Mounting Options - Extron electronics Mini Distribution Amplifier Specifications

S
PECIFICATIONS
Video input
Number/signal type .......................... 1 SMPTE-259M serial digital
Connectors........................................ 1 BNC female
Minimum/maximum levels .............. 0.5V to 1V p-p with no offset
Impedance ........................................ 75 ohms
Return loss ........................................ -15dB @ 5 to 270 MHz
Maximum DC offset ........................ 5V
Video output
Number/signal type .......................... 4 reclocked SMPTE-259M serial
Connectors........................................ 4 BNC female
Minimum/maximum levels .............. 0V to 1.0V p-p
Impedance ........................................ 75 ohms
Return loss ........................................ -30dB @ 5 MHz
DC offset .......................................... ±5mV maximum with input at
Sync
Standards .......................................... 4fscNTSC, 4fscPAL, SMPTE-
General
Power ................................................ 100VAC to 240VAC, 50/60 Hz,
Rack mount ...................................... Yes, with optional 1U rack shelf,
Enclosure type .................................. Metal
Enclosure dimensions ........................ 1.7" H x 4.3" W x 3.0" D (1U
Product weight .................................. 0.5 lbs (0.2 kg)
Shipping weight ................................ 2 lbs (0.9 kg)
Listings.............................................. UL, CUL
Compliances...................................... CE, FCC Class A, VCCI, AS/NZS,
Warranty .......................................... 3 years parts and labor
Composite Video Models
MDA 3V .......................................... 60-439-01
MDA 3AV ........................................ 60-439-20
MDA 3V DUAL .............................. 60-439-10
MDA 5V .......................................... 60-446-01
S-Video Models
MDA 3SV ........................................ 60-444-01
MDA 3SVA ...................................... 60-444-20
MDA 3SV DUAL ............................ 60-444-10
MDA 5SV ........................................ 60-447-01
Stereo Audio Models
MDA 3A .......................................... 60-440-01
MDA 3A RCA .................................. 60-440-30
MDA 5A RCA .................................. 60-441-01
SDI Models
MDA 4V SDI .................................. 60-448-01
Accessories
P/S 100 ............................................ 60-357-01
Extron Electronics, USA
1230 South Lewis Street
Anaheim, CA 92805
800.633.9876 714.491.1500
714.491.1517
FAX
Copyright © 2002 Extron Electronics. All rights reserved. All trademarks mentioned are the property of their respective owners.
(Cont.)
component video
digital component video
0 offset
259M
5 watts, external, auto-switchable;
to 12VDC, 1 A (max.) power
supply. Product requires 0.4 A.
part #60-190-01, or the
VersaTools™ rack shelf,
part #60-190-20
high, quarter rack width) 4.2 cm H
x 11.0 cm W x 7.6 cm D
ICES
Part Number
Extron Electronics, Europe
Beeldschermweg 6 C , 3821 Amersfoort
AH
The Netherlands
+800.3987.6673 +31.33.453.4040
+31.33.453.4050
FAX
A
PPLICATION
DVD
3
2 U T S R
T P 3
O U
I L
R
N 1
V 2
3 A L
A
M D
R
1
U T L
IN P
R R
W E
P O
L
V X
15 M A
.3 4A
Extron
MDA 3AV
Distribution
Amplifier

Mounting Options

D IS
T R
IB U
T IO
N A
M P
L IF
IE R
Projector
Mount
Ceiling
Digital Projector
Rack
Mount
DI ST
RI BU
TI ON
AM
PL IF IE
R
VersaTools Rack Shelf
1/4 Rack Width False Front
Face Plate
Use 2 mounting holes on
opposite corners
Extron Electronics, Asia
135 Joo Seng Rd. #04-01
Industrial Bldg.
PM
Singapore 368363
+65.6383.4400 +65.6383.4664
FAX
D
IAGRAMS
LCD Projector
O
U
T
L
BA
2 3
1 L
BA
UN
HDTV Plasma
Audio
HDTV Plasma
Under Table
Mount
Projector
Mounting
Bracket
Mounting
Bolt
DI ST
RI
BU
TI ON
AM
PL
IF IE
R
DI ST
RI BU
TI ON
AM
PL
IF IE
R
(2) 4-40 x 1/8" screws
