethernet Interface Settings By default the Ethernet interface on PX3TS or ETH1/ETH2 interface on PX3TS-iX7 is enabled. Enable Interface: Make sure the Ethernet interface is enabled, or all networking through this interface fails.
  • Page 297 Current State current speed and duplex mode. Note: Auto-negotiation is disabled after setting both the speed and duplex settings of the PX3TS to NON-Auto values, which may result in a duplex mismatch. Wireless Network Settings If the device's cascading mode is set to 'Bridging' or its role is set to 'Slave' in the port forwarding mode, the wireless settings will be disabled.
  • Page 298 Chapter 6: Using the Web Interface Field/setting Description Hardware State Check this field to ensure that the PX3TS device has detected a wireless USB LAN adapter. If not, verify whether the USB LAN adapter is firmly connected or whether it is supported.
  • Page 299 Chain (on page 783). Field/setting Description Enable verification Select this checkbox for the PX3TS to verify the of TLS certificate validity of the TLS certificate that will be installed. chain  For example, the PX3TS will check the certificate's validity period against the system time.
  • Page 300 Chapter 6: Using the Web Interface Field/setting Description  DHCP Configuration : Auto-configure IPv4 settings via DHCP servers.  Static : Manually configure the IPv4 settings.  DHCP settings: Optionally specify the preferred hostname, which must meet the following requirements: ...
  • Page 301 Chapter 6: Using the Web Interface Wireless LAN Diagnostic Log The PX3TS provides a diagnostic log for inspecting connection errors that occurred over the wireless network interface. The information is useful for technical support. Note that the WLAN Diagnostic Log shows data only after the Network Interface is set to Wireless.
  • Page 302 (NIC) have been installed in one network server, leading to two available subnets, and IP forwarding has been enabled. All of the NICs and PX3TS devices in the examples use static IP addresses.
  • Page 303 Chapter 6: Using the Web Interface In this example, NIC-2 (192.168.100.88) is the next hop router for your PX3TS to communicate with any device in the other subnet 192.168.200.0. In the IPv4 "Static Routes" section, you should enter the data as shown below.
  • Page 304 Tip: If you have configured multiple static routes, you can click on any route and then make changes, use to re-sort the priority, or click to delete it. IPv6 example:  fd07:2fa:6cff:2405::30 Your PX3TS:  Two NICs: fd07:2fa:6cff:1111::50 fd07:2fa:6cff:2405::80  fd07:2fa:6cff:1111::0 fd07:2fa:6cff:2405::0 Two networks: ...
  • Page 305 Chapter 6: Using the Web Interface In this example, NIC-2 (fd07:2fa:6cff:2405::80) is the next hop router for your PX3TS to communicate with any device in the other subnet fd07:2fa:6cff:1111::0. In the IPv6 "Static Routes" section, you should enter the data as shown below.
  • Page 306 Chapter 6: Using the Web Interface Setting the Cascading Mode A maximum of 16 PX3TS devices can be cascaded to share one Ethernet connection. See Cascading Multiple PX3TS Devices for Sharing Ethernet Connectivity (on page 28). The cascading mode configured on the master device determines the...
  • Page 307 Chapter 6: Using the Web Interface 5. For the Port Forwarding mode, one to two more fields have to be configured. Note that if either setting below is incorrectly configured, a networking issue occurs. Field Description Master or Slave. Role This is to determine which device is the (available on all master and which ones are slave...
  • Page 308 Chapter 6: Using the Web Interface Online cascading information: For detailed information on the cascading configuration and restrictions, see the Cascading Guide , which is available from Raritan website's Support page http://www.raritan.com/support/ Overview of the Cascading Modes Setting You must apply a cascading mode to the cascading chain. See the Cascading Mode (on page 282).
  • Page 309 Chapter 6: Using the Web Interface In this mode, the DHCP server communicates with the master device alone and assigns one IP address to the master device. All slave devices share the same IP address as the master device. You must specify a 5XXXX port number (where X is a number) when remotely accessing any slave device with the shared IP address.
  • Page 310 Chapter 6: Using the Web Interface Protocols HTTP TELNET SNMP MODBUS  XX is a two-digit number representing the device position as shown below. Position Position Master device Slave 8 Slave 1 Slave 9 Slave 2 Slave 10 Slave 3 Slave 11 Slave 4 Slave 12...
  • Page 311 HTTP TELNET SNMP MODBUS In the Port Forwarding mode, the PX3TS does NOT allow you to modify the standard TCP/UDP port configuration, including HTTP, HTTPS, SSH, Telnet and Modbus/TCP. Port Forwarding Examples To access a cascaded device in the Port Forwarding mode, assign a port number to the IP address.
  • Page 312 Chapter 6: Using the Web Interface  To access the master device via SSH, the command is: ssh -p 50200 192.168.84.77 Examples using standard TCP/UDP ports:  To access the master device via HTTPS, the IP address is: https://192.168.84.77:443/  To access the master device via HTTP, the IP address is: http://192.168.84.77:80/ ...
  • Page 313 (on page 773). To add a device to an existing chain: 1. Connect the Raritan device to the LAN and find its IP address, or connect it to a computer. 2. Log in to this device and set its cascading mode to be the same as Setting the Cascading the existing chain's cascading mode.
  • Page 314 Chapter 6: Using the Web Interface To swap the master and slave device:  In the Bridging mode, you can swap the master and slave devices by simply disconnecting ALL cascading cables from them, and then reconnecting cascading cables. No changes to software settings are required.

  • Page 315: Configuring Network Services

    Chapter 6: Using the Web Interface Configuring Network Services The PX3TS supports the following network communication services. HTTPS and HTTP enable the access to the web interface. Telnet and SSH Using the enable the access to the command line interface. See Command Line Interface (on page 461).
  • Page 316 Changing HTTP(S) Settings HTTPS uses Transport Layer Security (TLS) technology to encrypt all traffic to and from the PX3TS so it is a more secure protocol than HTTP. The PX3TS supports TLS By default, any access to the PX3TS via HTTP is automatically redirected to HTTPS.
  • Page 317 Configuring SNMP Settings You can enable or disable SNMP communication between an SNMP manager and the PX3TS device. Enabling SNMP communication allows the manager to retrieve and even control the power status of each outlet. Besides, you may need to configure the SNMP destination(s) if the built-in "System SNMP Notification Rule"...
  • Page 318 Chapter 6: Using the Web Interface 2. Enable or disable "SNMP v1 / v2c" and/or "SNMP v3" by clicking the corresponding checkbox.  The SNMP v1/v2c read-only access is enabled by default. The default Read Community String is 'public.'  To enable read-write access, type the Write Community String.
  • Page 319 See (on page 363). Send an SNMP Notification 5. You must download the SNMP MIB for your PX3TS to use with your SNMP manager. a. Click the Download MIBs title bar to show the download links. Downloading SNMP b.
  • Page 320 Chapter 6: Using the Web Interface Field Description Server Name Type the name or IP address of the mail server. Port Type the port number.  Default is 25 Sender Email Type an email address for the sender. Address Number of Sending Type the number of email retries.
  • Page 321 PX3TS and the client's cipher availability/settings. Tip: If intending to force the PX3TS to use a specific AES cipher, refer to your client's user documentation for information on configuring AES settings.
  • Page 322 3. To use a different port, type a new port number. 4. Click Save. Changing Modbus Settings You can enable or disable the Modbus/TCP access to the PX3TS, set it to the read-only mode, or change the TCP port. To change the Modbus/TCP settings: 1.
  • Page 323 .local host name, that is, <preferred_host_name>.local , where <preferred_host_name> is the preferred host name you have specified for PX3TS. The IPv4 host name is the first priority. If an IPv4 host name is not available, then use the IPv6 host name.

  • Page 324: Configuring Security Settings

    This product supports SHA-2 TLS certificates. Tip: To force all HTTP accesses to the PX3TS to be redirected to HTTPS, (on page 292). Changing HTTP(S) Settings...
  • Page 325 Creating IP Access Control Rules IP access control rules (firewall rules) determine whether to accept or discard traffic to/from the PX3TS, based on the IP address of the host sending or receiving the traffic. When creating rules, keep these principles in mind: ...
  • Page 326 Chapter 6: Using the Web Interface ADD a rule to the end of the list  Click Append.  Type an IP address and subnet mask in the IP/Mask field.  Select an option in the Policy field.  Accept: Accepts traffic from/to the specified IP address(es). ...
  • Page 327 Chapter 6: Using the Web Interface  You can select any existing rule and then click to change its priority. 7. Click Save. The rules are applied. To configure IPv6 access control rules: 1. On the same page, select the Enable IPv6 Access Control checkbox to enable IPv6 access control rules.
  • Page 328 Chapter 6: Using the Web Interface Editing or Deleting IP Access Control Rules When an existing IP access control rule requires updates of IP address range and/or policy, modify them accordingly. Or you can delete any unnecessary rules. To modify or delete a rule: 1.
  • Page 329 Chapter 6: Using the Web Interface  Deny: Rejects any user's login attempt when no matching rules are present. 4. Create rules. Refer to the tables below for different operations. ADD a rule to the end of the list  Click Append. ...
  • Page 330 Chapter 6: Using the Web Interface  You can select any existing rule and then click to change its priority. 6. Click Save. The rules are applied. To configure IPv6 access control rules: 1. On the same page, select the "Enable Role Based Access Control for IPv6"...
  • Page 331 As of release 3.4.0, you can create or apply for a multi-domain certificate with subject alternative names. To obtain a CA-signed certificate: 1. Create a Certificate Signing Request (CSR) on the PX3TS. See Creating a CSR (on page 308). 2. Submit it to a certificate authority (CA). After the CA processes the information in the CSR, it provides you with a certificate.
  • Page 332 Chapter 6: Using the Web Interface Creating a CSR Follow this procedure to create the CSR for your PX3TS device. Note that you must enter information in the fields showing the message 'required.' To create a CSR: 1. Choose Device Settings > Security > SSL Certificate.
  • Page 333 To get a certificate from a certificate authority (CA), first create a CSR and send it to the CA. See Creating a CSR (on page 308). After receiving the CA-signed certificate, install it onto the PX3TS. To install the CA-signed certificate: 1. Choose Device Settings > Security > SSL Certificate.
  • Page 334 Active SSL Certificate section. Creating a Self-Signed Certificate When appropriate certificate and key files for the PX3TS device are unavailable, the alternative, other than submitting a CSR to the CA, is to generate a self-signed certificate.
  • Page 335 Installing or Downloading Existing Certificate and Key You can download the already-installed certificate and private key from any PX3TS for backup or file transfer. For example, you can install the files onto a replacement PX3TS device, add the certificate to your browser and so on.
  • Page 336 3. You are prompted to open or save the file. Click Save to save it onto your computer. To install available key and certificate files onto the PX3TS: 1. Choose Device Settings > Security > SSL Certificate. 2. Select the "Upload Key and Certificate" checkbox at the bottom of the page.
  • Page 337 When configured for external authentication, all PX3TS users must have an account on the external AA server. Local-authentication-only users will have no access to the PX3TS except for the admin, who always can access the PX3TS. If the external authentication fails, an "Authentication failed" message is displayed.
  • Page 338 PX3TS and the client (such as a web browser), which is impacted by the cipher priority of the PX3TS and the client's cipher availability/settings. Tip: If intending to force the PX3TS to use a specific AES cipher, refer to your client's user documentation for information on configuring AES settings.
  • Page 339 Copy settings from This checkbox appears only when there are existing AA server existing LDAP server settings on the PX3TS. To duplicate any existing AA server's settings, refer to the duplicating procedure below.
  • Page 340 LDAP/LDAPS directory services by Microsoft for use in Windows environments. Security Determine whether you would like to use Transport Layer Security (TLS) encryption, which allows the PX3TS to communicate securely with the LDAPS server. Three options are available:  StartTLS ...
  • Page 341  Example: testradius.com 4. To verify if the authentication configuration is set correctly, click Test Connection to check whether the PX3TS can connect to the new server successfully. Tip: You can also test the connection on the Authentication page after finishing adding servers.
  • Page 342 4. Modify the IP Address/Hostname field. 5. Click Add Server. Note: If the PX3TS clock and the LDAP server clock are out of sync, the installed TLS certificates, if any, may be considered expired. To ensure proper synchronization, administrators should configure the PX3TS and the LDAP server to use the same NTP server(s).
  • Page 343 Confirm Shared Secret 4. To verify if the authentication configuration is set correctly, click Test Connection to check whether the PX3TS can connect to the new server successfully. Tip: You can also test the connection on the Authentication page after finishing adding servers.
  • Page 344 Save Order to save the new sequence. Note: Whenever the PX3TS is successfully connected to one external authentication server, it STOPS trying to access the remaining servers in the authentication list regardless of the user authentication result.
  • Page 345 Chapter 6: Using the Web Interface 2. Select the following checkbox. Then the PX3TS always tries external authentication first. Whenever the external authentication fails, the PX3TS switches to local authentication. 3. Click Save. To disable external authentication: 1. In the Authentication Type, select Local.
  • Page 346 Keep the idle timeout to 20 minutes or less if possible. This reduces the number of idle sessions connected, and the number of simultaneous commands sent to the PX3TS. 2. Select the "Prevent concurrent login with same username" checkbox if intending to prevent multiple persons from using the same login name simultaneously.
  • Page 347 = Required At least one special character = Required Number of forbidden previous passwords Note: The maximum password length accepted by the PX3TS is 64 characters. 2. Make changes to the default settings as needed. 3. Click Save. Enabling the Restricted Service Agreement The restricted service agreement feature, if enabled, forces users to read a security agreement when they log in to the PX3TS.
  • Page 348 Chapter 6: Using the Web Interface Login manner after enabling the service agreement: After the Restricted Service Agreement feature is enabled, the agreement's content is displayed on the login screen. Do either of the following, or the login fails:  In the web interface, select the checkbox labeled "I understand and accept the Restricted Service Agreement."...

  • Page 349: Setting The Date And Time

    Chapter 6: Using the Web Interface Setting the Date and Time Set the internal clock on the PX3TS device manually, or link to a Network Time Protocol (NTP) server. Note: If you are using Sunbird's Power IQ to manage the PX3TS, you must configure Power IQ and the PX3TS to have the same date/time or NTP settings.
  • Page 350 Click Check NTP Servers to verify the validity and accessibility of the manually-specified NTP servers. Click Save. The PX3TS follows the NTP server sanity check per the IETF RFC. If your PX3TS has problems synchronizing with a Windows NTP server, see Windows NTP Server Synchronization Solution...
  • Page 351 Chapter 6: Using the Web Interface Calendar The calendar icon in the Date field is a convenient tool to select a custom date. Click it and a calendar similar to the following appears. Number Item Description arrows Switch between months. dates All dates of the selected month.
  • Page 352 Chapter 6: Using the Web Interface Windows NTP Server Synchronization Solution The NTP client on the PX3TS follows the NTP RFC so the PX3TS rejects any NTP servers whose root dispersion is more than one second. An NTP server with a dispersion of more than one second is considered an inaccurate NTP server by the PX3TS.

