- Page 1 Harrier 41 CODES 410E 412E 413E (Push) (Electric Start) (Auto Drive) Variable Speed Variable Speed OWNER'S HANDBOOK (English Version) HANDBOOK: 111-1148 (Rev.B.) CODE SERIAL NO. 410E 270000001 412E 270000001 413E 270000001 Issue : 23.03.07...
-
Page 2: Specifications
MAIN FEATURES /SPECIFICATIONS Main Features Air Cleaner Fuel Filler Cap Oil Filler Cap and Dipstick Handlebar Securing Knob Engine Start-Grip Throttle Control. Engine Stop lever. Handlebar Ground Drive Clutch Lever (412 & 413 Only) 10 Variable Speed Control (412 & 413 Only) 11 Grassbag Assembly 12 Height of Cut Adjuster 13 Serial No. - Page 3 1ST Year (12 months) 1ST Year (12 months) Owner’s Name: We certify that this service has been carried out by an Authorised Hayter Serial Number: Service Dealer Date: Date: Note for dealer: Please retain this voucher for your records. 2nd Year (24 months) 2nd Year (24 months) Owner’s Name: We certify that this service has been...
-
Page 5: Table Of Contents
CONTENTS 1.2 Main Features/Specifications 1.20 - 1.21 Lawn Care Calendar - Guide only 1.21 Lawn Stripes 1.5 Contents 1.22 - 1.23 Maintenance Schedule 1.6 Introduction 1.23 - 1.30 Mower Maintenance 1.7 Warranty 1.23 - Engine 1.23 - Throttle Cable Adjustment 1.8 - 1.11 Safety Precautions 1.23 - Carburettor Adjustments... -
Page 6: Introduction
Any arbitrary modifications carried out to this machine may relieve Hayter Limited of liability for any resulting damage or injury. Hayter mowers are robustly constructed and designed for efficient economical performance under normal mowing conditions. Correct operation and maintenance will ensure a long and satisfactory service life. -
Page 7: Warranty
WARRANTY LIMITED WARRANTY Hayter Limited warrants to the original user/purchaser that this unit shall be free from defects in material and workmanship under normal use and service for a period of three years from the date of purchase. The manufacturer of major proprietry components ie. engines, gearbox / transaxle (where applicable) furnish their own warranty and services are provided through their authorised network. -
Page 8: 1.11 Safety Precautions
SAFETY PRECAUTIONS Safety Alert Symbol This safety alert symbol indicates important safety messages. When you see this symbol be alert to the possibility of injury. Carefully read the following and inform others. Your mower is perfectly safe if used correctly. Failure to observe the following precautions may result in serious injury. -
Page 9: Preparation
SAFETY PRECAUTIONS Preparation Continued - Always use fresh fuel. Stale fuel can block the carburettor and cause leakage. - Replace fuel tank and oil tank caps securely. A damaged cutterblade or loose fixing bolt are major hazards. Before use, always visually inspect the cutting mechanism to ensure that it is in good condition. -
Page 10: Operation
SAFETY PRECAUTIONS Operation Continued Do not tilt the mower when starting the engine. Do not put hands or feet near or under rotating parts. Never pick up or carry the mower while the engine is running. Never lift the rear deflector while the engine is running. Never touch the exhaust/exhaust guard or cooling fins when the engine is hot. -
Page 11: Maintenance & Storage
SAFETY PRECAUTIONS Maintenance & Storage Continued Allow the engine to cool before storing in any enclosure. To reduce the fire hazard, keep the engine and the surrounding deck area free of grass, leaves, or excessive grease. Check the rear deflector and grassbag frequently for wear or deterioration. Replace worn or damaged parts for safety. -
Page 12: Assembling The Mower
ASSEMBLING THE MOWER Delivery Checklist Remove the mower from the packaging and check that the following items have been supplied correctly. If any items are missing contact, your local Hayter dealer. 1. Grassbag. 2. Charger (412 Only) 3. Ignition Key (412 Only) To prevent accidents cut off the long ribbon attached to the grass- bag and discard. -
Page 13: Before Starting The Mower
STARTING MOWER BEFORE Prevent Engine Damage To prevent engine damage the engine is shipped without oil or petrol. The engine must be filled with the correct grade of oil and petrol before starting the engine. Oil Type Always use high quality detergent oil classified SAE 30 oil. Never use additives with recommended oil. -
