Summary of Contents for FARGO electronics PrimeraPro 76500
-
Page 1: Operating Instructions
® ELECTRONICS, INCORPORATED Operating Instructions Models: 76500 (110/120 V AC) 76501 (220/250 V AC) 76502 (110/120 V AC) 76503 (220/250 V AC) 76504 (110/120 V AC) 76505 (220/250 V AC) © 1994 by FARGO Electronics, Incorporated 960102-510448-(07)-76500-01-02-03-04-05... -
Page 2: Trademark Acknowledgements
Notices The information in this document is subject to change without notice. FARGO ELECTRONICS, INCORPORATED, MAKES NO WARRANTY OF ANY KIND WITH REGARD TO THIS MATERIAL, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. - Page 3 For Users in the United States: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 4: Table Of Contents
D. About Paper and Transparency Film ...21 E. Installing and Adjusting Paper Trays ...22 F. Loading Paper or Transparency Film ...23 Section 5: Powering Up the Printer A. Applying Power ...27 B. Running the Self Test ...29 Section 6: Using PrimeraPro With an IBM-PC or Compatible A. - Page 5 B. Standard Print Head Cleaning ...66 C. Expanded Print Head Cleaning ...67 D. Cleaning the PrinterÕs Case ...67 E. Cleaning the Inside of the Printer ...67 F. Clearing a Paper Jam ...69 G. Clearing a Ribbon Jam ...69 H. Cleaning the Drive Roller ...70 Section 11: Troubleshooting A.
-
Page 6: How Your Primerapro Color Printer Works
A. How Your related printing technologies to achieve its PrimeraPro Color remarkable outputÑwax thermal transfer and dye- Printer Works sublimation. Wax thermal transfer is a process which uses a wax based ribbon roll that is partitioned by a number of consecutive 9"... -
Page 7: Special Features
Color QuickDraw Amiga ¨ with system software 2.x or higher. This means that you can use the printer with virtually any software package running under these operating environments without any special set-up or configuration beyond the initial installation of the specific software driver and interface cable. -
Page 8: Section 2: Safety Precautions
Warnings CAUTION! TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THE UNIT TO RAIN OR MOISTURE. TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE SIDE OR BACK PANELS. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Before operating the unit, please read the following safety... - Page 9 S icherheits- ma§nahmen Machen Sie sich vor Inbetriebnahme des GerŠts mit den Sicherheitsma§-nahmen grŸndlich vertra Sicherheitshinweise VORSICHT! ZUR VERH†TUNG VON FEUERGEFAHR ODER ELEKTRISCHEN SCHL€GEN DAS GER€T VOR REGEN ODER FEUCHTIGKEIT SCH†TZEN. UM DIE GEFAHR VON STROMSCHL€GEN ZU VERHINDERN, SEITENABDECKUNGEN ODER R†CKWAND NICHT ABNEHMEN.
- Page 10 Avertissements ATTENTION! POUR EVITER TOUT RISQUE DÕINCENDIE OU DÕELECTROCUTION, NE PAS EXPOSER LÕAPPAREIL A LA PLUIE OU A LÕHUMIDITE. POUR EVITER TOUTE DECHARGE ELECTRIQUE, NE PAS RETIRER LES PANNEAUX LATERAUX OU ARRIERE. NE PAS TENTER DE REPARER SOI-MEME LES PIECES A LÕINTERIEUR DE LÕAPPAREIL. CONFIER LÕENTRETIEN DE LÕAPPAREIL A UN PERSONNEL QUALIFIE.