  • Page 353: Event Rules And Actions

    Action: This is the response to the event. For example, the PX3TS notifies the system administrator of the event via email. If you want the PX3TS to perform one action at a regular interval instead of waiting until an event occurs, you can schedule that action. For example, you can make the PX3TS email the temperature report every hour.
  • Page 354 Built-in rules:  System Event Log Rule: This causes ANY event occurred to the PX3TS to be recorded in the internal log. It is enabled by default. Note: For the default log messages generated for each event, see (on page 336).
  • Page 355  <Any sub-event> means all events shown on the list.  <Any Numeric Sensor> means all numeric sensors of the PX3TS, including internal and environmental sensors. <Any Numeric Sensor> is especially useful if you want to receive the notifications when any numeric sensor's readings pass through a specific threshold.
  • Page 356 6. In this example, 'Above upper critical threshold' is selected because we want the PX3TS to react only when the selected temperature sensor's reading enters the upper critical range. A "Trigger condition" field appears, requiring you to define the "exact" condition related to the "upper critical"...
  • Page 357 That is, the status of the selected event transits from TRUE to FALSE.  Both: The PX3TS takes the action both when the event occurs (asserts) and when the event stops/disappears (deasserts). State sensor state...
  • Page 358  Both: The PX3TS takes the action both when the chosen sensor becomes unavailable or available.  Link state is up: The PX3TS takes the action Network interface only when the network link state changes link state from down to up.
  • Page 359  Monitoring stopped: The PX3TS takes the action only when the monitoring of any specified server stops.  Both: The PX3TS takes the action when the monitoring of any specified server starts or stops.  Unreachable: The PX3TS takes the action...
  • Page 360 Chapter 6: Using the Web Interface Default Log Messages Following are default log messages recorded internally and emailed to specified recipients when PX3TS events occur (are TRUE) or, in some Send Email cases, stop or become unavailable (are FALSE). See page 357) for information configuring email messages to be sent when specified events occur.
  • Page 361 Chapter 6: Using the Web Interface Event/context Default message when the event = Default message when the event TRUE = FALSE Asset Management > Blade Blade extension overflow occurred on Blade extension overflow cleared Extension Overflow strip [AMSNUMBER] ('[AMSNAME]'). for strip [AMSNUMBER] ('[AMSNAME]').
  • Page 362 Chapter 6: Using the Web Interface Event/context Default message when the event = Default message when the event TRUE = FALSE Device > Device settings saved Device settings saved by user '[USERNAME]' from host '[USERIP]'. Device > Device settings Device settings restored from host restored '[USERIP]'.
  • Page 363 Chapter 6: Using the Web Interface Event/context Default message when the event = Default message when the event TRUE = FALSE Device > Unknown peripheral An unknown peripheral device with device attached rom code '[ROMCODE]' was attached at position '[PERIPHDEVPOSITION]'. Device >...
  • Page 364 Chapter 6: Using the Web Interface Event/context Default message when the event = Default message when the event TRUE = FALSE Peripheral Device Slot > * > Peripheral device Peripheral device Numeric Sensor > Below lower '[EXTSENSORNAME]' in slot '[EXTSENSORNAME]' in slot critical threshold [EXTSENSORSLOT] asserted 'below [EXTSENSORSLOT] deasserted...
  • Page 365 Chapter 6: Using the Web Interface Event/context Default message when the event = Default message when the event TRUE = FALSE Inlet > * > Sensor > * > Warning Sensor '[INLETSENSOR]' on inlet Sensor '[INLETSENSOR]' on inlet '[INLET]' entered warning state. '[INLET]' exited warning state.
  • Page 366 Chapter 6: Using the Web Interface Event/context Default message when the event = Default message when the event TRUE = FALSE Outlet > * > Sensor > * > Below Sensor '[OUTLETSENSOR]' on outlet Sensor '[OUTLETSENSOR]' on lower warning threshold '[OUTLET]' asserted 'below lower outlet '[OUTLET]' deasserted 'below warning' at [SENSORREADING]...
  • Page 367 Chapter 6: Using the Web Interface Event/context Default message when the event = Default message when the event TRUE = FALSE Overcurrent Protector > * > Sensor '[OCPSENSOR]' on overcurrent Sensor '[OCPSENSOR]' on Sensor > * > Unavailable protector '[OCP]' unavailable. overcurrent protector '[OCP]' available.
  • Page 368 Chapter 6: Using the Web Interface Event/context Default message when the event = Default message when the event TRUE = FALSE PDU > Sensor > * > Above upper Global sensor '[PDUSENSOR]' Global sensor '[PDUSENSOR]' critical threshold asserted 'above upper critical' at deasserted 'above upper critical' at [SENSORREADING] [SENSORREADING]...
  • Page 369 Chapter 6: Using the Web Interface Event/context Default message when the event = Default message when the event TRUE = FALSE Server Monitoring > * > Connection to server Unrecoverable '[MONITOREDHOST]' could not be restored. Transfer Switch > Active Inlet Active inlet on transfer switch '[TRANSFERSWITCH]' changed to '[ACTIVEINLET]' due to...
  • Page 370 Chapter 6: Using the Web Interface Event/context Default message when the event = Default message when the event TRUE = FALSE Transfer Switch > Sensor > * > Operational state of transfer switch Operational state of transfer switch Normal '[TRANSFERSWITCH]' is now normal. '[TRANSFERSWITCH]' is no longer normal.
  • Page 371 Chapter 6: Using the Web Interface Event/context Default message when the event = Default message when the event TRUE = FALSE User Administration > User User '[UMTARGETUSER]' modified by modified user '[USERNAME]' from host '[USERIP]'. User Administration > User User '[UMTARGETUSER]' deleted by deleted user '[USERNAME]' from host '[USERIP]'.
  • Page 372 Chapter 6: Using the Web Interface Event/context Default message when the event = Default message when the event TRUE = FALSE LHX/SHX > Sensor > Above Sensor '[LHXSENSORID]' on LHX at Sensor '[LHXSENSORID]' on LHX at upper critical threshold [PORTTYPE] port '[PORTID]' asserted [PORTTYPE] port '[PORTID]' 'above upper critical' at deasserted 'above upper critical' at...
  • Page 373 Chapter 6: Using the Web Interface Event/context Default message when the event = Default message when the event TRUE = FALSE LHX/SHX > ST-Bus An ST-Bus communication error was Communication Error detected on LHX at [PORTTYPE] port '[PORTID]'. LHX/SHX > Collective fault A collective fault occurred on LHX at [PORTTYPE] port '[PORTID]'.
  • Page 374  System Tamper Alarm: This action causes the PX3TS to show the alarm for the DX tamper sensor, if any, on the Dashboard page until a person acknowledges it. By default, this action has been assigned to the built-in tamper detection event rules.
  • Page 375 Chapter 6: Using the Web Interface 2. Click the Action field to select an action type from the list. 3. Below is the list of available actions. Note: The "Change load shedding state" and "Switch outlets" options are only available for outlet-switching capable models. Action Function Alarm...
  • Page 376 (on page 363). Start/stop Lua script If you are a developer who can create a Lua script, you can upload it to the PX3TS, and have the PX3TS automatically perform or stop the Start or script in response to an event. See Stop a Lua Script (on page 365).
  • Page 377 6. In the "Re-scheduling Limit" field, specify the maximum number of times the alert notification is resent. Values range from 1 to infinite. 7. (Optional) You can instruct the PX3TS to send the acknowledgment notification after the alarm is acknowledged in the Acknowledgment Notifications field.
  • Page 378 Change Load Shedding State The "Change load shedding state" action is available only when your PX3TS is able to control outlet power. Use this action to activate or deactivate the load shedding mode for responding to a specific event. For...
  • Page 379 Internal Beeper You can have the built-in beeper of the PX3TS turned on or off when a certain event occurs. Operation: 1. Choose Device Settings > Event Rules >...
  • Page 380 Chapter 6: Using the Web Interface Push Out Sensor Readings You can configure the PX3TS to push sensor log to a remote server after a certain event occurs, including logs of internal sensors, environmental sensors and actuators. If you have connected Raritan's asset strips to the PX3TS, you can also configure the PX3TS to push the data to a server.
  • Page 381 Chapter 6: Using the Web Interface The maximum amount of snapshots that can be stored on the PX3TS is 10. If you set it for a number greater than 10 and the storage location is on the PX3TS, after the 10th snapshot is taken and stored, the oldest snapshots are overwritten.
  • Page 382 Chapter 6: Using the Web Interface Placeholders for For a list and definition of available variables, see Custom Messages (on page 375). Operation: 1. Choose Device Settings > Event Rules > 2. Select "Send email" from the Action list. 3. In the "Recipient Email Addresses" field, specify the email address(es) of the recipient(s).
  • Page 383 Send Sensor Report You may set the PX3TS so that it automatically reports the latest readings or states of one or multiple sensors by sending a message or email or simply recording the report in a log. These sensors can be either internal or environmental sensors as listed below.
  • Page 384 Chapter 6: Using the Web Interface b. To select any methods, select them one by one in the Available field. To add all available methods, simply click Select All. c. To delete any methods, click a method's in the Selected field.
  • Page 385 Only the 7-bit ASCII charset is supported for SMS messages. Messages consist of a combination of free text and PX3TS placeholders. The placeholders represent information which is pulled from the PX3TS and inserted into the message.
  • Page 386 Chapter 6: Using the Web Interface 2. Select "Send SMS message" from the Action list. 3. In the Recipient Phone Number field, specify the phone number of the recipient. 4. Select the Use Custom Log Message checkbox, and then create a custom message in the provided text box.
  • Page 387 Chapter 6: Using the Web Interface 3. In the "Recipient Email Addresses" field, specify the email address(es) of the recipient(s). Use a comma to separate multiple email addresses. 4. To use the SMTP server specified on the SMTP Server page, select the "Use default settings"...
  • Page 388 5. In the Community fields, enter the SNMP community string to access the device(s). The community is the group representing the PX3TS and all SNMP management stations. Tip: An SNMP v2c notification action permits only a maximum of three SNMP destinations.
  • Page 389 Start or Stop a Lua Script If you have created or loaded a Lua script file into the PX3TS, you can have that script automatically run or stop in response to a specific event. For instructions on creating or loading a Lua script into this product, see Lua Scripts (on page 396).
  • Page 390 To remove any LHX/SHX device from the Selected LHX/SHX field, click that device's . To remove all devices, click Deselect All. Switch Outlets The "Switch outlets" action is available only when your PX3TS is outlet-switching capable. This action turns on, off or power cycles a specific outlet. Operation: 1.
  • Page 391 Outlets (on page 190). Switch Peripheral Actuator If you have any actuator connected to the PX3TS, you can set up the PX3TS so it automatically turns on or off the system controlled by the actuator when a specific event occurs.
  • Page 392 Chapter 6: Using the Web Interface 3. In the Syslog Server field, specify the IP address to which the syslog is forwarded. 4. In the Transport Protocol field, select one of the syslog protocols: TCP, UDP or TCP+TLS. The default is UDP. Transport Next steps protocols...
  • Page 393 An action can be regularly performed at a preset time interval instead of being triggered by a specific event. For example, you can make the PX3TS report the reading or state of a specific sensor regularly by scheduling the "Send Sensor Report" action.
  • Page 394 Chapter 6: Using the Web Interface Execution Frequency settings time Click the Frequency field to select an option. Minutes The frequency ranges from every minute, every 5 minutes, every 10 minutes and so on until every 30 minutes. Type a value in the Minute field, which is set to either of the Hourly following: ...
  • Page 395 Chapter 6: Using the Web Interface Execution Frequency settings time This option requires three settings: Yearly  Month - January through December.  Day of month - 1 to 31.  Time - the value is measured in 12-hour format so you must correctly specify AM or PM by clicking the AM/PM button.
  • Page 396 Chapter 6: Using the Web Interface  If intended, you can customize the email messages in this action. 2. Click to create a 'Send sensor report' action that includes the 'Email a Sensor Report' action as its destination action. For details, see Send Sensor Report (on page 359).
  • Page 397 Chapter 6: Using the Web Interface  You can specify more than one temperature sensor as needed in this action. 3. Click to create a timer for performing the 'Send Temperature Sensor Readings' action hourly. Scheduling an Action For details, see (on page 369).
  • Page 398 To perform the specified action at 12:30 pm, 01:30 pm, 02:30 pm, and so on, select Hourly, and set the Minute to 30. Then the PX3TS will send out an email containing the specified temperature sensor readings hourly every day.
  • Page 399 Chapter 6: Using the Web Interface Placeholders for Custom Messages Actions of "Send email" and "Send SMS message" allow you to customize event messages. See Send Email (on page 357) or Send SMS Message (on page 361). When clicking anywhere inside the text box, the Event Context Information displays, showing a list of placeholders and their definitions.
  • Page 400 Chapter 6: Using the Web Interface Placeholder Definition [AMSNUMBER] The numeric ID of an asset strip [AMSRACKUNITPOSITION] The (vertical) rack unit position, an action applies to [AMSSTATE] The human readable state of an asset strip [AMSTAGID] The asset tag ID [CARDREADERID] The id of a card reader [CIRCUITCTRATING]...
  • Page 401 Chapter 6: Using the Web Interface Placeholder Definition [ISASSERTED] Boolean flag whether an event condition became true (1) or false (0) [LDAPERRORDESC] An LDAP error occurred [LHXFANID] The ID of a fan connected to an LHX/SHX [LHXPOWERSUPPLYID] The ID of an LHX/SHX power supply [LHXSENSORID] The ID of an LHX/SHX sensor probe [LOGMESSAGE]...
  • Page 402 Chapter 6: Using the Web Interface Placeholder Definition [POWERMETER] The PMC power meter ID [RADIUSERRORDESC] A Radius error occurred [ROMCODE] The rom code of an attached peripheral device [SENSORREADINGUNIT] The unit of a sensor reading [SENSORREADING] The value of a sensor reading [SENSORREPORT] The formatted sensor report contents [SENSORSTATENAME]...
  • Page 403 Then click Delete on the confirmation message. Sample Event Rules Sample PDU-Level Event Rule In this example, we want the PX3TS to record the firmware upgrade failure in the internal log when it happens. The event rule involves: ...
  • Page 404 Chapter 6: Using the Web Interface 3. To make the PX3TS record the firmware update failure event in the internal log, select "System Event Log Action" in the Available Actions field. Sample Outlet-Level Event Rule In this example, we want the PX3TS to send SNMP notifications to the SNMP manager for any sensor change event of outlet 3.
  • Page 405 SNMP notifications are sent again. Sample Inlet-Level Event Rule In this example, we want the PX3TS to send SNMP notifications to the SNMP manager for any sensor change event of the Inlet I1. The event rule involves: ...
  • Page 406 4. To make the PX3TS send SNMP notifications, select "System SNMP Notification Action" in the Available Actions box. Note: The SNMP notifications may be SNMP v2c or SNMP v3 traps/informs, depending on the settings for the System SNMP Notification Action.
  • Page 407 Sample Environmental-Sensor-Level Event Rule This section applies to outlet-switching capable models only. In this example, we want PX3TS to activate the load shedding function when a contact closure sensor enters the alarmed state. This event rule requires creating a new action before creating the rule.
  • Page 408 Peripherals 5. Select "State Sensor/Actuator" because the contact closure sensor is a state sensor. 6. Select "Alarmed" since we want the PX3TS to respond when the selected contact closure sensor changes its state related to the "alarmed" state. 7. In the "Trigger condition" field, select the Alarmed/Open/On radio button so that the action is taken only when the contact closure sensor enters the alarmed state.
  • Page 409 A Note about Infinite Loop You should avoid building an infinite loop when creating event rules. The infinite loop refers to a condition where the PX3TS keeps busy because the action or one of the actions taken for a certain event triggers an identical or similar event which will result in an action triggering one more event.

  • Page 410: Setting Data Logging

    In some cases, a measurement exceeds a threshold causing the PX3TS to generate an alert. The measurement then returns to a value within the threshold, but the PX3TS does not generate an alert message for the Deassertion event. Such scenarios can occur due to the hysteresis "To De-assert"...

  • Page 411: Configuring Data Push Settings

    5. Click Save. This button is located at the bottom of the page. Important: Although it is possible to selectively enable/disable logging for individual sensors on the PX3TS, it is NOT recommended to do so. Configuring Data Push Settings You can push the sensor or asset strip data to a remote server for data synchronization.
  • Page 412 Setting Data Logging (on page 386). 7. If "Asset management tag list" is selected in the above step, specify the asset strip(s) whose information to send. For PX3TS with only one FEATURE port, only one asset strip is available. ...

  • Page 413: Monitoring Server Accessibility

    This function is especially useful when you are not located in an area with Internet connectivity. PX3TS can monitor the accessibility of any IT device, such as database servers, remote authentication servers, power distribution units (PDUs), and so on. It supports monitoring a maximum of 8 devices.
  • Page 414 In the beginning, the status of the added IT equipment shows "Waiting for reliable connection," which means the requested number of consecutive successful or unsuccessful pings has not reached before the PX3TS can declare that the monitored device is reachable or unreachable.
  • Page 415 In this illustration, it is assumed that a significant PDU (IP address: 192.168.84.95) shall be monitored by your PX3TS to make sure that PDU is properly operating all the time, and the PX3TS must send out SNMP notifications (trap or inform) if that PDU is declared unreachable due to power or network failure.
  • Page 416 Number of consecutive unsuccessful pings for failure  To make the PX3TS stop pinging the target PDU for 60 seconds (1 minute) after the PDU inaccessibility is declared. After 60 seconds, the PX3TS will re-ping the target PDU, enter the following data.

  • Page 417: Front Panel Settings

    PX3TS series. This is because only PX3TS-iX7 product models have the dot-matrix panel for this operation.  Default front panel mode setup -- available on all PX3TS-iX7 series, but NOT available on PX3TS series. To configure the front panel settings: 1.

  • Page 418: Configuring The Serial Port

    Configuring the Serial Port You can change the bit rate of the serial port labeled CONSOLE / MODEM on the PX3TS. The default bit rate for both console and modem operation is 115200 bps. The PX3TS supports using the following devices via the serial interface: ...
  • Page 419 3. If needed, click Advanced Information to view detailed information about the modem, SIM and mobile network. 4. To test whether the PX3TS can successfully send out SMS messages with the modem settings: a. Enter the number of the recipient's phone in the Recipient Phone field.

  • Page 420: Lua Scripts

    Raritan also provides some Lua scripts examples, which you can load as needed. Note: Not all Raritan Lua script examples can apply to your PX3TS model. You should read each example's introduction before applying them. You must have the Administrator Privileges to manage Lua scripts.
  • Page 421 Source Code section. Therefore, do not load a new script if the current script meets your needs. 6. If you chose to load a script or Raritan's example in the previous step, its codes are then displayed in the Source Code section. Double check the codes.
  • Page 422 When starting a script, you can choose to start it either with its default arguments or with new arguments. Tip: To have the PX3TS automatically start or stop a script in response to an event, create an event rule. See...
  • Page 423 Chapter 6: Using the Web Interface  Click if needing additional arguments. 5. Click Start. 6. The script output will be shown in the Script Output section.  If needed, click to delete the existing output data. To manually stop a script: 1.
  • Page 424 Chapter 6: Using the Web Interface To return to the scripts list:  Click "Lua Scripts" on the top of the page.  Menu Or click "Lua Scripts" in the (on page 146). Checking Lua Scripts States Choose Device Settings > Lua Scripts to show the scripts list, which indicates the current state and settings of each script.
  • Page 425 Modifying or Deleting a Script You can edit an existing script's codes or even replace it with a new script. Or you can simply remove a unnecessary script from the PX3TS. To modify or replace a script: 1. Choose Device Settings > Lua Scripts.

  • Page 426: Miscellaneous

    EnergyWise energy management architecture is implemented ® in your place, you can enable the Cisco EnergyWise endpoint implemented on the PX3TS so that this PX3TS becomes part of the Cisco EnergyWise domain. To enable either feature, choose Device Settings > Miscellaneous.

  • Page 427: Maintenance

    Chapter 6: Using the Web Interface Field Description Polling interval Type a polling interval to determine how often the PX3TS is queried in the Cisco EnergyWise domain.  Range from 30 to 600 ms.  Default is 180 ms. EnergyWise 3.
  • Page 428 Viewing Connected Users Connected Users (on page 410) Viewing or Clearing the Local Event Log Event Log (on page 412) Updating the PX3TS Firmware Update Firmware (on page 413) Viewing Firmware Update History Firmware History (on page 417) Bulk Configuration...

  • Page 429: Device Information

    Device Information Using the web interface, you can retrieve hardware and software information of components or peripheral devices connected to your PX3TS. Tip: If the information shown on this page does not match the latest status, press F5 to reload it.
  • Page 430 402). Network The network information, such as the current networking mode, IPv4 and/or IPv6 addresses and so on. This tab also indicates whether the PX3TS is part of a cascading configuration. See Identifying Cascaded Devices (on page 407). Port Forwarding...
  • Page 431 Chapter 6: Using the Web Interface Identifying Cascaded Devices Cascading For information on how to cascade PX3TS devices, see Multiple PX3TS Devices for Sharing Ethernet Connectivity (on page 28). This section explains how to identify a cascaded device on the Device Information page.
  • Page 432 Indicates the Port Forwarding is enabled. See Setting the Cascading Mode (on page 282). Cascade Position Indicates the position of the PX3TS in the cascading chain.  0 (zero) represents the master device.  A non-zero number represents a slave device. 1 is Slave 1, 2 is Slave 2, 3 is Slave 3 and so on.
  • Page 433 Chapter 6: Using the Web Interface  A master device shows (zero) in the Cascade Position field and in the Cascaded Device Connected field.  A slave device in the middle position shows a non-zero number which indicates its exact position in the Cascade Position field in the Cascaded Device Connected field.

  • Page 434: Viewing Connected Users

    Port Forwarding mode, click the Port Forwarding title bar on the same page. Viewing Connected Users You can check which users have logged in to the PX3TS device and their status. If you have administrator privileges, you can terminate any user's connection to the PX3TS.
  • Page 435 USB), <local> is displayed instead of an IP address. Client Type The interface through which the user is being connected to the PX3TS.  Web GUI: Refers to the web interface.  CLI: Refers to the command line interface (CLI).

  • Page 436: Viewing Or Clearing The Local Event Log

    By default, the PX3TS captures certain system events and saves them in a local (internal) event log. You can view over 2000 historical events that occurred on the PX3TS in the local event log. When the log size exceeds 256KB, each new entry overwrites the oldest one.

  • Page 437: Updating The Px3Ts Firmware

    Support page http://www.raritan.com/support/ the Raritan website's If you have any questions or concerns about the upgrade, contact Raritan Technical Support BEFORE upgrading. Note that firmware upgrade via iOS mobile devices, such as iPad, requires the use of iCloud Drive or a file manager app.
  • Page 438 No users can successfully log in to the PX3TS.  Other users' operation, if any, is forced to suspend. 7. When the update is complete, the PX3TS resets, and the Login page re-appears.  Other logged-in users are logged out when the firmware update is complete.
  • Page 439 Firmware version 3.3.10 is compatible with later firmware versions so you can upgrade all devices of the chain in a random order. Important: Raritan does not guarantee that no upgrade sequence limitation will be required for all future firmware versions. It is...
  • Page 440 PDU itself. This note does not address the upgrades using other management systems. Full Disaster Recovery If the firmware upgrade fails, causing the PX3TS device to stop working, you can recover it by using a special utility rather than returning the device to Raritan.