Page 14: 1.17 Operating The Mower
OPERATING THE MOWER Controls Operate all control levers several times and ensure that the cables move freely. Check that the engine stop and ground drive clutch levers return freely to their rest position when released. Whilst operating the engine throttle mechanism slight resistance should be felt when moving the lever to the ‘choke’... -
Page 15: Electric Start
OPERATING MOWER Step 3 Allow the engine to warm up and move the throttle lever to the ‘fast’ position after starting a cold engine. To prevent damage never pull the engine start grip when the engine is running. Electric Start (412 Only) - Stand behind the mower and hold the handlebar together with the engine stop lever. -
Page 16: Reverse Travel
OPERATING THE MOWER Reverse Travel Hold and pull against the handlebar with both hands to reverse the mower. Turning To make a wide turn steer the mower with the handlebar in the direc- tion required. To make a tight turn release the ground drive clutch lever, apply down- ward pressure on the handlebar to raise the front wheels just above ground level and steer in the required direction. -
Page 17: Slopes
OPERATING MOWER Slopes To prevent engine damage do not use the mower on slopes greater than 20 degrees. Height of Cut Move the height of cut lever sideways to disengage it from the locking notch, then push forwards to lower or pull backwards to raise the height of cut. -
Page 18: Before Mowing
OPERATING THE MOWER Before Mowing To prevent accidents thoroughly inspect the area and remove all objects which when contacted by the mower cutterblade could become dangerous projectiles. Inspect the area for hidden obstruc- tions which when contacted by the cutterblade could risk health and safety or result in damage to the mower. -
Page 19: Heavy Growth
OPERATING MOWER Heavy Growth Areas of heavy growth should be mown without collecting the clip- pings. If collection is required, first mow the area without the grass- bag at the maximum height of cut setting. Allow the grass clippings to dry out and then mow the area at the maximum height of cut setting with the grassbag fitted. -
Page 20: Lawn Care Calendar
LAWN CARE CALENDAR To be used as a guide only. January There is very little work to do this month apart from brushing away leaves. Keep off the grass if frozen or waterlogged. February Rake the grass thoroughly. Spike the lawn to aerate and stimulate soil organisms and root growth and apply lawn sand if necessary. -
Page 21: Lawn Care
LAWN CARE CALENDAR August Keep mowing regularly and watering as necessary. Fill any cracks caused by drought with a mixture of sharp sand and soil. In dry weath- er conditions leave the grass longer to help retain ground moisture. September Raise the height of cut to allow the grass to thicken and protect the roots from the winter frost and snow. -
Page 22: Maintenance Schedule
MAINTENANCE SCHEDULE To prevent accidents stop the engine and disconnect the spark plug lead before attempting to carry out maintenance procedures on the mower. After the very first hour check clutch adjustment. See page 1.26. After the very first five hours change the engine oil. Follow the hourly or calendar intervals, whichever occurs first. -
Page 23: 1.30 Mower Maintenance - Engine
MOWER MAINTENANCE 100Hrs or Every Season Clean the engine cooling system. Clean more often under dusty conditions or when airborne debris is present or after prolonged operation whilst cutting tall, dry grass. Replace the spark plug. Engine Air Filter Fuel Cap Start Grip Oil Cap/ Dipstick Exhaust Guard... -
Page 24: Oil Service
MAINTENANCE MOWER Oil Service Check the oil level daily before starting the engine and ensure that the correct oil level is maintained. Refer to-‘Before Starting the Mower’ for oil checking and filling instructions. Change the engine oil after the first 5 hours of operation and thereafter according to the ‘Maintenance Schedule’:- 1. -
Page 25: Spark Plug Service
MOWER MAINTENANCE Spark Plug Service Use only Briggs & Stratton spark tester (1) to check for a spark as shown in the diagram. Replace the spark plug every 100 hours or every season, whichever occurs first. A spark plug wrench is available from any authorised Briggs &... -
