5 CONFIGURING THE FIEL DSERVER AS AN OPTOMUX DRIVER CLIENT
For a detailed discussion on FieldServer configuration, please refer to the FieldServer Configuration Manual. The
information that follows describes how to expand upon the factory defaults provided in the configuration files
included with the FieldServer (See ".csv" files on the driver diskette).
This section documents and describes the parameters necessary for configuring the FieldServer to communicate
with an Optomux Device.
The configuration file tells the FieldServer about its interfaces, and the routing of data required. In order to enable
the FieldServer for Optomux Driver communications, the driver independent FieldServer buffers need to be
declared in the "Data Arrays" section, the destination device addresses need to be declared in the "Client Side
Nodes" section, and the data required from the servers needs to be mapped in the "Client Side Map Descriptors"
section. Details on how to do this can be found below.
Note that in the tables, * indicates an optional parameter, with the bold legal value being the default.
5.1 Client S ide Connection Parameters
Section Title
Connections
Column Title Function
Specify which port the device is
Port
connected to the FieldServer
Baud* Specify baud rate
Parity* Specify parity
Data_Bits* Specify data bits
Stop_Bits* Specify stop bits
Protocol Specify protocol used
Poll Delay* Time between internal polls
Example
// Client Side Connections
Connections
Port , Baud , Parity
R1 , 9600 , None
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com
Legal Values
R1-R2, (FS-X40 Series)
R1 (FS-X20 Series)
Standard baud Rates in the range 300-38400. (Vendor
Limitation), 9600
Even, Odd, None, Mark, Space
7, 8
1 (Vendor Limitation)
Optomux
0-32000 seconds, 1 second
, Protocol , Poll_Delay
,Opto22 , 0.100s
