Configure The Switch; Network Configuration Parameters - Qlogic 9000 Series Installation Manual

3–Installation
Installing a Switch

Configure the Switch

You can configure the switch using the Enterprise Fabric Suite 2007 application,
the QuickTools web applet, or the command line interface. To configure the switch
using Enterprise Fabric Suite 2007, click the Open Configuration Wizard radio
button in the Initial Start dialog, then click the Proceed button. The Configuration
wizard prompts you for the network configuration information listed in
Temporary IP address
Temporary subnet mask
Current Admin account password
Archive template file
Switch domain ID (1–-239)
Domain ID Lock (Locked/Unlocked)
Switch name
Permanent IP address
Permanent subnet mask
Permanent gateway address
Permanent network discovery method
Ethernet port selection
Date and time
New Admin account password
Create a configuration archive?
To configure the switch using the command line interface, do the following:
1. Open a command window according to the type of workstation and
connection:

3-20
Table 3-2. Network Configuration Parameters
Ethernet (all platforms): Open a Telnet session with the default switch
IP address and log in to the switch with account name admin and the
default password password.
telnet 10.0.0.1
Switch Login: admin
Password:
Factory default is password.
*******
Table 3-2.
59229-05 A
