Fujitsu Inverter 9319356068 Operating Manual

Compact wall mounted type
Hide thumbs

Advertisement

Quick Links

Download this manual
Table of Contents

ROOM AIR CONDITIONER

COMPACT WALL MOUNTED TYPE
KEEP THIS OPERATION MANUAL
FOR FUTURE REFERENCE
FUJITSU GENERAL LIMITED
9319356068_OM_En.indd 1

OPERATING MANUAL

REFRIGERANT
THIS PRODUCT MUST ONLY BE INSTALLED OR SERVICED
BY QUALIFIED PERSONNEL.
Refer to Commonwealth, State, Territory and local legislation,
regulations, codes, installation & operation manuals, before
the installation, maintenance and/or service of this product.
R410A
This Air Conditioner contains and
operates with refrigerant R410A.
PART No. 9319356068
4/27/2012 1:15:38 PM