  • Page 441: Viewing Firmware Update History

    Chapter 6: Using the Web Interface Viewing Firmware Update History The firmware upgrade history is permanently stored on the PX3TS. It remains available even though you perform a device reboot or any firmware update. To view the firmware update history: 1.

  • Page 442: Bulk Configuration

    The Bulk Configuration feature lets you save generic settings of a configured PX3TS device to your computer. You can use this configuration file to copy common settings to other PX3TS devices of the Bulk Configuration Restrictions same model and firmware version. See (on page 419).
  • Page 443 The last configuration-copying record: If you once copied any bulk configuration or device backup file to the PX3TS, the last record similar to the following is displayed at the bottom of both the Bulk Configuration and Backup/Restore pages. Tip: The date and time shown on the PX3TS web interface are automatically converted to your computer's time zone.
  • Page 444 "mechanical designs" which are indicated in the table below, the bulk configuration remains feasible. These mechanical designs are represented by suffixes added to the model name of a PX3TS device. In the table, represents a number. For example, A can be A1, A2, A3, and so on.
  • Page 445 To create new bulk profile(s): 1. Log in to the source PX3TS device, whose settings you want to download. 2. Choose Maintenance > Bulk Configuration.
  • Page 446 Step 1: Select the desired bulk configuration profile (optional) 1. Log in to the source PX3TS, whose settings you want to copy. 2. Choose Maintenance > Bulk Configuration. 3. Click on the row of the wanted profile to open the Edit Bulk Profile page.
  • Page 447 Step 3: Perform bulk configuration You must have the Administrator Privileges to upload the configuration. 1. Log in to the target PX3TS, which is of the same model and runs the same firmware. 2. Choose Maintenance > Bulk Configuration. 3. Click to select the configuration file.
  • Page 448 Chapter 6: Using the Web Interface Alternatives: To use a different method to perform bulk configuration, refer to:  Bulk Configuration via SCP (on page 651)  Bulk Configuration or Firmware Upgrade via DHCP/TFTP page 679)  Configuration or Firmware Upgrade with a USB Drive (on page 666) Modifying or Removing Bulk Profiles...

  • Page 449: Backup And Restore Of Device Settings

    Unlike the bulk configuration file, the backup file contains ALL device settings, including device-specific data like device names and all network settings. To back up or restore a PX3TS device's settings, you should perform the Backup/Restore feature. All PX3TS information is captured in the plain-TEXT-formatted backup file except for the device logs and TLS certificate.

  • Page 450: Network Diagnostics

    "Bulk configuration copied" event rule. The last configuration-copying record: If you once copied any bulk configuration or device backup file to the PX3TS, the last record similar to the following is displayed at the bottom of both the Bulk Configuration and Backup/Restore pages. Alternative: To use a different method to perform backup/restore, refer to: ...

  • Page 451: Downloading Diagnostic Information

    Important: This function is for use by Raritan Field Engineers or when you are directed by Raritan Technical Support. You can download the diagnostic file from the PX3TS to a client machine. The file is compressed into a .tgz file and should be sent to Raritan Technical Support for interpretation.

  • Page 452: Rebooting The Px3Ts Device

    Chapter 6: Using the Web Interface Rebooting the PX3TS Device You can remotely reboot the PX3TS device via the web interface. Resetting the PX3TS does not interrupt the operation of connected servers because there is no loss of power to outlets. During and after the reboot, outlets that have been powered on prior to the reboot remain powered on, and outlets that have been powered off remain powered off.

  • Page 453: Retrieving Software Packages Information

    To reset the device to factory defaults: 1. Choose Maintenance > Unit Reset > 2. Click Factory Reset to reset the PX3TS to factory defaults. 3. A message appears, with a countdown timer showing the remaining time of the operation. It takes about two minutes to complete.

  • Page 454: Webcam Management

    2. You can click any link to access related information or download any software package. Webcam Management The 'Webcams' menu item appears only when there is any webcam(s) connected to the PX3TS, or when there are snapshots saved onto the Connecting a Logitech Webcam PX3TS already. See (on page 74).
  • Page 455 Chapter 6: Using the Web Interface With a Logitech webcam connected to the PX3TS, you can visually ® monitor the environment around the PX3TS via snapshots or videos captured by the webcam. Permissions required: To do... Permission(s) required Either permission below:...

  • Page 456: Configuring Webcams And Viewing Live Images

    Chapter 6: Using the Web Interface Configuring Webcams and Viewing Live Images To configure a webcam or view live snapshot/video sessions, choose Menu Webcams in the (on page 146). Then click the desired webcam to open that webcam's page. Note that default webcam names are determined by the detection order. Webcam The one that is detected first is named , and the other that is...
  • Page 457 PX3TS to your computer. 2. To save the current image onto PX3TS or a remote server, click  The default storage location for snapshots is the PX3TS device.
  • Page 458 It is suggested to customize a webcam's name prior to saving snapshots on the remote server. In case you change the webcam's name after saving any snapshots, PX3TS will create a new folder with the new webcam name while keeping the old folder with the old name.

  • Page 459: Sending Links To Snapshots Or Videos

    Chapter 6: Using the Web Interface To return to the Webcam Management page:  Click Webcam Management on the top of the page.  Menu Or click Webcams again in the (on page 146). Sending Links to Snapshots or Videos When opening a Primary Standalone Live Preview window, a unique URL is generated for this window session.
  • Page 460 Chapter 6: Using the Web Interface  Note that default webcam names are determined by the Webcam detection order. The one that is detected first is named Webcam 2 and the other that is detected later is named 3. Click in the Live Preview section.

  • Page 461: Viewing And Managing Locally-Saved Snapshots

    URL link remains valid, which can be one of these scenarios:  The Primary Standalone Live Preview window remains open on User A's computer. If so, even though User A logs out of the PX3TS or the login session times out, the link remains accessible. ...
  • Page 462 2. Click the snapshot you want to view from the list. Tip: The date and time shown on the PX3TS web interface are automatically converted to your computer's time zone. To avoid any time confusion, you can apply the same time zone settings as those of PX3TS to your computer.
  • Page 463 Chapter 6: Using the Web Interface  To select all images, select the top-most checkbox in the header row. 3. On the top of the list, click 4. Click Delete on the confirmation message. To download any image onto the computer: ...

  • Page 464: Changing Storage Settings

    FTP client, to access and manage the snapshots stored on remote servers. The default is to store snapshots onto the PX3TS device, which has a limitation of 10 snapshots. Note that any operation involving device reboot will remove the snapshots saved on the PX3TS, such as firmware upgrade.
  • Page 465 PX3TS web interface. If this issue occurs, first restore the connectivity of the remote server...

  • Page 466: Identifying Snapshots Folders On Remote Servers

    All snapshots are saved as JPEG and named according to the date and time when saving the snapshots. Note that the date and time of the filename are based on the time zone of the PX3TS device rather than that of the computer or mobile device you are operating.
  • Page 467 Note: It is suggested to customize a webcam's name prior to saving snapshots on the remote server. In case you change the webcam's name after saving any snapshots, PX3TS will create a new folder with the new webcam name while keeping the old folder with the old name.

  • Page 468: Smartlock And Card Reader

    DX2-DH2C2 and the door handles included in the kit. Note: For information on DX2-DH2C2, you can refer to either the user documentation accompanying the SmartLock kit or 'Environmental Sensors and Actuators Guide' (or Online Help) on Raritan website's Support page http://www.raritan.com/support/...

  • Page 469: Smartlock

    Chapter 6: Using the Web Interface Note that "SmartLock" appears only when your door handles are connected via DX2-DH2C2 to PX3TS, but "Card Readers" appears as long as the PX3TS detects any card reader -- directly connected to PX3TS, or indirectly connected via DX2-DH2C2. SmartLock: ...
  • Page 470 Chapter 6: Using the Web Interface  Configure the door handles connected to DX2-DH2C2. You must set this because PX3TS cannot detect the types of connected door handles.  Control the door handles connected to DX2-DH2C2. To view the status of the door and card reader:...
  • Page 471 Chapter 6: Using the Web Interface Section Description Shows all sensor states detected by DX2-DH2C2, Door State including:  Door : States of contact closure sensors connected to DX2-DH2C2. Contact closure sensors detect whether the door is physically opened or closed. ...
  • Page 472 Chapter 6: Using the Web Interface  If no door handle is being connected to the door-handle port in question on the DX2-DH2C2, select or leave this field to "None." 3. Click Save. To control the door handles: 1. Make sure you have configured the door handle type properly in the above procedure.

  • Page 473: Card Readers

    146). This page lists all card readers connected to PX3TS, indirectly or directly. When a user scans his/her smart card with the card reader, PX3TS will retrieve the card 's type and ID and show them in the corresponding Card Type and Card ID column.
  • Page 474 Chapter 6: Using the Web Interface External USB card readers:  This is an external USB card reader.  It is directly connected to PX3TS via USB.  The Channel column does not show any data.

  • Page 475: Chapter 7 Using Snmp

    Chapter 7 Using SNMP This SNMP section helps you set up the PX3TS for use with an SNMP manager. The PX3TS can be configured to send traps or informs to an SNMP manager, as well as receive GET and SET commands in order to retrieve status and configure some basic settings.

  • Page 476: Snmpv2C Notifications

    Chapter 7: Using SNMP To enable SNMP notifications: 1. Choose Device Settings > Network Services > SNMP. 2. In the SNMP Notifications section, enable the SNMP notification feature, and configure related fields. For details, refer to:  SNMPv2c Notifications (on page 452) ...

  • Page 477: Snmpv3 Notifications

    The port number used to access the device(s). Community The SNMP community string to access the device(s). The community is the group representing the PX3TS and all SNMP management stations. 6. Click Save. SNMPv3 Notifications 1. Choose Device Settings > Network Services > SNMP.
  • Page 478 Chapter 7: Using SNMP 3. In the SNMP Notifications section, make sure the Enable SNMP Notifications checkbox is selected. 4. Select SNMPv3 Trap or SNMPv3 Inform as the notification type. 5. For SNMP TRAPs, the engine ID is prepopulated. 6. Type values in the following fields.
  • Page 479 Chapter 7: Using SNMP Field Description Host The IP address of the device(s) you want to access. This is the address to which notifications are sent by the SNMP agent. Port The port number used to access the device(s). User ID User name for accessing the device.

  • Page 480: Downloading Snmp Mib

    1. Choose Device Settings > Network Services > SNMP. 2. Click the Download MIBs title bar. 3. Select the desired MIB file to download.  PDU2-MIB: The SNMP MIB file for PX3TS power management.  ASSETMANAGEMENT-MIB: The SNMP MIB file for asset management.

  • Page 481: Snmp Gets And Sets

    Valid objects for these requests are limited to those found in the SNMP MIB-II System Group and the custom PX3TS MIB. The PX3TS MIB The SNMP MIB file is required for using your PX3TS device with an SNMP manager. An SNMP MIB file describes the SNMP functions.
  • Page 482 For example, the measurementsGroup group contains objects for sensor readings of PX3TS as a whole. One object listed under this group, measurementsUnitSensorValue, is described later in the MIB as "The sensor value". pduRatedCurrent, part of the configGroup group,...
  • Page 483 Some objects can be configured from the SNMP manager using SNMP set commands. Objects that can be configured have a MAX-ACCESS level of "read-write" in the MIB. These objects include threshold objects, which causes the PX3TS to generate a warning and send an SNMP notification when certain Sensor Threshold Settings parameters are exceeded.

  • Page 484: Retrieving Energy Usage

    Active Energy for the outlet this IT device is plugged into. The Active Energy values are included in the outletSensorMeasurementsTable, along with other outlet sensor readings. Note: PX3TS-1000 series does not support this functionality. A Note about Enabling Thresholds When enabling previously-disabled thresholds via SNMP, make sure you set a correct value for all thresholds that are supposed to be enabled prior to actually enabling them.

  • Page 485: Chapter 8 Using The Command Line Interface

    Showing Information ................467 Clearing Information ................499 Entering Configuration Mode ..............500 Quitting Configuration Mode ..............501 PX3TS Control and Configuration ............501 Load Shedding Configuration Commands ..........636 Power Control Operations............... 638 Actuator Control Operations ..............641 Unblocking a User ................... 643 Resetting the PX3TS ................

  • Page 486: About The Interface

    This section illustrates HyperTerminal, which is part of Windows operating systems prior to Windows Vista. To log in using HyperTerminal: 1. Connect your computer to the PX3TS via a local (USB or RS-232) connection. 2. Launch HyperTerminal on your computer and open a console window.

  • Page 487: With Ssh Or Telnet

    "Dominion PX2 Serial Console" under the Ports group. 3. In the communications program, press Enter to send a carriage return to the PX3TS. The Username prompt appears. 4. Type a name and press Enter. The name is case sensitive. Then you are prompted to enter a password.

  • Page 488: With An Analog Modem

    6. You are now logged in to the command line interface and can begin administering the PX3TS. With an Analog Modem The PX3TS supports remote access to the CLI via a connected analog modem. This feature is especially useful when the LAN access is not available.

  • Page 489: The ? Command For Showing Available Commands

     Configuration Mode: You can enter the configuration mode from the administrator or user mode. In this mode, the prompt changes to config:# or config:> and you can change PX3TS device and network Entering Configuration Mode configurations. See (on page 500).

  • Page 490: Querying Available Parameters For A Command

    Chapter 8: Using the Command Line Interface In the configuration mode: config:# In the diagnostic mode: diag:# Press Enter after pressing the ? command, and a list of main commands for the current mode is displayed. Tip: To automatically complete a command after typing part of the full command, see Automatically Completing a Command (on page 648).

  • Page 491: Showing Information

    Showing Information You can use the show commands to view current settings or the status of the PX3TS device or part of it, such as the IP address, networking mode, firmware version, states or readings of internal or external sensors, user profiles, and so on.

  • Page 492: Transfer Switch Information

    Chapter 8: Using the Command Line Interface Transfer Switch Information This command shows the transfer switch-related information of the PX3TS device. show ts To show detailed information, add the parameter "details" to the end of the command. show ts details Displayed information includes: ...
  • Page 493 Chapter 8: Using the Command Line Interface Power Quality Settings This command shows the power quality criteria of the PX3TS device, including voltage and frequency thresholds per inlet. show ts powerQualityParameters Transfer Timing Statistics This command shows statistics on how long a power transfer takes, including power failure detection time, relay open time and total transfer time (in milliseconds).

  • Page 494: Network Configuration

    , or Note that you must choose/configure the bridge interface if your PX3TS is set to the bridging mode. Note: In the bridging mode, only the IP parameters of the BRIDGE interface function. The IP parameters of the ETHERNET and WIRELESS interfaces do NOT function.
  • Page 495 Chapter 8: Using the Command Line Interface Interface Description wireless Show the IP-related configuration of the WIRELESS interface. bridge Show the IP-related configuration of the BRIDGE interface. Show the IP-related configuration of all interfaces. Tip: You can also type the command without adding this option "all"...
  • Page 496 , or Note that you must choose/configure the bridge interface if your PX3TS is set to the bridging mode. Note: In the bridging mode, only the IP parameters of the BRIDGE interface function. The IP parameters of the ETHERNET and WIRELESS interfaces do NOT function.
  • Page 497 , or Note that you must choose/configure the bridge interface if your PX3TS is set to the bridging mode. Note: In the bridging mode, only the IP parameters of the BRIDGE interface function. The IP parameters of the ETHERNET and WIRELESS interfaces do NOT function.
  • Page 498 Chapter 8: Using the Command Line Interface Interface Description wireless Show the WIRELESS interface's non-IP settings. bridge Show the BRIDGE interface's non-IP settings. Show the non-IP settings of all interfaces. Tip: You can also type the command without adding this option "all" to get the same data. That show network interface Network Service Settings This command shows the network service settings only, including the...

  • Page 499: Pdu Configuration

    Chapter 8: Using the Command Line Interface PDU Configuration This command shows the PDU configuration, such as the device name, firmware version and model type. show pdu To show detailed information, add the parameter "details" to the end of the command. show pdu details Outlet Information This command syntax shows the outlet information.

  • Page 500: Inlet Information

    Chapter 8: Using the Command Line Interface Inlet Information This command syntax shows the inlet information. show inlets <n> To show detailed information, add the parameter "details" to the end of the command. show inlets <n> details Variables:  <n> is one of the options: , or a number.

  • Page 501: Overcurrent Protector Information

    RMS current value.  For Raritan's outlet-metered models that support "outlet peak current" sensors, information indicating which outlet MAY cause the Possible OCP-tripped event is available with this command. See OCP-Tripped Root Cause (on page 216).

  • Page 502: Date And Time Settings

    Note: If a user has set his/her own preferred measurement units or the administrator has changed any user's preferred units, the web and CLI interfaces show the preferred measurement units for that user instead of the default ones after that user logs in to the PX3TS. See Existing User Profiles (on page 489) for the preferred measurement units for a specific user.

  • Page 503: Environmental Sensor Information

    Chapter 8: Using the Command Line Interface Environmental Sensor Information This command syntax shows the environmental sensor's information. show externalsensors <n> To show detailed information, add the parameter "details" to the end of the command. show externalsensors <n> details Variables: ...

  • Page 504: Environmental Sensor Package Information

    Chapter 8: Using the Command Line Interface * The environmental sensor number is the ID number assigned to the sensor, which can be found on the Peripherals page of the PX3TS web interface. Displayed information:  Without the parameter "details," only the sensor ID, sensor type and reading are displayed.

  • Page 505: Actuator Information

    * The actuator number is the ID number assigned to the actuator. The ID number can be found using the PX3TS web interface or CLI. It is an integer starting at 1. Displayed information:  Without the parameter "details," only the actuator ID, type and state are displayed.

  • Page 506: Outlet Sensor Threshold Information

    Chapter 8: Using the Command Line Interface Outlet Sensor Threshold Information This command syntax shows the specified outlet sensor's threshold-related information. show sensor outlet <n> <sensor type> To show detailed information, add the parameter "details" to the end of the command. show sensor outlet <n>...

  • Page 507: Inlet Sensor Threshold Information

    Chapter 8: Using the Command Line Interface Inlet Sensor Threshold Information This command syntax shows the specified inlet sensor's threshold-related information. show sensor inlet <n> <sensor type> To show detailed information, add the parameter "details" to the end of the command. show sensor inlet <n>...

  • Page 508: Overcurrent Protector Sensor Threshold Information

    Chapter 8: Using the Command Line Interface Overcurrent Protector Sensor Threshold Information This command is only available for models with overcurrent protectors for protecting outlets. This command syntax shows the specified overcurrent protector sensor's threshold-related information. show sensor ocp <n> <sensor type> To show detailed information, add the parameter "details"...

