Video bandwidth:
435 MHz (-3db) on
composite models
Video bandwidth:
270 MHz (-3db) on
S-video models
Quarter rack width
metal enclosure
Versatile mounting
options including rack
and under-desk mounts
Unity audio gain:
selectable output audio
gain (captive screw
V
T
M
D
A
™
ERSA
OOLS
INI
ISTRIBUTION
MPLIFIERS
models only)
100-240VAC external
international power
supply
www.extron.com
Advertisement
Related Manuals for Extron electronics Mini Distribution Amplifier
Summary of Contents for Extron electronics Mini Distribution Amplifier
- Page 1 Video bandwidth: 435 MHz (-3db) on composite models Video bandwidth: 270 MHz (-3db) on S-video models Quarter rack width metal enclosure Versatile mounting options including rack and under-desk mounts Unity audio gain: selectable output audio gain (captive screw ™ ERSA OOLS ISTRIBUTION MPLIFIERS...
- Page 2 ESCRIPTION Composite Video Models MDA 3AV S-Video Models MDA 3SVA Stereo Audio Models MDA 3A SDI Model MDA 4V SDI Extron VersaTools™ is a new line of compact, versatile solution products designed for high-quality performance. VersaTools’ small, quarter rack width enclosures, flexible mounting options (rack, under- desk, or stand-alone), and adaptable, external international power supply allow for easy integration into both new and existing A/V systems including boardrooms, training facilities, home theater,...
- Page 3 PECIFICATIONS Video Gain ... Unity Bandwidth MDA 3SV/3SVA/3SV Dual, MDA 5SV ... 270 MHz (-3dB) MDA 3V/3AV/3V Dual, MDA 5V ... 435 MHz (-3dB) Differential phase error... 0.05 Differential gain error... <0.05%, 0 to 50 MHz K factor ... <0.05% Video input Number/signal type MDA 3SV/3SVA, MDA 5SV ...
-
Page 4: Mounting Options
(Cont.) PECIFICATIONS Video input Number/signal type ... 1 SMPTE-259M serial digital component video Connectors... 1 BNC female Minimum/maximum levels ... 0.5V to 1V p-p with no offset Impedance ... 75 ohms Return loss ... -15dB @ 5 to 270 MHz Maximum DC offset ...