-
Page 11: Precauciones De Seguridad
P recauciones de seguridad Antes de operar la unidad, haga el favor de leer detenidamente las siguientes precauciones de seguridad. Advertencias ÁPRECAUCION! PARA EVITAR PELIGROS DE INCENDIO O CHOQUE ELECTRICO, NO EXPONGA LA UNIDAD A LA LLUVIA NI A LA HUMEDAD. PARA REDUCIR EL RIESGO DE CHOQUE ELECTRICO, NO QUITE LOS PANELES LATERALES NI DE FONDO. -
Page 12: Precauzioni Per La Sicurezza
Avvertenze ATTENZIONE! ONDE EVITARE IL PERICOLO DI INCENDIO O SCOSSA ELETTRICA, NON ESPORRE LÕUNITË ALLA PIOGGIA OD UMIDITË. PER RIDURRE IL RISCHIO DI SCOSSA ELETTRICA EVITARE DI RIMUOVERE I PANNELLI LATERALE O POSTERIORE. LA FUNZIONALITË DELLE PARTI ALLÕINTERNO DELLA UNITË NON é DI COMPETENZA DELLÕUTENTE. - Page 13 P recau•›es seguran•a Antes de operar esta unidade leia cuidadosamente as seguintes precau•›es de seguran•a. Advert•ncia CUIDADO! PARA EVITAR PERIGO DE CHOQUES ELƒTRICOS OU INCæNDIO, NÌO EXPONHA A UNIDADE Ë CHUVA OU UMIDADE. PARA REDUZIR O RISCO DE CHOQUES ELƒTRICOS, NÌO REMOVA OS PAINƒIS LATERAIS OU TRASEIRO.
-
Page 14: Getting Started
A. Choosing a Good Location Place the unit in a location with adequate air circulation to prevent internal heat build up. G etting Started specified in these two drawings as a guideline for the minimum clearances to the unit. unit in a location where the ventilation holes located on the rear of the unit could become... -
Page 15: About Moisture Condensation
Leave the unit turned off in a warm, dry room for several hours before using. This will allow the moisture to evaporate. C. Unpacking While unpacking your printer, inspect the carton to ensure that no damage has occurred during and Inspection shipping. Make sure that all supplied accessories are included with your unit. -
Page 16: Identifying The Parts
D. Identifying the Parts These illustrations show the controls, switches and indicator lights, and input jacks found on your PrimeraPro. For complete instructions about each control or feature, see later sections of this manual. Power On LED Power Switch AMIGA AND PC Ventilation Slots Power Parallel... -
Page 17: Removing The Ribbon Cartridge
E. Removing the Ribbon Cartridge The printerÕs Ribbon Cartridge is located inside the unit during shipment. Remove the cartridge from the printer using the following procedure: Press the Cover Release Lever. Allow the cover to swing up and open. With the cover open, you can see the Ribbon Cartridge. - Page 18 Flip open the Ribbon Cartridge Cover. You are now ready to go on to Section Four to learn about paper, ribbons, transparencies and how to load the various media. NOTE Your PrimeraPro ships with two separate ribbon cartridges; one for wax thermal transfer ribbons and one for dye-sublimation ribbons.
-
Page 19: About Ribbons
Your PrimeraPro initially comes equipped with both A. About a 30 print 3-color wax thermal transfer Starter Ribbons Ribbon and a 10 print dye-sublimation Starter Kit. Normally, wax thermal 3-color ribbons have 115 prints. With a 3-color ribbon, all three colors (C,M,Y) are used to print a ÒprocessÓ... -
Page 20: Loading Ribbon Into The Ribbon Cartridge
NOTE B. Loading Ribbon into the Ribbon Cartridge Follow these steps to load ribbon into the Ribbon Cartridge: Remove the ribbon from its box. For wax thermal ribbons, remove the end caps which were used for shipping protection. For dye-sublimation ribbons, simply remove the ribbon from its plastic wrap. - Page 21 IMPORTANT! DO NOT REVERSE THE RIBBON. DAMAGE MAY OCCUR TO THE THERMAL PRINT HEAD! After the ribbon has been installed into the Ribbon Cartridge, close the Ribbon Cartridge Cover. You are now ready to place it back into the printer.