  • Page 509: Environmental Sensor Threshold Information

    1.0 deg C Assertion timeout: 0 samples Variables:  <n> is the environmental sensor number. The environmental sensor number is the ID number assigned to the sensor, which can be found on the Peripherals page of the PX3TS web interface.

  • Page 510: Environmental Sensor Default Thresholds

    Chapter 8: Using the Command Line Interface Displayed information:  Without the parameter "details," only the reading, threshold, deassertion hysteresis and assertion timeout settings of the specified environmental sensor are displayed.  With the parameter "details," more sensor information is displayed, including resolution and range.

  • Page 511: Security Settings

    With the parameter "details," the threshold range is displayed in addition to default thresholds settings. Security Settings This command shows the security settings of the PX3TS. show security To show detailed information, add the parameter "details" to the end of the command.

  • Page 512: Authentication Settings

    Chapter 8: Using the Command Line Interface Authentication Settings General authentication settings: This command displays the authentication settings of the PX3TS, including both LDAP and Radius settings. show authentication One LDAP server's settings: To show the configuration of a specific LDAP server, assign the desired LDAP server with its sequential number in the command.

  • Page 513: Existing User Profiles

    Chapter 8: Using the Command Line Interface  With the parameter "details" added, detailed information of the specified server is displayed, such as an LDAP server's bind DN and the login name attribute, or a Radius server's timeout and retries values.

  • Page 514: Existing Roles

    Chapter 8: Using the Command Line Interface Existing Roles This command shows the data of one or all existing roles. show roles <role_name> Variables:  <role_name> is the name of the role whose permissions you want to query. The variable can be one of the following options: Option Description This option shows all existing roles.

  • Page 515: Serial Port Settings

    Serial Port Settings This command shows the baud rate setting of the serial port labeled CONSOLE / MODEM on the PX3TS device. show serial EnergyWise Settings This command shows the PX3TS device's current configuration for Cisco EnergyWise. ® show energywise...

  • Page 516: Rack Unit Settings Of An Asset Strip

    <n> <rack_unit> Variables:  <n> is the number of the FEATURE port where the selected asset strip is physically connected. For the PX3TS device with only one FEATURE port, the number is always 1.  <rack_unit> is one of the options: or a specific rack unit's index number.

  • Page 517: Blade Extension Strip Settings

    Variables:  <n> is the number of the FEATURE port where the selected asset strip is physically connected. For the PX3TS device with only one FEATURE port, the number is always 1.  <rack_unit> is the index number of the desired rack unit (tag port) on the selected asset strip.

  • Page 518: Event Log

    Chapter 8: Using the Command Line Interface Event Log The command used to show the event log begins with show eventlog. You can add either the limit class parameters or both to show specific events. Show the last 30 entries: show eventlog Show a specific number of last entries in the event log: show eventlog limit <n>...

  • Page 519: Wireless Lan Diagnostic Log

    Internal or external sensor events, such as state changes of any sensors. serverMonitor Server-monitoring records, such as a server being declared reachable or unreachable. assetManagement Raritan asset management events, such as asset tag connections or disconnections. Schroff LHX/SHX heat exchanger events. ® modem Modem-related events.
  • Page 520 Chapter 8: Using the Command Line Interface Server Reachability Information for a Specific Server To show the server reachability information for a certain IT device only, use the following command. show serverReachability server <n> To show detailed information, add the parameter "details" to the end of the command.

  • Page 521: Command History

    Chapter 8: Using the Command Line Interface Command History This command shows the command history for current connection session. show history Displayed information:  A list of commands that were previously entered in the current session is displayed. Reliability Data This command shows the reliability data.
  • Page 522 Chapter 8: Using the Command Line Interface Example 1 - Basic Security Information show security The diagram shows the output of the command. Example 2 - In-Depth Security Information show security details More information is displayed when typing the command.

  • Page 523: Clearing Information

    Clearing Information You can use the clear commands to remove unnecessary data from the PX3TS. After typing a "clear" command, press Enter to execute it. Note: Depending on your login name, the # prompt may be replaced by the > prompt. See (on page 465).

  • Page 524: Entering Configuration Mode

    Chapter 8: Using the Command Line Interface Clearing Event Log This command removes all data from the event log. clear eventlog -- OR -- clear eventlog /y If you entered the command without "/y," a message appears, prompting you to confirm the operation. Type y to clear the event log or n to abort the operation.

  • Page 525: Quitting Configuration Mode

    Prompts (on page 465). PX3TS Control and Configuration To configure the PX3TS device or network settings through the CLI, it is highly recommended to log in as the administrator so that you have full permissions. To configure any settings, enter the configuration mode. Configuration commands are case sensitive so ensure you capitalize them correctly.
  • Page 526 4. Manual transfer may be prevented in certain scenarios. If so, a "Transfer failed" message is displayed. Note: Whenever the PX3TS prevents a manual transfer from being performed, it is disabled across all interfaces, including the front panel button, web interface and CLI command. See Manual Transfer (on page 84).
  • Page 527 Chapter 8: Using the Command Line Interface Configuring Power Transfer Features Enter the configuration mode to change the following power transfer Entering Configuration Mode settings. See (on page 500). You can change various power transfer settings at a time by combining Multi-Command Syntax various commands.
  • Page 528 Chapter 8: Using the Command Line Interface Option Description disable Disables the automatic retransfer.  <option3> is an integer number up to 180 in seconds.  enable disable <option4> is one of the options: Option Description enable Automatic retransfer is performed only when inlets are in phase.
  • Page 529 Chapter 8: Using the Command Line Interface config:# ts powerQualityParameters upperCriticalVoltage <threshold_volts> Set the Upper Warning voltage threshold: config:# ts powerQualityParameters upperWarningVoltage <threshold_volts> Set the Voltage deassertion hysteresis: config:# ts powerQualityParameters voltageHysteresis <volt_hysteresis> Set the Voltage assertion timeout: config:# ts powerQualityParameters voltageAssertionTimeout <volt_timeout> Set the Lower Critical frequency threshold: config:# ts powerQualityParameters lowerCriticalFrequency <threshold_Hz>...

  • Page 530: Pdu Configuration Commands

    A PDU configuration command begins with . You can use the PDU configuration commands to change the settings that apply to the whole PX3TS device. Changing the PDU Name This command changes the PX3TS device's name. config:# pdu name "<name>" Variables: ...
  • Page 531 Description default All outlets are switched ON in the ASCENDING order (from outlet 1 to the final outlet) when the PX3TS device powers up. A comma- All outlets are switched ON in the order you separated list specify using the comma-separated list.
  • Page 532 This command determines the initial power condition of all outlets after powering up the PDU. config:# pdu outletStateOnDeviceStartup <option> Variables:  lastKnownState <option> is one of the options: Option Description Switches OFF all outlets when the PX3TS device powers up. Switches ON all outlets when the PX3TS device powers up.
  • Page 533 PX3TS device when the PDU powers up again. Note: This feature does NOT take effect and cannot be configured on a PX3TS device after the outlet relay is set to the "Latching" mode. See PX3TS Latching Relay Behavior (on page 182).
  • Page 534 <timing> is a delay time between 1 and 3600 seconds. Note: This feature does NOT take effect and cannot be configured on a PX3TS device after the outlet relay is set to the "Latching" mode. See (on page 182). PX3TS Latching Relay Behavior Specifying Non-Critical Outlets This section applies to outlet-switching capable models only.
  • Page 535 Chapter 8: Using the Command Line Interface Enabling or Disabling Data Logging This command enables or disables the data logging feature. config:# pdu dataRetrieval <option> Variables:  enable disable <option> is one of the options: Option Description enable Enables the data logging feature. disable Disables the data logging feature.
  • Page 536 Specifying the Device Altitude This command specifies your PX3TS device's altitude above sea level (in meters). You must specify the PX3TS device's altitude above sea level if a Raritan's DPX differential air pressure sensor is attached. This is because the device's altitude is associated with the altitude correction Altitude Correction Factors (on page 771).
  • Page 537 For more information, see Works (on page 184). Setting the Maximum Number of Active Powered Dry Contact Actuators This command determines the upper limit of "active" powered dry contact actuators on one PX3TS device. config:# pdu activePoweredDryContactLimit <number> Variables: ...

  • Page 538: Network Configuration Commands

    , or bridge Note that you must choose/configure the bridge interface if your PX3TS is set to the bridging mode. Note: In the bridging mode, only the IP parameters of the BRIDGE interface function. The IP parameters of the ETHERNET and...
  • Page 539 , or Note that you must choose/configure the bridge interface if your PX3TS is set to the bridging mode. Note: In the bridging mode, only the IP parameters of the BRIDGE interface function. The IP parameters of the ETHERNET and WIRELESS interfaces do NOT function.
  • Page 540 Cannot contain punctuation marks, spaces, and other symbols Setting the IPv4 Address After selecting the static IP configuration mode, you can use this command to assign a permanent IP address to the PX3TS device. config:# network ipv4 interface <ETH> address <ip address>...
  • Page 541 Determine the IPv4 address of the BRIDGE interface (that is, the bridging mode).  <ip address> is the IP address being assigned to your PX3TS device. 192.168.84.99/24 Its format is "IP address/prefix". For example, Setting the IPv4 Gateway After selecting the static IP configuration mode, you can use this command to specify the gateway.
  • Page 542 <ETH> is one of the interfaces: . Type "bridge" only when your PX3TS is in the bridging mode.  <route_ID> is the ID number of the route setting which you want to delete or modify.  <dest-2> is a modified route setting that will replace the original route setting.
  • Page 543 , or Note that you must choose/configure the bridge interface if your PX3TS is set to the bridging mode. Note: In the bridging mode, only the IP parameters of the BRIDGE interface function. The IP parameters of the ETHERNET and WIRELESS interfaces do NOT function.
  • Page 544 Cannot contain punctuation marks, spaces, and other symbols Setting the IPv6 Address After selecting the static IP configuration mode, you can use this command to assign a permanent IP address to the PX3TS device. config:# network ipv6 interface <ETH> address <ip address>...
  • Page 545 (that is, the bridging mode).  <ip address> is the IP address being assigned to your PX3TS device. This value uses the IPv6 address format. Note that you must add which indicates a prefix length of bits such as /64, to the end of this IPv6 address.
  • Page 546 <ETH> is one of the interfaces: ethernet wireless bridge . Type "bridge" only when your PX3TS is in the bridging mode.  <route_ID> is the ID number of the route setting which you want to delete or modify.  <dest-2> is a modified route setting that will replace the original IP address/prefix length route setting.
  • Page 547 <ip address> is the IP address of the DNS server.  <suffix1>, <suffix2>, and the like are the DNS suffixes that automatically apply when searching for any device via PX3TS. For example, <suffix1> can be raritan.com , and <suffix2> can be legrand.com...
  • Page 548 <ETH> is one of the options -- , which depends on your model. Option Description ethernet ETHERNET port of the PX3TS model. (PX3TS) eth1 ETH1 port of the iX7 model. ™ (PX3TS-iX7) eth2 ETH2 port of the iX7 model.
  • Page 549 System determines the optimum LAN speed through auto-negotiation. 10Mbps The LAN speed is always 10 Mbps. 100Mbps The LAN speed is always 100 Mbps. 1000Mbps This option is only available on PX3TS-iX7 models. The LAN speed is always 1000 Mbps.
  • Page 550 <ETH> is one of the options -- , which depends on your model. Option Description ethernet ETHERNET port of the PX3TS model. (PX3TS) eth1 ETH1 port of the iX7 model. ™ (PX3TS-iX7) eth2 ETH2 port of the iX7 model.
  • Page 551 Chapter 8: Using the Command Line Interface Setting Wireless Parameters You must configure wireless parameters, including Service Set Identifier (SSID), authentication method, Pre-Shared Key (PSK), and Basic Service Set Identifier (BSSID) after the wireless networking mode is enabled. network wireless A wireless configuration command begins with Note: If current networking mode is not wireless, the SSID, PSK and BSSID values are not applied until the networking mode is changed to...
  • Page 552 Chapter 8: Using the Command Line Interface Setting the PSK If the Pre-Shared Key (PSK) authentication method is selected, you must assign a PSK passphrase by using this command. config:# network wireless PSK <psk> Variables:  <psk> is a string or passphrase that consists of: - 8 to 63 characters - No spaces - ASCII codes 0x20 ~ 0x7E...
  • Page 553 <identity> Set the EAP password: config:# network wireless eapPassword After performing the above command, the PX3TS prompts you to enter the password. Then type the password and press Enter. Provide a CA TLS certificate: config:# network wireless eapCACertificate...
  • Page 554 <option3> is one of the options: Option Description true Make the wireless network connection successful when the PX3TS system time is earlier than the firmware build before synchronizing with the NTP server, causing the TLS certificate to become invalid.
  • Page 555 Option Description false The wireless network connection is NOT successfully established when the PX3TS finds that the TLS certificate is not valid due to incorrect system time. EAP CA Certificate Example This section provides a CA certificate example only. Your CA certificate contents should be different from the contents displayed in this example.
  • Page 556 Chapter 8: Using the Command Line Interface MIICjTCCAfigAwIBAgIEMaYgRzALBgkqhkiG9w0BAQQwRTELMAk GA1UEBhMCVVMxNjA0BgNVBAoTLU5hdGlvbmFsIEFlcm9uYXV0aW NzIGFuZCBTcGFjZSBBZG1pbmlzdHJhdGlvbjAmFxE5NjA1MjgxM zQ5MDUrMDgwMBcROTgwNTI4MTM0OTA1KzA4MDAwZzELMAkGA1UE BhMCVVMxNjA0BgNVBAoTLU5hdGlvbmFsIEFlcm9uYXV0aWNzIGF uZCBTcGFjZSBBZG1pbmlzdHJhdGlvbjEgMAkGA1UEBRMCMTYwEw YDVQQDEwxTdGV2ZSBTY2hvY2gwWDALBgkqhkiG9w0BAQEDSQAwR gJBALrAwyYdgxmzNP/ts0Uyf6BpmiJYktU/w4NG67ULaN4B5CnE z7k57s9o3YY3LecETgQ5iQHmkwlYDTL2fTgVfw0CAQOjgaswgag wZAYDVR0ZAQH/BFowWDBWMFQxCzAJBgNVBAYTAlVTMTYwNAYDVQ QKEy1OYXRpb25hbCBBZXJvbmF1dGljcyBhbmQgU3BhY2UgQWRta W5pc3RyYXRpb24xDTALBgNVBAMTBENSTDEwFwYDVR0BAQH/BA0w C4AJODMyOTcwODEwMBgGA1UdAgQRMA8ECTgzMjk3MDgyM4ACBSA wDQYDVR0KBAYwBAMCBkAwCwYJKoZIhvcNAQEEA4GBAH2y1VCEw/ A4zaXzSYZJTTUi3uawbbFiS2yxHvgf28+8Js0OHXk1H1w2d6qOH H21X82tZXd/0JtG0g1T9usFFBDvYK8O0ebgz/P5ELJnBL2+atOb EuJy1ZZ0pBDWINR3WkDNLCGiTkCKp0F5EWIrVDwh54NNevkCQRZ ita+z4IBO 6. Paste the contents in the terminal. 7. Press Enter. 8. Verify whether the system shows the following command prompt, indicating the provided CA certificate is valid.
  • Page 557 Chapter 8: Using the Command Line Interface Configuring the Cascading Mode This command determines the cascading mode. config:# network <mode> enabled <option1> Variables:  <mode> is one of the following cascading modes. Mode Description bridge The Bridging mode, where each cascaded device is assigned a unique IP address.
  • Page 558 Chapter 8: Using the Command Line Interface If Port Forwarding mode is enabled, you must configure two more settings to finish the configuration: On ALL cascaded devices, you must configure the 'role' setting one by one. config:# network portForwarding role <option2> On the master device, you must configure the 'downstream interface' setting.
  • Page 559 Chapter 8: Using the Command Line Interface Setting the HTTP Port The commands used to configure the HTTP port settings begin with network services http Change the HTTP port: config:# network services http port <n> Enable or disable the HTTP port: config:# network services http enabled <option>...
  • Page 560 <option> is one of the options: Option Description true Forces any access to the PX3TS via HTTP to be redirected to HTTPS. false No HTTP access is redirected to HTTPS. Changing the Telnet Configuration You can enable or disable the Telnet service, or change its TCP port using the CLI commands.
  • Page 561 Chapter 8: Using the Command Line Interface Option Description false The Telnet service is disabled. Changing the Telnet Port This command changes the Telnet port. config:# network services telnet port <n> Variables:  <n> is a TCP port number between 1 and 65535. The default Telnet port is 23.
  • Page 562 Chapter 8: Using the Command Line Interface Determining the SSH Authentication Method This command syntax determines the SSH authentication method. config:# network services ssh authentication <auth_method> Variables:  <option> is one of the options: passwordOnly publicKeyOnly passwordOrPublicKey Option Description passwordOnly Enables the password-based login only.
  • Page 563 Chapter 8: Using the Command Line Interface Enabling or Disabling SNMP v3 This command enables or disables the SNMP v3 protocol. config:# network services snmp v3 <option> Variables:  <option> is one of the options: enable disable Option Description enable The SNMP v3 protocol is enabled.
  • Page 564 Chapter 8: Using the Command Line Interface Setting the sysName Value This command sets the SNMP MIB-II sysName value. config:# network services snmp sysName <value> Variables:  <value> is a string comprising 0 to 255 alphanumeric characters. Setting the sysLocation Value This command sets the SNMP MIB-II sysLocation value.
  • Page 565 Chapter 8: Using the Command Line Interface Enabling or Disabling the Read-Only Mode This command enables or disables the read-only mode for the Modbus agent. config:# network services modbus readonly <option> Variables:  <option> is one of the options: true false Option Description...

  • Page 566: Time Configuration Commands

    Chapter 8: Using the Command Line Interface Examples This section illustrates several network configuration examples. Example 1 - Networking Mode The following command enables the wired networking mode. config:# network mode wired Example 2 - Enabling Both IP Protocols The following command determines that both IPv4 and IPv6 protocols are enabled.
  • Page 567 Chapter 8: Using the Command Line Interface Determining the Time Setup Method This command determines the method to configure the system date and time. config:# time method <method> Variables:  <method> is one of the time setup options: manual Mode Description manual The date and time settings are customized.
  • Page 568 Chapter 8: Using the Command Line Interface Setting NTP Parameters A time configuration command for NTP-related parameters begins with time ntp Specify the primary time server: config:# time ntp firstServer <first_server> Specify the secondary time server: config:# time ntp secondServer <second_server> To delete the primary time server: config:# time ntp firstServer ""...
  • Page 569 1:50:20 pm. Setting the Time Zone The CLI has a list of time zones to configure the date and time for the PX3TS. config:# time zone After a list of time zones is displayed, type the index number of the time zone or press Enter to cancel.
  • Page 570 Chapter 8: Using the Command Line Interface 2. The system shows a list of time zones. Type the index number of the desired time zone and press Enter. 3. Type apply for the selected time zone to take effect. Setting the Automatic Daylight Savings Time This command determines whether the daylight savings time is applied to the time settings.

