  • Page 1: Quick Start Guide

    Quick Start Guide F I B R E C H A N N E L S W I T C H I N S T A L L A T I O N ® S A N b o x 9 0 0 0 S e r i e s ®...
  • Page 2 Purchasers of OEM products should consult with the OEM for support. Support Headquarters QLogic Web Site Technical Support Web Site Technical Support Email Technical Training Email North American Region Email Phone Europe, Middle East, and Africa Region Email Phone Numbers by Language Asia Pacific Region Email Phone Numbers by Language...

  • Page 3: Installation Instructions

    Quick Start Guide Installation Instructions Congratulations on your purchase of the SANbox install and activate your new switch using a Windows® workstation. For advanced options and instructions (including ® ® ® Solaris , Linux , and Mac OS X installations), refer to the SANbox 9000 Series Stackable Chassis Switch Installation Guide on the product CD.

  • Page 4: Step 4. Apply Power To The Switch

    Step 4. Apply Power to the Switch The maximum current requirements are 10 amps at 100 VAC or 4.2 amps at 240 VAC. ❑ Attach the AC power cords to the Power Supply blades and wall outlets or power strips. Secure the strain relief bales to the plugs.

  • Page 5: Step 6. Connect The Workstation To The Switch

    Step 6. Connect the Workstation to the Switch ❑ Connect the CPU0 blade Ethernet port directly to the workstation using an Ethernet cable, or indirectly through a switch or hub. The Ethernet port automatically discovers straight and cross-over cables. You must have a live Ethernet connection when the workstation powers up.

  • Page 6: Step 9. Run The Configuration Wizard

    Step 9. Run the Configuration Wizard ❑ Double-click the Enterprise Fabric Suite 2007 shortcut, or select Enterprise Fabric Suite 2007 from Start menu, depending on how you installed it. ❑ The Configuration Wizard tool auto-detects and configures the switch based on selected options and recommended settings.
  • Page 7 © 2007 QLogic Corporation. QLogic, the QLogic logo, SANbox, and Enterprise Fabric Suite 2007 are trademarks or registered trademarks of QLogic Corporation. Microsoft , Windows, and Internet Explorer are registered trademarks of the Microsoft Corporation. MacOS X is a registered trademark of Apple Computer, Inc. Linux is a registered trademark of Linus Torvalds.
  • Page 8 QLogic Corporation 949.389.6000 *50688-03 26650 Aliso Viejo Parkway www.qlogic.com Aliso Viejo, CA 92656 50688-03 A...