-
Page 22: Placing The Ribbon Cartridge Into The Printer
Release Lever. Allow the cover to swing up and open. With the cover open, place the Ribbon Cartridge into the printer. Be certain that the supply end of the Ribbon Cartridge is towards the rear of the printer. Close the cover. -
Page 23: About Paper And Transparency Film
(Print on the smooth, coated side). Both are available in A-Size (8.5" x 11") and A4-Size (210 x 297mm). You may also wish to experiment with very high-quality laser printer papers. Depending upon the paper selected, quality may range from very poor to excellent. -
Page 24: Installing And Adjusting Paper Trays
Place one post into the mounting hole located on either side of the front interior of the printer. Please contact your local dealer or FARGO for current ribbon, paper, and transparency film selection and pricing. -
Page 25: Loading Paper Or Transparency Film
(steps 1Ð3 are illustrated up to this point on page 70 of this manual). 4. Looking inside the printer, the Paper Feed Roller and the two black brackets which attach it to the printer should now be visible. -
Page 26: Important Note
Paper Input Tray to the left or right for A and A4 size sheets. To adjust between regular and long lengths of paper, you must make an adjustment in the printer driver setup (see Section 6, 7, or 9 for instructions on using your specific printer driver). Keep in mind the following information when selecting your paper size. - Page 27 Follow these steps to load paper or transparency film: A maximum of 50 sheets of thermal transfer paper, 25 sheets of dye- sublimation paper, or 30 sheets of transparency film (Òprint mediaÓ) can be loaded at a time. Do not attempt to load more than these amounts.
-
Page 28: Important Notes
IMPORTANT NOTES 1.You must firmly push the stack of print media into the printer. A small amount of extra pressure is required to push the paper underneath the internal feed roller. If inserting a stack of standard A-size (8.5Ó x 11Ó) paper, for example, the paper should be... -
Page 29: Applying Power
If you have any doubts about the plug configuration or the voltage, DO NOT ATTEMPT TO USE THE PRINTER. Contact your dealer or FARGO for information on the correct transformer. Use your printer only if you are certain that the plug and power rating are correct. - Page 30 Power is automatically applied to the printer when it is plugged in. Press the Power switch if you wish to turn the power off. Optional external Transformer must be a Listed device with an output rating of 16.5 volts and 4.5 amps AC...
-
Page 31: Running The Self Test
B. Running the Self Test A self test can now be performed to check for proper operation of the printer. The self test should be conducted only with the wax thermal transfer supplies installed in your printer. PrimeraPro does not... - Page 32 Release the Power switch followed by the On Line switch. The self test pattern should now be printing. Color Self Test Example: (Approximately 35% of actual size)
-
Page 33: Ibm-Pc Or Compatible
PrimeraPro uses a standard Centronics parallel port, commonly referred to as LPT1 or LPT2 on most PCÕs. If you already have another printer attached to this port and donÕt have a second parallel port available, you may wish to add another parallel port. - Page 34 PrimeraPro must have its On Line light illuminated to receive data. If the light is not on, press the On Line switch. If the On Line light is flashing, check for a paper mis-feed or jam. Press the On Line switch to resume operation.
-
Page 35: B. Installing The Windows 3.1 Printer Driver
PrimeraPro. This is accomplished the first time you use the printer by installing in Windows what is called a Òprinter driver.Ó The printer driver is simply a diskette with software on it that gives PrimeraPro the proper commands it needs in order to print. - Page 36 Manager at the bottom left of the Printers group (should have an ÒXÓ). Select the Add>> button. Highlight the Install Unlisted or Updated Printer option from List of Printers. Select the Install button. Insert the supplied PrimeraPro Printer Driver diskette into your computerÕs A: or...
- Page 37 FARGO PrimeraPro should now be listed in the Add Unlisted or Updated Printer dialog box. Select the OK button. Your PCÕs disk drive will now load PrimeraProÕs printer driver. Depending upon your computer, loading will take about 10 to 20 seconds.