  • Page 571: Checking The Accessibility Of Ntp Servers

    A security configuration command begins with Firewall Control You can manage firewall control features through the CLI. The firewall control lets you set up rules that permit or disallow access to the PX3TS device from a specific or a range of IP addresses. ...
  • Page 572 Chapter 8: Using the Command Line Interface config:# security ipAccessControl ipv4 enabled <option> Determine the default IPv4 firewall control policy for inbound traffic: config:# security ipAccessControl ipv4 defaultPolicyIn <policy> Determine the default IPv4 firewall control policy for outbound traffic: config:# security ipAccessControl ipv4 defaultPolicyOut <policy>...
  • Page 573 Chapter 8: Using the Command Line Interface  <policy> is one of the options: accept, drop reject Option Description accept Accepts traffic from all IP addresses. drop Discards traffic from all IP addresses, without sending any failure notification to the source host. reject Discards traffic from all IP addresses, and an ICMP message is sent to the source host for...
  • Page 574 Chapter 8: Using the Command Line Interface config:# security ipAccessControl ipv4 rule add <direction> <insert> <rule_number> <ip_mask> <policy>  IPv6 commands Add a new rule to the bottom of the IPv6 rules list: config:# security ipAccessControl ipv6 rule add <direction> <ip_mask> <policy> Add a new IPv6 rule by inserting it above or below a specific rule: config:# security ipAccessControl ipv6 rule add <direction>...
  • Page 575 Chapter 8: Using the Command Line Interface  <insert> is one of the options: insertAbove insertBelow Option Description insertAbove Inserts the new rule above the specified rule number. Then: new rule's number = the specified rule number insertBelow Inserts the new rule below the specified rule number.
  • Page 576 Chapter 8: Using the Command Line Interface config:# security ipAccessControl ipv6 rule modify <direction> <rule_number> policy <policy> Modify all contents of an IPv6 existing rule: config:# security ipAccessControl ipv6 rule modify <direction> <rule_number> ipMask <ip_mask> policy <policy> Variables:  <direction> is one of the options: Direction Description Inbound traffic.
  • Page 577 Chapter 8: Using the Command Line Interface config:# security ipAccessControl ipv4 rule delete <direction> <rule_number> IPv6 commands config:# security ipAccessControl ipv6 rule delete <direction> <rule_number> Variables:  <direction> is one of the options: Direction Description Inbound traffic. Outbound traffic.  <rule_number>...
  • Page 578 Chapter 8: Using the Command Line Interface After the Restricted Service Agreement feature is enabled, the agreement's content is displayed on the login screen. Do either of the following, or the login fails:  In the web interface, select the checkbox labeled "I understand and accept the Restricted Service Agreement."...
  • Page 579 Chapter 8: Using the Command Line Interface Specifying the Agreement Contents This command allows you to create or modify contents of the Restricted Service Agreement. config:# security restrictedServiceAgreement bannerContent After performing the above command, do the following: 1. Type the text comprising up to 10,000 ASCII characters when the CLI prompts you to enter the content.
  • Page 580 Chapter 8: Using the Command Line Interface Login Limitation The login limitation feature controls login-related limitations, such as password aging, simultaneous logins using the same user name, and the idle time permitted before forcing a user to log out. security loginLimits A login limitation command begins with You can combine multiple commands to modify various login limitation Multi-Command Syntax...
  • Page 581 The interval ranges from 7 to 365 days. Idle Timeout This command determines how long a user can remain idle before that user is forced to log out of the PX3TS web interface or CLI. config:# security loginLimits idleTimeout <value>...
  • Page 582 Chapter 8: Using the Command Line Interface Strong Passwords The strong password commands determine whether a strong password is required for login, and what a strong password should contain at least. A strong password command begins with security strongPasswords. You can combine multiple strong password commands to modify different parameters at a time.
  • Page 583 Chapter 8: Using the Command Line Interface Lowercase Character Requirement This command determines whether a strong password includes at least a lowercase character. config:# security strongPasswords enforceAtLeastOneLowerCaseCharacter <option> Variables:  enable disable <option> is one of the options: Option Description enable At least one lowercase character is required.
  • Page 584 Chapter 8: Using the Command Line Interface Option Description disable No numeric character is required. Special Character Requirement This command determines whether a strong password includes at least a special character. config:# security strongPasswords enforceAtLeastOneSpecialCharacter <option> Variables:  enable disable <option>...
  • Page 585 Chapter 8: Using the Command Line Interface Modifying Role-Based Access Control Parameters There are different commands for modifying role-based access control parameters.  IPv4 commands Enable or disable the IPv4 role-based access control feature: config:# security roleBasedAccessControl ipv4 enabled <option> Determine the IPv4 role-based access control policy: config:# security roleBasedAccessControl ipv4 defaultPolicy <policy>...
  • Page 586 Chapter 8: Using the Command Line Interface Tip: You can combine both commands to modify all role-based access control parameters at a time. See (on page Multi-Command Syntax 635). Managing Role-Based Access Control Rules You can add, delete or modify role-based access control rules. ...
  • Page 587 Chapter 8: Using the Command Line Interface config:# security roleBasedAccessControl ipv6 rule add <start_ip> <end_ip> <role> <policy> <insert> <rule_number> Variables:  <start_ip> is the starting IP address.  <end_ip> is the ending IP address.  <role> is the role for which you want to create an access control rule.
  • Page 588 Chapter 8: Using the Command Line Interface config:# security roleBasedAccessControl ipv4 rule modify <rule_number> startIpAddress <start_ip> endIpAddress <end_ip> Modify an IPv4 rule's role: config:# security roleBasedAccessControl ipv4 rule modify <rule_number> role <role> Modify an IPv4 rule's policy: config:# security roleBasedAccessControl ipv4 rule modify <rule_number> policy <policy>...
  • Page 589 Chapter 8: Using the Command Line Interface config:# security roleBasedAccessControl ipv6 rule modify <rule_number> startIpAddress <start_ip> endIpAddress <end_ip> role <role> policy <policy> Variables:  <rule_number> is the number of the existing rule that you want to modify.  <start_ip> is the starting IP address. ...
  • Page 590 Chapter 8: Using the Command Line Interface Enabling or Disabling Front Panel Outlet Switching This section applies to outlet-switching capable models only. The following CLI commands control whether you can turn on or off an outlet by operating the front panel display. To enable the front panel outlet control feature: config:# security frontPanelPermissions add switchOutlet...
  • Page 591 Chapter 8: Using the Command Line Interface Example 1 - IPv4 Firewall Control Configuration The following command sets up two parameters of the IPv4 access control feature. config:# security ipAccessControl ipv4 enabled true defaultPolicyIn accept defaultPolicyOut accept Results:  The IPv4 access control feature is enabled. ...

  • Page 592: Outlet Configuration Commands

    Chapter 8: Using the Command Line Interface Example 4 - Adding an IPv4 Role-based Access Control Rule The following command creates a newIPv4 role-based access control rule and specifies its location in the list. config:# security roleBasedAccessControl ipv4 rule add 192.168.78.50 192.168.90.100 admin deny insertAbove 3 Results: ...
  • Page 593 Chapter 8: Using the Command Line Interface Changing an Outlet's Default State This section applies to outlet-switching capable models only. This command determines the initial power condition of an outlet after the PX3TS powers up. config:# outlet <n> stateOnDeviceStartup <option> Variables: ...

  • Page 594: Inlet Configuration Commands

    Chapter 8: Using the Command Line Interface Setting an Outlet's Cycling Power-Off Period This section applies to outlet-switching capable models only. This command determines the power-off period of the power cycling operation for a specific outlet. config:# outlet <n> cyclingPowerOffPeriod <timing> Variables: ...

  • Page 595: Overcurrent Protector Configuration Commands

    The <name> variable must be enclosed in quotes when it contains spaces. Example - Inlet Naming The following command assigns the name "AC source" to the inlet 1. If your PX3TS device contains multiple inlets, this command names the 1st inlet. config:# inlet 1 name "AC source"...

  • Page 596: User Configuration Commands

    This command creates a new user profile. config:# user create <name> <option> <roles> After performing the user creation command, the PX3TS prompts you to assign a password to the newly-created user. Then: 1. Type the password and press Enter. 2. Re-type the same password for confirmation and press Enter.
  • Page 597 Administrator Privileges. config:# user modify <name> password After performing the above command, PX3TS prompts you to enter a new password. Then: 1. Type a new password and press Enter. 2. Re-type the new password for confirmation and press Enter.
  • Page 598 Chapter 8: Using the Command Line Interface Example The following procedure illustrates how to change the password of the user "May." Entering 1. Verify that you have entered the configuration mode. See Configuration Mode (on page 500). 2. Type the following command to change the password for the user profile "May."...
  • Page 599 Chapter 8: Using the Command Line Interface Modifying a User's Personal Data You can change a user's personal data, including the user's full name, telephone number, and email address. Various commands can be combined to modify the parameters of a Multi-Command Syntax specific user profile at a time.
  • Page 600 Chapter 8: Using the Command Line Interface Enabling or Disabling a User Profile This command enables or disables a user profile. A user can log in to the PX3TS device only after that user's user profile is enabled. config:# user modify <name> enabled <option>...
  • Page 601 You can combine all of the following commands to modify the SNMPv3 parameters at a time. See Multi-Command Syntax (on page 635). Enable or disable the SNMP v3 access to PX3TS for the specified user: config:# user modify <name> snmpV3Access <option1>...
  • Page 602 Chapter 8: Using the Command Line Interface config:# user modify <name> userPasswordAsAuthenticationPassphrase <option3> Variables:  <name> is the name of the user whose settings you want to change.  <option3> is one of the options: true false Option Description true Authentication passphrase is identical to the password.
  • Page 603 Chapter 8: Using the Command Line Interface Determine the privacy passphrase: config:# user modify <name> privacyPassPhrase <privacy_passphrase> Variables:  <name> is the name of the user whose settings you want to change.  <privacy_passphrase> is a string used as a privacy passphrase, comprising 8 to 32 ASCII printable characters.
  • Page 604 (on page 635). Note: The measurement unit change only applies to the web interface and command line interface. Tip: To set the default measurement units applied to the PX3TS user interfaces for all users via CLI, see Setting Default Measurement Units (on page 582).
  • Page 605 Chapter 8: Using the Command Line Interface Set the preferred length unit: config:# user modify <name> preferredLengthUnit <option2> Variables:  <name> is the name of the user whose settings you want to change.  <option2> is one of the options: meter feet Option...
  • Page 606 After performing this command, the PX3TS prompts you to enter both current and new passwords respectively. Important: After the password is changed successfully, the new password is effective immediately no matter you type the command "apply"...
  • Page 607 Setting Default Measurement Units Default measurement units, including temperature, length, and pressure units, apply to the PX3TS user interfaces across all users except for those whose preferred measurement units are set differently by themselves or the administrator. Diverse measurement unit commands...
  • Page 608 Chapter 8: Using the Command Line Interface config:# user defaultpreferences preferredLengthUnit <option2> Variables:  meter feet <option2> is one of the options: Option Description meter This option displays the length or height in meters. feet This option displays the length or height in feet. Set the default pressure unit: config:# user defaultpreferences preferredPressureUnit <option3>...
  • Page 609 Chapter 8: Using the Command Line Interface Example 1 - Creating a User Profile The following command creates a new user profile and sets two parameters for the new user. config:# user create May enable admin Results:  A new user profile "May" is created. ...
  • Page 610 All Privileges This table lists all privileges. Note that available privileges vary according to the model you purchased. For example, a PX3TS device without the outlet switching function does not have the privilege "switchOutlet." Privilege...
  • Page 611 Chapter 8: Using the Command Line Interface Privilege Description changeAssetStripConfiguration Change Asset Strip Configuration changeAuthSettings Change Authentication Settings changeDataTimeSettings Change Date/Time Settings changeExternalSensorsConfiguration Change Peripheral Device Configuration changeLhxConfiguration Change LHX/SHX Configuration changeModemConfiguration Change Modem Configuration changeNetworkSettings Change Network Settings changePassword Change Own Password changePduConfiguration Change Pdu, Inlet, Outlet &...
  • Page 612 An actuator's ID number. For example: switchActuator:1 switchActuator:2 switchActuator:3  A list of comma-separated ID numbers of different actuators. For example: switchActuator:1,3,6 Note: The ID number of each actuator is shown in the PX3TS web interface. It is an integer between 1 and 32.
  • Page 613 Chapter 8: Using the Command Line Interface Modifying a Role You can modify diverse parameters of an existing role, including its privileges. Modify a role's description: config:# role modify <name> description "<description>" Variables:  <name> is a string comprising up to 32 ASCII printable characters. ...
  • Page 614 Chapter 8: Using the Command Line Interface config:# role modify <name> addPrivileges <privilege1>:<argument1>,<argument2>...; <privilege2>:<argument1>,<argument2>...; <privilege3>:<argument1>,<argument2>...; Variables:  <name> is a string comprising up to 32 ASCII printable characters.  <privilege1>, <privilege2>, <privilege3> and the like are names of the privileges assigned to the role. Separate each privilege with a semi-colon.

  • Page 615: Authentication Commands

    Chapter 8: Using the Command Line Interface Deleting a Role This command deletes an existing role. config:# role delete <name> Example - Creating a Role The following command creates a new role and assigns privileges to the role. config:# role create tester firmwareUpdate;viewEventSetup Results: ...
  • Page 616 Chapter 8: Using the Command Line Interface config:# authentication type <option1> useLocalIfRemoteUnavailable <option2> Note: You cannot enable or disable the option of switching to local authentication without determining the authentication type in the CLI. Therefore, always type "authentication type <option1>" when setting up "useLocalIfRemoteUnavailable".
  • Page 617 Chapter 8: Using the Command Line Interface Adding an LDAP Server Adding an LDAP server requires the entry of quite a lot of parameters, such as the server's IP address, TCP port number, Base DN and so on. You can repeat the following CLI command to add more than one LDAP server.
  • Page 618 Chapter 8: Using the Command Line Interface Type Description activeDirectory Microsoft Active Directory  <security> is one of the security options: none startTls Type Description none No security startTls StartTLS  anonymouseBind <bind_type> is one of the bind options: , or authenticatedBind Type Description...
  • Page 619 Chapter 8: Using the Command Line Interface config:# authentication ldap add <host> <port> <ldap_type> <security> <bind_type> <base_DN> <login_name_att> <user_entry_class> bindDN <bind_DN> "Optional Parameters" table: Parameters To configure userSearchSubfilter <filter> User search subfilter bindDN <bind_DN> bind DN  The system will prompt you to enter and re-confirm the bind password after adding this parameter to the command.
  • Page 620 The "verifyServerCertificate" parameter is added to the command and set to "true." config:# authentication ldap add ldap.raritan.com 389 openldap startTls ... inetOrgPerson verifyServerCertificate true b. The system now prompts you to enter the certificate's content. c. Type or copy the certificate's content in the CLI and press Enter.
  • Page 621 <host> is the IP address or host name of the LDAP server.  <server_num> is the sequential number of the specified server shown on the server list of the PX3TS. See Authentication Settings (on page 488). Modifying an Existing LDAP Server You can modify one or multiple parameters of an existing LDAP server, such as its IP address, TCP port number, Base DN and so on.
  • Page 622 Chapter 8: Using the Command Line Interface Parameters Description Change the IP address or host name. host <host>  <host> is the new IP address or host name. Change the TCP port number. port <port>  <port> is the new TCP port number. Change the server type.
  • Page 623 Chapter 8: Using the Command Line Interface Parameters Description Re-upload a different certificate. certificate a. First add the "certificate" parameter to the command, and press Enter. b. The system prompts you for the input of the certificate. c. Type or copy the content of the certificate in the CLI and press Enter.
  • Page 624 Chapter 8: Using the Command Line Interface config:# authentication ldap modify 1 host 192.168.3.3 port 633 serverType activeDirectory Removing an Existing LDAP Server This command removes an existing LDAP server from the server list. config:# authentication ldap delete <server_num> Variables: ...
  • Page 625 Chapter 8: Using the Command Line Interface  <auth_port> is the authentication port number.  <acct_port> is the accounting port number.  <timeout> is the timeout value in seconds. It ranges between 1 to 10 seconds.  <retries> is the number of retries. It ranges between 0 to 5. To enter the shared secret: 1.
  • Page 626 Chapter 8: Using the Command Line Interface config:# authentication radius modify <server_num> retries <retries> Change the shared secret: config:# authentication radius modify <server_num> secret Change the priority of the specified server: config:# authentication radius modify <server_num> sortPositon <position> Tip: You can add more than one parameters to the command. For example, "...
  • Page 627  <n> is the ID number of the environmental sensor that you want to configure. The ID number is available in the PX3TS web interface or using the command "show externalsensors <n>" in the CLI. It is an integer between 1 and 32.
  • Page 628  <n> is the ID number of the environmental sensor that you want to configure. The ID number is available in the PX3TS web interface or using the command "show externalsensors <n>" in the CLI. It is an integer between 1 and 32.
  • Page 629  <n> is the ID number of the environmental sensor that you want to configure. The ID number is available in the PX3TS web interface or using the command "show externalsensors <n>" in the CLI. It is an integer between 1 and 32.
  • Page 630  <n> is the ID number of the environmental sensor that you want to configure. The ID number is available in the PX3TS web interface or using the command "show externalsensors <n>" in the CLI. It is an integer between 1 and 32.
  • Page 631  <n> is the ID number of the environmental sensor that you want to configure. The ID number is available in the PX3TS web interface or using the command "show externalsensors <n>" in the CLI. It is an integer between 1 and 32.

  • Page 632: Configuring Environmental Sensors' Default Thresholds

    Chapter 8: Using the Command Line Interface Configuring Environmental Sensors' Default Thresholds You can set the default values of upper and lower thresholds, deassertion hysteresis and assertion timeout on a sensor type basis, including temperature, humidity, air pressure and air flow sensors. The default thresholds automatically apply to all environmental sensors that are newly detected or added.
  • Page 633 Chapter 8: Using the Command Line Interface config:# defaultThresholds <sensor type> assertionTimeout <as_value> Variables:  <sensor type> is one of the following numeric sensor types: Sensor types Description absoluteHumidity Absolute humidity sensors relativeHumidity Relative humidity sensors temperature Temperature sensors airPressure Air pressure sensors airFlow Air flow sensors...

