Specifying information about your system

In addition to configuring the sources, and programming their
levels, you can configure many other aspects of the operation of
the 502 Analogue Controller to suit the way your system is set
up, and the way in which you want to use it.
Note that any settings that you configure are reset to standard
values when you choose one of the standard settings: see
Choosing standard settings, page 14.
To configure the analogue controller
Switch off the analogue controller, using the power switch on
the back panel.
Switch on the power again while holding down the Display
key on the front panel.
The display will show:
It will then show the first
configuration option:
Press Display to move between the options.
Press A or V to change the value of the current option.
22
The table below shows the options you can configure.
Option
Communications mode (500 or 200)
Controller mode (Auto, Con., or N.Con.)
System address (1–8)
Product address (1–8)
Volume mode (M, S, or N)
Copy address (2-room) (1 to 8)
C o n f i g
Source info display (2-room) (Y or N)
5 0 0
These settings are configured automatically to appropriate
values when you choose one of the standard Type settings, and
you should not normally need to alter them; see Choosing
standard settings, page 14.
Initial Value
500
Aut o
S.A . 1
P.A . 1
Vol . M
C.A . 2
Dis . N