-
Page 38: Using Primeraproõs Windows 3.1 Printer Driver
Some applications allow you to change these same printer driver options from their ÒPrintÓ and/or ÒPrinter SetupÓ screens. This means that you donÕt have to go back to Control Panel each time you want to change a setting or option in PrimeraProÕs printer driver. -
Page 39: Paper Size
300 DPI (dots per inch) or 600 x 300 DPI. The 300 DPI setting offers high resolution output at the printerÕs standard print resolution. The 600 x 300 DPI setting offers an increased resolution print for highly detailed graphics and text printing. Printing with the... - Page 40 Select Algebraic if you would like the printer driver to make very simple, yet fast, color balance adjustments. This option gives you more natural...
-
Page 41: Printing A Color Page
OK button to return to the Printers group. Press Close to return to the Control Panel group. Exit the Control Panel and youÕre ready to go to an application program and print. All printer driver options you selected will stay the same until you change them. -
Page 42: Printing A Color Page
Wait until all the panels printed and the sheet is fully ejected before trying to pull it out of the printer. If everything looks good and youÕve printed your first page of color output, congratulations! YouÕve successfully completed set-up and initial testing. -
Page 43: Apple Macintosh
Minimum System Requirements Recommended PrimeraPro can either be connected directly to your MacintoshÕs printer port or to your AppleTalkª Network. If connecting directly to a Macintosh, use a standard serial cable with an 8 pin mini-DIN connection on each end. If... -
Page 44: Quick Start
B. Installing the FARGO Driver Connect your PrimeraPro to your AppleTalk Network or directly to the Printer port (not the modem port) on your Macintosh. Install the FARGO driver. Use the Chooser to select the driver you have just installed. - Page 45 Backgrounder is included with your PrimeraPro printer driver. Although installing this feature is not essential to the initial operation of the printer, you may wish to utilize the Backgrounder at a later date. For installation instructions and for more information on the FARGO Backgrounder, refer to Section 8 of this manual.
-
Page 46: Using The Fargo Driver
FargoPrimera001, the second will be named FargoPrimera002, and so on. If your printer does not appear on the list, be sure that it has power and is connected properly to your computer or network. -
Page 47: Expert Options
(72 dpi) resolution. Since rasterization is done at a lower resolution, the printer will begin printing faster. The 300 x 300 selection will give much better results but will require more time for rasterization and more memory. - Page 48 72 dots per inch (dpi). When a 72-dpi bitmap is printed on a high- resolution printer, the number of dots in the image must be increased. Each dot on the printer is smaller than a pixel on the screen; therefore, dots must be added to maintain the overall size.
- Page 49 Making the dots four or five times larger, however, can make the bitmaps look ragged. The Better bitmap scaling option works by enlarging the size of the print enough for all 72-dpi bitmaps to be printed with an integer dot increase. If this option is selected, however, the image printed will be reduced in size by 4%.
- Page 50 As a solution, raw printer profiles are included with this upgrade in case you would like to combine your custom monitor profiles with the printer profiles. This is...
-
Page 51: Printing A Color Page
Solid Color Relative: All colors that fall within the range of both source and printer profiles are left unchanged. This type of color matching allows some colors to be exactly the same. A... - Page 52 Click OK to print the document. Status messages display during processing: Before printing, check that the printer has paper and the proper ribbon installed, and that it is powered on. Both the power and On Line lights should remain solid throughout the printing process.