  • Page 634: Sensor Threshold Configuration Commands

    Chapter 8: Using the Command Line Interface Example - Default Upper Thresholds for Temperature It is assumed that your preferred measurement unit for temperature is set to degrees Celsius. Then the following command sets the default Upper Warning threshold to 20 and Upper Critical threshold to 24 for all temperature sensors.
  • Page 635 Chapter 8: Using the Command Line Interface config:# sensor inlet <n> <sensor type> lowerCritical <option> Set the Lower Warning threshold for an inlet sensor: config:# sensor inlet <n> <sensor type> lowerWarning <option> Set the deassertion hysteresis for an inlet sensor: config:# sensor inlet <n>...
  • Page 636 Chapter 8: Using the Command Line Interface  enable disable <option> is one of the options: or a numeric value. Option Description enable Enables the specified threshold for a specific inlet sensor. disable Disables the specified threshold for a specific inlet sensor.
  • Page 637 Chapter 8: Using the Command Line Interface config:# sensor outlet <n> <sensor type> lowerWarning <option> Set the deassertion hysteresis for an outlet sensor: config:# sensor outlet <n> <sensor type> hysteresis <hy_value> Set the assertion timeout for an outlet sensor: config:# sensor outlet <n>...
  • Page 638 Chapter 8: Using the Command Line Interface  <hy_value> is a numeric value that is assigned to the hysteresis for "To De-assert" and Deassertion the specified outlet sensor. See Hysteresis (on page 766).  <as_value> is a number in samples that is assigned to the assertion "To Assert"...
  • Page 639 Chapter 8: Using the Command Line Interface config:# sensor ocp <n> <sensor type> assertionTimeout <as_value> Variables:  <n> is the number of the overcurrent protector that you want to configure.  <sensor type> is one of the following sensor types: Sensor type Description current...
  • Page 640  <n> is the ID number of the environmental sensor that you want to configure. The ID number is available in the PX3TS web interface or using the command "show externalsensors <n>" in the CLI. It is an integer between 1 and 32.
  • Page 641 Chapter 8: Using the Command Line Interface  enable disable <option> is one of the options: or a numeric value. Option Description enable Enables the specified threshold for a specific environmental sensor. disable Disables the specified threshold for a specific environmental sensor.
  • Page 642 Chapter 8: Using the Command Line Interface config:# sensor ts inletPhaseSyncAngle lowerWarning <option> Set the deassertion hysteresis for the inlet phase sync angle: config:# sensor ts inletPhaseSyncAngle hysteresis <hy_value> Set the assertion timeout for the inlet phase sync angle: config:# sensor ts inletPhaseSyncAngle assertionTimeout <as_value>...
  • Page 643 Chapter 8: Using the Command Line Interface config:# sensor inlet 1 current upperWarning 20 lowerWarning 12 Results:  The Upper Warning threshold for the inlet 1 RMS current is set to 20A. It also enables the upper warning threshold if this threshold has not been enabled yet.

  • Page 644: Actuator Configuration Commands

    Variables:  <n> is the ID number assigned to the actuator. The ID number can be found using the PX3TS web interface or CLI. It is an integer starting at 1.  <name> is a string comprising up to 64 ASCII printable characters.

  • Page 645: Server Reachability Configuration Commands

    Chapter 8: Using the Command Line Interface Note: To specify the Z coordinate using the rack units, see Setting the Z Coordinate Format for Environmental Sensors (on page 512).  <description> is a sentence or paragraph comprising up to 64 ASCII printable characters, and it must be enclosed in quotes.
  • Page 646 <fail_wait> is the wait time to send the next ping after a unsuccessful ping. Valid range is 3 to 600 (seconds).  <resume> is the wait time before the PX3TS resumes pinging after declaring the monitored device "Unreachable." Valid range is 5 to 120 (seconds).
  • Page 647 Chapter 8: Using the Command Line Interface config:# serverReachability modify <n> ipAddress <IP_host> Enable or disable the ping monitoring feature for the device: config:# serverReachability modify <n> pingMonitoringEnabled <option> Modify the number of successful pings for declaring "Reachable": config:# serverReachability modify <n> numberOfSuccessfulPingsToEnable <succ_number>...
  • Page 648 <fail_wait> is the wait time to send the next ping after a unsuccessful ping. Valid range is 3 to 600 (seconds).  <resume> is the wait time before the PX3TS resumes pinging after declaring the monitored device "Unreachable." Valid range is 5 to 120 (seconds).

  • Page 649: Energywise Configuration Commands

    An EnergyWise configuration command begins with energywise Enabling or Disabling EnergyWise This command syntax determines whether the Cisco EnergyWise ® endpoint implemented on the PX3TS device is enabled. config:# energywise enabled <option> Variables:  <option> is one of the options:...
  • Page 650  <port> is the UDP port number ranging between 1 and 65535. Setting the Polling Interval This command syntax determines the polling interval at which the Cisco ® EnergyWise domain queries the PX3TS device. config:# energywise polling <timing> Variables: ...

  • Page 651: Asset Management Commands

    Variables:  <n> is the number of the FEATURE port where the selected asset strip is physically connected. For the PX3TS device with only one FEATURE port, the number is always 1.  <name> is a string comprising up to 64 ASCII printable characters.
  • Page 652 Variables:  <n> is the number of the FEATURE port where the selected asset strip is physically connected. For the PX3TS device with only one FEATURE port, the number is always 1.  <number> is the total number of rack units available on the connected asset strip.
  • Page 653 Specifying the Asset Strip Orientation This command syntax specifies the orientation of the asset strips connected to the PX3TS device. Usually you do not need to perform this command unless your asset strips do NOT come with the tilt sensor, causing the PX3TS unable to detect the asset strips' orientation.
  • Page 654 Chapter 8: Using the Command Line Interface Setting LED Colors for Connected Tags This command syntax sets the LED color for all rack units on the asset strip #1 to indicate the presence of a connected asset tag. config:# assetStrip <n> LEDColorForConnectedTags <color> Variables: ...
  • Page 655 Variables:  <n> is the number of the FEATURE port where the selected asset strip is physically connected. For the PX3TS device with only one FEATURE port, the number is always 1.  <rack_unit> is the index number of the desired rack unit. The index number is available on the asset strip or the Asset Strip page of the web interface.
  • Page 656 Variables:  <n> is the number of the FEATURE port where the selected asset strip is physically connected. For the PX3TS device with only one FEATURE port, the number is always 1.  <rack_unit> is the index number of the desired rack unit. The index number is available on the asset strip or the Asset Strip page of the web interface.
  • Page 657 Variables:  <n> is the number of the FEATURE port where the selected asset strip is physically connected. For the PX3TS device with only one FEATURE port, the number is always 1.  <rack_unit> is the index number of the desired rack unit. The index number is available on the asset strip or the Asset Strip page of the web interface.

  • Page 658: Serial Port Configuration Commands

    Raritan's P2CIM-SER, or a modem, through the serial port, or there are communications errors. If you change the baud rate dynamically after the connection has been made, you must reset the PX3TS or power cycle the connected device for proper communications.
  • Page 659 Chapter 8: Using the Command Line Interface Forcing the Device Detection Mode This command forces the serial port on the PX3TS to enter a specific device detection mode. config:# serial deviceDetectionType <mode> Variables:  <mode> is one of the detection modes:...

  • Page 660: Multi-Command Syntax

    Chapter 8: Using the Command Line Interface Multi-Command Syntax To shorten the configuration time, you can combine various configuration commands in one command to perform all of them at a time. All combined commands must belong to the same configuration type, such network user modify sensor externalsensor...

  • Page 661: Load Shedding Configuration Commands

    Chapter 8: Using the Command Line Interface Example 3 - Combination of SSID and PSK Parameters This multi-command syntax configures both SSID and PSK parameters simultaneously for the wireless feature. config:# network wireless SSID myssid PSK encryp_key Results:  The SSID value is set to myssid. ...

  • Page 662: Enabling Or Disabling Load Shedding

    <option> After performing the above command, PX3TS prompts you to confirm the operation. Press y to confirm or n to abort the operation. To skip the confirmation step, you can add the "/y" parameter to the end of the command so that the operation is executed immediately.

  • Page 663: Power Control Operations

    Chapter 8: Using the Command Line Interface Power Control Operations This section applies to outlet-switching capable models only. Outlets on the PX3TS device can be turned on or off or power cycled through the CLI. Besides, you can cancel the power-on process while the PX3TS is powering on ALL outlets.

  • Page 664: Turning Off The Outlet(S)

    Chapter 8: Using the Command Line Interface If you entered the command without "/y", a message appears, prompting you to confirm the operation. Then:  Type y to confirm the operation, OR  Type n to abort the operation Turning Off the Outlet(s) This section applies to outlet-switching capable models only.

  • Page 665: Power Cycling The Outlet(S)

    Chapter 8: Using the Command Line Interface If you entered the command without "/y", a message appears, prompting you to confirm the operation. Then:  Type y to confirm the operation, OR  Type n to abort the operation Power Cycling the Outlet(s) This section applies to outlet-switching capable models only.

  • Page 666: Canceling The Power-On Process

    Chapter 8: Using the Command Line Interface If you entered the command without "/y", a message appears, prompting you to confirm the operation. Then:  Type y to confirm the operation, OR  Type n to abort the operation Canceling the Power-On Process This section applies to outlet-switching capable models only.

  • Page 667: Switching On An Actuator

     <n> is an actuator's ID number. The ID number is available in the PX3TS web interface or using the show command in the CLI. It is an integer between 1 and 32. If you entered the command without "/y", a message appears, prompting you to confirm the operation.

  • Page 668: Example - Turning On A Specific Actuator

    The following command turns on the actuator whose ID number is 8. control actuator 8 on Unblocking a User If any user is blocked from accessing the PX3TS, you can unblock them at the local console. To unblock a user: 1.

  • Page 669: Restarting The Pdu

    Chapter 8: Using the Command Line Interface Restarting the PDU This command restarts the PX3TS device. It is not a factory default reset. To restart the PX3TS device: 1. Ensure you have entered administrator mode and the # prompt is displayed.

  • Page 670: Resetting To Factory Defaults

    Note: The outlet active energy reset feature is only available for models with outlet switching. Resetting to Factory Defaults The following commands restore all settings of the PX3TS device to factory defaults. To reset PX3TS settings after login, use either command:...

  • Page 671: Quitting Diagnostic Mode

    Chapter 8: Using the Command Line Interface 2. Type diag and press Enter. The diag# or diag> prompt appears, indicating that you have entered the diagnostic mode. 3. Now you can type any diagnostic commands for troubleshooting. Quitting Diagnostic Mode To quit the diagnostic mode, use this command: diag>...
  • Page 672 Chapter 8: Using the Command Line Interface Option Description connections Shows network connections. Testing the Network Connectivity This ping command sends the ICMP ECHO_REQUEST message to a network host for checking its network connectivity. If the output shows the host is responding properly, the network connectivity is good. If not, either the host is shut down or it is not being properly connected to the network.

  • Page 673: Retrieving Previous Commands

    Chapter 8: Using the Command Line Interface Tracing the Route This command syntax traces the network route between your PX3TS device and a network host. diag> traceroute <host> Variables:  <host> is the name or IP address of the host you want to trace.

  • Page 674: Logging Out Of Cli

    Chapter 8: Using the Command Line Interface Examples:  Example 1 (only one possible command): a. Type the first word and the first letter of the second word of the "reset factorydefaults" command -- that is, reset f. b. Then press Tab or Ctrl+i to complete the second word. ...

  • Page 675: Chapter 9 Using Scp Commands

    Chapter 9 Using SCP Commands You can perform a Secure Copy (SCP) command to update the PX3TS firmware, do bulk configuration, or back up and restore the configuration. In This Chapter Firmware Update via SCP ............... 650 Bulk Configuration via SCP ..............651 Backup and Restore via SCP..............
  • Page 676 IP address of the PX3TS whose configuration you want to save. 2. Type the user password when prompted. 3. The system saves the configuration from the PX3TS to a file named "bulk_config.txt." To copy the configuration via SCP: 1.

  • Page 677: Backup And Restore Via Scp

     <device ip> is the IP address of the PX3TS whose settings you want to back up. 2. Type the user password when prompted. 3. The system saves the settings from the PX3TS to a file named "backup_settings.txt."...

  • Page 678: Downloading Diagnostic Data Via Scp

    "admin" or any user profile with the administrator privileges.  <device ip> is the IP address of the PX3TS whose settings you want to restore. 2. Type the user password when prompted. 3. The system copies the configuration included in the file "backup_settings.txt"...
  • Page 679 Scenario 1: Use the default SCP port and default filename  SSH/SCP port is the default (22), and the accessed PX3TS is a standalone device.  The diagnostic file's default filename "diag-data.zip" is wanted. Then add a dot (.) in the end of the SCP command as shown below.
  • Page 680 Chapter 9: Using SCP Commands  If you do NOT specify a new filename in the command, such as Scenario 1 or 2, the downloaded file's default name is "diag-data.zip."  If you specify a new filename in the command, such as Scenario 3 or 4, the downloaded file is renamed accordingly.

  • Page 681: Technical Specifications

    Appendix A Specifications In This Chapter Technical Specifications................656 Serial RS-232 "DB9" Port Pinouts ............658 Serial RS-232 "RJ-45" Port Pinouts (for iX7™ Only)....... 659 Sensor RJ-45 Port Pinouts..............659 Feature RJ-45 Port Pinouts ..............660 Expansion RJ-45 Port Pinouts (for iX7™ Only) ........660 Technical Specifications...
  • Page 682 Appendix A: Specifications See the label or nameplate on your PX3TS Rated voltage and current model 50/60Hz +/- 5Hz Rated frequency 0.60 to 1.00 (leading or lagging) Load power factor Rated current up to crest factor 3.5 Non-linear load 4-8 milliseconds...

  • Page 683: Serial Rs-232 "Db9" Port Pinouts

     24A or 32A models: Bussmann FWP-50A14F (50A/660V) Raritan part number: 557-90-0038-00 You can also find the appropriate fuse types by checking the model names shown on the Raritan-provided fuses accompanying your PX3TS models. Serial RS-232 "DB9" Port Pinouts RS-232 Pin/signal definition Pin No.

  • Page 684: Serial Rs-232 "Rj-45" Port Pinouts (For Ix7™ Only)

    Appendix A: Specifications RS-232 Pin/signal definition Input Ring indicator Serial RS-232 "RJ-45" Port Pinouts (for iX7™ Only) RJ-45 Pin/signal definition Pin No. Signal Direction Description Output Request to send Output Data terminal ready Output Transmit data ― Signal ground Input Data Input Receive data (data in)

  • Page 685: Feature Rj-45 Port Pinouts

    Raritan devices. Output Transmit Data (Data out) Input Receive Data (Data in) +12V ― Warning: Pin 6 is only intended for use with Raritan devices. Do NOT connect. ― Signal Ground Input Reserved Expansion RJ-45 Port Pinouts (for iX7™ Only)
  • Page 686 Appendix A: Specifications RJ-45 Pin/signal definition Pin No. Signal Direction Description +12V ― Power (fuse protected) +12V ― Power (fuse protected) ― Signal Ground RS485_DP bi-directional Data Positive of the RS-485 bus RS485_DN bi-directional Data Negative of the RS-485 bus ―...

  • Page 687: Appendix B Equipment Setup Worksheet

    Appendix B Equipment Setup Worksheet PX3TS Series Model ____________ PX3TS Series Serial Number ____________ OUTLET 1 OUTLET 2 OUTLET 3 MODEL MODEL MODEL SERIAL NUMBER SERIAL NUMBER SERIAL NUMBER OUTLET 4 OUTLET 5 OUTLET 6 MODEL MODEL MODEL SERIAL NUMBER...
  • Page 688 Appendix B: Equipment Setup Worksheet OUTLET 7 OUTLET 8 OUTLET 9 MODEL MODEL MODEL SERIAL NUMBER SERIAL NUMBER SERIAL NUMBER OUTLET 10 OUTLET 11 OUTLET 12 MODEL MODEL MODEL SERIAL NUMBER SERIAL NUMBER SERIAL NUMBER OUTLET 13 OUTLET 14 OUTLET 15 MODEL MODEL MODEL...
  • Page 689 Appendix B: Equipment Setup Worksheet OUTLET 16 OUTLET 17 OUTLET 18 MODEL MODEL MODEL SERIAL NUMBER SERIAL NUMBER SERIAL NUMBER OUTLET 19 OUTLET 20 OUTLET 21 MODEL MODEL MODEL SERIAL NUMBER SERIAL NUMBER SERIAL NUMBER...
  • Page 690 Appendix B: Equipment Setup Worksheet OUTLET 22 OUTLET 23 OUTLET 24 MODEL MODEL MODEL SERIAL NUMBER SERIAL NUMBER SERIAL NUMBER Types of adapters _________________________________________________________ Types of cables _________________________________________________________ Name of software program _________________________________________________________...

  • Page 691: System And Usb Requirements

    PX3TS system requirements:  There is at least one USB-A port available on your Raritan device.  Your PX3TS must be version 2.2.13 or later. Note that the PX3TS interpreted the USB drive's contents using the firmware which was running when plugging the USB drive, not the new firmware after firmware upgrade.

  • Page 692: Fwupdate.cfg

    This file is required only when there are device-specific settings to devices.csv configure for multiple PX3TS devices. See (on page 674). Raritan provides a Mass Deployment Utility, which helps you to quickly Creating generate all configuration files for your PX3TS. See Configuration Files via Mass Deployment Utility...
  • Page 693 For a PX3TS with factory default configuration, set this option to raritan. logfile  Specify the name of a text file where the PX3TS will append the log messages when interpreting the USB drive contents.  If the specified file does not exist in the USB drive, it will be automatically created.

  • Page 694: Config.txt

    This option is used only if the "device_list" option has been set. collect_diag  If this option is set to true, the diagnostic data of the PX3TS is transmitted to the USB drive.  The filename of the diagnostic data written into the USB drive varies, depending on the PX3TS firmware version: ...
  • Page 695 The PX3TS beeps after it finishes writing the diagnostic data to the USB drive. factory_reset  If this option is set to true, the PX3TS will be reset to factory defaults.  If the device configuration will be updated at the same time, the factory reset will be executed before updating the device configuration.
  • Page 696  Specify the filename of the wanted TLS server certificate. The filename can contain a single placeholder ${SERIAL} that is replaced with the serial number of the PX3TS.  This option should be used with tls_key_file listed below. ...
  • Page 697 PX3TS model. You can use Raritan's Mass Deployment Utility to create this file by yourself, or contact Raritan to get a device configuration file specific to your PX3TS model and firmware version.

  • Page 698: Devices.csv

    Appendix C: Configuration or Firmware Upgrade with a USB Drive Special configuration keys: There are 3 special configuration keys that are prefixed with magic:.  A special key that sets a user account's password without knowing the firmware's internal encryption/hashing algorithms is implemented as of release 2.2.13.
  • Page 699 MAC address to one of the columns in the file. Determine the column to identify PX3TS devices:  By default, a PX3TS searches for its serial number in the 1st column.  match To override the default, set the option in the "fwupdate.cfg"...

  • Page 700: Creating Configuration Files Via Mass Deployment Utility

    After entering required information, you can generate all configuration fwupdate.cfg config.txt files with only one click, including devices.csv To use the Mass Deployment Utility: 1. Download the Mass Deployment Utility from the Raritan website.  mass_deployment-xxx The utility is named (where xxx is the firmware version number).

  • Page 701: Data Encryption In 'Config.txt

    If an appropriate "config.txt" is not created yet, see Configuration Files via Mass Deployment Utility (on page 675). 2. Launch a terminal to log in to the CLI of any PX3TS running version Logging in to CLI 3.2.20 or later. See (on page 462).