Page 26: Deck Housing
MOWER MAINTENANCE Deck Housing Remove grass debris from the top and underside of the deck housing immediately after use. Fertilisers and top dressings are particularly corrosive. Thoroughly clean the mower deck immediately after use on treat- ed grass and store well away from corrosive materials. Securing Nuts &... -
Page 27: Lubrication
MOWER MAINTENANCE Lubrication Lubricate the wheels, pivot points and linkages with engine oil every 25 operating hours. Apply a good quality medium grease to the inner control cables at the point of entry and exit from their outer casing. Cutterblade Removal Drain the fuel by running the engine until the fuel tank is empty and the engine stops. -
Page 28: Cutterblade Assembly
MOWER MAINTENANCE Cutterblade Assembly Assemble the cutterblade with the turned up edges facing towards the engine. Secure the cutterblade using the bolt (1), spring washer (2), and distance piece (3) and tighten to a torque of 54Nm Cutterblade Sharpening A slightly worn cutterblade may be re-sharpened. Both blade edges must be sharpened equally to ensure balance. -
Page 29: Storage
MOWER MAINTENANCE Storage To store the handlebar unscrew the 2 small securing knobs sufficient- ly to allow it to be pivoted forwards to rest against the mower. Take care to ensure that the control cables do not become snagged at the pivot point and depress the engine stop lever to prevent it being dam- aged through contact with the engine spark plug. -
Page 30: Battery Charging
MOWER MAINTENANCE Battery charging (412 only) - PREVENT ACCIDENTS: ALWAYS charge the bat- tery in a well ventilated area. NEVER charge the battery near naked flames or direct heat. ALWAYS switch off the mains electricity supply before discon- necting the charger from the battery. ALWAYS use the battery charger supplied with the mower. -
Page 31: 1.32 Trouble Shooting
TROUBLE SHOOTING PROBLEM POSSIBLE FAULT REMEDY Engine will not turn over Engine stop lever released. Operate engine stop lever. Incorrect oil level. Check oil level. Obstruction under deck. Remove obstruction. Battery discharged (412 Only) Charge battery Engine smokes Excess oil level. Check oil level. - Page 32 TROUBLE SHOOTING PROBLEM POSSIBLE FAULT REMEDY Engine vibrates excessively Mounting bolts loose. Tighten bolts Cutterblade bolt loose. Tighten bolt Cutterblade out of balance. Balance cutterblade Bent crankshaft. Consult your dealer Uneven cut Undulating ground conditions Change direction of travel Cutterblade worn Sharpen the cutterblade Cutterblade out of balance Balance the cutterblade...
-
Page 33: Declaration Of Conformity
DECLARATION CONFORMITY EC DECLARATION OF CONFORMITY Manufacturer: HAYTER LIMITED, Address: Spellbrook, Bishop’s Stortford, Herts. CM23 4BU. ENGLAND declare that the lawnmower: Model name: Harrier 41 Harrier 41 Harrier 41 Push Electric Start Electric Start Type: Pedestrian rotary Pedestrian rotary Pedestrian rotary Model No: CODE 410E CODE 412E... - Page 34 PARTS LIST QTY. DESCRIPTION ITEM NOTE ITEM NO. PART NO. 410E 412E 413E Mainframe 410010V Cover- Side RH 410033 Screw - Taptite M6x16 09365 Rod - Deflector 305103 Key - Woodruff 1662 Lead - Battery 412014 Engine - E/S 111-1001 Engine - 111-0999 Decal - Engine...
- Page 35 PARTS LIST QTY. DESCRIPTION ITEM NO. PART NO. ITEM NOTE 410E 412E 413E Frame - Grassbag 410038W Fabric - Grassbag 410039 Deflector - Rear 410028 Bolt - Coach M8x40 09379 Plug - Drive Small 300144 Ratchet - HOC HY410006 Decal - HOC 320006 Screw - Self Tap Engine 09349...
-
Page 36: Engine
PARTS LIST QTY. DESCRIPTION ITEM NO. PART NO. 410E 412E 413E ITEM NOTE Bush 340154 Bearing - Support 410048 Cover - Side LH 410032 Lever - HOC 480128 Spring - HOC 480132 Screw - Taptite M6x35 09786 Frame - Roller W/A 410011W Shell - Roller 410044... - Page 37 PARTS LIST 410E 1.37...
- Page 38 412E/413E PARTS LIST 1.38...
- Page 39 NOTES Notes:- 1.39...
-
Page 40: Customer Information
CUSTOMER INFORMATION Serial No: Engine:-Briggs & Stratton Quantum XTS-50 Engine Type:-12F802-1788-B1 Engine Type:-12F807-1787-B1 Date of Sale:- Your Local Dealer:- 1.40...