-
Page 53: For Macintosh
B. Installing The The Backgrounder is installed by selecting the Install Backgrounder option from within the FARGO printer driverÕs installer program. This option is Backgrounder pre-selected when you first install the printer driver. Therefore, if you did not deselect the Backgrounder option when installing the printer driver, it is most likely already installed. -
Page 54: Printing With The Fargo Backgrounder
While Backgrounder is running, you can quit the current application and start another without disturbing your print jobs. Backgrounder processes all print jobs in the order in which they were sent to the printer. Status of currently processing print job “On hold”... -
Page 55: Fargo Backgrounder Menus
The list of queued jobs displays below the current job in the order in which they were sent to the printer. Some applications, however, may put each page of the document into a separate spool file, creating a different job in the queue for each page. -
Page 56: Admin Menu
NOTE NOTE Double-clicking on a job in the status window is a shortcut for Get Info. Quit: Exits the Backgrounder. Note that you cannot quit while a job is being processed (see Stop Processing on the following page). All jobs in the queue are retained and processed when FARGO Backgrounder is next started. -
Page 57: Problems During A Background Print
Canceling the current job can take some time, since the printer software may be performing a lengthy task that cannot be interrupted. Remove Hold: Moves the job from the hold section of the list and places it at the bottom of the waiting queue. -
Page 58: Tips For Using Fargo Backgrounder
G. Tips for Using FARGO Backgrounder Memory Usage The FARGO Backgrounder processes documents faster if it is given more memory in which to operate. You can change the amount of memory used by Backgrounder by clicking on the Backgrounder icon and selecting Get Info from the File menu. -
Page 59: Commodore Amiga
FARGO and connect PrimeraPro to your Amiga as follows: IMPORTANT ALWAYS connect the printer with the power OFF to both the PrimeraPro and the Amiga. Failure to do so NOTE may damage, or at least lock-up the parallel port on the Amiga. -
Page 60: Installing The Amiga Printer Driver
If your application program allows printing, it will more than likely be compatible with PrimeraPro. Before printing, you must first install the PrimeraPro printer driver and the FARGO: device print program for the Amiga. The PrimeraPro driver, the FARGO: device print program, and the installation software have been provided on an Amiga DOS, 3.5Ó... -
Page 61: Using Primeraproõs Preferences Printer Driver
Printer Preferences (sys:Prefs/Printer) PrimeraProÕs Use the Prefs/Printer program to select Preferences ÒPrimeraProÓ as the current printer and set the Printer Driver other gadgets as described below. Other PrimeraPro files may be visible on the list but should not be selected. - Page 62 Green: Blue: Colors: 4096 The density or resolution of the printer is set by the PPCI program, so the density gadget tells the driver which type of wax ribbon you are using: Density 1: 3 color wax ribbon (YMC). Density 2: Monochrome wax ribbon (K).
- Page 63 The PPCI.info icon contains tool types which may be edited to alter the operation of the printer. However, this program may be ignored if you donÕt need to change the printer settings from the defaults (the heat setting is a common adjustment).
- Page 64 Tool Types: (Continued) Disk Buf=OFF Force disk buffering. ToFile=No Print to Printer (default) or to file. High DPI=OFF Selects 600x300 DPI. Once the changes have been made, quit the PPCI and then reopen it to set the permanent changes. Basename is the location of the temp file created during printing.
-
Page 65: Using Primeraproõs Fargo: Device Print Program
If you attempt to print from the second application, a warning may or may not be issued to tell you that the printer is still in use (even if it is idle). Applications The PrimeraPro will print well with any application which uses the ÓPreferences PrinterÒ... - Page 66 This PPCI.DOC file can be opened and read in any text program such as Directory Opus, Final Writer, etc. You should also refer to the READ ME file contained on the printer driver diskette for further printer driver and FARGO: device information.
-
Page 67: Section 10: Maintenance
Optional: PrimeraPro Print Head Cleaning CAUTION Unplug the printerÕs main power cord before performing any type of maintenance procedure. Also, never use a sharp tool or a metal object of any kind to clean the print head. You will damage the print head! -
Page 68: Standard Print Head Cleaning
Open the printerÕs top cover with the Cover Release Lever. Remove the Ribbon Cartridge from the printer. If you observe dust and/or other par- ticles laying on the top surface of the ribbon, manually roll it up into the take-up roll. -
Page 69: Expanded Print Head Cleaning
Periodically, use the following procedure to remove dust and paper particles: Open the printerÕs top cover with the Cover Remove the Ribbon Cartridge from the printer. Use a soft, lint-free cloth soaked lightly with... - Page 70 (most computer stores sell devices just for this purpose), use it to vacuum out all visible areas inside the printer. If you donÕt have such a device, use a soft, lint-free rag slightly moistened with isopropyl alcohol to wipe out all visible areas inside the printerÕs cabinet.
