FS-8700-83 Gamewell Serial Driver
APPLICABILITY & EFFECTIVITY
Effective for all systems manufactured after May 1, 2001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Gamewell FS-8700-83 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for FieldServer Gamewell FS-8700-83

  • Page 1 A Sierra Monitor Company Driver Manual (Supplement to the FieldServer Instruction Manual) FS-8700-83 Gamewell Serial Driver APPLICABILITY & EFFECTIVITY Effective for all systems manufactured after May 1, 2001...
  • Page 2: Table Of Contents

    GAMEWELL SERIAL DRIVER DESCRIPTION ... 1 DRIVER SCOPE OF SUPPLY ... 1 UPPLIED BY IELD ERVER ... 1 ROVIDED BY USER HARDWARE CONNECTIONS... 2 CONFIGURING THE FIELDSERVER AS A GAMEWELL SERIAL DRIVER CLIENT ... 3 ... 3 RRAYS LIENT ONNECTIONS ... 5 LIENT ODES...
  • Page 3: Gamewell Serial Driver Description

    Design Basis: Gamewell serial port protocol specification “IF 600r7 Message Stream” (not dated) and “SmartNet Data stream information” (not dated). The driver is capable of exposing communication statistics in a FieldServer Data Array so that a remote device can monitor them.
  • Page 4: Hardware Connections

    The bridge is connected to the Gamewell panel as shown below. Configure the Gamewell panel according to manufacturer’s instructions FIELDSERVER RS232 PORT FS-8915-10 FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com GAMEWELL SIM 232 RJ45-01...
  • Page 5: Configuring The Fieldserver As A Gamewell Serial Driver Client

    For a detailed discussion on FieldServer configuration, please refer to the FieldServer Configuration Manual. The information that follows describes how to expand upon the factory defaults provided in the configuration files included with the FieldServer (See “.csv” files on the driver diskette).
  • Page 6: Client Side Connections

    Client Side Connections Connections Port, Baud, Parity, Protocol, Handshaking, Poll_Delay, IC_Timeout P8, 9600, None, Gamewell, None FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com Function P1-P8, R1-R2 2400...
  • Page 7: Client Side Nodes

    Nodes Node_Name, Node_ID, Protocol, Port Panel1 , 0 , Gamewell, P8 FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com Function Provide name for node Gamewell panel node address.
  • Page 8: Client Side Map Descriptors

    Driver Related Map Descriptor Parameters Column Title Node_Name Data_Type FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com Function Name of this Map Descriptor Name of Data Array where data...
  • Page 9: Timing Parameters

    You should always Ack before you silence the panel. Timing Parameters Column Title Scan_Interval FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com Function Rate at which data is polled Page 7 of 24 1 –...
  • Page 10: Map Descriptor Example 1 - Store Data From Incoming Messages

    FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com Page 8 of 24 , Dev, Length, Data_Type , Clear_On_Reset...
  • Page 11: Map Descriptor Example 2 - Send A Reset / Ack / Silence Command

    Sil_md , DA_SILENCE Res_md , DA_RESET FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com Page 9 of 24 element (because = 0 ) has its value updated, even if the value...
  • Page 12: Configuring The Fieldserver As A Gamewell Serial Driver Server

    FS-8700-83 Gamewell 5. Configuring the FieldServer as a Gamewell Serial Driver Server The Gamewell Serial Driver provides limited server functionality. This has been developed to allows for automated testing and Quality Assurance. It is not supported or documented however, at a client’s request it can be extended &...
  • Page 13: Status Types And Values

    The value’s can be changed by using the method below to add, but when you add, use the existing name and a new value. FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com bit to be set.
  • Page 14: Adding A New Status Type

    This provides a good technique of synchronizing the panel and the FieldServer. When you restart the FieldServer you should push the reset button on the panel so that the panel sends messages for all points that are not in a normal state. If you don’t do this, and some points are in a not-normal state then the FieldServer will not know about them until their state changes This is potentially dangerous.
  • Page 15 29 Key Stuck in 30 Display Missing for 31 Bad Card @ 32 Card Missing @ FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com Description Driver did not recognize action type...
  • Page 16 57 Secondary Bus Error 58 Printer fault 59 Batt. Charging OK 60 Batt. Charging FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com System Problem System Problem Supervisory or trouble in circuit that automatically...
  • Page 17: Adding New Action Types

    The driver can store a maximum of 100 action types. The maximum length of the string is 49 characters. FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com , 100...
  • Page 18: Advanced Map Descriptor Examples

    You would need another set of these map descriptors for any other circuit you are monitoring. FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com Page 16 of 24...
  • Page 19: Example 2 : Action Numbers

    , Data_Array_Offset, Function, node_name, ckt Ckt1128_data12 , DA_ACTION128 , 000 FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com Page 17 of 24 , Length , Data_Type , passive , panel1...
  • Page 20: Example 3 : Action Bits

    , Data_Array_Offset, Function, Node_Name, Ckt, Dev, Length , Data_Type Ckt1128_data12 , DA_ACTION_BITS , 000 FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com Page 18 of 24 ‘ then first the array element at offset 11 would be set to 1 and then element...
  • Page 21: Example 4 : Ignored Messages

    Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, node_name, Length , Data_Type , Clear_on_Reset, Store_As Store_Ignored_Msg , DA_DUMP_IGNORED, 000 FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com Page 19 of 24 , passive , panel1...
  • Page 22: Driver Notes

    2400, None 7.2 Driver Stats In addition to the standard FieldServer communication statistics described in the FieldServer User’s Manual, the Gamewell Serial Driver can also expose some driver statistics by writing data to a data array. A special map descriptor is required. The driver recognizes the map descriptor by its name which must be "Gamewell-stats"...
  • Page 23 84 114 85 115 86 116 87 117 88 118 FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com Description Available for future use Available for future use Available for future use...
  • Page 24: Revision History

    1.00 18Sep2002 1.01 25Nov02 1.02 20Aug03 1.02 FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com Document Resp Comment Revision Initial Release. Issued for review, formatting. Connection diagrams required.
