- Page 1 A Sierra Monitor Company Driver Manual (Supplement to the FieldServer Instruction Manual) FS-8700-103 ATMI-TGM Serial Driver APPLICABILITY & EFFECTIVITY Effective for all systems manufactured after May 1, 2001 Driver Version: 1.00 Document Revision: 2...
-
Page 2: Table Of Contents
Exposing Driver Operating Statistics...25 APPENDIX D. TROUBLESHOOTING TIPS...27 Appendix D.1. Connection Tips & Hints...27 FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com TABLE OF CONTENTS Party Equipment ...4 Table of Contents... -
Page 3: Atmi Tgm Serial Driver Description
FS-8700-103_ATMI_TGM_Serial Manual ATMI TGM Serial Driver Description The ATMI-TGM driver allows the FieldServer to transfer data to and from devices over RS-232 using the ATMI-TGM printer port protocol. This driver connects to an ATMI TGM device using a serial connection. One device may be connected per FieldServer port. -
Page 4: Required 3 Rd Party Hardware
2.2.2. Required 3 The FieldServer’s serial port must be configured to be used as a ‘Console Port’ on the TGM device. The ‘Console Port’ is configurable. At least one of the two serial ports on the TGM device must be configured to enable the ‘Console Port’. This is not always the case when the TGM is shipped. -
Page 5: Hardware Connections
FS-8700-103_ATMI_TGM_Serial Manual Page 5 of 28 Hardware Connections The FieldServer is connected to the TGM device’s printer port as shown in connection drawing. Configure the TGM device according to manufacturer’s instructions FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com... -
Page 6: Hardware Connection Tips / Hints
The driver does not provide the hardware handshaking required and assumes the hardware control has been defeated with jumpers. FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com Page 6 of 28... -
Page 7: Configuring The Fieldserver As A Atmi Tgm Serial Client
For a detailed discussion on FieldServer configuration, please refer to the FieldServer Configuration Manual. The information that follows describes how to expand upon the factory defaults provided in the configuration files included with the FieldServer (See “.csv” sample files provided with the FieldServer). -
Page 8: Client Side Connection Descriptions
Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction manual for details of the ports available on specific hardware. FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com... -
Page 9: Client Side Map Descriptors
Set the Scan_Interval for the QLA and QIR reports to zero to have the driver poll for this data as often as possible. FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com... -
Page 10: Map Descriptor Example #1 - Calr Report
Data Array’s format is BYTE so that it can be viewed as a string when using Ruinet. FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com Data_Array_Offset, Function,... -
Page 11: Map Descriptor Example #2 - Qla Report
Data Array FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com Function, Node_Name Address... -
Page 12: Map Descriptor Example #3 - Qir Report - Malfunctions
Refer to Appendix A.2 for this list. The list can be modified in the configuration CSV file. CAUTION: When the QIR report is polled it responds with the latest incidents only. This means that care should be taken to synchronize the FieldServer and the TGM. Read more about this in Appendix B.8 Client Side Map Descriptors... -
Page 13: Appendix A. Tgm Tables
POCL3 SIHX SIHx TMBP FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com If a match is found then the driver stores the Index Value Page 13 of 28... -
Page 14: Appendix A.2. Malfunction Table
ACOUSTIC SENSOR FAILURE GETTER TEMPERATURE LOW LOW SAMPLE FLOW TGM HYDROGEN LEAK FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com Page 14 of 28 Return to Normal BASELINE BACK TO NORMAL... -
Page 15: Appendix A.3. Gas Concentration Engineering Units
The table may be extended/modified using the configuration file. Refer to Appendix B.1 Engineering Units Error / Unknown FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com Index Value... -
Page 16: Appendix B. Advanced Topics
If a similar match is made the driver reports this in the error log. 16 T02> TGM:#21 FYI. Malfunction. Dont recognize <POWER FAILED> 17 T02> FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com 00:00 00 10:29 16 FEB 04... -
Page 17: Appendix B.2. How Gas Data Is Stored
‘BYTE’ format is reccomended. FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com Two additional Data Array’s can be... -
Page 18: Appendix B.3. Adding/Modifying Gas Concentration Value Engineering Units
20. // Change index value of existing gas to 20. Driver_Table TGM_Gas_Name, FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com TGM_Units_Index_Value, TGM_Units_Index_Value,... -
Page 19: Appendix B.5. Adding / Modifying Malfunction Strings
20. It will be added to the table. // Add a new malfunction Driver_Table TGM_Malfunction_Name, DISK IS FULL, FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com TGM_Gas_Index_Value, TGM_Malfunction_Index, TGM_Malfunction_Index,... -
Page 20: Appendix B.6. Adding / Modifying 'Return To Normal' Strings
Appendix B.7. Using the TGM’s Config.dat file to customize malfunctions Copy the TGM’s config.dat file to the FieldServer as a file called atmitgm.ini. When the driver starts it looks for this file and updates the malfunction table based on the malfunction strings found inside the config file. -
Page 21: Appendix B.8. Synchronizing Malfunctions
The following procedure is recommended for synchronizing the FieldServer and the TGM 1. Turn off the FieldServer. Clear all events on the TGM and then restart the FieldServer. With the FieldServer online, cause the TGM to send an RESET ALARMS message to the FieldServer. -
Page 22: Appendix C. Driver Error Messages
Modify the configuration CSV file. Download the modified file to the FieldServer and Reset the FieldServer for the changes to take effect. FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com... - Page 23 Event=<%s> Index Val=%d Modify the configuration CSV file. Download the modified file to the FieldServer and Reset the FieldServer for the changes to take effect. FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com Notes and Corrective Action An attempt has been made to extend the gas name table.
- Page 24 Unknown. Read manual. TGM: TGM_Function=%s invalid. Modify the configuration CSV file. Download the modified file to the FieldServer and Reset the FieldServer for the changes to take effect. FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com...
-
Page 25: Appendix C.1. Exposing Driver Operating Statistics
FS-8700-103_ATMI_TGM_Serial Manual Appendix C.1. Exposing Driver Operating Statistics In addition to the standard FieldServer operating statistics the driver exposes certain key stats in a Data Array if required. These stats can then be monitored by an upstream device. Add the following to your configuration file to activate these stats Expose Driver Operating Stats. - Page 26 FS-8700-103_ATMI_TGM_Serial Manual Page 26 of 28 FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com...
-
Page 27: Appendix D. Troubleshooting Tips
9600, // [3] // cous chan FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com */ /* PMC */ */ /* PMC, too slow and wont finish printing in time... - Page 28 FS-8700-103_ATMI_TGM_Serial Manual Page 28 of 28 THIS PAGE INTENTIONALLY LEFT BLANK FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: support@fieldserver.com...