-
Page 71: Clearing A Paper Jam
This will rotate the drive roller backwards and eject the ribbon while you are pulling gently upwards. Leave the power on and open the cover of the Remove the Ribbon Take-Up core (the side Firmly pull the ribbon up and out of the printer... -
Page 72: Cleaning The Drive Roller
Remove the Ribbon Cartridge. Locate the Drive Roller. It is a long, black rubber roller directly underneath the print head when the printerÕs cover is closed. Lightly moisten a clean, lint-free cloth with isopropyl alcohol. Wipe the roller thoroughly. You can use... -
Page 73: Section 11: Troubleshooting
Make sure that the power cord is plugged in securely on both ends and that the printer is turned on. Confirm power is applied by pressing the Power button on the printer. The green LED above both the Power and the On line buttons should be illuminated. - Page 74 Replace media as required. Check that paper or transparency film is pushed all the way into the printer (see NOTE #1 at the end of Section 4-F). Also, check for a paper jam. Be sure to turn the printer off and on, then cancel and restart your print job if you detect and clear a jam.
- Page 75 Most likely due to dust inside the printer. Review the procedures in Section 10 for cleaning the inside of the printer. Also, be sure the Ribbon Cartridge is clean and free of any dust particles.
- Page 76 Check that the ribbon is seated properly in the Ribbon Cartridge. Check that nothing did in fact fall into the printer. Then, go ahead and push slightly harder. A microswitch and the ribbonÕs locating cam both have to engage, and this requires some pressure as the cover is closed.
- Page 77 A-size paper, for example, the paper should be pushed into the printer until the head of the arrow on the fully- extended Paper Input tray is visible. YouÕre trying to feed media thatÕs too thick or too heavy.
- Page 78 See page 23 for more paper guide information. This signifies a data transmission error. This could be caused by a bad printer cable or port. Try switching to a different printer cable, preferably 6 feet in length. If using a switch box, try printing with your printer connected directly to your computer.
- Page 79 Located on the perfed extension, is a white sensing strip which the printer needs to detect each end of the transparency. Dye-sublimation transparencies are standard A (letter) or A4 length sheets with a white sensing strip at the top and bottom of the sheet.
-
Page 80: Troubleshooting For Fargoõs Macintosh Printer Driver And Backgrounder
If you are having difficulty using the FARGO driver, run through the following check list. Is the printer plugged into the wall outlet? Is the Power light on? Is the printer selected in the Chooser? Is the printer connected to the printer... - Page 81 Make sure that the printer is visible from the Chooser and that its name is listed and selected. If it is not visible, make sure that the printer has power and is connected to AppleTalk network or the printer port of the Macintosh. Try disconnecting and re-applying power to the printer.
- Page 82 Extensions folder and restart. Extensions that may cause a conflict would most likely offer some sort of enhancement to a printer or other output device. To isolate the extension causing the problem try reinstalling suspected extensions one at a time...
-
Page 83: Section 12: Technical Specifications
Printing Method: Non-impact wax thermal transfer/dye-sublimation Printing Resolution: Software-selectable, color and monochrome: Thermal Print Head Heating element: Thin-film resistor Element layout: Single horizontal row Element density: 300 dots per inch (11.3 dots/mm) Color Panel Order Color: Yellow, Magenta, Cyan, Black (if used) Monochrome: Continuous single color Printing Speed... - Page 84 0% to 95% (RH non-condensation) (15% to 85% for Ink Ribbon) Engine requires 16.5 VAC at 4.5 Amps 76500, 76502, 76504 Units will operate 105 - 127 76501, 76503, 76505 Units will operate 210 - 254 50 Hz/60 Hz USA Ñ UL1950 Canada Ñ...