  • Page 702: Firmware Upgrade Via Usb

    Support page http://www.raritan.com/support/ Note that if the firmware file used for firmware upgrade is the same as the firmware version running on the PX3TS, no firmware upgrade will be force_update performed unless you have set the option to true in the fwupdate.cfg...
  • Page 703 4. The PX3TS performs the firmware upgrade. The firmware upgrade message "FUP" is displayed on the front panel display. Tip: You can remove the USB drive and plug it into another PX3TS for firmware upgrade when the firmware upgrade message displays.

  • Page 704: Bulk Configuration/Upgrade Procedure

    Bulk Configuration/Upgrade Procedure The DHCP/TFTP feature is supported as of release 3.1.0 so make sure that all PX3TS devices which you want to configure or upgrade are running firmware version 3.1.0 or later. Steps of using DHCP/TFTP for bulk configuration/upgrade: 1.

  • Page 705: Tftp Requirements

    DHCP IPv4 Configuration in Linux (on page 698)  DHCP IPv6 Configuration in Linux (on page 700) 5. Make sure all of the desired PX3TS devices use DHCP as the IP directly configuration method and have been connected to the network.
  • Page 706 See (on page 679). If you are going to upload any PX3TS diagnostic file or create a log file in the TFTP server, the first of the following requirements is also required.  The TFTP server supports the write operation, including file creation and upload.
  • Page 707 Appendix D: Bulk Configuration or Firmware Upgrade via DHCP/TFTP The vendor class is named "Raritan PDU" in this illustration. 2. Define one DHCP standard option - Vendor Class Identifier. a. Right-click the IPv4 node in DHCP to select Set Predefined...
  • Page 708 Appendix D: Bulk Configuration or Firmware Upgrade via DHCP/TFTP b. Select DHCP Standard Options in the "Option class" field, and Vendor Class Identifier in the "Option name" field. Leave the String field blank. 3. Add three options to the new vendor class "Raritan PDU" in the same dialog.
  • Page 709 Appendix D: Bulk Configuration or Firmware Upgrade via DHCP/TFTP a. Select Raritan PDU in the "Option class" field. b. Click Add to add the first option. Type "pdu-tftp-server" in the Name field, select IP Address as the data type, and type 1 in the...
  • Page 710 Name field, select String as the data type, and type 3 in the Code field. 4. Create a new policy associated with the "Raritan PDU" vendor class. a. Right-click the Policies node under IPv4 to select New Policy. b. Specify a policy name, and click Next.
  • Page 711 Appendix D: Bulk Configuration or Firmware Upgrade via DHCP/TFTP The policy is named "PDU" in this illustration. c. Click Add to add a new condition.
  • Page 712 Appendix D: Bulk Configuration or Firmware Upgrade via DHCP/TFTP d. Select the vendor class "Raritan PDU" in the Value field, click Add and then Ok. e. Click Next.
  • Page 713 Appendix D: Bulk Configuration or Firmware Upgrade via DHCP/TFTP Select DHCP Standard Options in the "Vendor class" field, select "060 Vendor Class Identifier" from the Available Options list, and type "Raritan PDU 1.0" in the "String value" field.
  • Page 714 Appendix D: Bulk Configuration or Firmware Upgrade via DHCP/TFTP g. Select the "Raritan PDU" in the "Vendor class" field, select "001 pdu-tftp-server" from the Available Options list, and type your TFTP server's IPv4 address in the "IP address" field.
  • Page 715 Appendix D: Bulk Configuration or Firmware Upgrade via DHCP/TFTP h. Select "002 pdu-update-control-file" from the Available Options list, and type the filename "fwupdate.cfg" in the "String value" field. Select "003 pdu-update-magic" from the Available Options list, and type any string in the "String value" field. This third option/code is the magic cookie to prevent the fwupdate.cfg commands from being executed repeatedly.

  • Page 716: Dhcp Ipv6 Configuration In Windows

    Appendix D: Bulk Configuration or Firmware Upgrade via DHCP/TFTP Important: The magic cookie is transmitted to and stored in PX3TS at the time of executing the "fwupdate.cfg" commands. The DHCP/TFTP operation is triggered only when there is a mismatch between the magic cookie in DHCP and the one stored in PX3TS.
  • Page 717 Click Add to add a new vendor class. c. Specify a unique name for the vendor class, type "13742" in the "Vendor ID (IANA)" field, and type the binary codes of "Raritan PDU 1.0" in the New Class dialog.
  • Page 718 Appendix D: Bulk Configuration or Firmware Upgrade via DHCP/TFTP 2. Add three options to the "Raritan PDU 1.0" vendor class. a. Right-click the IPv6 node in DHCP to select Set Predefined Options.
  • Page 719 Appendix D: Bulk Configuration or Firmware Upgrade via DHCP/TFTP b. Select Raritan PDU 1.0 in the "Option class" field. c. Click Add to add the first option. Type "pdu-tftp-server" in the Name field, select IP Address as the data type, and type 1 in the...
  • Page 720 Click Add to add the third one. Type "pdu-update-magic" in the Name field, select String as the data type, and type 3 in the Code field. 3. Configure server options associated with the "Raritan PDU 1.0" vendor class. a. Right-click the Server Options node under IPv6 to select Configure Options.
  • Page 721 Appendix D: Bulk Configuration or Firmware Upgrade via DHCP/TFTP c. Select "Raritan PDU 1.0" in the "Vendor class" field, select "00001 pdu-tftp-server" from the Available Options list, and type your TFTP server's IPv6 address in the "IPv6 address" field.
  • Page 722 Appendix D: Bulk Configuration or Firmware Upgrade via DHCP/TFTP d. Select "00002 pdu-update-control-file" from the Available Options list, and type the filename "fwupdate.cfg" in the "String value" field. e. Select "00003 pdu-update-magic" from the Available Options list, and type any string in the "String value" field. This third fwupdate.cfg option/code is the magic cookie to prevent the commands from being executed repeatedly.

  • Page 723: Dhcp Ipv4 Configuration In Linux

    Appendix D: Bulk Configuration or Firmware Upgrade via DHCP/TFTP Important: The magic cookie is transmitted to and stored in PX3TS at the time of executing the "fwupdate.cfg" commands. The DHCP/TFTP operation is triggered only when there is a mismatch between the magic cookie in DHCP and the one stored in PX3TS.
  • Page 724 In the following illustration diagram, it is a combination of a date and a serial number. Important: The magic cookie is transmitted to and stored in PX3TS at the time of executing the "fwupdate.cfg" commands. The DHCP/TFTP operation is triggered only when there is a mismatch between the magic cookie in DHCP and the one stored in PX3TS.

  • Page 725: Dhcp Ipv6 Configuration In Linux

    Linux. Required Linux IPv6 settings in DHCP: 1. Locate and open the "dhcpd6.conf" file of the DHCP server. 2. The PX3TS will provide the following values to the "vendor-class" option (option 16). Configure related settings in DHCP accordingly. ...
  • Page 726 In the following illustration diagram, it is a combination of a date and a serial number. Important: The magic cookie is transmitted to and stored in PX3TS at the time of executing the "fwupdate.cfg" commands. The DHCP/TFTP operation is triggered only when there is a mismatch between the magic cookie in DHCP and the one stored in PX3TS.

  • Page 727: Appendix E Resetting To Factory Defaults

    Computer (on page 24). 2. Launch a terminal emulation program such as HyperTerminal, Kermit, or PuTTY, and open a window on the PX3TS. For information on the serial port configuration, see Step 2 of Initial Network Configuration via CLI (on page 777).
  • Page 728 To reset to factory defaults without logging in to the CLI: The PX3TS provides an easier way to reset the product to factory defaults in the CLI prior to login. 1. Connect to the PX3TS and launch a terminal emulation program as described in the above procedure.
  • Page 729 Appendix E: Resetting to Factory Defaults Username: factorydefaults 3. Type y on a confirmation message to perform the reset.

  • Page 730: Appendix F Ldap Configuration Illustration

    Step A. Determine User Accounts and Roles Determine the user accounts and roles (groups) that are authenticated for accessing the PX3TS. In this example, we will create two user roles with different permissions. Each role (group) will consist of two user accounts available on the AD server.
  • Page 731 Appendix F: LDAP Configuration Illustration Step B. Configure User Groups on the AD Server You must create the groups (roles) for the PX3TS on the AD server, and then make appropriate users members of these groups. In this illustration, we assume: ...

  • Page 732: Step C. Configure Ldap Authentication On The Px3Ts Device

    Appendix F: LDAP Configuration Illustration Step C. Configure LDAP Authentication on the PX3TS Device You must enable and set up LDAP authentication properly on the PX3TS device to use external authentication. In the illustration, we assume:  Wired The DNS server settings have been configured properly. See...

  • Page 733: Step D. Configure Roles On The Px3Ts Device

    5. In the Authentication Type field, select LDAP. 6. Click Save. The LDAP authentication is activated. Note: If the PX3TS clock and the LDAP server clock are out of sync, the installed TLS certificates, if any, may be considered expired. To ensure proper synchronization, administrators should configure the PX3TS and the LDAP server to use the same NTP server(s).
  • Page 734 Appendix F: LDAP Configuration Illustration 2. Click to add a new role. a. Type PX_User in the Role Name field. b. Type a description for the PX_User role in the Description field. In this example, we type "View PX settings" to describe the role. c.
  • Page 735 In this example, we type "Includes all PX privileges" to describe the role. c. In the Privileges list, select Administrator Privileges. The Administrator Privileges allows users to configure or change all PX3TS settings. d. Click Save. The PX_Admin role is created.

  • Page 736: Appendix G Updating The Ldap Schema

    From LDAP/LDAPS When an LDAP/LDAPS authentication is successful, the PX3TS determines the permissions for a given user based on the permissions of the user's role. Your remote LDAP server can provide these user role...
  • Page 737 Appendix G: Updating the LDAP Schema Setting the Registry to Permit Write Operations to the Schema To allow a domain controller to write to the schema, you must set a registry entry that permits schema updates. To permit write operations to the schema: 1.

  • Page 738: Adding Attributes To The Class

    Appendix G: Updating the LDAP Schema 3. Click New and then choose Attribute. When the warning message appears, click Continue and the Create New Attribute dialog appears. 4. Type rciusergroup in the Common Name field. rciusergroup 5. Type in the LDAP Display Name field. 6.
  • Page 739 Appendix G: Updating the LDAP Schema 2. Scroll to the user class in the right pane and right-click it. 3. Choose Properties from the menu. The user Properties dialog appears. 4. Click the Attributes tab to open it. 5. Click Add.

  • Page 740: Updating The Schema Cache

    Appendix G: Updating the LDAP Schema 6. Choose rciusergroup from the Select Schema Object list. 7. Click OK in the Select Schema Object dialog. 8. Click OK in the User Properties dialog. Updating the Schema Cache To update the schema cache: 1.
  • Page 741 Appendix G: Updating the LDAP Schema 3. Go to the directory where the support tools were installed. Run adsiedit.msc. The ADSI Edit window opens. 4. Open the Domain. 5. In the left pane of the window, select the CN=Users folder.
  • Page 742 7. Click the Attribute Editor tab if it is not already open. Choose rciusergroup from the Attributes list. 8. Click Edit. The String Attribute Editor dialog appears. 9. Type the user role (created in the PX3TS) in the Edit Attribute field. Click OK.

  • Page 743: Appendix H Radius Configuration Illustration

    Servers (on page 318). 2. Configure roles on the PX3TS. See Creating Roles (on page 262). 3. Configure PX3TS user credentials and roles on your RADIUS server.  To configure using standard attributes, see Standard Attributes (on page 718). ...
  • Page 744 (on page 750). Step A: Add Your PX3TS as a RADIUS Client The RADIUS implementation on a PX3TS follows the standard RADIUS Internet Engineering Task Force (IETF) specification so you must select "RADIUS Standard" as its vendor name when configuring the NPS server.
  • Page 745 2. Right-click NPS (Local), and select Properties. Verify the authentication and accounting port numbers shown in the properties dialog are the same as those specified on your PX3TS. In this example, they are 1812 and 1813. Then close this dialog.
  • Page 746 New RADIUS Client. The New RADIUS Client dialog appears. 4. Do the following to add your PX3TS to NPS: a. Verify the "Enable this RADIUS client" checkbox is selected. b. Type a name for identifying your PX3TS in the "Friendly name" field. c. Type 192.168.56.29...
  • Page 747 Appendix H: RADIUS Configuration Illustration Type the shared secret in the "Shared secret" and "Confirm shared secret" fields. The shared secret must be the same as the one specified on your PX3TS. 5. Click OK.
  • Page 748 Appendix H: RADIUS Configuration Illustration Step B: Configure Connection Policies and Standard Attributes You need to configure the following for connection request policies:  IP address or host name of the PX3TS  Connection request forwarding method  Authentication method(s) ...
  • Page 749 Appendix H: RADIUS Configuration Illustration 2. Right-click Connection Request Policies and select New. The New Connection Request Policy dialog appears. 3. Type a descriptive name for identifying this policy in the "Policy name" field.
  • Page 750 Appendix H: RADIUS Configuration Illustration  You can leave the "Type of network access server" field to the default -- Unspecified.
  • Page 751 Appendix H: RADIUS Configuration Illustration 4. Click Next to show the "Specify Conditions" screen. Click Add. 5. The "Select condition" dialog appears. Click Add.
  • Page 752 Appendix H: RADIUS Configuration Illustration 6. The NAS IPv4 Address dialog appears. Type the PX3TS IP address -- 192.168.56.29 , and click OK. 7. Click Next in the New Connection Request Policy dialog. 8. Select "Authenticate requests on this server" because a local NPS...
  • Page 753 Note: Connection Request Forwarding options must match your environment. 9. When the system prompts you to select the authentication method, select the following two options:  Override network policy authentication settings  CHAP -- the PX3TS uses "CHAP" in this example...
  • Page 754 Appendix H: RADIUS Configuration Illustration Note: If your PX3TS uses PAP, then select "PAP."...
  • Page 755 Appendix H: RADIUS Configuration Illustration 10. Select Standard to the left of the dialog and then click Add.
  • Page 756 Appendix H: RADIUS Configuration Illustration 11. Select Filter-Id from the list of attributes and click Add.
  • Page 757 Appendix H: RADIUS Configuration Illustration 12. In the Attribute Information dialog, click Add. Raritan:G{Admin} 13. Select String, type in the text box, and then click...
  • Page 758 Appendix H: RADIUS Configuration Illustration Admin inside the curved brackets {} is the existing role on the PX3TS. It is recommended to use the Admin role to test this configuration. The role name is case sensitive.
  • Page 759 Appendix H: RADIUS Configuration Illustration 14. The new attribute is added. Click OK.
  • Page 760 Appendix H: RADIUS Configuration Illustration 15. Click Next to continue.
  • Page 761 Appendix H: RADIUS Configuration Illustration 16. A summary showing connection request policy settings is displayed. Click Finish to close the dialog. FreeRADIUS Standard Attribute Illustration With standard attributes, NO dictionary files are required. You simply add all user data, including user names, passwords, and roles, in the following FreeRADIUS path.

  • Page 762: Vendor-Specific Attributes

    To configure Windows 2008 NPS with the vendor-specific attribute , you must: Step A: Add Your PX3TS as a RADIUS a. Add your PX3TS to NPS. See Client (on page 719). b. On the NPS, configure connection request policies and the vendor-specific attribute.
  • Page 763 Appendix H: RADIUS Configuration Illustration Step A: Add Your PX3TS as a RADIUS Client The RADIUS implementation on a PX3TS follows the standard RADIUS Internet Engineering Task Force (IETF) specification so you must select "RADIUS Standard" as its vendor name when configuring the NPS server.
  • Page 764 2. Right-click NPS (Local), and select Properties. Verify the authentication and accounting port numbers shown in the properties dialog are the same as those specified on your PX3TS. In this example, they are 1812 and 1813. Then close this dialog.
  • Page 765 New RADIUS Client. The New RADIUS Client dialog appears. 4. Do the following to add your PX3TS to NPS: a. Verify the "Enable this RADIUS client" checkbox is selected. b. Type a name for identifying your PX3TS in the "Friendly name" field. c. Type 192.168.56.29...
  • Page 766 Appendix H: RADIUS Configuration Illustration Type the shared secret in the "Shared secret" and "Confirm shared secret" fields. The shared secret must be the same as the one specified on your PX3TS. 5. Click OK.
  • Page 767 IP address of your PX3TS = 192.168.56.29  Local NPS server is used  RADIUS protocol selected on your PX3TS = CHAP  Existing roles of your PX3TS = Admin, User and SystemTester Illustration: 1. Open the NPS console, and expand the Policies folder.
  • Page 768 Appendix H: RADIUS Configuration Illustration 2. Right-click Connection Request Policies and select New. The New Connection Request Policy dialog appears. 3. Type a descriptive name for identifying this policy in the "Policy name" field.
  • Page 769 Appendix H: RADIUS Configuration Illustration  You can leave the "Type of network access server" field to the default -- Unspecified.
  • Page 770 Appendix H: RADIUS Configuration Illustration 4. Click Next to show the "Specify Conditions" screen. Click Add. 5. The "Select condition" dialog appears. Click Add.
  • Page 771 Appendix H: RADIUS Configuration Illustration 6. The NAS IPv4 Address dialog appears. Type the PX3TS IP address -- 192.168.56.29 , and click OK. 7. Click Next in the New Connection Request Policy dialog. 8. Select "Authenticate requests on this server" because a local NPS...
  • Page 772 Note: Connection Request Forwarding options must match your environment. 9. When the system prompts you to select the authentication method, select the following two options:  Override network policy authentication settings  CHAP -- the PX3TS uses "CHAP" in this example...
  • Page 773 Appendix H: RADIUS Configuration Illustration Note: If your PX3TS uses PAP, then select "PAP." 10. Select Vendor Specific to the left of the dialog, and click Add. The Add Vendor Specific Attribute dialog appears. 11. Select Custom in the Vendor field, and click Add. The Attribute Information dialog appears.
  • Page 774 A vendor-specific dictionary file is required for the vendor-specific-attribute configuration on FreeRADIUS. Therefore, there are two major configuration steps. a. Use a dictionary to define the Raritan vendor-specific attribute b. Add all user data, including user names, passwords, and roles Presumptions in the illustration: ...

  • Page 775: Ad-Related Configuration

    2. Add the data of the user "steve" by typing the following. Note that the values after the equal sign (=) must be enclosed in double quotes ("). steve Cleartext-Password := "test123" Raritan-PDU-User-Roles = "Raritan:G{Admin User SystemTester}" AD-Related Configuration When RADIUS authentication is intended, make sure you also configure the following settings related to Microsoft Active Directory (AD): ...
  • Page 776 Appendix H: RADIUS Configuration Illustration 2. Right-click NPS (Local) and select "Register server in Active Directory." 3. Click OK, and then OK again. To grant PX3TS users remote access permission: 1. Open Active Directory Users and Computers.
  • Page 777 Appendix H: RADIUS Configuration Illustration 2. Open the properties dialog of the user whom you want to grant the access permission. 3. Click the Dial-in tab and select the "Allow access" checkbox. To enable reversible encryption for CHAP authentication: 1. Open Active Directory Users and Computers. 2.
  • Page 778 Appendix H: RADIUS Configuration Illustration 3. Click the Account tab and select the "Store password using reversible encryption" checkbox.

