Specification and accessories

Specification
MM input option
MC input option
A2 – A7 inputs
Tape output
Main outputs
Communications
Noise and hum
Distortion
6
Sensitivity adjustable 0.5 – 17mV for
5cm/s @ 1kHz.
Overload point 47mV @ 1kHz.
Cartridge load 47k || 100pF.
Sensitivity adjustable 38 – 1200 V for
5cm/s @ 1kHz.
Cartridge load 220 || 10nF.
Sensitivity adjustable 27 – 840mV.
Input impedance 20k .
Output 1.5V rms.
Output 1.4V rms, 3V rms maximum.
Two 5 pin 240 DIN sockets, RS232
interface.
Less than -96dB for high-level
analogue inputs.
Less than -70dB for MM input.
Less than -60dB for MC input.
Less than 0.01% input to output.
Display Eight character display for current
source, volume, mute, and copy
source.
Finish Black textured enamel and glass.
Dimensions 88mm x 321mm x 332mm
(3.46" x 12.64" x 13.07").
Weight 5kg (10lbs).
Consumption 20VA.
Available accessories
The following accessories are available from your dealer:
MM mono phono modules.
MC mono phono modules.
Meridian System Remote.
Power cord Europe.
Power cord Canada and USA.
The MM and MC phono modules convert the LP audio input (A1)
for use with a moving magnet or moving coil pickup,
respectively.