-
Page 85: Appendix A: Switch Settings
To change the settings, use a pointed (but not sharp) object such as a pen or pencil. Turn the printerÕs power switch on and off to initialize the changes. The tables below list all possible switch settings on the PrimeraPro Color Printer. -
Page 86: Character Set Configuration
Therefore, the monochrome ribbon is advanced in order for the printer to verify that it is not printing on a yellow panel. In this configuration, the printer always assumes that a color ribbon is installed, even when printing monochrome information. - Page 87 COUNTRY U.S.A. FRANCE GERMANY U.K. DENMARK I SWEDEN ITALY SPAIN I JAPAN NORWAY DENMARK II SPAIN II LATIN AMERICA KOREA LEGAL TEST MODE TABLE A-2: Character Set Configuration TABLE A-3: Character Set Selections (FACTORY SETTING) (FACTORY USE ONLY)
-
Page 88: Appendix B: Interfacing Information
Parallel Interface Depending on your operating environment, the PrimeraPro Color Printer is equipped with either a standard 8-bit Centronics-type parallel data communications port for use with a PC or an Amiga, or an Apple LocalTalk port for use with a Macintosh. -
Page 89: Appletalk Interface
Interface PrimeraProÕs Apple LocalTalk (230.4 Kbps) compatible interface allows PrimeraPro to be connected either directly to the printer port of your Macintosh or to an Apple LocalTalk network. Direct-connect AppleTalk is supported for those who wish to use a standard serial cable to directly connect PrimeraPro to a Macintosh computer. -
Page 90: Appendix C: Primeraproõs Printer
Group at (612) 941-0050. Whenever standard ASCII (ASCII 32-127) data is sent to the printer and SW2 is ON, PrimeraPro will print out all such data as text. Therefore, SW2 must be ON in order to print from the DOS prompt. The resident bit-mapped font is Letter Gothic 12 cpi. - Page 91 The total number of repeated bytes and unrepeated bytes is 320. Blank raster line: $85 R $00 (R is repeat as described above). Page Eject: $87 Example: (in hexadecimal) 1B 00 FF 31 50 86 30 85 02 41 43 83 41 42 43 7F 00 15 00 00 87 This is for a 3-color ribbon, a heat setting of 48, a yellow panel, one set of raster bytes repeated...
-
Page 92: Index
A6-Accessory Kit...17 Adobe Type Manager...50 Amiga Printer Driver Installing ...58 Using ...59 Apple LocalTalk ...87 AppleTalk Interface...87 Index Backgrounder See FARGO Backgrounder Character Set...84 Chooser ...43 ColorSync Installing ...49 Options ...49 Commands and Control Codes ...88 Configuration Amiga Driver...58-63 Macintosh Driver ...44-49 Ribbon ...83... - Page 93 FARGO Backgrounder About ...51 Batch Printing ...56 Installing ...51 Memory Usage...56 Menus...53 Printing with ...52 FARGO: device...58, 63 FARGO Driver See Macintosh Printer Driver Interfacing Amiga...57 Macintosh...41-42 Parallel ...86 PC ...31 Macintosh Printer Driver Installation...42 Using ...44 Maintenance Cleaning Case...67 Drive Roller...70...
- Page 94 Write Direct to Port ...38 Specifications ...81 Switch Settings ...83-84 Technical Specifications ...81 Technical Support...71 Transparency Film ...21, 23, 77 Trays Supply Tray ...22 Output Tray...13, 22, 23 Troubleshooting...71 Wax Thermal Transfer ...1 Windows 3.1 Printer Driver Installing ...33 Using ...36...
- Page 95 FARGO Electronics, Incorporated Printed In The United States of America Eden Prairie, Minnesota, U.S.A. P/N 510448...