  • Page 779: Securelock™ Outlets And Cords

    SecureLock™ Outlets and Cords SecureLock is an innovative mechanism designed by Raritan, which ™ securely holds C14 or C20 plugs that are plugged into Raritan PDUs in place. This method requires the following two components:  Raritan PDU with SecureLock outlets, which have a latch slot inside ™...
  • Page 780 Appendix I: Additional PX3TS Information Only specific PDUs are implemented with the SecureLock mechanism. ™ If your PDU does not have this design, do NOT use the SecureLock cords ™ with it. Tip: The SecureLock outlets can accept regular power cords for power ™...

  • Page 781: Rj45-To-Db9 Cable Requirements For Modem Connections (For Ix7™ Only)

    Appendix I: Additional PX3TS Information RJ45-to-DB9 Cable Requirements for Modem Connections (for iX7™ Only) An RJ45-to-DB9 adapter/cable is required for connecting a modem to an PDU. ™ A third party RJ45-to-DB9 adapter/cable needs to meet the following requirements.  RJ-45 to "DB9 male"...

  • Page 782: Reserving Ip Addresses In Dhcp Servers

    The PX3TS uses its serial number as the client identifier in the DHCP request. Therefore, to successfully reserve an IP address for the PX3TS in a DHCP server, use the PX3TS device's serial number as the unique ID instead of the MAC address.

  • Page 783: Reserving Ip In Windows

    For each interface's client identifier, see DHCP Servers (on page 757). In the following illustration, it is assumed that the PX3TS serial number is PEG1A00003. Windows IP address reservation illustration: 1. Convert the client identifier of the desired network interface into...

  • Page 784: Reserving Ip In Linux

    For each interface's client identifier, see DHCP Servers (on page 757). In the following illustrations, it is assumed that the PX3TS serial number is PEG1A00003, and the IP address you want to reserve is 192.168.20.1. Illustration with ASCII code conversion: 1.
  • Page 785 Appendix I: Additional PX3TS Information Interface Client identifier conversion ETH2 PEG1A00003-ETH2 = 50 45 47 31 41 30 30 30 30 33 2D 45 54 48 32 (PX3TS-iX7)  The suffix comprising the dash symbol and the word "ETH2" is also converted.

  • Page 786: Sensor Threshold Settings

    Appendix I: Additional PX3TS Information Sensor Threshold Settings This section explains the thresholds settings for a numeric sensor. Thresholds and Sensor States A numeric sensor has four thresholds: Lower Critical, Lower Warning, Upper Warning and Upper Critical. The threshold settings determine how many sensor states are available for a certain sensor and the range of each sensor state.
  • Page 787 Appendix I: Additional PX3TS Information above upper critical Upper Critical above upper warning Upper Warning normal Lower Warning below lower warning Lower Critical below lower critical Available sensor states:...
  • Page 788 Appendix I: Additional PX3TS Information The more thresholds are enabled for a sensor, the more sensor states are available for it. The "normal' state is always available regardless of whether any threshold is enabled. For example:  When a sensor only has the Upper Critical threshold enabled, it has two sensor states: normal and above upper critical.

  • Page 789: To Assert" And Assertion Timeout

    Appendix I: Additional PX3TS Information "To Assert" and Assertion Timeout If multiple sensor states are available for a specific sensor, the PX3TS asserts a state for it whenever a bad state change occurs. To assert a state: To assert a state is to announce a new, "worse" state.
  • Page 790 3 seconds. How "Assertion Timeout" is helpful: If you have created an event rule that instructs the PX3TS to send notifications for assertion events, setting the "Assertion Timeout" is helpful for eliminating a number of notifications that you may receive in case the sensor's readings fluctuate around a certain threshold.

  • Page 791: To De-Assert" And Deassertion Hysteresis

    Appendix I: Additional PX3TS Information "To De-assert" and Deassertion Hysteresis After the PX3TS asserts a worse state for a sensor, it may de-assert that state later on if the readings improve. To de-assert a state: To de-assert a state is to announce the end of the previously-asserted worse state.
  • Page 792 Appendix I: Additional PX3TS Information...
  • Page 793 Deassertion Hysteresis to 0 (zero). How "Deassertion Hysteresis" is helpful: If you have created an event rule that instructs the PX3TS to send notifications for deassertion events, setting the "Deassertion Hysteresis" is helpful for eliminating a number of notifications that you may receive in case a sensor's readings fluctuate around a certain threshold.

  • Page 794: Default Voltage And Current Thresholds

    If the temperature falls between 20 and 17 degrees Celsius, the PX3TS does NOT perform the "deassertion" action.  If the temperature drops to 17 degrees Celsius or lower, the PX3TS performs the "deassertion" action to announce the end of the "above upper warning" state.
  • Page 795 Appendix I: Additional PX3TS Information Threshold Default value Hysteresis Multi-phase inlets or outlets:  Line-Line RMS voltage: Threshold Default value Lower critical -6% of minimum rating Lower warning -3% of minimum rating Upper warning +3% of maximum rating Upper critical...

  • Page 796: Altitude Correction Factors

    15mA Altitude Correction Factors If a Raritan differential air pressure sensor is attached to your device, the altitude you enter for the device can serve as an altitude correction factor. That is, the reading of the differential air pressure sensor will be multiplied by the correction factor to get a correct reading.

  • Page 797: Ways To Probe Existing User Profiles

    As Internet communications are carried out on the basis of IP addresses, appropriate DNS server settings are required for mapping domain names (host names) to corresponding IP addresses, or the PX3TS may fail to connect to the given host. Therefore, DNS server settings are important for external authentication.

  • Page 798: Cascading Troubleshooting

    The following lists the network accessibility issues and possible root causes. You can always troubleshoot the software settings by connecting the PX3TS to a computer if network access to that PX3TS fails. See Connecting the PX3TS to a Computer (on page 24).
  • Page 799 Appendix I: Additional PX3TS Information Symptom Probable cause  One of the following issues occurs on the master device: Failure to access a slave device  Network connection is lost.  The Ethernet or wireless interface is disabled.  One of the following issues occurs on the slave device in question or any upstream device (if available): ...

  • Page 800: Slave Device Events In The Log

    USB is detected, the PX3TS at the USB-A end of the USB cable logs it in the internal log. Note that the PX3TS at the USB-B end of the cable does NOT log these events.

  • Page 801: Installing The Usb-To-Serial Driver (Optional)

    Appendix I: Additional PX3TS Information The Ping Tool The PX3TS provides a ping tool in the web interface and CLI so you can ping any host or PX3TS in your data center. Ping via the Web Interface: To log in to the web interface, see Login (on page 140).

  • Page 802: Initial Network Configuration Via Cli

    Appendix I: Additional PX3TS Information Manual driver installation in Windows ® 1. Make sure the PX3TS has been connected to the computer via a USB cable. 2. The computer detects the new device and the "Found New Hardware Wizard" dialog appears.
  • Page 803 "Dominion PX2 Serial Console" under the Ports group. 3. In the communications program, press Enter to send a carriage return to the PX3TS. 4. The PX3TS prompts you to log in. Both user name and password are case sensitive. a. Username: admin b.
  • Page 804 Appendix I: Additional PX3TS Information To set or Use this command enable network ipv4 interface <ETH> IPv4 configMethod <mode> configuration method dhcp static <mode> = (default) or network ipv6 interface <ETH> IPv6 configMethod <mode> configuration method <mode> = automatic (default) or static network <ipvX>...
  • Page 805 Appendix I: Additional PX3TS Information To set Use this command network dns thirdServer <ip IPv4 or IPv6 address> third DNS server <ip address> = DNS server's IP address Commands for wireless networking:  General wireless settings: To set or Use this command...
  • Page 806 Appendix I: Additional PX3TS Information To set or Use this command enable network wireless eapIdentity EAP identity <identity> <identity> = your user name for EAP authentication EAP password network wireless eapPassword When prompted to enter the password for EAP authentication, type the password.

  • Page 807: Device-Specific Settings

    Appendix I: Additional PX3TS Information  Wireless IPv4 / IPv6 settings: Commands for wireless IP settings are identical to those for wired networking. Just replace the variable <ETH> with the word 'wireless'. The following illustrates a few examples. To set or...

  • Page 808: Tls Certificate Chain

    A certificate or a chain of certificates is used for trusting a TLS server that you want to connect. The receiver, such as PX3TS, can trust a TLS server only after an appropriate certificate (chain) which is "related to" that TLS server's certificate is uploaded to the receiver.
  • Page 809 Appendix I: Additional PX3TS Information  Certificate A. The self-signed certificate issued by Issuer A. Issuer A is a root CA. The above three certificates form a certificate path, which is called the "certificate chain". Each certificate in the chain is the issuer certificate of the certificate that follows it.
  • Page 810 When uploading a (partial) chain onto the PX3TS, it means you trust each certificate in the chain to certify the authenticity of certificates a server sends to PX3TS. Therefore, at least the root certificate must be authentic, issued by a CA you trust, and downloaded from that CA over a secure channel.
  • Page 811 Appendix I: Additional PX3TS Information For PX3TS, if any required certificate is missing, a certificate error message similar to the following is shown on the PX3TS web interface. It is NOT recommended to upload the server certificate to the receiver except when it is a self-signed certificate.

  • Page 812: Illustration - Gmail Smtp Certificate Chain

    Appendix I: Additional PX3TS Information Illustration - GMAIL SMTP Certificate Chain If you will apply your company's SMTP service to PX3TS, ignore this GMAIL illustration topic. Simply contact your IT department to retrieve the appropriate certificate (chain) file and upload it to the PX3TS.
  • Page 813 Appendix I: Additional PX3TS Information -----BEGIN CERTIFICATE----- MIIEKDCCAxCgAwIBAgIQAQAhJYiw+lmnd+8Fe2Yn3zANBgkqhkiG9w0BAQsFADBC MqO5tzHpCvX2HzLc -----END CERTIFICATE----- 2 s:/C=US/O=GeoTrust Inc./CN=GeoTrust Global CA i:/C=US/O=Equifax/OU=Equifax Secure Certificate Authority -----BEGIN CERTIFICATE----- MIIDfTCCAuagAwIBAgIDErvmMA0GCSqGSIb3DQEBBQUAME4xCzAJBgNVBAYTAlVT b8ravHNjkOR/ez4iyz0H7V84dJzjA1BOoa+Y7mHyhD8S -----END CERTIFICATE----- Server certificate subject=/C=US/ST=California/L=Mountain View/O=Google Inc/CN=smtp.gmail.com issuer=/C=US/O=Google Inc/CN=Google Internet Authority G2 3. Onscreen information under the title 'Certificate chain' indicates that there are three issuers and three certificates on this server.
  • Page 814 2. Save that file as a file. In this example, it is named as "my-root.pem." 3. Upload the file "my-root.pem" to PX3TS for using the GMAIL SMTP service. Note: If your SMTP server requires the upload of a certificate file comprising multiple certificates, make sure the order of these certificates is correct in the file.

  • Page 815: Browsing Through The Online Help

    Appendix I: Additional PX3TS Information Browsing through the Online Help The PX3TS Online Help is accessible over the Internet. To use online help, Active Content must be enabled in your browser. Consult your browser help for information on enabling the feature.
  • Page 816 Appendix I: Additional PX3TS Information 11. To print the currently selected topic, click the "Print this page" icon...

  • Page 817: Appendix J Integration

    ....................803 Dominion KX II / III Configuration Raritan PX2, PX3 or PX3TS series can be connected to the Raritan's Dominion KX II or KX III device (a digital KVM switch) to provide one more alternative of power management.

  • Page 818: Configuring Rack Pdu Targets

    KX III allows you to connect rack PDUs (power strips) to KX III ports. KX III rack PDU configuration is done from the KX III Port Configuration page. Note: Raritan recommends no more than eight (8) rack PDUs (power strips) be connected to a KX III at once since performance may be affected.
  • Page 819 Note: PX rack PDUs (power strips) can be named in the PX as well as in the KX III. Once a Raritan remote rack PDU is connected to the KX III, it will appear on the Port Configuration page. Click on the power port name on that page to access it.
  • Page 820 Appendix J: Integration 3. Click OK.

  • Page 821: Turning Outlets On/Off And Cycling Power

    Port Access page. To use this feature, you will need:  Raritan remote rack PDU(s)  Power CIMs (D2CIM-PWR) Make a Power Association...

  • Page 822: Dominion Ksx Ii, Sx Or Sx Ii Configuration

     SX II - a CSCSPCS cable Note: To only access the CLI of the PX3TS via SX / SX II, treat the PX3TS as a serial device by connecting SX /SX II to the PDU's serial port instead of the FEATURE port.
  • Page 823 Appendix J: Integration Connecting a Rack PDU To connect the Raritan PX to the KSX II: 1. Connect one end of a Cat5 cable to the following ports of different Raritan PX.  PX1 series: RJ-45 "SERIAL" port  PX2, PX3 or PX3TS series: RJ-45 "FEATURE" port 2.

  • Page 824: Dominion Sx And Sx Ii

    PX3TS device to specific SX or SX II ports. Dominion SX II The way to use Dominion SX II to configure and control a Raritan PDU is similar to using Dominion KX III, but the connection method is different from KX III.
  • Page 825 Power Strips Using CLI. in the SX II User Guide or Online Help. PX appliance SX II Dominion SX Configuring a PX3TS on Dominion SX 1. Choose Setup > Power Strip Configuration. 2. Click Add. The Power Strip Configuration screen appears.
  • Page 826 Appendix J: Integration 3. Type a name and description in the Name and Description fields. 4. Select the number of outlets from the Number of Outlets drop-down menu. 5. Type the port number in the Port field. 6. Click OK. Power Control 1.

  • Page 827: Power Iq Configuration

    Appendix J: Integration Checking Power Strip Status 1. Choose Power Control > Power Strip Status. 2. A status box appears, displaying details of the controlled PX3TS, including power state of each outlet on the device. Power IQ Configuration Sunbird's Power IQ is a software application that collects and manages the data from different PDUs installed in your server room or data center.

  • Page 828: Dctrack

    ® center. The PX3TS is categorized as a power item in dcTrack. dcTrack offers an import wizard for conveniently adding the PX3TS as well as other IT equipment to dcTrack for management.

  • Page 829: Dctrack Overview

    Appendix J: Integration dcTrack Overview dcTrack is a powerful and intelligent data center management and ® automation application. It has been designed by data center and IT professionals to provide broad and deep visibility into the data center. It empowers data center managers to plan for growth and change by optimizing their current operations, assets, and infrastructure.

  • Page 830: Asset Management Strips And Dctrack

    If any asset strips are connected to the PX3TS, the PX3TS can transmit their information to Sunbird's dcTrack. All you have to do is to add the PX3TS to dcTrack, and also add each IT item where an asset tag is attached to dcTrack.
  • Page 831 Backup and Restore of Device Settings • xxiii, Devices • 289 404, 418, 425, 671 Additional PX3TS Information • 755 Backup and Restore via SCP • 426, 653 AD-Related Configuration • 720, 738, 751 Beeper • 133, 137, 138, 181 Alarm •...
  • Page 832 Ethernet Connectivity • xx, 18, 28, 271, 282, Commands for Environmental Sensors • 615 Commands for Inlet Sensors • 610 Cascading PX3TS via USB • xx, 15, 30, 34, 95, Commands for Outlet Sensors • 612 Commands for Overcurrent Protector Sensors Cascading Troubleshooting •...
  • Page 833 262, 263, 266, 298, 313, 451 Customizing Bulk Configuration Profiles • xxiii, Connecting a Logitech Webcam • 74, 430 418, 421 Connecting a Mobile Device to PX3TS • xx, 19, Customizing the Date and Time • 545 Connecting a PX PDU • 794 D ...
  • Page 834 Index Determining the Time Setup Method • 543, Editing or Deleting Role Access Control Rules • 306 Device Info • xxi, 18, 19, 117, 126, 282 Editing or Deleting Roles • 263 Device Information • 404, 405, 442 Editing or Deleting Users • 142, 260, 263, 265 Device Settings •...
  • Page 835 Example 1 - Creating a User Profile • 585 • 661 Example 1 - Environmental Sensor Naming • Extended Cascading with PX3TS-iX7 Models • xx, 33, 97 Example 1 - IPv4 Firewall Control External Beeper • 238, 248, 351, 355 Configuration •...
  • Page 836 Index Firewall Control • 547 Individual Sensor/Actuator Pages • xxii, 154, Firmware Update via SCP • 414, 651 178, 184, 219, 222, 223, 232, 237 Firmware Upgrade via USB • 414, 678 Initial Installation and Configuration • 14 Forcing a Password Change • 576 Initial Network Configuration via CLI •...
  • Page 837 M  Modifying SNMPv3 Settings • 577 Monitoring Server Accessibility • 268, 389, 391 MAC Address • 104 Mounting a PX3TS Device • 10 Main Menu • xxi, 113, 116 Multi-Command Syntax • 503, 504, 549, 556, Maintenance • 148, 403 557, 558, 562, 573, 575, 577, 580, 583, 608, Make a Power Association •...
  • Page 838 Product Models • 1 Overcurrent Protectors for Outlets • 102, 133, Push Out Sensor Readings • 351, 356 PX3TS Character LCD Display • xxi, 97, 98 Overview of the Cascading Modes • 282, 284 PX3TS Connection Ports • xxi, 94 Overview of the LCD Display •...
  • Page 839 Resetting the Button-Type Circuit Breaker • 431, 433, 435 Sensor RJ-45 Port Pinouts • 660 Resetting the PX3TS • 644 Sensor Threshold Configuration Commands • Resetting to Factory Defaults • 132, 429, 646, Sensor Threshold Settings • 166, 186, 190, 196, Restarting the PDU •...
  • Page 840 Index Setting LED Colors for Disconnected Tags • Setting the PSK • 528 630, 631, 632 Setting the Registry to Permit Write Setting Network Service Parameters • 534 Operations to the Schema • 713 Setting Non-Critical Outlets • 192, 197, 199 Setting the SNMP Configuration •...
  • Page 841 TLS Certificate Chain • xxiv, xxv, 275, 296, 316, Step A 368, 388, 784 Add Your PX3TS as a RADIUS Client • 719, Tracing the Route • 649 720, 738, 739 Transfer Switch • xxi, 82, 83, 87, 89, 120, 133, Step A.
  • Page 842 Web Interface Overview • xxi, 144, 791 Webcam Management • xxiii, 147, 411, 430 What is a Certificate Chain • xxiv, xxv, 784, 790 What's New in the PX3TS User Guide • xx Windows NTP Server Synchronization Solution • 326, 328 Wired Network Settings •...

This manual is also suitable for:

Px3ts-ix7

Table of Contents
