OWNER'S OPERATING MANUAL
FREQUENCY CONVERTER &
UNINTERRUPTIBLE POWER SYSTEM
FOR MODELS:
ED3000-A
ED4000-A
®
FALCON
ELECTRIC INC.
5116 Azusa Canyon Road
Irwindale, CA 91706
Tel. 626-962-7770
Fax. 626 962-7720
T
®
he information contained herein is the property of FALCON
ELECTRIC INC., is proprietary, confidential, and not to be disclosed, disseminated or used except for the
purpose provided.
OMED3-4K-LC 05-7-04 Rev. A
Advertisement
Table of Contents
Related Manuals for Falcon ED3000-A
Summary of Contents for Falcon ED3000-A
-
Page 1: Frequency Converter
Irwindale, CA 91706 Tel. 626-962-7770 Fax. 626 962-7720 ® he information contained herein is the property of FALCON ELECTRIC INC., is proprietary, confidential, and not to be disclosed, disseminated or used except for the purpose provided. OMED3-4K-LC 05-7-04 Rev. A... -
Page 2: Table Of Contents
Chapter 6, Maintenance & Technical Support Care & Maintenance Battery Life vs. Temperature Battery Replacement Storing the UPS and Batteries . FCC . Technical Support & RMA Procedure . Requesting Technical Information or Support. FALCON Web Support Brochure Specifications (READ FIRST) -
Page 3: Important Safety Instructions (Read First)
This UPS utilizes voltage that may be hazardous. Do not attempt to disassemble. This unit contains no user replaceable parts. Refer all servicing to Falcon Electric, Inc. This unit is not intended to be used in conjunction with life support or operating room equipment. -
Page 4: Chapter 1, Ed Series Overview
ED Series represents one of the smallest and most compact units of the FALCON ® (UPS) product line. In the tradition of all FALCON highest reliability and the most complete on-line, sinewave power conversion and protection available. An on-line, sinewave converter is the only solution to AC line frequency conversion. -
Page 5: Block Diagram
ED on-line topology is unique to other on-line systems, in that, it is designed to meet the needs of non-linear loads. Equipment, configured with a switching power supply, is considered a non-linear load which can be very abusive to most power conversion and protection equipment, and could decrease its life-expectancy. -
Page 6: Chapter 2, Installation
To file a claim for shipping damage or concealed damage: 1) File with the carrier within 15 days of receipt of the equipment; 2) Send a copy of the damage claim within 15 days to the Falcon ED Setup Verify that the following is included in the ED shipping carton: ED Frequency Converter &... -
Page 7: Chapter 3, Controls, Displays & Functions
ED is overloaded or has failed. Should this occur, check the load level and correct any overload condition if present. Should the unit not be overloaded, call FALCON LOW BATT.- LOW BATTERY WARNING INDICATOR The red LED will turn on when the ED is configured with an optional external battery bank, operating in battery mode and the low battery level warning point has be reached. -
Page 8: Rear Panel Diagram & Description
TYPICAL ED3000 & ED4000 REAR PANEL LAYOUT DB-9F COMMUNICATIONS INTERFACE This connector gives access to the ED contact closure status interface. Please reference page 7 of this manual for details. Hardwire conduit connector mounting holes for input and output wiring. COOLING FANS (4) Cooling fans draw cool air from the outside of the rear panel and exhaust it out through slots in the ED front panel. -
Page 9: Chapter 4, Communications Interface
CHAPTER 4 CHAPTER 4 DB-9 COMMUNICATIONS INTERFACE... -
Page 10: Chapter 5, Operation
OPERATION The FALCON ® ED unit is very simple to use. Verify the unit is connected to the correct voltage power source. Activate the power switch to the "ON" position. The green AC LED illuminates. The green INV LED illuminates. -
Page 11: Operational Mode Table
To escape this condition, the problem must first be corrected then turn the ED power switch "OFF", then back "ON". For models supplied with batteries it is recommended that you leave the ED unit power switch "ON" at all times and switch your devices "OFF"... -
Page 12: Chapter 6, Maintenance & Technical Support
C. Spent batteries must be recycled in accordance with all Federal, State and local laws. To locate a recycling center near you contact the Falcon service department. A. Do not open or mutilate the battery or batteries. Released electrolyte is harmful to the skin and eyes. -
Page 13: Storing The Ups And Batteries
The following precautions should be observed by a qualified technician when working with batteries. Remove watches, rings, or other metal objects. Use tools with insulated handles. Wear rubber gloves and boots. Do not lay tools or metal parts on top of batteries. Storing the ED unit Should you need to store the ED for a long period, if supplied with batteries, fully recharge the battery just prior to storage and recharge the battery every 6... -
Page 14: Technical Support & Rma Procedure
You may request technical information or support by Email or telephone. Please send your technical or support questions by Email to: SUPPORT@FALCONUPS.COM You may contact a FALCON support engineer directly by calling the FALCON support line between 9:00 am and 4:00 pm PST. 800-842-6940 FALCON Web Support Product data sheets, specification and owner’s guides are available in Adobe... -
Page 15: Brochure
Constant voltage transformers, line conditioners and other devices are not designed to prevent damage from these problems. Falcon Electric, Inc. - 5116 Azusa Canyon Rd. - Irwindale, CA 91706 - 800.842.6940 Fax 626.962.7720 www.falconups.com - email: sales@falconups.com Uninterruptible Power Systems &... -
Page 16: Specifications
Weight (kg) Specify input/output frequency, 50/60 or 400Hz (any combination). Standard models shown. Custom configurations available; Consult Factory. Note: For ED3000-A and ED4000-A models add a -400 to the end of the model number for a 400Hzoutput ® ED-1000-A ED-1500-A...
