Specifications — DVS 100/150 Digital Video Scalers

Video input

Number/signal type ................... Both models ............................. 1 component video (Y, R-Y, B-Y), 1 S-video,
Connectors .................................... 3 BNC female .......................... component video
Nominal level(s) .......................... Analog — 0.7V to 1.0V p-p
Impedance .................................... 75 ohms
Vertical frequency ....................... 50 Hz to 60 Hz (does not apply to DVS 150 pass-through)

Video output

Number/type/format ................ 1 scaled RGBHV, RGBS, RGsB
Connectors .................................... 6 BNC female
Nominal level ............................... 0.7V p-p
Impedance .................................... 75 ohms
Vertical frequency ....................... 56 Hz, 60 Hz or 75 Hz
Scaled VGA resolution ............... 640x480, 800x600, 832x624, 848x480, 852x480, 1024x768, 1280x768, 1280x1024,

Sync

Input type ..................................... DVS 150 only ........................... RGBHV, RGBS, RGsB
Output type .................................. RGBHV, RGBS, RGsB
Standards ...................................... NTSC 3.58, NTSC 4.43, PAL, SECAM
Output level ................................. TTL — 5.0V p-p
Output impedance ...................... 75 ohms
Polarity .......................................... Positive or negative (switch-selectable)
Control/Remote — decoder/scaler
Serial control port ........................ RS-232, 9-pin female D connector
Baud rate and protocol ............... 9600, 8-bit, 1 stop bit, no parity
Pin configurations ....................... 1 = input 1 select
Contact closure ............................ 9-pin female D connector
Program control ........................... Extron's control program for Windows®
1-2
DVS 100, DVS 150 Specifications
DVS 150 only ........................... 1 RGBHV, RGBS, RGsB pass-through
1 4-pin mini-DIN female ...... S-video
1 BNC female .......................... composite video
1 15-pin HD female ............... RGB pass-through (DVS 150 only)
1 scaled RGBHV or pass-through RGBHV/RGBS/RGsB
1 15-pin HD female
1360x765, HDTV 480p, 720p and 1080p
2 = TX
3 = RX
4 = input 2 select
5 = GND
6 = input 3 select
7 = input 4 select (DVS 150 only)
Extron's Simple Instruction Set
1 composite video
– SIS
™ ™
