7. Secure the HyperStack cables in place using ties wraps as shown in
Figure
cables to each other. This reduces cable clearance to 7–8 inches and
provides room for the removal of the Power Supply and Fan blades on the
lower switch.
Tie Wraps
8. Confirm that the ICC port Logged-In LEDs are illuminated. This indicates
that the switches are communicating.
9. Enter the Show Interconnect CLI command to confirm each ICC port is
online.
QLogic #> show interconnect
59229-05 A
3-8. Secure the outer cables to the rack posts; secure the inner
Figure 3-8 Securing HyperStack Cables
Blade ID ICC ID State
-------- ------ -----
CPU0 ICC0 Online
ICC1 Online
CPU1 ICC0 Online
ICC1 Online
3–Installation
HyperStacking
LSDB ID ISOREASON
------- ---------
0x1000 NotApplicable
0x1001 NotApplicable
0x1010 NotApplicable
0x1011 NotApplicable
3-31
